Anisotropic Thermal Transport in Quasi-2D Ruddlesden-Popper Hybrid Perovskite Superlattices

Du Chen1,2, Thu T. M. Chu3, Yanyan Li1,2, Shunran Li1,2, Qixuan Hu4, Jee Yung Park1,2, Tyler Wang2,5, Luoqi Dai3, Ming Lu6 et al.

Mengxia Liu2,7, Letian Dou4,8, Xiaotong Li3, Yi Xia9, and Peijun Guo1,2,*

  • *Contact author: peijun.guo@yale.edu
PDF

Phys. Rev. X 15, 041054 – Published 22 December, 2025

DOI: https://doi.org/10.1103/kh5d-jrxw

Abstract

Two-dimensional hybrid metal-halide perovskites (2D-MHPs) have emerged as important solution-processed semiconductors with favorable optical and electronic properties for diverse applications in photovoltaics, optoelectronics, and spintronics. The quasi-2D layered structures, featuring large acoustic impedance mismatches between the organic and inorganic sublattices, are expected to result in distinct and anisotropic thermal transport properties along the cross-plane and in-plane directions. Here, we introduce transducer-free vibrational-pump-visible-probe (VPVP) approaches that enable accurate quantification of anisotropic thermal transport properties in various archetypical single-crystalline 2D-MHPs. Specifically, using VPVP spectroscopy and VPVP microscopy, we measure the anisotropic thermal diffusivities of 2D-MHPs with systematically varied Pb-I octahedral layer thicknesses, as well as organic spacer types and lengths, revealing how these structural parameters alter the cross-plane and in-plane thermal transport properties in distinct ways. While diffuse interface scattering plays an important role in dictating cross-plane thermal transport, in-plane thermal transport is primarily determined by phonon transport within interconnected inorganic layers. Density functional theory incorporating four-phonon scatterings provides further insight into the low thermal conductivity and modest thermal conduction anisotropy in 2D-MHPs. Our work demonstrates a new all-optical and noncontact method, which requires minimal sample preparation and allows direct visualization of cross-plane and in-plane thermal transport, potentially compatible with in situ sample environments. The demonstrated VPVP approaches can advance understanding of thermal transport in 2D-MHPs as well as wide-ranging hybrid and polymeric semiconductors beyond 2D-MHPs.

View figure in article

Physics Subject Headings (PhySH)

Popular Summary

Understanding and controlling the flow of heat is important for improving the performance and stability of devices such as solar cells and light-emitting devices. We developed an all-optical and nondestructive method to measure how heat flows in 2D hybrid perovskites. Taking advantage of the infrared light absorption of the organic sublattice and the sensitivity of visible light reflectance to lattice temperature, our devised pump-probe scheme tracks the spatiotemporal temperature decay after impulsive infrared thermal excitation. We found that heat moves very slowly across the layer-stacking direction due to the organic-inorganic packing, whereas heat transfer along the layer is tied to the intrinsic properties of the constituent building blocks. This work provides a comprehensive view of anisotropic heat flow in 2D hybrid perovskites, informing strategies for tailoring these properties through structural design. The all-optical approach is versatile, useful for other layered or nanoscale hybrid and polymeric materials. This opens exciting possibilities for characterizing and engineering heat flow at the microscopic level.

Article Text

Supplemental Material

References (89)

