Exact Nematic and Mixed Magnetic Phases Driven by Competing Orders on the Pyrochlore Lattice

Niccolò Francini, Lukas Schmidt, Lukas Janssen, and Daniel Lozano-Gómez

PDF

Phys. Rev. X 16, 031070 – Published 16 September, 2026

DOI: https://doi.org/10.1103/vwx8-mdtw

Abstract

Pyrochlore magnets are a paradigmatic example of three-dimensional frustrated systems and provide an excellent platform for studying a variety of exotic many-body phenomena, including spin liquids, nematic phases, fragmentation, and order by disorder. In recent years, increasing attention has been devoted to bilinear spin models on this lattice, where multiple magnetic phases can be degenerate in energy, often stabilizing unconventional magnetic states. In this work, we focus on one such model, parametrized by the interaction coupling Jz±, which defines a line in parameter space corresponding to the phase boundary between three distinct magnetic phases. Using a combination of analytical and numerical methods, we show that this model exhibits an order-by-disorder mechanism at low temperatures, giving rise to a mixed magnetic phase. This realizes a q=0 long-range-ordered phase in a pyrochlore magnet characterized by two distinct order parameters, which we denote as the A2⊕ψ2 phase. Furthermore, at Jz±=1/2, the model acquires a subextensive number of discrete symmetries, which preclude the stabilization of conventional long-range order and instead lead to the emergence of a novel nematic phase. We characterize this nematic phase, describe how its ground-state configurations are constructed, and analyze its stability at higher temperatures and under small deviations from Jz±=1/2.

View figure in article

Physics Subject Headings (PhySH)

Popular Summary

Determining ground-state magnetic order in geometrically frustrated pyrochlore lattices remains difficult because competing interactions prevent atomic spins from settling into a single low-energy configuration. We investigated this degeneracy by studying a pyrochlore spin model with three competing magnetic phases and found that thermal fluctuations systematically select a composite ordered configuration.

We showed that tuning specific interaction parameters generates additional emergent symmetries that prevent conventional long-range magnetic ordering. Instead, we discovered that these emergent constraints stabilize a nematic state driven by the interplay of frustration and fluctuations. Our work illuminates how symmetry and fluctuations conspire to stabilize exotic phases, providing a theoretical framework to guide the search for unconventional states in frustrated quantum materials.

Article Text

References (111)

