Stealthy-Hyperuniform Wave Dynamics in Two-Dimensional Photonic Crystals

Maria Barsukova1,*, Zeyu Zhang1,*, Brian Gould1,*, Koorosh Sadri1, Christian Rosiek1,2, Søren Stobbe2, Jonas Karcher1,3, and Mikael C. Rechtsman1,†

  • *These authors contributed equally to this work.
  • †Contact author: mcrworld@psu.edu
PDF

Phys. Rev. X 16, 021028 – Published 7 May, 2026

DOI: https://doi.org/10.1103/8bz9-5g8s

Abstract

Hyperuniform structures are spatial patterns whose fluctuations disappear on long length scales, making them effectively homogeneous when observed from afar. Mathematically, this means that their spectral density ρ˜(k) approaches zero for low wave number |k|. Crystalline lattices are hyperuniform, as are certain quasicrystals, maximally random jammed packings of spheres, and electrons in the fractional quantum Hall state. Stealthy hyperuniformity is an even stronger constraint on the spectral density: It requires that ρ˜(k) is strictly zero in a finite range of wave vectors around k=0, called the stealthy regime, or exclusion region. Since the degree of scattering by disorder is, to leading order, proportional to ρ˜(k), waves propagating through such structures may do so without scattering for sufficiently long wavelengths and short distances. Here, we measure scattering by disorder in photonic crystal slabs with stealthy-hyperuniform disorder by measuring the linewidths of the photonic bands. We observe the transition between the stealthy and nonstealthy regimes, marked by a sharp increase in linewidth. We also observe the effects of multiple scattering in the stealthy regime, which implies diminishing transparency. Moreover, we show that residual single scattering in the stealthy regime arises from an intrinsically non-Hermitian effect: Propagating light has a complex effective mass due to radiative loss out of the slab.

View figure in article

Physics Subject Headings (PhySH)

synopsis

Surprising Scattering in Stealthy Structures

Published 7 May, 2026

Experiments shed light on the uncertain optical response of so-called stealthy hyperuniform materials.

See more in Physics

Popular Summary

Disorder has long shaped our understanding of wave transport in solid-state systems, but it is typically modeled as an uncorrelated spatial variation where each point acts independently. Here, we experimentally probe strongly correlated stealthy-hyperuniform disorder by measuring the scattering losses in extremely large two-dimensional silicon photonic crystal slabs. Although this type of disorder suppresses density fluctuations on long length scales and is expected to be largely transparent for a corresponding range of wavelengths, we observe residual single scattering in the stealthy regime. We demonstrate that this unexpected scattering arises from an intrinsically non-Hermitian effect where propagating light acquires a complex effective mass due to radiative loss out of the slab. We anticipate that exploring these strongly spatially correlated disorder phenomena can ultimately inform wave-transport applications across electronic, acoustic, and hybrid wave platforms.

Article Text

References (44)