  1. Z.-K. Tan et al., Bright light-emitting diodes based on organometal halide perovskite, Nat. Nanotechnol. 9, 687 (2014).
  2. J. Y. Kim, J.-W. Lee, H. S. Jung, H. Shin, and N.-G. Park, High-efficiency perovskite solar cells, Chem. Rev. 120, 7867 (2020).
  3. W. Nie et al., High-efficiency solution-processed perovskite solar cells with millimeter-scale grains, Science 347, 522 (2015).
  4. G. E. Eperon, S. D. Stranks, C. Menelaou, M. B. Johnston, L. M. Herz, and H. J. Snaith, Formamidinium lead trihalide: A broadly tunable perovskite for efficient planar heterojunction solar cells, Energy Environ. Sci. 7, 982 (2014).
  5. K. X. Steirer, P. Schulz, G. Teeter, V. Stevanovic, M. Yang, K. Zhu, and J. J. Berry, Defect tolerance in methylammonium lead triiodide perovskite, ACS Energy Lett. 1, 360 (2016).
  6. I. C. Smith, E. T. Hoke, D. Solis-Ibarra, M. D. McGehee, and H. I. Karunadasa, A Layered hybrid perovskite solar-cell absorber with enhanced moisture stability, Angew. Chem., Int. Ed. 53, 11232 (2014).
  7. H. Tsai et al., High-efficiency two-dimensional Ruddlesden-Popper perovskite solar cells, Nature (London) 536, 312 (2016).
  8. C. Katan, N. Mercier, and J. Even, Quantum and dielectric confinement effects in lower-dimensional hybrid perovskite semiconductors, Chem. Rev. 119, 3140 (2019).
  9. J. Xing et al., Color-stable highly luminescent sky-blue perovskite light-emitting diodes, Nat. Commun. 9, 3541 (2018).
  10. C. Qin et al., Triplet management for efficient perovskite light-emitting diodes, Nat. Photonics 14, 70 (2020).
  11. Y.-H. Kim et al., Chiral-induced spin selectivity enables a room-temperature spin light-emitting diode, Science 371, 1129 (2021).
  12. M. K. Jana, R. Song, Y. Xie, R. Zhao, P. C. Sercel, V. Blum, and D. B. Mitzi, Structural descriptor for enhanced spin-splitting in 2D hybrid perovskites, Nat. Commun. 12, 4982 (2021).
  13. D. Chen, S. Li, B. Li, and P. Guo, Thermal transport in metal halide perovskites and other third-generation photovoltaic materials, Appl. Phys. Rev. 11, 041311 (2024).
  14. A. Giri, A. Z. Chen, A. Mattoni, K. Aryana, D. Zhang, X. Hu, S.-H. Lee, J. J. Choi, and P. E. Hopkins, Ultralow thermal conductivity of two-dimensional metal halide perovskites, Nano Lett. 20, 3331 (2020).
  15. A. Pisoni, J. Jaćimović, O. S. Barišić, M. Spina, R. Gaál, L. Forró, and E. Horváth, Ultra-low thermal conductivity in organic-inorganic hybrid perovskite CH3NH3PbI3, J. Phys. Chem. Lett. 5, 2488 (2014).
  16. C. C. Boyd, R. Cheacharoen, T. Leijtens, and M. D. McGehee, Understanding degradation mechanisms and improving stability of perovskite photovoltaics, Chem. Rev. 119, 3418 (2019).
  17. B. Conings et al., Intrinsic thermal instability of methylammonium lead trihalide perovskite, Adv. Energy Mater. 5, 1500477 (2015).
  18. A. D. Christodoulides et al., Signatures of coherent phonon transport in ultralow thermal conductivity two-dimensional Ruddlesden-Popper phase perovskites, ACS Nano 15, 4165 (2021).
  19. M. A. J. Rasel, A. Giri, D. H. Olson, C. Ni, P. E. Hopkins, and J. P. Feser, Chain-length dependence of thermal conductivity in 2D alkylammonium lead iodide single crystals, ACS Appl. Mater. Interfaces 12, 53705 (2020).