  1. C. Lacroix, P. Mendels, and F. Mila, Introduction to Frustrated Magnetism (Springer, New York, 2011).
  2. L. Balents, Spin liquids in frustrated magnets, Nature (London) 464, 199 (2010).
  3. L. Savary, K. A. Ross, B. D. Gaulin, Jacob P. C. Ruff, and L. Balents, Order by quantum disorder in Er2Ti2O7, Phys. Rev. Lett. 109, 167201 (2012).
  4. P. Nikolić and T. Senthil, Theory of the kagome lattice Ising antiferromagnet in weak transverse fields, Phys. Rev. B 71, 024401 (2005).
  5. K. B. Yogendra, S. Karmakar, and T. Das, Symmetry, superposition, and fragmentation in classical spin liquids: A general framework and applications to square kagome magnets, Phys. Rev. B 110, L060401 (2024).
  6. J. G. Rau and M. J. Gingras, Frustrated quantum rare-earth pyrochlores, Annu. Rev. Condens. Matter Phys. 10, 357 (2019).
  7. W. Witczak-Krempa, G. Chen, Y. B. Kim, and L. Balents, Correlated quantum phenomena in the strong spin-orbit regime, Annu. Rev. Condens. Matter Phys. 5, 57 (2014).
  8. S. Trebst and C. Hickey, Kitaev materials, Phys. Rep. 950, 1 (2022).
  9. C. Castelnovo, R. Moessner, and S. L. Sondhi, Magnetic monopoles in spin ice, Nature (London) 451, 42 (2008).
  10. H. Yan, O. Benton, L. D. C. Jaubert, and N. Shannon, Rank–2 U(1) spin liquid on the breathing pyrochlore lattice, Phys. Rev. Lett. 124, 127203 (2020).
  11. R. Moessner and J. T. Chalker, Properties of a classical spin liquid: The Heisenberg pyrochlore antiferromagnet, Phys. Rev. Lett. 80, 2929 (1998).
  12. M. Taillefumier, O. Benton, H. Yan, L. D. C. Jaubert, and N. Shannon, Competing spin liquids and hidden spin-nematic order in spin ice with frustrated transverse exchange, Phys. Rev. X 7, 041057 (2017).
  13. O. Benton, L. D. C. Jaubert, H. Yan, and N. Shannon, A spin-liquid with pinch-line singularities on the pyrochlore lattice, Nat. Commun. 7, 11572 (2016).
  14. O. Benton, O. Sikora, and N. Shannon, Seeing the light: Experimental signatures of emergent electromagnetism in a quantum spin ice, Phys. Rev. B 86, 075154 (2012).
  15. E. M. Smith et al., Case for a U(1)π quantum spin liquid ground state in the dipole-octupole pyrochlore Ce2Zr2O7, Phys. Rev. X 12, 021015 (2022).
  16. D. Lozano-Gómez, V. Noculak, J. Oitmaa, R. R. P. Singh, Y. Iqbal, J. Reuther, and M. J. P. Gingras, Competing gauge fields and entropically driven spin liquid to spin liquid transition in non-Kramers pyrochlores, Proc. Natl. Acad. Sci. U.S.A. 121, e2403487121 (2024).
  17. K. T. K. Chung and Michel J. P. Gingras, 2-form U(1) spin liquids: A classical model and quantum aspects, Phys. Rev. B 111, 064417 (2025).
  18. D. Lozano-Gómez, Y. Iqbal, and M. Vojta, A classical chiral spin liquid from chiral interactions on the pyrochlore lattice, Nat. Commun. 15, 10162 (2024).
  19. J. Villain, R. Bidaux, J.-P. Carton, and R. Conte, Order as an effect of disorder, J. Phys. (Les Ulis, Fr.), 41, 1263 (1980).
  20. E. Belorizky, R. Casalegno, and J. J. Niez, Calculation of the spin wave energy gap at k=o for a simple cubic ferromagnet with anisotropic exchange interactions, Phys. Status Solidi B 102, 365 (1980).
  21. M. E. Zhitomirsky, M. V. Gvozdikova, P. C. W. Holdsworth, and R. Moessner, Quantum order by disorder and accidental soft mode in Er2Ti2O7, Phys. Rev. Lett. 109, 077204 (2012).
  22. M. E. Zhitomirsky and A. L. Chernyshev, Colloquium: Spontaneous magnon decays, Rev. Mod. Phys. 85, 219 (2013).
  23. G.-W. Chern, Pyrochlore antiferromagnet with antisymmetric exchange interactions: Critical behavior and order from disorder, arXiv:1008.3038.
  24. V. Noculak, D. Lozano-Gómez, J. Oitmaa, Rajiv R. P. Singh, Y. Iqbal, Michel J. P. Gingras, and J. Reuther, Classical and quantum phases of the pyrochlore S=12 magnet with Heisenberg and Dzyaloshinskii-Moriya interactions, Phys. Rev. B 107, 214414 (2023).
  25. A. Hickey, D. Lozano-Gómez, and Michel J. P. Gingras, Order-by-disorder without quantum zero-point fluctuations in the pyrochlore Heisenberg ferromagnet with Dzyaloshinskii-Moriya interactions, Phys. Rev. B 111, 184434 (2025).
  26. M. E. Brooks-Bartlett, S. T. Banks, L. D. C. Jaubert, A. Harman-Clarke, and P. C. W. Holdsworth, Magnetic-moment fragmentation and monopole crystallization, Phys. Rev. X 4, 011007 (2014).
  27. S. Petit, E. Lhotel, B. Canals, M. Ciomaga Hatnean, J. Ollivier, H. Mutka, E. Ressouche, A. R. Wildes, M. R. Lees, and G. Balakrishnan, Observation of magnetic fragmentation in spin ice, Nat. Phys. 12, 746 (2016).
  28. O. Benton, Quantum origins of moment fragmentation in Nd2Zr2O7, Phys. Rev. B 94, 104430 (2016).
  29. D. Lozano-Gómez and H. Yan, Fragmented spin liquid and shadow pinch points in dipole-octupole pyrochlore spin systems, arXiv:2509.09205.
  30. Y. Onose, T. Ideue, H. Katsura, Y. Shiomi, N. Nagaosa, and Y. Tokura, Observation of the magnon Hall effect, Science 329, 297 (2010).
  31. N. Francini, L. Janssen, and D. Lozano-Gómez, Higher-rank spin liquids and spin nematics from competing orders in pyrochlore magnets, Phys. Rev. B 111, 085140 (2025).
  32. H. Yan, O. Benton, L. Jaubert, and N. Shannon, Theory of multiple-phase competition in pyrochlore magnets with anisotropic exchange with application to Yb2Ti2O7,Er2Ti2O7, and Er2Sn2O7, Phys. Rev. B 95, 094422 (2017).
  33. Anson W. Wong, Z. Hao, and Michel J. Gingras, Ground state phase diagram of generic XY pyrochlore magnets with quantum fluctuations, Phys. Rev. B 88, 144402 (2013).
  34. D. Lozano-Gómez, O. Benton, M. J. P. Gingras, and H. Yan, An atlas of classical pyrochlore spin liquids, arXiv:2411.03547.
  35. K. T. K. Chung, S. Petit, J. Robert, and P. McClarty, Geometrically frustrated quadrupoles on the pyrochlore lattice and generalized spin liquids, arXiv:2506.19908.
  36. L. Gresista, D. Lozano-Gómez, M. Vojta, S. Trebst, and Y. Iqbal, Quantum effects on pyrochlore higher-rank U(1) spin liquids: Pinch-line singularities, spin nematics, and connections to oxide materials, Phys. Rev. Res. 7, 033109 (2025).
  37. O. Benton, Classical and quantum spin liquids on the pyrochlore lattice, Ph.D. thesis, University of Bristol, 2014.
  38. V. Noculak and J. Reuther, Pseudo-fermion functional renormalization group with magnetic fields, Phys. Rev. B 109, 174414 (2024).
  39. S. Khatua, Michel J. P. Gingras, and J. G. Rau, Pseudo-Goldstone modes and dynamical gap generation from order by thermal disorder, Phys. Rev. Lett. 130, 266702 (2023).
  40. A. Hickey, J. G. Rau, S. Khatua, and M. J. P. Gingras, Universal temperature-dependent power law excitation gaps in frustrated quantum spin systems harboring order-by-disorder, arXiv:2505.18253.
  41. S. Khatua, G. C. Howson, M. J. P. Gingras, and J. G. Rau, Finite-size spectral signatures of order by quantum disorder: A perspective from Anderson’s tower of states, Phys. Rev. Lett. 136, 146702 (2026).
  42. R. Schick, T. Ziman, and M. E. Zhitomirsky, Quantum versus thermal fluctuations in the fcc antiferromagnet: Alternative routes to order by disorder, Phys. Rev. B 102, 220405(R) (2020).
  43. C. L. Sarkis, J. G. Rau, L. D. Sanjeewa, M. Powell, J. Kolis, J. Marbey, S. Hill, J. A. Rodriguez-Rivera, H. S. Nair, D. R. Yahne, S. Säubert, M. J. P. Gingras, and K. A. Ross, Unravelling competing microscopic interactions at a phase boundary: A single-crystal study of the metastable antiferromagnetic pyrochlore Yb2Ge2O7, Phys. Rev. B 102, 134418 (2020).

