Self-Organized Homogenization of Flow Networks

Julien Bouvard1,*, Swarnavo Basu2,*, Charlott Leu3, Onurcan Bektas2,3,4, Joachim O. Rädler3, Gabriel Amselem1,†, and Karen Alim2,‡

  • *These authors contributed equally to this work.
  • †Contact author: gabriel.amselem@polytechnique.edu
  • ‡Contact author: k.alim@tum.de
PDF

Phys. Rev. X 15, 041038 – Published 26 November, 2025

DOI: https://doi.org/10.1103/j5ch-4vkh

Abstract

From the vasculature of animals to the porous media making up batteries, the core task of flow networks is to transport solutes and perfuse all cells or media equally with resources. Yet, living flow networks have a key advantage over porous media: They are adaptive, and they self-organize their geometry for homogeneous perfusion throughout the network. Here, we show that artificial flow networks can also self-organize toward homogeneous perfusion by the versatile adaption of controlled erosion. Flowing a pulse of cleaving enzyme through a network patterned into an erodible hydrogel, with initial channels disparate in width, we observe a homogenization in channel resistances. Experimental observations are matched with numerical simulations of the diffusion-advection-sorption dynamics of an eroding enzyme within a network. Analyzing transport dynamics theoretically, we show that homogenization only occurs if the pulse of the eroding enzyme lasts longer than the time it takes any channel to equilibrate to the pulse concentration. The equilibration time scale derived analytically is in agreement with simulations. Lastly, we show both numerically and experimentally that erosion leads to the homogenization of complex networks containing loops. Erosion being an omnipresent reaction, our results pave the way for a very versatile self-organized increase in the performance of porous media.

View figure in article

Physics Subject Headings (PhySH)

Popular Summary

Flow networks—from animal blood vessels to the porous structures inside batteries—share a common goal: to deliver fluids or solutes evenly throughout their systems. Living networks naturally adjust their architecture to maintain uniform flow, but artificial networks typically lack this self-organizing ability. In this study, we demonstrate a simple yet powerful method to help inanimate flow networks achieve similar self-organization using controlled pulsing of an erosive chemical. This approach allows the network to restructure itself so that all channels carry fluid more evenly, improving overall performance.

We create flow networks patterned into erodible hydrogels and introduce a pulse of a cleaving enzyme that gradually dissolves the material. Over time, the resistances of individual channels become more balanced, leading to more uniform flow. Using simulations to describe these experiments, we find that successful homogenization occurs only when the enzyme pulse lasts longer than the time it takes fluid in each channel to reach equilibrium. From this, we derive a simple analytical rule that predicts how long a pulse must last to achieve homogenization. Applying this rule, we can balance flow even in complex networks that contain multiple loops.

Our findings reveal a general strategy for reducing disorder in artificial flow networks through erosion-driven self-organization. Because this mechanism depends only on basic material and flow properties, it can be applied broadly to systems made from erodible materials. This principle could guide the design of next-generation porous materials and devices, including more efficient batteries, reactors, and filtration systems.

Article Text

Supplemental Material

References (67)

