Probing the Flat-Band Limit of the Superconducting Proximity Effect in Twisted Bilayer Graphene Josephson Junctions

A. Díez-Carlón1,2, J. Díez-Mérida1,2, P. Rout1,2, D. Sedov3, P. Virtanen4, S. Banerjee3, R. P. S. Penttilä5, P. Altpeter1, K. Watanabe6 et al.

T. Taniguchi7, S.-Y. Yang8, K. T. Law9, T. T. Heikkilä4, P. Törmä5, M. S. Scheurer3, and D. K. Efetov1,2,*

  • *Contact author: dmitri.efetov@lmu.de
PDF

Phys. Rev. X 15, 041033 – Published 20 November, 2025

DOI: https://doi.org/10.1103/ccb4-tqxq

Abstract

While extensively studied in normal metals, semimetals, and semiconductors, the superconducting (SC) proximity effect remains elusive in the emerging field of flat-band systems. In this study, we probe proximity-induced superconductivity in Josephson junctions (JJs) formed between superconducting NbTiN electrodes and twisted bilayer graphene (TBG) weak links. Here, the TBG acts as a highly tunable topological flat-band system, which, due to its twist-angle-dependent bandwidth, allows us to probe the SC proximity effect at the crossover from the dispersive to the flat-band limit. Contrary to our original expectations, we find that the induced superconductivity remains strong even in the flat-band limit and gives rise to broad, dome-shaped SC regions, in the filling-dependent phase diagram. In addition, we find that, unlike in conventional JJs, the critical current Ic strongly deviates from a scaling with the normal state conductance GN. We attribute these findings to the onset of strong electron interactions, which can give rise to an excess critical current. By also studying the dependence of Ic on the filling and twist angle across multiple samples, we further uncover the importance of quantum geometric terms as well as multiband pairing mechanisms in describing the induced superconductivity in the TBG flat bands as their bandwidth decreases. To the best of our knowledge, our results present the first detailed study of the SC proximity effect in the flat-band limit and shed new light on the mechanisms that drive the formation of SC domes in flat-band systems.

View figure in article

Physics Subject Headings (PhySH)

Collections

This article appears in the following collection:

Special Collection on 2D Materials

PRX launches this collection to showcase articles in the exciting field of 2D materials and van der Waals heterostructures to constitute an emblematic example of the diversity of physics in this very active scientific domain.

Popular Summary

According to standard theory, a Josephson junction—a device that carries a supercurrent between two superconductors—should not conduct any current if the material in the middle has a flat electronic band, meaning that its electrons do not move or spread out in energy. However, recent theoretical advances suggest that the quantum geometry of such bands, describing how electron wave functions overlap, can sustain a finite supercurrent even without dispersion. To test this idea, we create Josephson junctions using twisted bilayer graphene (TBG), a material made by stacking two sheets of graphene at a slight angle. This twist produces flat bands whose degree of flatness can be adjusted by changing the angle or applying an electric voltage.

At very low temperatures, we measure how supercurrent flows through these TBG junctions. Surprisingly, we find that the current remains strong even when the electronic bands are extremely flat—just as strong as when the bands allow electrons to move more freely. This result cannot be explained by traditional ideas about how electrons travel through a material. Instead, it points to the importance of collective electronic behavior, quantum geometry, and the interplay among multiple electronic states in sustaining the current.

Our findings reveal that superconductivity can survive even when electrons are almost completely localized, challenging long-held assumptions about how supercurrents form. This discovery also opens new possibilities for exploring superconductivity in other materials with flat electronic structures, which may help in developing future quantum technologies, including more robust types of quantum computers.

Article Text

Supplemental Material

References (63)