  44. This extensive degeneracy is typically seen in low-energy flat bands in the interaction matrix, which reflects an extensive ground-state degeneracy, hinting at a spin-liquid state.

  45. K. T. K. Chung, Mapping the phase diagram of a frustrated magnet: Degeneracies, flat bands, and canting cycles on the pyrochlore lattice, arXiv:2411.03429.
  46. K. A. Ross, L. Savary, B. D. Gaulin, and L. Balents, Quantum excitations in quantum spin ice, Phys. Rev. X 1, 021002 (2011).
  47. A. Sadeghi, M. Alaei, F. Shahbazi, and Michel J. P. Gingras, Spin Hamiltonian, order out of a Coulomb phase, and pseudocriticality in the frustrated pyrochlore Heisenberg antiferromagnet FeF3, Phys. Rev. B 91, 140407(R) (2015).
  48. P. A. McClarty, S. H. Curnoe, and M. J. P. Gingras, Energetic selection of ordered states in a model of the Er2Ti2O7 frustrated pyrochlore XY antiferromagnet, J. Phys. Conf. Ser. 145, 012032 (2009).
  49. S. E. Palmer and J. T. Chalker, Order induced by dipolar interactions in a geometrically frustrated antiferromagnet, Phys. Rev. B 62, 488 (2000).
  50. D. R. Yahne, D. Pereira, L. D. C. Jaubert, L. D. Sanjeewa, M. Powell, J. W. Kolis, G. Xu, M. Enjalran, M. J. P. Gingras, and K. A. Ross, Understanding reentrance in frustrated magnets: The case of the Er2Sn2O7 pyrochlore, Phys. Rev. Lett. 127, 277206 (2021).