  1. P. P. Stankey, K. T. Kroll, A. J. Ainscough, D. S. Reynolds, A. Elamine, B. T. Fichtenkort, S. G. Uzel, and J. A. Lewis, Embedding biomimetic vascular networks via coaxial sacrificial writing into functional tissue, Adv. Mater. 36, e2401528 (2024).
  2. H. Sun, J. Zhu, D. Baumann, L. Peng, Y. Xu, I. Shakir, Y. Huang, and X. Duan, Hierarchical 3D electrodes for electrochemical energy storage, Nat. Rev. Mater. 4, 45 (2019).
  3. C. Tien and A. C. Payatakes, Advances in deep bed filtration, AIChE J. 25, 737 (1979).
  4. W. R. Bowen and F. Jenner, Theoretical descriptions of membrane filtration of colloids and fine particles: An assessment and review, Adv. Colloid Interface Sci. 56, 141 (1995).
  5. K. Beven and P. Germann, Macropores and water flow in soils, Water Resour. Res. 18, 1311 (1982).
  6. L. Lebon, L. Oger, J. Leblond, J. P. Hulin, N. S. Martys, and L. M. Schwartz, Pulsed gradient NMR measurements and numerical simulation of flow velocity distribution in sphere packings, Phys. Fluids 8, 293 (1996).
  7. Y. E. Kutsovsky, L. E. Scriven, H. T. Davis, and B. E. Hammer, NMR imaging of velocity profiles and velocity distributions in bead packs, Phys. Fluids 8, 863 (1996).
  8. M. D. Shattuck, R. P. Behringer, G. A. Johnson, and J. G. Georgiadis, Convection and flow in porous media. Part 1. Visualization by magnetic resonance imaging, J. Fluid Mech. 332, 215 (1997).
  9. R. S. Maier, D. M. Kroll, Y. E. Kutsovsky, H. T. Davis, and R. S. Bernard, Simulation of flow through bead packs using the lattice Boltzmann method, Phys. Fluids 10, 60 (1998).
  10. A. Sederman and L. Gladden, Magnetic resonance visualisation of single- and two-phase flow in porous media, Magn. Reson. Imaging 19, 339 (2001).
  11. M. Moroni and J. H. Cushman, Statistical mechanics with three-dimensional particle tracking velocimetry experiments in the study of anomalous dispersion. II. Experiments, Phys. Fluids 13, 81 (2001).
  12. S. S. Datta, H. Chiang, T. S. Ramakrishnan, and D. A. Weitz, Spatial fluctuations of fluid velocities in flow through a three-dimensional porous medium, Phys. Rev. Lett. 111, 064501 (2013).
  13. K. Alim, S. Parsa, D. A. Weitz, and M. P. Brenner, Local pore size correlations determine flow distributions in porous media, Phys. Rev. Lett. 119, 144501 (2017).
  14. M. Matyka, J. Gołembiewski, and Z. Koza, Power-exponential velocity distributions in disordered porous media, Phys. Rev. E 93, 013110 (2016).
  15. F. J. Meigel, T. Darwent, L. Bastin, L. Goehring, and K. Alim, Dispersive transport dynamics in porous media emerge from local correlations, Nat. Commun. 13, 5885 (2022).
  16. Z. A. Sexton, D. Rütsche, J. E. Herrmann, A. R. Hudson, S. Sinha, J. Du, D. J. Shiwarski, A. Masaltseva, F. S. Solberg, J. Pham, J. M. Szafron, S. M. Wu, A. W. Feinberg, M. A. Skylar-Scott, and A. L. Marsden, Rapid model-guided design of organ-scale synthetic vasculature for biomanufacturing, Science 388, 1198 (2025).
  17. S. Isogai, M. Horiguchi, and B. M. Weinstein, The vascular anatomy of the developing zebrafish: An atlas of embryonic and early larval development, Dev. Biol. 230, 278 (2001).
  18. L. Boddy, J. Hynes, D. P. Bebber, and M. D. Fricker, Saprotrophic cord systems: Dispersal mechanisms in space and time, Mycoscience 50, 9 (2009).
  19. A. Tero, S. Takagi, T. Saigusa, K. Ito, D. P. Bebber, M. D. Fricker, K. Yumiki, R. Kobayashi, and T. Nakagaki, Rules for biologically inspired adaptive network design, Science 327, 439 (2010).
  20. S.-S. Chang and M. Roper, Microvascular networks with uniform flow, J. Theor. Biol. 462, 48 (2019).
  21. S.-S. Chang, S. Tu, K. I. Baek, A. Pietersen, Y.-H. Liu, V. M. Savage, S.-P. L. Hwang, T. K. Hsiai, and M. Roper, Optimal occlusion uniformly partitions red blood cells fluxes within a microvascular network, PLoS Comput. Biol. 13, e1005892 (2017).
  22. J. B. Kirkegaard and K. Sneppen, Optimal transport flows for distributed production networks, Phys. Rev. Lett. 124, 208101 (2020).