  1. P. G. De Gennes, Boundary effects in superconductors, Rev. Mod. Phys. 36, 225 (1964).
  2. K. K. Likharev, Superconducting weak links, Rev. Mod. Phys. 51, 101 (1979).
  3. T. M. Klapwijk, Proximity effect from an Andreev perspective, J. Supercond. 17, 593 (2004).
  4. M. Tinkham, Introduction to Superconductivity (Dover, Mineola, 1996).
  5. A. A. Golubov, M. Yu. Kupriyanov, and E. Il’ichev, The current-phase relation in Josephson junctions, Rev. Mod. Phys. 76, 411 (2004).
  6. Z. Li et al., Realization of flat band with possible nontrivial topology in electronic kagome lattice, Sci. Adv. 4, eaau4511 (2018).
  7. M. Kang et al., Dirac fermions and flat bands in the ideal kagome metal FeSn, Nat. Mater. 19, 163 (2020).
  8. L. Balents, C. R. Dean, D. K. Efetov, and A. F. Young, Superconductivity and strong correlations in moiré flat bands, Nat. Phys. 16, 725 (2020).
  9. S. Mukherjee, A. Spracklen, D. Choudhury, N. Goldman, P. Öhberg, E. Andersson, and R. R. Thomson, Observation of a localized flat-band state in a photonic Lieb lattice, Phys. Rev. Lett. 114, 245504 (2015).
  10. A. Julku, S. Peotta, T. I. Vanhala, D.-H. Kim, and P. Törmä, Geometric origin of superfluidity in the Lieb-lattice flat band, Phys. Rev. Lett. 117, 045303 (2016).
  11. S. Ahmadkhani and M. V. Hosseini, Superconducting proximity effect in flat band systems, J. Phys. Condens. Matter 32, 315504 (2020).
  12. Z. C. F. Li, Y. Deng, S. A. Chen, D. K. Efetov, and K. T. Law, Flat band Josephson junctions with quantum metric, Phys. Rev. Res. 7, 023273 (2025).
  13. P. Virtanen, R. P. S. Penttilä, P. Törmä, A. Díez-Carlón, D. K. Efetov, and T. T. Heikkilä, Superconducting junctions with flat bands, Phys. Rev. B 112, L100502 (2025).
  14. S. Peotta and P. Törmä, Superfluidity in topologically nontrivial flat bands, Nat. Commun. 6, 1 (2015).
  15. P. Törmä, S. Peotta, and B. A. Bernevig, Superconductivity, superfluidity and quantum geometry in twisted multilayer systems, Nat. Rev. Phys. 4, 528 (2022).
  16. H. Tian et al., Evidence for Dirac flat band superconductivity enabled by quantum geometry, Nature (London) 614, 440 (2023).
  17. Y. Cao, V. Fatemi, S. Fang, K. Watanabe, T. Taniguchi, E. Kaxiras, and P. Jarillo-Herrero, Unconventional superconductivity in magic-angle graphene superlattices, Nature (London) 556, 43 (2018).
  18. X. Lu et al., Superconductors, orbital magnets and correlated states in magic-angle bilayer graphene, Nature (London) 574, 653 (2019).
  19. Y. Cao et al., Correlated insulator behaviour at half-filling in magic-angle graphene superlattices, Nature (London) 556, 80 (2018).
  20. M. Yankowitz, S. Chen, H. Polshyn, Y. Zhang, K. Watanabe, T. Taniguchi, D. Graf, A. F. Young, and C. R. Dean, Tuning superconductivity in twisted bilayer graphene, Science 363, 1059 (2019).
  21. M. Serlin, C. L. Tschirhart, H. Polshyn, Y. Zhang, J. Zhu, K. Watanabe, T. Taniguchi, L. Balents, and A. F. Young, Intrinsic quantized anomalous Hall effect in a moiré heterostructure, Science 367, 900 (2020).
  22. K. P. Nuckolls, M. Oh, D. Wong, B. Lian, K. Watanabe, T. Taniguchi, B. A. Bernevig, and A. Yazdani, Strongly correlated Chern insulators in magic-angle twisted bilayer graphene, Nature (London) 588, 610 (2020).
  23. I. Das, X. Lu, J. Herzog-Arbeitman, Z.-D. Song, K. Watanabe, T. Taniguchi, B. A. Bernevig, and D. K. Efetov, Symmetry-broken Chern insulators and Rashba-like Landau-level crossings in magic-angle bilayer graphene, Nat. Phys. 17, 710 (2021).