  1. S. Torquato and F. H. Stillinger, Local density fluctuations, hyperuniformity, and order metrics, Phys. Rev. E 68, 041113 (2003).
  2. S. Torquato, Hyperuniform states of matter, Phys. Rep. 745, 1 (2018).
  3. O. Leseur, R. Pierrat, and R. Carminati, High-density hyperuniform materials can be transparent, Optica 3, 763 (2016).
  4. É. Chéron et al., Wave transport in stealth hyperuniform materials: The diffusive regime and beyond, Appl. Phys. Lett. 121 (2022).
  5. J. Kim and S. Torquato, Theoretical prediction of the effective dynamic dielectric constant of disordered hyperuniform anisotropic composites beyond the long-wavelength regime, Opt. Mater. Express 14, 194 (2023).
  6. J. Kim and S. Torquato, Effective electromagnetic wave properties of disordered stealthy hyperuniform layered media beyond the quasistatic regime, Optica 10, 965 (2023).
  7. M. Florescu, S. Torquato, and P. J. Steinhardt, Designer disordered materials with large, complete photonic band gaps, Proc. Natl. Acad. Sci. U.S.A. 106, 20658 (2009).
  8. W. Man et al., Isotropic band gaps and freeform waveguides observed in hyperuniform disordered photonic solids, Proc. Natl. Acad. Sci. U.S.A. 110, 15886 (2013).
  9. N. Muller et al., Silicon hyperuniform disordered photonic materials with a pronounced gap in the shortwave infrared, Adv. Opt. Mater. 2, 115 (2013).
  10. L. S. Froufe-Pérez, M. Engel, P. F. Damasceno, N. Muller, J. Haberko, S. C. Glotzer, and F. Scheffold, Role of short-range order and hyperuniformity in the formation of band gaps in disordered photonic materials, Phys. Rev. Lett. 117, 053902 (2016).
  11. G. Gkantzounis, T. Amoah, and M. Florescu, Hyperuniform disordered phononic structures, Phys. Rev. B 95, 094120 (2017).
  12. G. J. Aubry, L. S. FroufePerez, U. Kuhl, O. Legrand, F. Scheffold, and F. Mortessagne, Experimental tuning of transport regimes in hyperuniform disordered photonic materials, Phys. Rev. Lett. 125, 127402 (2020).
  13. M. A. Klatt et al., Wave propagation and band tails of two-dimensional disordered systems in the thermodynamic limit, Proc. Natl. Acad. Sci. U.S.A. 119, e2213633119 (2022).
  14. K. Vynck, R. Pierrat, R. Carminati, L. S. FroufePerez, F. Scheffold, R. Sapienza, S. Vignolini, and J. J. Saenz, Light in correlated disordered media, Rev. Mod. Phys. 95, 045003 (2023).
  15. L. Siedentop et al., Stealthy and hyperuniform isotropic photonic band gap structure in 3D, PNAS Nexus 3, 383 (2024).
  16. M. Casiulis, A. Shih, and S. Martiniani, Gyromorphs: A new class of functional disordered materials, Phys. Rev. Lett. 135, 196101 (2025).
  17. N. Granchi et al., Near-field investigation of luminescent hyperuniform disordered materials, Adv. Opt. Mater. 10, 2102565 (2022).
  18. L. S. Froufe-Pérez et al., Band gap formation and Anderson localization in disordered photonic materials with structural correlations, Proc. Natl. Acad. Sci. U.S.A. 114, 9570 (2017).
  19. A. Dikopoltsev et al., Observation of Anderson localization beyond the spectrum of the disorder, Sci. Adv. 8, eabn7769 (2022).
  20. R. Monsarrat, R. Pierrat, A. Tourin, and A. Goetschy, Pseudogap and Anderson localization of light in correlated disordered media, Phys. Rev. Res. 4, 033246 (2022).
  21. M. A. Klatt et al., Transparency versus Anderson localization in one-dimensional disordered stealthy hyperuniform layered media, arXiv:2507.22377.
  22. C. Vanoni et al., Effective delocalization in the one-dimensional Anderson model with stealthy disorder, arXiv:2509.13502.
  23. F. Sgrignuoli, S. Torquato, and L. Dal Negro, Subdiffusive wave transport and weak localization transition in three-dimensional stealthy hyperuniform disordered systems, Phys. Rev. B 105, 064204 (2022).
  24. J. F. Karcher, S. Gopalakrishnan, and M. C. Rechtsman, Effect of hyperuniform disorder on band gaps, Phys. Rev. B 110, 174205 (2024).
  25. A. F. Koenderink, A. Lagendijk, and W. L. Vos, Optical extinction due to intrinsic structural variations of photonic crystals, Phys. Rev. B 72, 153102 (2005).
  26. P. D. García, R. Sapienza, C. Toninelli, C. Lopez, and D. S. Wiersma, Photonic crystals with controlled disorder, Phys. Rev. A 84, 023813 (2011).
  27. S. Takeda et al., Order to disorder optical phase transition in random photonic crystals, Appl. Phys. B 106, 95 (2012).
  28. J. M. Escalante and S. E. Skipetrov, Level spacing statistics for light in two-dimensional disordered photonic crystals, Sci. Rep. 8, 11569 (2018).
  29. S. Aeby et al., Scattering from controlled defects in woodpile photonic crystals, Adv. Opt. Mater. 9, 2001699 (2021).
  30. R. D. Batten, F. H. Stillinger, and S. Torquato, Classical disordered ground states, J. Appl. Phys. 104 (2008).
  31. S. Fan and J. D. Joannopoulos, Analysis of guided resonances in photonic crystal slabs, Phys. Rev. B 65, 235112 (2002).
  32. B. Zhen et al., Spawning rings of exceptional points out of Dirac cones, Nature (London) 525, 354 (2015).
  33. P. Lalanne et al., Light interaction with photonic and plasmonic resonances, Laser Photonics Rev. 12, 1700113 (2018).
  34. M. Minkov et al., Inverse design of photonic crystals through automatic differentiation, ACS Photonics 7, 1729 (2020).
  35. L. C. Andreani and D. Gerace, Photonic-crystal slabs investigated using a guided-mode expansion method, Phys. Rev. B 73, 235114 (2006).
  36. C. W. Hsu et al., Bound states in the continuum, Nat. Rev. Mater. 1, 1 (2016).
  37. K. Koshelev, S. Lepeshov, M. Liu, A. Bogdanov, and Y. Kivshar, Asymmetric metasurfaces with high-Q resonances governed by bound states in the continuum, Phys. Rev. Lett. 121, 193903 (2018).
  38. P. K. Morse, J. Kim, P. J. Steinhardt, and S. Torquato, Generating large disordered stealthy hyperuniform systems with ultrahigh accuracy, Phys. Rev. Res. 5, 033190 (2023).
  39. H. A. Makse, S. Havlin, M. Schwartz, and H. E. Stanley, Method for generating long-range correlations for large systems, Phys. Rev. E 53, 5445 (1996).
  40. Z. Zhang et al., Airy resonances in photonic crystal superpotentials, arXiv:2510.07522.
  41. M. Barsukova, Z. Zhang, B. Gould, K. Sadri, C. A. Rosiek, S. Stobbe, J. Karcher, M. Rechtsman (2026), Experimental data in stealthy-hyperuniform wave dynamics in two-dimensional photonic crystals [Data set]. Scholarsphere, 10.26207/6tq5-qz28.
  42. J. D. Joannopoulos et al., Photonic Crystals: Molding the Flow of Light, 2nd ed. (Princeton University Press, Princeton, NJ, 2008).
  43. P. A. Lee and T. V. Ramakrishnan, Disordered electronic systems, Rev. Mod. Phys. 57, 287 (1985).
  44. A. Luce et al., TMM-fast, a transfer matrix computation package for multilayer thin-film optimization, J. Opt. Soc. Am. A 39, 1007 (2022).

Outline

Information

Phys. Rev. X 16, 021028– Published 7 May, 2026
  • Received 22 August 2025
  • Accepted 13 March 2026