  23. A. Simonin, J. Palma-Guerrero, M. Fricker, and N. L. Glass, Physiological significance of network organization in fungi, Eukaryot. Cell 11, 1345 (2012).
  24. K. Alim, N. Andrew, A. Pringle, and M. P. Brenner, Mechanism of signal propagation in physarum polycephalum, Proc. Natl. Acad. Sci. U.S.A. 114, 5136 (2017).
  25. S. Liese, L. Mahadevan, and A. Carlson, Balancing efficiency and homogeneity of biomaterial transport in networks, Europhys. Lett. 135, 58001 (2021).
  26. F. Kramer and C. D. Modes, Biological flow networks: Antagonism between hydrodynamic and metabolic stimuli as driver of topological transitions, Phys. Rev. Res. 5, 023106 (2023).
  27. J. Karschau, A. Scholich, J. Wise, H. Morales-Naverrete, M. Zerial, and B. M. Friedrich, Resilience of three-dimensional sinusoidal networks in liver tissue, PLoS Comput. Biol. 16, e1007965 (2020).
  28. F. J. Meigel and K. Alim, Flow rate of transport network controls uniform metabolite supply to tissue, J. R. Soc. Interface 15, 20180075 (2018).
  29. Y. Qi and M. Roper, Control of low flow regions in the cortical vasculature determines optimal arterio-venous ratios, Proc. Natl. Acad. Sci. U.S.A. 118, e2021840118 (2021).
  30. C. D. Murray, The physiological principle of minimum work: I. The vascular system and the cost of blood volume, Proc. Natl. Acad. Sci. U.S.A. 12, 207 (1926).
  31. S. Marbach, N. Ziethen, L. Bastin, F. K. Bäuerle, and K. Alim, Vein fate determined by flow-based but time-delayed integration of network architecture, eLife 12, e78100 (2023).
  32. A. Zareei, D. Pan, and A. Amir, Temporal evolution of erosion in pore networks: From homogenization to instability, Phys. Rev. Lett. 128, 234501 (2022).
  33. T. Gavrilchenko and E. Katifori, Distribution networks achieve uniform perfusion through geometric self-organization, Phys. Rev. Lett. 127, 078101 (2021).
  34. M. Kramar and K. Alim, Encoding memory in tube diameter hierarchy of living flow network, Proc. Natl. Acad. Sci. U.S.A. 118, e2007815118 (2021).
  35. K. H. Wong, J. M. Chan, R. D. Kamm, and J. Tien, Microfluidic models of vascular functions, Annu. Rev. Biomed. Eng. 14, 205 (2012).
  36. B. Sebastian and P. S. Dittrich, Microfluidics to mimic blood flow in health and disease, Annu. Rev. Fluid Mech. 50, 483 (2018).
  37. M. Fenech, V. Girod, V. Claveria, S. Meance, M. Abkarian, and B. Charlot, Microfluidic blood vasculature replicas using backside lithography, Lab Chip 19, 2096 (2019).
  38. D. J. Beebe, J. S. Moore, J. M. Bauer, Q. Yu, R. H. Liu, C. Devadoss, and B.-H. Jo, Functional hydrogel structures for autonomous flow control inside microfluidic channels, Nature (London) 404, 588 (2000).
  39. D. T. Eddington and D. J. Beebe, Flow control with hydrogels, Adv. Drug Delivery Rev. 56, 199 (2004).
  40. A. Richter, D. Kuckling, S. Howitz, T. Gehring, and K.-F. Arndt, Electronically controllable microvalves based on smart hydrogels: Magnitudes and potential applications, J. Microelectromech. Syst. 12, 748 (2003).
  41. L. D’eramo, B. Chollet, M. Leman, E. Martwong, M. Li, H. Geisler, J. Dupire, M. Kerdraon, C. Vergne, F. Monti et al., Microfluidic actuators based on temperature-responsive hydrogels, Microsyst. Nanoeng. 4, 17069 (2018).
  42. A. Baldi, Y. Gu, P. Loftness, R. Siegel, and B. Ziaie, A hydrogel-actuated smart microvalve with a porous diffusion barrier back-plate for active flow control, in Technical Digest. MEMS 2002 IEEE International Conference. Fifteenth IEEE International Conference on Micro Electro Mechanical Systems (Cat. No.02CH37266), MEMSYS-02, IEEE (IEEE, Las Vegas, NV, 2002), pp. 105–108, 10.1109/MEMSYS.2002.984101.
  43. R. H. Liu, Q. Yu, and D. J. Beebe, Fabrication and characterization of hydrogel-based microvalves, J. Microelectromech. Syst. 11, 45 (2002).
  44. C. B. Goy, R. E. Chaile, and R. E. Madrid, Microfluidics and hydrogel: A powerful combination, React. Funct. Polym. 145, 104314 (2019).
  45. F. Paratore, V. Bacheva, M. Bercovici, and G. V. Kaigala, Reconfigurable microfluidics, Nat. Rev. Chem. 6, 70 (2022).