  20. N. S. Dahod, W. Paritmongkol, and W. A. Tisdale, Efficient thermal transport across molecular chains in hybrid 2D lead bromide perovskites, arXiv:2303.17397.
  21. P. Jiang, X. Qian, and R. Yang, Tutorial: Time-domain thermoreflectance (TDTR) for thermal property characterization of bulk and thin film materials, J. Appl. Phys. 124, 161103 (2018).
  22. J. P. Feser and D. G. Cahill, Probing anisotropic heat transport using time-domain thermoreflectance with offset laser spots, Rev. Sci. Instrum. 83, 104901 (2012).
  23. M. Li, H. Wu, E. M. Avery, Z. Qin, D. P. Goronzy, H. D. Nguyen, T. Liu, P. S. Weiss, and Y. Hu, Electrically gated molecular thermal switch, Science 382, 585 (2023).
  24. J. P. Feser, J. Liu, and D. G. Cahill, Pump-probe measurements of the thermal conductivity tensor for materials lacking in-plane symmetry, Rev. Sci. Instrum. 85, 104903 (2014).
  25. H. Malekpour and A. A. Balandin, Raman-based technique for measuring thermal conductivity of graphene and related materials, J. Raman Spectrosc. 49, 106 (2018).
  26. S. Vaziri et al., Ultrahigh thermal isolation across heterogeneously layered two-dimensional materials, Sci. Adv. 5, eaax1325 (2019).
  27. M. Menahem, Z. Dai, S. Aharon, R. Sharma, M. Asher, Y. Diskin-Posner, R. Korobko, A. M. Rappe, and O. Yaffe, Strongly anharmonic octahedral tilting in two-dimensional hybrid halide perovskites, ACS Nano 15, 10153 (2021).
  28. See Supplemental Material at http://link.aps.org/supplemental/10.1103/kh5d-jrxw for sample preparation, experimental methods, and data analysis, which includes Refs. [29–35].
  29. C. C. Stoumpos, D. H. Cao, D. J. Clark, J. Young, J. M. Rondinelli, J. I. Jang, J. T. Hupp, and M. G. Kanatzidis, Ruddlesden–Popper hybrid lead iodide perovskite 2D homologous semiconductors, Chem. Mater. 28, 2852 (2016).
  30. J. Hou et al., Synthesis of 2D perovskite crystals via progressive transformation of quantum well thickness, Nat. Synth. 3, 265 (2024).
  31. P. Guo et al., Slow thermal equilibration in methylammonium lead iodide revealed by transient mid-infrared spectroscopy, Nat. Commun. 9, 2792 (2018).
  32. I. H. Malitson, F. V. Murphy, and W. S. Rodney, Refractive index of synthetic sapphire, J. Opt. Soc. Am. 48, 72 (1958).
  33. T. Favaloro, J.-H. Bahk, and A. Shakouri, Characterization of the temperature dependence of the thermoreflectance coefficient for conductive thin films, Rev. Sci. Instrum. 86, 024903 (2015).
  34. D. Kim, E. S. Vasileiadou, I. Spanopoulos, M. G. Kanatzidis, and Q. Tu, In-plane mechanical properties of two-dimensional hybrid organic-inorganic perovskite nanosheets: Structure-property relationships, ACS Appl. Mater. Interfaces 13, 31642 (2021).
  35. M. Haterbouch and R. Benamar, The effects of large vibration amplitudes on the axisymmetric mode shapes and natural frequencies of clamped thin isotropic circular plates. Part I: Iterative and explicit analytical solution for non-linear transverse vibrations, J. Sound Vib. 265, 123 (2003).
  36. C. Li et al., Remarkably weak anisotropy in thermal conductivity of two-dimensional hybrid perovskite butylammonium lead iodide crystals, Nano Lett. 21, 3708 (2021).