  51. For a specific combination of the interaction parameters {Jzz,J±,J±±,Jz±} one of the T1 irreps is identified with a collinear ferromagnet while the remaining one is a coplanar antiferromagnet [24]. Aside from these cases, the two T1 irreps are always ferromagnetic.

  52. J. D. Thompson, P. A. McClarty, D. Prabhakaran, I. Cabrera, T. Guidi, and R. Coldea, Quasiparticle breakdown and spin Hamiltonian of the frustrated quantum pyrochlore Yb2Ti2O7 in a magnetic field, Phys. Rev. Lett. 119, 057203 (2017).
  53. H. Yan, O. Benton, R. Moessner, and A. H. Nevidomskyy, Classification of classical spin liquids: Typology and resulting landscape, Phys. Rev. B 110, L020402 (2024).

  54. The three low-energy degenerate irreps A2, E, and T1− have different dimensions, being one, two, and three dimensional, respectively, yielding a total of 6 degrees of freedom.

  55. This should not be surprising as for Jz±=0 both the E and the T1− irreps modes have all spins lying in the local xy. As such, the A2 mode, where the spins are aligned with the local z direction, can smoothly fluctuate into all other states.

  56. States with nonvanishing contribution of T1− irrep have fewer soft modes than any states on the A2⊕E sphere. Thus, to quadratic order, the inclusion of T1− states does not introduce any additional fluctuation mechanism leading to its selection.

  57. A. J. Raja and R. Ganesh, Entropic sampling in frustrated magnets: Role of self-intersecting spaces, Phys. Rev. B 109, 144401 (2024).
  58. B. Canals, M. Elhajal, and C. Lacroix, Ising-like order by disorder in the pyrochlore antiferromagnet with Dzyaloshinskii-Moriya interactions, Phys. Rev. B 78, 214431 (2008).
  59. S. Khatua, D. Sen, and R. Ganesh, Effective theories for quantum spin clusters: Geometric phases and state selection by singularity, Phys. Rev. B 100, 134411 (2019).
  60. S. Srinivasan, S. Khatua, G. Baskaran, and R. Ganesh, Order by singularity in Kitaev clusters, Phys. Rev. Res. 2, 023212 (2020).
  61. B. Javanparast, A. G. Day, Z. Hao, and M. J. Gingras, Order-by-disorder near criticality in XY pyrochlore magnets, Phys. Rev. B 91, 174424 (2015).

  62. We note that this simplification implies that this Landau theory can also be used to characterize models describing the phase boundary between the A2 and E irreps.

