Modeling bulk mechanical effects in a planar cellular monolayer

Natasha Cowley*

Sarah Woolner†

Oliver E. Jensen‡

  • Division of Cell Matrix Biology & Regenerative Medicine, University of Manchester, Oxford Road, Manchester M13 9PT, United Kingdom

  • *Contact author: Natasha.Cowley@manchester.ac.uk
  • †Contact author: Sarah.Woolner@manchester.ac.uk
  • ‡Contact author: Oliver.Jensen@manchester.ac.uk
PDF

Phys. Rev. E 112, 054401 – Published 3 November, 2025

DOI: https://doi.org/10.1103/5l56-wc8f

Abstract

We use a three-dimensional formulation of the cell vertex model to describe the mechanical properties of a confluent planar monolayer of prismatic cells. Treating cell height as a degree of freedom, we reduce the model to a two-dimensional form. We show how bulk effects, associated with cell volume and total surface area, lead to coupling between energy variations arising from changes in the cell apical area and the apical perimeter, a feature missing from standard implementations of the two-dimensional vertex model. The model identifies five independent mechanisms by which cells can lose in-plane rigidity, relating to variations in total cell surface area, the strength of lateral adhesion, and constrictive forces at the apical cortex. The model distinguishes bulk from in-plane stresses, and it identifies two primary measures of cell shear stress. In the rigid regime, the model shows how lateral crowding in a disordered isolated monolayer can lead to cell elongation towards the monolayer center. We examine the loss of in-plane rigidity in a disordered monolayer and connect isolated patches of stiffness that persist during the rigidity transition to the spectrum of a Laplacian matrix. This approach enables bulk mechanical effects in an epithelium to be captured within a two-dimensional framework.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (45)