  37. S. Varghese et al., A pre-time-zero spatiotemporal microscopy technique for the ultrasensitive determination of the thermal diffusivity of thin films, Rev. Sci. Instrum. 94, 034903 (2023).
  38. R. A. Kerner, P. Schulz, J. A. Christians, S. P. Dunfield, B. Dou, L. Zhao, G. Teeter, J. J. Berry, and B. P. Rand, Reactions at noble metal contacts with methylammonium lead triiodide perovskites: Role of underpotential deposition and electrochemistry, APL Mater. 7, 041103 (2019).
  39. M. A. Pérez-Osorio, R. L. Milot, M. R. Filip, J. B. Patel, L. M. Herz, M. B. Johnston, and F. Giustino, Vibrational properties of the organic-inorganic halide perovskite CH3NH3PbI3 from theory and experiment: Factor group analysis, first-principles calculations, and low-temperature infrared spectra, J. Phys. Chem. C 119, 25703 (2015).
  40. Y. Li, S. Li, D. Chen, C. A. Kocoj, A. Yang, B. T. Diroll, and P. Guo, Mid-infrared photodetection with 2D metal halide perovskites at ambient temperature, Sci. Adv. 10, eadk2778 (2024).
  41. S. Li et al., Ultrafast excitonic response in two-dimensional hybrid perovskites driven by intense midinfrared pulses, Phys. Rev. Lett. 129, 177401 (2022).
  42. A. D. Wright, C. Verdi, R. L. Milot, G. E. Eperon, M. A. Pérez-Osorio, H. J. Snaith, F. Giustino, M. B. Johnston, and L. M. Herz, Electron-phonon coupling in hybrid lead halide perovskites, Nat. Commun. 7, 11755 (2016).
  43. R. B. Wilson, B. A. Apgar, L. W. Martin, and D. G. Cahill, Thermoreflectance of metal transducers for optical pump-probe studies of thermal properties, Opt. Express 20, 28829 (2012).
  44. B. Li, J. Xu, C. A. Kocoj, S. Li, Y. Li, D. Chen, S. Zhang, L. Dou, and P. Guo, Dual-hyperspectral optical pump-probe microscopy with single-nanosecond time resolution, J. Am. Chem. Soc. 146, 2187 (2024).
  45. P. Guo et al., Infrared-pump electronic-probe of methylammonium lead iodide reveals electronically decoupled organic and inorganic sublattices, Nat. Commun. 10, 482 (2019).
  46. J. Fu, T. Bian, J. Yin, M. Feng, Q. Xu, Y. Wang, and T. C. Sum, Organic and inorganic sublattice coupling in two-dimensional lead halide perovskites, Nat. Commun. 15, 4562 (2024).
  47. D. Chen et al., Direct spectroscopic observation of cross-plane heat transfer in a two-dimensional van der Waals heterostructure, J. Phys. Chem. C 127, 9121 (2023).
  48. Q. Tu, I. Spanopoulos, S. Hao, C. Wolverton, M. G. Kanatzidis, G. S. Shekhawat, and V. P. Dravid, Out-of-plane mechanical properties of 2D hybrid organic-inorganic perovskites by nanoindentation, ACS Appl. Mater. Interfaces 10, 22167 (2018).
  49. D. Shen et al., Enhanced thermal conductivity of epoxy composites with core-shell SiC@SiO2 nanowires, High Volt. 2, 154 (2017).
  50. G. A. Elbaz, W. L. Ong, E. A. Doud, P. Kim, D. W. Paley, X. Roy, and J. A. Malen, Phonon speed, not scattering, differentiates thermal transport in lead halide perovskites, Nano Lett. 17, 5734 (2017).
  51. M. Born and E. Wolf, Principles of Optics: Electromagnetic Theory of Propagation, Interference and Diffraction of Light (Elsevier, New York, 2013).
  52. K. Nassau, CRC Handbook of Laser Science and Technology, Volume IV edited by M. J. Weber (CRC Press, Boca Raton, 1986).