  24. A. Bussmann-Holder, H. Keller, A. Simon, and A. Bianconi, Multi-band superconductivity and the steep band/flat band scenario, Condens. Matter 4, 91 (2019).
  25. M. Christos, S. Sachdev, and M. S. Scheurer, Nodal band-off-diagonal superconductivity in twisted graphene superlattices, Nat. Commun. 14, 1 (2023).
  26. R. Khasanov, B.-B. Ruan, Y.-Q. Shi, G.-F. Chen, H. Luetkens, Z.-A. Ren, and Z. Guguchia, Tuning of the flat band and its impact on superconductivity in Mo5Si3–xPx, Nat. Commun. 15, 2197 (2024).
  27. F. K. de Vries, E. Portolés, G. Zheng, T. Taniguchi, K. Watanabe, T. Ihn, K. Ensslin, and P. Rickhaus, Gate-defined Josephson junctions in magic-angle twisted bilayer graphene, Nat. Nanotechnol. 16, 760 (2021).
  28. D. Rodan-Legrain, Y. Cao, J. M. Park, S. C. de la Barrera, M. T. Randeria, K. Watanabe, T. Taniguchi, and P. Jarillo-Herrero, Highly tunable junctions and non-local Josephson effect in magic-angle graphene tunnelling devices, Nat. Nanotechnol. 16, 769 (2021).
  29. J. Díez-Mérida et al., Symmetry-broken Josephson junctions and superconducting diodes in magic-angle twisted bilayer graphene, Nat. Commun. 14, 1 (2023).
  30. See Supplemental Material at http://link.aps.org/supplemental/10.1103/ccb4-tqxq for [brief description].
  31. R. Jha, M. Endres, K. Watanabe, T. Taniguchi, M. Banerjee, C. Schönenberger, and P. Karnatak, Large tunable kinetic inductance in a twisted graphene superconductor, Phys. Rev. Lett. 134, 216001 (2025).
  32. M. R. Sinko, S. C. De La Barrera, O. Lanes, K. Watanabe, T. Taniguchi, S. Tan, D. Pekker, M. Hatridge, and B. M. Hunt, Superconducting contact and quantum interference between two-dimensional van der Waals and three-dimensional conventional superconductors, Phys. Rev. Mater. 5, 014001 (2021).
  33. P. Dubos, H. Courtois, B. Pannetier, F. K. Wilhelm, A. D. Zaikin, and G. Schön, Josephson critical current in a long mesoscopic S−N−S junction, Phys. Rev. B 63, 064502 (2001).
  34. H. B. Heersche, P. Jarillo-Herrero, J. B. Oostinga, L. M. K. Vandersypen, and A. F. Morpurgo, Bipolar supercurrent in graphene, Nature (London) 446, 56 (2007).
  35. S. A. Chen and K. T. Law, Ginzburg-Landau theory of flat-band superconductors with quantum metric, Phys. Rev. Lett. 132, 026002 (2024).
  36. J.-X. Hu, S. A. Chen, and K. T. Law, Anomalous coherence length in superconductors with quantum metric, Commun. Phys. 8, 20 (2025).
  37. M. Oh, K. P. Nuckolls, D. Wong, R. L. Lee, X. Liu, K. Watanabe, T. Taniguchi, and A. Yazdani, Evidence for unconventional superconductivity in twisted bilayer graphene, Nature (London) 600, 240 (2021).
  38. M. Tanaka et al., Superfluid stiffness of magic-angle twisted bilayer graphene, Nature (London) 638, 99 (2025).
  39. R. Bistritzer and A. H. MacDonald, Moiré bands in twisted double-layer graphene, Proc. Natl. Acad. Sci. U.S.A. 108, 12233 (2011).
  40. J. Hu, C. Wu, and X. Dai, Proposed design of a Josephson diode, Phys. Rev. Lett. 99, 067004 (2007).
  41. F. Ando, Y. Miyasaka, T. Li, J. Ishizuka, T. Arakawa, Y. Shiota, T. Moriyama, Y. Yanase, and T. Ono, Observation of superconducting diode effect, Nature (London) 584, 373 (2020).
  42. M. Nadeem, M. S. Fuhrer, and X. Wang, The superconducting diode effect, Nat. Rev. Phys. 5, 558 (2023).
  43. J.-X. Lin, P. Siriviboon, H. D. Scammell, S. Liu, D. Rhodes, K. Watanabe, T. Taniguchi, J. Hone, M. S. Scheurer, and J. I. A. Li, Zero-field superconducting diode effect in small-twist-angle trilayer graphene, Nat. Phys. 18, 1221 (2022).