  63. N. Metropolis, A. W. Rosenbluth, M. N. Rosenbluth, A. H. Teller, and E. Teller, Equation of state calculations by fast computing machines, J. Chem. Phys. 21, 1087 (1953).
  64. M. Creutz, Overrelaxation and Monte Carlo simulation, Phys. Rev. D 36, 515 (1987).
  65. E. Marinari and G. Parisi, Simulated tempering: A new Monte Carlo scheme, Europhys. Lett. 19, 451 (1992).
  66. K. Hukushima and K. Nemoto, Exchange Monte Carlo method and application to spin glass simulations, J. Phys. Soc. Jpn. 65, 1604 (1996).
  67. K. Hukushima, Domain-wall free energy of spin-glass models: Numerical method and boundary conditions, Phys. Rev. E 60, 3606 (1999).
  68. D. P. Landau and K. Binder, A Guide to Monte Carlo Simulations in Statistical Physics, 4th ed. (Cambridge University Press, Cambridge, England, 2014).
  69. http://www.nhr-verein.de/en/our-partners.
  70. E. C. Andrade, J. A. Hoyos, S. Rachel, and M. Vojta, Cluster-glass phase in pyrochlore XY antiferromagnets with quenched disorder, Phys. Rev. Lett. 120, 097204 (2018).
  71. M. E. Zhitomirsky, P. C. W. Holdsworth, and R. Moessner, Nature of finite-temperature transition in anisotropic pyrochlore Er2Ti2O7, Phys. Rev. B 89, 140403(R) (2014).
  72. N. Shannon, T. Momoi, and P. Sindzingre, Nematic order in square lattice frustrated ferromagnets, Phys. Rev. Lett. 96, 027213 (2006).
  73. A. Smerald, H. T. Ueda, and N. Shannon, Theory of inelastic neutron scattering in a field-induced spin-nematic state, Phys. Rev. B 91, 174402 (2015).
  74. L. Janssen and I. F. Herbut, Nematic quantum criticality in three-dimensional Fermi system with quadratic band touching, Phys. Rev. B 92, 045117 (2015).
  75. N. Francini and L. Janssen, Spin vestigial orders in extended Heisenberg-Kitaev models near hidden SU(2) points: Application to Na2Co2TeO6, Phys. Rev. B 109, 075104 (2024).
  76. M. Hecker, A. Rastogi, D. F. Agterberg, and R. M. Fernandes, Classification of electronic nematicity in three-dimensional crystals and quasicrystals, Phys. Rev. B 109, 235148 (2024).

  77. In the global basis, the nematic-order-parameter components decompose into a doublet and a triplet under the symmetry group Td. However, our use of a local definition of the nematic parameter leads to more involved transformation rules; see Appendix pp6 for details.

  78. For example, for an A2 state, we obtain d=(1,0,0,0,0).

  79. S. Petit, E. Lhotel, S. Guitteny, O. Florea, J. Robert, P. Bonville, I. Mirebeau, J. Ollivier, H. Mutka, E. Ressouche, C. Decorse, M. Ciomaga Hatnean, and G. Balakrishnan, Antiferroquadrupolar correlations in the quantum spin ice candidate Pr2Zr2O7, Phys. Rev. B 94, 165153 (2016).
  80. A. Pelissetto and E. Vicari, Critical phenomena and renormalization-group theory, Phys. Rep. 368, 549 (2002).
  81. C.-H. Chang, V. Dommes, R. S. Erramilli, A. Homrich, P. Kravchuk, A. Liu, M. S. Mitchell, D. Poland, and D. Simmons-Duffin, Bootstrapping the 3D Ising stress tensor, J. High Energy Phys. 03 (2025) 136.
  82. J. T. Chalker, P. C. W. Holdsworth, and E. F. Shender, Hidden order in a frustrated system: Properties of the Heisenberg kagomé antiferromagnet, Phys. Rev. Lett. 68, 855 (1992).
  83. F. Y. Wu, The Potts model, Rev. Mod. Phys. 54, 235 (1982).

  84. Here we have excluded the possibility of a first-order phase transition, as the finite-size scaling of the hump in the specific heat does not indicate a linear dependence of this feature with L.

  85. J. Hove and A. Sudbø, Criticality versus q in the (2+1)-dimensional Zq clock model, Phys. Rev. E 68, 046107 (2003).
  86. M. Hasenbusch, Monte Carlo study of an improved clock model in three dimensions, Phys. Rev. B 100, 224517 (2019).
  87. S. M. Chester, W. Landry, J. Liu, D. Poland, D. Simmons-Duffin, N. Su, and A. Vichi, Carving out OPE space and precise O(2) model critical exponents, J. High Energy Phys. 06 (2020) 142.
  88. J. L. Jiménez, S. P. G. Crone, E. Fogh, M. E. Zayed, R. Lortz, E. Pomjakushina, K. Conder, A. M. Läuchli, L. Weber, S. Wessel, A. Honecker, B. Normand, C. Rüegg, P. Corboz, H. M. Rønnow, and F. Mila, A quantum magnetic analogue to the critical point of water, Nature (London) 592, 370 (2021).
  89. Z. Nussinov and J. van den Brink, Compass models: Theory and physical motivations, Rev. Mod. Phys. 87, 1 (2015).

  90. We note that these three ways are related by a cubic C3 symmetry.

  91. S. Vijay, J. Haah, and L. Fu, Fracton topological order, generalized lattice gauge theory, and duality, Phys. Rev. B 94, 235157 (2016).
  92. R. M. Nandkishore and M. Hermele, Fractons, Annu. Rev. Condens. Matter Phys. 10, 295 (2019).