  53. S. Li, Z. Dai, L. Li, N. P. Padture, and P. Guo, Time-resolved vibrational-pump visible-probe spectroscopy for thermal conductivity measurement of metal-halide perovskites, Rev. Sci. Instrum. 93, 053003 (2022).
  54. A. J. Schmidt, X. Chen, and G. Chen, Pulse accumulation, radial heat conduction, and anisotropic thermal conductivity in pump-probe transient thermoreflectance, Rev. Sci. Instrum. 79, 114902 (2008).
  55. D. G. Cahill, Analysis of heat flow in layered structures for time-domain thermoreflectance, Rev. Sci. Instrum. 75, 5119 (2004).
  56. L. N. Quan et al., Vibrational relaxation dynamics in layered perovskite quantum wells, Proc. Natl. Acad. Sci. U.S.A. 118, e2104425118 (2021).
  57. M. B. Fridriksson, N. van der Meer, J. de Haas, and F. C. Grozema, Tuning the structural rigidity of two-dimensional Ruddlesden-Popper perovskites through the organic cation, J. Phys. Chem. C 124, 28201 (2020).
  58. A. Negi et al., Anomalous correlation between thermal conductivity and elastic modulus in two-dimensional hybrid metal halide perovskites, ACS Nano 18, 14218 (2024).
  59. C. Yang, S. Raza, X. Li, and J. Liu, Thermal transport in poly(p-phenylene): Anomalous dimensionality dependence and role of π−π stacking, J. Phys. Chem. B 127, 6804 (2023).
  60. R.-I. Biega, M. Bokdam, K. Herrmann, J. Mohanraj, D. Skrybeck, M. Thelakkat, M. Retsch, and L. Leppert, Dynamic distortions of quasi-2D Ruddlesden–Popper perovskites at elevated temperatures: Influence on thermal and electronic properties, J. Phys. Chem. C 127, 9183 (2023).
  61. S. Park, J. Jang, H. Kim, D. I. Park, K. Kim, and H. J. Yoon, Thermal conductance in single molecules and self-assembled monolayers: Physicochemical insights, progress, and challenges, J. Mater. Chem. A 8, 19746 (2020).
  62. J. Ravichandran et al., Crossover from incoherent to coherent phonon scattering in epitaxial oxide superlattices, Nat. Mater. 13, 168 (2014).
  63. D. G. Cahill, S. K. Watson, and R. O. Pohl, Lower limit to the thermal conductivity of disordered crystals, Phys. Rev. B 46, 6131 (1992).
  64. R. Heiderhoff, T. Haeger, N. Pourdavoud, T. Hu, M. Al-Khafaji, A. Mayer, Y. Chen, H.-C. Scheer, and T. Riedl, Thermal conductivity of methylammonium lead halide perovskite single crystals and thin films: A comparative study, J. Phys. Chem. C 121, 28306 (2017).
  65. P. Acharyya, T. Ghosh, K. Pal, K. Kundu, K. Singh Rana, J. Pandey, A. Soni, U. V. Waghmare, and K. Biswas, Intrinsically ultralow thermal conductivity in Ruddlesden-Popper 2D perovskite Cs2PbI2Cl2: Localized anharmonic vibrations and dynamic octahedral distortions, J. Am. Chem. Soc. 142, 15595 (2020).
  66. P. Acharyya et al., Glassy thermal conductivity in Cs3Bi2I6Cl3 single crystal, Nat. Commun. 13, 5053 (2022).
  67. M. Simoncelli, N. Marzari, and F. Mauri, Unified theory of thermal transport in crystals and glasses, Nat. Phys. 15, 809 (2019).
  68. M. R. Filip, D. Y. Qiu, M. Del Ben, and J. B. Neaton, Screening of excitons by organic cations in quasi-two-dimensional organic-inorganic lead-halide perovskites, Nano Lett. 22, 4870 (2022).
  69. S. Krach, N. Forero-Correa, R.-I. Biega, S. E. Reyes-Lillo, and L. Leppert, Emergence of Rashba-Dresselhaus effects in Ruddlesden-Popper halide perovskites with octahedral rotations, J. Phys. Condens. Matter 35, 174001 (2023).