  46. H. Na, Y.-W. Kang, C. S. Park, S. Jung, H.-Y. Kim, and J.-Y. Sun, Hydrogel-based strong and fast actuators by electroosmotic turgor pressure, Science 376, 301 (2022).
  47. See Supplemental Material at http://link.aps.org/supplemental/10.1103/j5ch-4vkh for details on enzyme dynamics, more network architectures self-organizing, flow distributions of self-organizing networks, full parameter sweeps for homogenization, details on the simulation and derivations, as well as movies of experimental observations. The experimental data, simulation code, and movies are available in the mediaTUM repository at [48]. The Supplemental Material also includes Ref. [49].
  48. J. Bouvard, S. Basu, C. Leu, O. Bektas, J. O. Rädler, G. Amselem, and K. Alim, Experimental data and MATLAB code, Self-organized homogenization of flow networks, mediaTUM (2025), 10.14459/2024mp1752696.
  49. L. M. Weber, C. G. Lopez, and K. S. Anseth, Effects of PEG hydrogel crosslinking density on protein diffusion and encapsulated islet survival and function, J. Biomed. Mater. Res. A 90A, 720 (2009).
  50. H. Bruus, Acoustofluidics 1: Governing equations in microfluidics, Lab Chip 11, 3742 (2011).
  51. M. P. Lutolf, J. L. Lauer-Fields, H. G. Schmoekel, A. T. Metters, F. E. Weber, G. B. Fields, and J. A. Hubbell, Synthetic matrix metalloproteinase-sensitive hydrogels for the conduction of tissue regeneration: Engineering cell-invasion characteristics, Proc. Natl. Acad. Sci. U.S.A. 100, 5413 (2003).
  52. H. Nagase and G. B. Fields, Human matrix metalloproteinase specificity studies using collagen sequence-based synthetic peptides, Pept. Sci. 40, 399 (1996).
  53. J. Patterson and J. A. Hubbell, Enhanced proteolytic degradation of molecularly engineered peg hydrogels in response to MMP-1 and MMP-2, Biomaterials 31, 7836 (2010).
  54. G. I. Taylor, Dispersion of soluble matter in solvent flowing slowly through a tube, Proc. R. Soc. A 219, 186 (1953).
  55. R. Aris, On the dispersion of a solute in a fluid flowing through a tube, Proc. R. Soc. A 235, 67 (1956).
  56. P. M. Kharkar, K. L. Kiick, and A. M. Kloxin, Designing degradable hydrogels for orthogonal control of cell microenvironments, Chem. Soc. Rev. 42, 7335 (2013).
  57. L. Zhang, M. A. Hesse, and M. Wang, Transient solute transport with sorption in Poiseuille flow, J. Fluid Mech. 828, 733 (2017).
  58. P. B. Gaspers, C. R. Robertson, and A. P. Gast, Enzymes on immobilized substrate surfaces: Diffusion, Langmuir 10, 2699 (1994).
  59. H. Boukellal, Š. Selimović, Y. Jia, G. Cristobal, and S. Fraden, Simple, robust storage of drops and fluids in a microfluidic device, Lab Chip 9, 331 (2009).
  60. C. Jorge, A. Chardac, A. Poncet, and D. Bartolo, Active hydraulics laws from frustration principles, Nat. Phys. 20, 303 (2024).
  61. F. G. Woodhouse, A. Forrow, J. B. Fawcett, and J. Dunkel, Stochastic cycle selection in active flow networks, Proc. Natl. Acad. Sci. U.S.A. 113, 8200 (2016). 1607.08015.
  62. P. Gravesen, J. Branebjerg, and O. S. Jensen, Microfluidics-a review, J. Micromech. Microeng. 3, 168 (1993).
  63. J. H. Sung and M. L. Shuler, Prevention of air bubble formation in a microfluidic perfusion cell culture system using a microscale bubble trap, Biomed. Microdevices 11, 731 (2009).
  64. C. Lochovsky, S. Yasotharan, and A. Günther, Bubbles no more: In-plane trapping and removal of bubbles in microfluidic devices, Lab Chip 12, 595 (2012).
  65. S. Stöberl, M. Balles, T. Kellerer, and J. O. Rädler, Photolithographic microfabrication of hydrogel clefts for cell invasion studies, Lab Chip 23, 1886 (2023).
  66. J. G. Skinner, T. R. Groves, A. Novembre, H. Pfeiffer, and R. Singh, Photomask fabrication procedures and limitations, in Handbook of Microlithography, Micromachining, and Microfabrication. Volume 1: Microlithography (SPIE Press, 1997), Vol. 1, pp. 377–474.
  67. M. Dietrich, H. Le Roy, D. B. Brückner, H. Engelke, R. Zantl, J. O. Rädler, and C. P. Broedersz, Guiding 3d cell migration in deformed synthetic hydrogel microstructures, Soft Matter 14, 2816 (2018).