  93. For a general bilinear spin model, a Hamiltonian can be rewritten in the form H=12∑i,jsiαJijαβsjβ.

  94. K. T. K. Chung, J. S. K. Goh, A. Mukherjee, W. Jin, D. Lozano-Gómez, and M. J. P. Gingras, Probing flat band physics in spin ice systems via polarized neutron scattering, Phys. Rev. Lett. 128, 107201 (2022).
  95. D. A. Garanin and B. Canals, Classical spin liquid: Exact solution for the infinite-component antiferromagnetic model on the kagomé lattice, Phys. Rev. B 59, 443 (1999).
  96. B. Canals and D. A. Garanin, Spin-liquid phase in the pyrochlore anti-ferromagnet, Can. J. Phys. 79, 1323 (2001).

  97. The additional Z2 subsystem symmetry at the point Jz±=1/2 yields a low-temperature phase featuring a reappearance of the T1− irreps, which contrasts with the depopulation of the T1− mode throughout the rest of the phase diagram.

  98. This conclusion is based on a soft-spin system where the spin-length constraint would only be enforced on average [95, 96, 99].

  99. B. Canals and D. A. Garanin, Classical spin liquid properties of the infinite-component spin vector model on a fully frustrated two dimensional lattice, Eur. Phys. J. B 26, 439 (2002).

  100. As discussed in Ref. [31], the structure factor for a single C3 symmetry sector would only display continuous lines along one Cartesian axis.

  101. Interestingly, and to the best of our knowledge, this is the first instance where a classical Monte Carlo simulation captures a peak in the specific heat for a transition between a phase with ψ2 order (A2⊕ψ2 in this case) and a phase with ψ3 order.

  102. A. Scheie, J. Kindervater, S. Zhang, H. J. Changlani, G. Sala, G. Ehlers, A. Heinemann, G. S. Tucker, S. M. Koohpayeh, and C. Broholm, Multiphase magnetism in Yb2Ti2O7, Proc. Natl. Acad. Sci. U.S.A. 117, 27245 (2020).
  103. A. Scheie, O. Benton, M. Taillefumier, L. D. C. Jaubert, G. Sala, N. Jalarvo, S. M. Koohpayeh, and N. Shannon, Dynamical scaling as a signature of multiple phase competition in Yb2Ti2O7, Phys. Rev. Lett. 129, 217202 (2022).
  104. A. Szabó, S. A. Grigera, P. C. W. Holdsworth, Ludovic D. C. Jaubert, R. Moessner, D. G. Slobinsky, M. Sturla, and R. A. Borzi, Hidden order and Z2 confinement transition in a fully packed monopole liquid, Phys. Rev. B 112, 014452 (2025).
  105. D. Slobinsky, G. Baglietto, and R. A. Borzi, Charge and spin correlations in the monopole liquid, Phys. Rev. B 97, 174422 (2018).
  106. Y. Zhang, Z. Dun, Y. Cai, C. Xing, Q. Cui, N. K. C. Muniraju, Q. Zhang, Y. Li, J. Cheng, and H. Zhou, Local distortion driven magnetic phase switching in pyrochlore Yb2(Ti1−xSnx)2O7, Phys. Rev. B 109, 144407 (2024).
  107. E. Kermarrec, J. Gaudet, K. Fritsch, R. Khasanov, Z. Guguchia, C. Ritter, K. A. Ross, H. A. Dabkowska, and B. D. Gaulin, Ground state selection under pressure in the quantum pyrochlore magnet Yb2Ti2O7, Nat. Commun. 8, 14810 (2017).
  108. N. Francini, L. Schmidt, L. Janssen, and D. Lozano-Gómez, Data for “Exact nematic and mixed magnetic phases driven by competing orders on the pyrochlore lattice,” Version 1, 10.25532/OPARA-1035 (2025).

  109. We introduce both of these terms to ensure that the free energy does not diverge to negative infinity, yielding an unphysical behavior.

  110. F. Gao and L. Han, Implementing the Nelder-Mead simplex algorithm with adaptive parameters, Comput. Optim. Applic. 51, 259 (2012).
  111. K. Harada, Bayesian inference in the scaling analysis of critical phenomena, Phys. Rev. E 84, 056704 (2011).