  70. P. Guo et al., Polar fluctuations in metal halide perovskites uncovered by acoustic phonon anomalies, ACS Energy Lett. 2, 2463 (2017).
  71. O. Yaffe et al., Local polar fluctuations in lead halide perovskite crystals, Phys. Rev. Lett. 118, 136001 (2017).
  72. P. Guo, C. C. Stoumpos, L. Mao, S. Sadasivam, J. B. Ketterson, P. Darancet, M. G. Kanatzidis, and R. D. Schaller, Cross-plane coherent acoustic phonons in two-dimensional organic-inorganic hybrid perovskites, Nat. Commun. 9, 2019 (2018).
  73. Y. Li et al., Measurement of the optical dielectric function of monolayer transition-metal dichalcogenides: MoS2,MoSe2,WS2, and WSe2, Phys. Rev. B 90, 205422 (2014).
  74. P. Guo et al., Hyperbolic dispersion arising from anisotropic excitons in two-dimensional perovskites, Phys. Rev. Lett. 121, 127401 (2018).
  75. S. Li et al., Large exchange-driven intrinsic circular dichroism of a chiral 2D hybrid perovskite, Nat. Commun. 15, 2573 (2024).
  76. G. Kresse and J. Hafner, Ab initio molecular dynamics for liquid metals, Phys. Rev. B 47, 558 (1993).
  77. G. Kresse and J. Hafner, Ab initio molecular-dynamics simulation of the liquid-metal–amorphous-semiconductor transition in germanium, Phys. Rev. B 49, 14251 (1994).
  78. G. Kresse and J. Furthmüller, Efficiency of ab-initio total energy calculations for metals and semiconductors using a plane-wave basis set, Comput. Mater. Sci. 6, 15 (1996).
  79. G. Kresse and J. Furthmüller, Efficient iterative schemes for ab initio total-energy calculations using a plane-wave basis set, Phys. Rev. B 54, 11169 (1996).
  80. P. E. Blöchl, Projector augmented-wave method, Phys. Rev. B 50, 17953 (1994).
  81. J. P. Perdew, K. Burke, and M. Ernzerhof, Generalized gradient approximation made simple, Phys. Rev. Lett. 77, 3865 (1996).
  82. J. P. Perdew, A. Ruzsinszky, G. I. Csonka, O. A. Vydrov, G. E. Scuseria, L. A. Constantin, X. Zhou, and K. Burke, Restoring the density-gradient expansion for exchange in solids and surfaces, Phys. Rev. Lett. 100, 136406 (2008).
  83. J. P. Perdew, K. Burke, and Y. Wang, Generalized gradient approximation for the exchange-correlation hole of a many-electron system, Phys. Rev. B 54, 16533 (1996).
  84. P. Hohenberg and W. Kohn, Inhomogeneous electron gas, Phys. Rev. 136, B864 (1964).
  85. A. Togo and I. Tanaka, First principles phonon calculations in materials science, Scr. Mater. 108, 1 (2015).
  86. F. Zhou, W. Nielson, Y. Xia, and V. Ozoliņš, Lattice anharmonicity and thermal conductivity from compressive sensing of first-principles calculations, Phys. Rev. Lett. 113, 185501 (2014).
  87. Y. Xia, Revisiting lattice thermal transport in PbTe: The crucial role of quartic anharmonicity, Appl. Phys. Lett. 113, 073901 (2018).
  88. Y. Xia, D. Gaines, J. He, K. Pal, Z. Li, M. G. Kanatzidis, V. Ozoliņš, and C. Wolverton, A unified understanding of minimum lattice thermal conductivity, Proc. Natl. Acad. Sci. U.S.A. 120, e2302541120 (2023).
  89. Y. Xia, V. I. Hegde, K. Pal, X. Hua, D. Gaines, S. Patel, J. He, M. Aykol, and C. Wolverton, High-throughput study of lattice thermal conductivity in binary rocksalt and zinc blende compounds including higher-order anharmonicity, Phys. Rev. X 10, 041029 (2020).