  1. R. Farhadifar, J.-C. Röper, B. Aigouy, S. Eaton, and F. Jülicher, The influence of cell mechanics, cell-cell interactions, and proliferation on epithelial packing, Curr. Biol. 17, 2095 (2007).
  2. P. Gómez-Gálvez, P. Vicente-Munuera, S. Anbari, J. Buceta, and L. M. Escudero, The complex three-dimensional organization of epithelial tissues, Development 148, dev195669 (2021).
  3. T. Sego, T. Comlekoglu, S. M. Peirce, D. W. Desimone, and J. A. Glazier, General, open-source vertex modeling in biological applications using tissue forge, Sci. Rep. 13, 17886 (2023).
  4. S. Runser, R. Vetter, and D. Iber, SimuCell3D: 3D simulation of tissue mechanics with cell polarization, Nat. Comput. Sci. 4, 299 (2024).
  5. H. Honda, M. Tanemura, and T. Nagai, A three-dimensional vertex dynamics cell model of space-filling polyhedra simulating cell behavior in a cell aggregate, J. Theor. Biol. 226, 439 (2004).
  6. S. Okuda, Y. Inoue, M. Eiraku, Y. Sasai, and T. Adachi, Reversible network reconnection model for simulating large deformation in dynamic tissue morphogenesis, Biomech. Model. Mechanobiol. 12, 627 (2013).
  7. O. M. Drozdowski and U. S. Schwarz, Morphological instability at topological defects in a three-dimensional vertex model for spherical epithelia, Phys. Rev. Res. 6, L022045 (2024).
  8. E. Hannezo, J. Prost, and J.-F. Joanny, Theory of epithelial sheet morphology in three dimensions, Proc. Natl. Acad. Sci. USA 111, 27 (2014).
  9. P. Sahu, J. Schwarz, and M. L. Manning, Geometric signatures of tissue surface tension in a three-dimensional model of confluent tissue, New J. Phys. 23, 093043 (2021).
  10. C. Villeneuve, A. Hashmi, I. Ylivinkka, E. Lawson-Keister, Y. A. Miroshnikova, C. Pérez-González, S.-M. Myllymäki, F. Bertillot, B. Yadav, T. Zhang et al., Mechanical forces across compartments coordinate cell shape and fate transitions to generate tissue architecture, Nat. Cell Biol. 26, 207 (2024).
  11. M. Merkel and M. L. Manning, A geometrically controlled rigidity transition in a model for confluent 3D tissues, New J. Phys. 20, 022002 (2018).
  12. F. Ioannou, M. A. Dawi, R. J. Tetley, Y. Mao, and J. J. Muñoz, Development of a new 3D hybrid model for epithelia morphogenesis, Front. Bioeng. Biotechnol. 8, 405 (2020).
  13. A. K. Khan, G. Muñoz-Castro, and J. J. Muñoz, Single and two-cells shape analysis from energy functionals for three-dimensional vertex models, Int. J. Num. Meth. Biomed. Eng. 39, e3766 (2023).
  14. C. H. Durney and J. J. Feng, A three-dimensional vertex model for drosophila salivary gland invagination, Phys. Biol. 18, 046005 (2021).
  15. X. Du, M. Osterfield, and S. Y. Shvartsman, Computational analysis of three-dimensional epithelial morphogenesis using vertex models, Phys. Biol. 11, 066007 (2014).
  16. N. Noll, S. J. Streichan, and B. I. Shraiman, Variational method for image-based inference of internal stress in epithelial tissues, Phys. Rev. X 10, 011072 (2020).
  17. G. Ogita, T. Kondo, K. Ikawa, T. Uemura, S. Ishihara, and K. Sugimura, Image-based parameter inference for epithelial mechanics, PLoS Comput. Biol. 18, e1010209 (2022).
  18. D. Bi, J. Lopez, J. Schwarz, and M. Manning, A density-independent rigidity transition in biological tissues, Nat. Phys. 11, 1074 (2015).
  19. T. Zhang and J. M. Schwarz, Topologically-protected interior for three-dimensional confluent cellular collectives, Phys. Rev. Res. 4, 043148 (2022).
  20. K. Kim, T. Zhang, and J. Schwarz, Mean-field elastic moduli of a three-dimensional, cell-based vertex model, New J. Phys. 26, 043009 (2024).
  21. Y. Mao and B. Baum, Tug of war—the influence of opposing physical forces on epithelial cell morphology, Dev. Biol. 401, 92 (2015).
  22. T. Kondo and S. Hayashi, Mechanisms of cell height changes that mediate epithelial invagination, Dev. Growth Differ. 57, 313 (2015).
  23. J. M. Gomez, Y. Wang, and V. Riechmann, Tao controls epithelial morphogenesis by promoting fasciclin 2 endocytosis, J. Cell Biol. 199, 1131 (2012).
  24. R. P. Ray, P. S. Ganguly, S. Alt, J. R. Davis, A. Hoppe, N. Tapon, G. Salbreux, and B. J. Thompson, Apical and basal matrix remodeling control epithelial morphogenesis, Dev. Cell 46, 23 (2018).
  25. P. Khandelwal, S. N. Abraham, and G. Apodaca, Cell biology and physiology of the uroepithelium, Am. J. Phys. - Renal Phys. 297, F1477 (2009).
  26. S. Harmansa and T. Lecuit, Mechanical regulation of cuboidal-to-squamous epithelial transition in the Drosophila developing wing, bioRxiv 2024.09.21.614249 (2024), doi: https://doi.org/10.1101/2024.09.21.614249.
  27. S. J. Chisolm, E. Guo, V. Subramaniam, K. D. Schulze, and T. E. Angelini, Elastic modulus versus cell packing density in mdck epithelial monolayers, J. Biomech. 184 112648 (2025).
  28. V. Barone, A. Tagua, J. Á. Román, A. Hamdoun, J. Garrido-García, D. C. Lyons, and L. M. Escudero, Local and global changes in cell density induce reorganisation of 3d packing in a proliferating epithelium, Development 151, dev202362 (2024).
  29. P. Gómez-Gálvez, P. Vicente-Munuera, A. Tagua, C. Forja, A. M. Castro, M. Letrán, A. Valencia-Expósito, C. Grima, M. Bermúdez-Gallardo, Ó. Serrano-Pérez-Higueras et al., Scutoids are a geometrical solution to three-dimensional packing of epithelia, Nat. Commun. 9, 1 (2018).
  30. J. Rozman, M. Krajnc, and P. Ziherl, Basolateral mechanics prevents rigidity transition in epithelial monolayers, Phys. Rev. Lett. 133, 168401 (2024).
  31. T. Sarkar and M. Krajnc, Reentrant rigidity transition in planar epithelia with volume-and area elasticity, arXiv:2505.12558.
  32. M. De Marzio, A. Das, J. J. Fredberg, and D. Bi, Epithelial layer fluidization by curvature-induced unjamming, Phys. Rev. Lett. 134, 138402 (2025).
  33. N. Harmand, A. Huang, and S. Hénon, 3d shape of epithelial cells on curved substrates, Phys. Rev. X 11, 031028 (2021).
  34. M. Chiang, A. Hopkins, B. Loewe, D. Marenduzzo, and M. C. Marchetti, Multiphase field model of cells on a substrate: From three dimensional to two dimensional, Phys. Rev. E 110, 044403 (2024).
  35. N. Cowley, C. K. Revell, E. Johns, S. Woolner, and O. E. Jensen, Spectral approaches to stress relaxation in epithelial monolayers, Proc. R. Soc. A 480, 20240224 (2024).
  36. C. K. Revell and O. E. Jensen, VertexModel.Jl, https://github.com/chris-revell/VertexModel (2022).
  37. J. Kursawe, R. E. Baker, and A. G. Fletcher, Impact of implementation choices on quantitative predictions of cell-based computational models, J. Comput. Phys. 345, 752 (2017).
  38. A. Nestor-Bergmann, G. Goddard, S. Woolner, and O. E. Jensen, Relating cell shape and mechanical stress in a spatially disordered epithelium using a vertex-based model, Math. Med. Biol. 35, i1 (2018).
  39. O. E. Jensen, E. Johns, and S. Woolner, Force networks, torque balance and airy stress in the planar vertex model of a confluent epithelium, Proc. R. Soc. A 476, 20190716 (2020).
  40. O. K. Damavandi, V. F. Hagh, C. D. Santangelo, and M. L. Manning, Energetic rigidity. I. A unifying theory of mechanical stability, Phys. Rev. E 105, 025003 (2022).
  41. O. K. Damavandi, V. F. Hagh, C. D. Santangelo, and M. L. Manning, Energetic rigidity. II. Applications in examples of biological and underconstrained materials, Phys. Rev. E 105, 025004 (2022).
  42. S. Tong, R. Sknepnek, and A. Košmrlj, Linear viscoelastic response of the vertex model with internal and external dissipation: Normal modes analysis, Phys. Rev. Res. 5, 013143 (2023).
  43. N. Cowley, https://github.com/chris-revell/VertexModel/tree/pseudo2Dmodel (2025).
  44. O. E. Jensen and C. K. Revell, Couple stresses and discrete potentials in the vertex model of cellular monolayers, Biomech. Model. Mechanobiol. 22, 1465 (2023).
  45. A. Nestor-Bergmann, E. Johns, S. Woolner, and O. E. Jensen, Mechanical characterization of disordered and anisotropic cellular monolayers, Phys. Rev. E 97, 052409 (2018).