  44. C.-C. Tseng, X. Ma, Z. Liu, K. Watanabe, T. Taniguchi, J.-H. Chu, and M. Yankowitz, Anomalous Hall effect at half filling in twisted bilayer graphene, Nat. Phys. 18, 1038 (2022).
  45. J.-X. Hu, Z.-T. Sun, Y.-M. Xie, and K. T. Law, Josephson diode effect induced by valley polarization in twisted bilayer graphene, Phys. Rev. Lett. 130, 266003 (2023).
  46. Y. Jiang, X. Lai, K. Watanabe, T. Taniguchi, K. Haule, J. Mao, and E. Y. Andrei, Charge order and broken rotational symmetry in magic-angle twisted bilayer graphene, Nature (London) 573, 91 (2019).
  47. Y. Cao, D. Rodan-Legrain, J. M. Park, N. F. Q. Yuan, K. Watanabe, T. Taniguchi, R. M. Fernandes, L. Fu, and P. Jarillo-Herrero, Nematicity and competing orders in superconducting magic-angle graphene, Science 372, 264 (2021).
  48. K. P. Nuckolls et al., Quantum textures of the many-body wavefunctions in magic-angle graphene, Nature (London) 620, 525 (2023).
  49. N. Bultinck, E. Khalaf, S. Liu, S. Chatterjee, A. Vishwanath, and M. P. Zaletel, Ground state and hidden symmetry of magic-angle graphene at even integer filling, Phys. Rev. X 10, 031034 (2020).
  50. M. Christos, S. Sachdev, and M. S. Scheurer, Correlated insulators, semimetals, and superconductivity in twisted trilayer graphene, Phys. Rev. X 12, 021018 (2022).
  51. F. Mesple, A. Missaoui, T. Cea, L. Huder, F. Guinea, G. Trambly de Laissardière, C. Chapelier, and V. T. Renard, Heterostrain determines flat bands in magic-angle twisted graphene layers, Phys. Rev. Lett. 127, 126405 (2021).
  52. E. Portolés, S. Iwakiri, G. Zheng, P. Rickhaus, T. Taniguchi, K. Watanabe, T. Ihn, K. Ensslin, and F. K. de Vries, A tunable monolithic SQUID in twisted bilayer graphene, Nat. Nanotechnol. 17, 1159 (2022).
  53. T. Golod and V. M. Krasnov, Demonstration of a superconducting diode-with-memory, operational at zero magnetic field with switchable nonreciprocity, Nat. Commun. 13, 1 (2022).
  54. F. Tafuri, Fundamentals and Frontiers of the Josephson Effect (Springer International Publishing, New York, 2019), Vol. 286.
  55. J. R. Clem, Josephson junctions in thin and narrow rectangular superconducting strips, Phys. Rev. B 81, 144515 (2010).
  56. J. G. Kroll et al., Magnetic-field-resilient superconducting coplanar-waveguide resonators for hybrid circuit quantum electrodynamics experiments, Phys. Rev. Appl. 11, 064053 (2019).
  57. R. C. Dynes and T. A. Fulton, Supercurrent density distribution in Josephson junctions, Phys. Rev. B 3, 3015 (1971).
  58. S. Hart, H. Ren, T. Wagner, P. Leubner, M. Mühlbauer, C. Brüne, H. Buhmann, L. W. Molenkamp, and A. Yacoby, Induced superconductivity in the quantum spin Hall edge, Nat. Phys. 10, 638 (2014).
  59. S. Chen et al., Current induced hidden states in Josephson junctions, Nat. Commun. 15, 8059 (2024).
  60. M. Alvarado, P. Burset, and A. L. Yeyati, Intrinsic nonmagnetic ϕ0 Josephson junctions in twisted bilayer graphene, Phys. Rev. Res. 5, L032033 (2023).
  61. H. Sainz-Cruz, P. A. Pantaleón, V. T. Phong, A. Jimeno-Pozo, and F. Guinea, Junctions and superconducting symmetry in twisted bilayer graphene, Phys. Rev. Lett. 131, 016003 (2023).
  62. C.-Z. Chen, J. J. He, M. N. Ali, G.-H. Lee, K. C. Fong, and K. T. Law, Asymmetric Josephson effect in inversion symmetry breaking topological materials, Phys. Rev. B 98, 075430 (2018).
  63. M. Endres, A. Kononov, H. S. Arachchige, J. Yan, D. Mandrus, K. Watanabe, T. Taniguchi, and C. Schönenberger, Current–phase relation of a WTe2 Josephson junction, Nano Lett. 23, 4654 (2023).
