Orientation-Dependent Structural Phase Transitions and Melting in Shock-Compressed MgO

Raymond F. Smith1, Saransh Singh1, Zixuan Ye2, Marius Millot1, Melissa Sims2,*, Anirudh Hari2,3,†, Jon H. Eggert1, Federica Coppari1, and June K. Wicks2

  • *Present address: Department of Physics, University of Alabama, Birmingham, Alabama 35294, USA.
  • †Present address: Stanford University, Department of Materials Science and Engineering, and PULSE Institute, California 94305, USA.
PDF

Phys. Rev. X 16, 041019 – Published 19 October, 2026

DOI: https://doi.org/10.1103/vt45-32bb

Abstract

Magnesium oxide (MgO) is a prototypical strongly bonded ionic solid and an expected major constituent of rocky planet mantles and gas giant cores, yet its high-pressure phase diagram and shock response remain incompletely understood. Here we combine laser-driven decaying-shock and steady-shock compression with nanosecond x-ray diffraction, velocimetry, and optical pyrometry to investigate phase transitions in single-crystal MgO compressed to 600 GPa and 13 000 K. We observe a pronounced crystallographic orientation dependence in the B1→B2 transformation pathway and subsequent melting behavior. For compression along [111], the shock-temperature evolution exhibits distinct plateaus consistent with equilibrium B1→B2→liquid transitions. In contrast, compression along [110] produces a single temperature discontinuity and diffraction signatures indicative of B2 nucleation from a transient disordered layer at the shock front. The combined thermodynamic and structural data indicate that near-instantaneous disordering can mediate stress relaxation under rapid uniaxial compression. Above 572±24  GPa, all orientations converge to complete melting at 13 200±600  K, constraining the B2-liquid boundary at multimegabar pressures and identifying MgO as the highest-temperature solid measured at planetary interior conditions. These results demonstrate that crystallographic orientation governs phase-transition pathways in strongly compressed ionic solids and provide a benchmark for modeling matter under extreme planetary interior conditions.

View figure in article

Physics Subject Headings (PhySH)

Popular Summary

Materials squeezed to extreme pressures and temperatures can change their internal structure in surprising ways, which is important for the behavior of matter inside planets and testing fundamental condensed-matter theories. We investigated MgO, a major building block of rocky planet mantles, subjected to rapid, direction compression. We compressed tiny single crystals of MgO to extreme conditions using shock waves while simultaneously collecting ultrafast x-ray diffraction and optical measurements to track the crystal structure and temperature. The crystal’s orientation impacts the outcome in that MgO transforms with near-equilibrium behavior in one direction but has an 80 GPa delay when compressed in other directions. All orientations converge to complete melting at 572 GPa and 13 200 K, the highest experimentally measured melting temperature of any material. We resolved long-standing discrepancies in the MgO phase diagram and demonstrated the crystal compression direction can control how it transforms. This provides an experimental framework for understanding nonequilibrium phase transitions and improves planetary modeling constraints.

Article Text

Supplemental Material

References (86)

  1. J. K. Wicks, S. Singh, M. Millot, D. E. Fratanduono, F. Coppari, M. Gorman, Z. Ye, J. R. Rygg, A. Hari, J. H. Eggert, T. S. Duffy, and R. F. Smith, B1-B2 transition in shock-compressed MgO, Sci. Adv. 10, eadk0306 (2024).
  2. S. Mazevet, R. Musella, and F. Guyot, The fate of planetary cores in giant and ice-giant planets, Astron. Astrophys. 631, L4 (2019).
  3. T. Irifune and T. Tsuchiya, Phase Transitions and Mineralogy of the Lower Mantle, in Treatise on Geophysics (Second Edition) (Elsevier, New York, 2015).
  4. F. Coppari, R. Smith, J. Wang, M. Millot, D. Kim, J. Rygg, S. Hamel, J. Eggert, and T. Duffy, Implications of the iron oxide phase transition on the interiors of rocky exoplanets, Nat. Geosci. 14, 121 (2021).
  5. S. Ichiro Karato, Rheological structure of the mantle of a super-Earth: Some insights from mineral physics, Icarus 212, 14 (2011).
  6. S. Ritterbex, T. Harada, and T. Tsuchiya, Vacancies in MgO at ultrahigh pressure: About mantle rheology of super-Earths, Icarus 305, 350 (2018).
  7. R. S. McWilliams, D. K. Spaulding, J. H. Eggert, P. M. Celliers, D. G. Hicks, R. F. Smith, G. W. Collins, and R. Jeanloz, Phase transformations and metallization of magnesium oxide at high pressure and temperature, Science 338, 1330 (2012).
  8. J. Badro, J. Siebert, and F. Nimmo, An early geodynamo driven by exsolution of mantle components from Earth’s core, Nature (London) 536, 326 (2016).
  9. J. G. O’Rourke and D. J. Stevenson, Powering Earth’s dynamo with magnesium precipitation from the core, Nature (London) 529, 387 (2016).
  10. Y. Zhao and D. Ni, Understanding the interior structure of gaseous giant exoplanets with machine learning techniques, Astron. Astrophys. 658, A201 (2022).
  11. Y. B. Zeldovich and Y. P. Raizer, Physics of Shock Waves and High-Temperature Hydrodynamic Phenomena (Courier Corporation, New York, 2002).
  12. V. I. Levitas and R. Ravelo, Virtual melting as a new mechanism of stress relaxation under high strain rate loading, Proc. Natl. Acad. Sci. U.S.A. 109, 13204 (2012).
  13. S. Singh, M. G. Gorman, P. G. Heighway, J. V. Bernier, D. McGonegle, H. J. Lee, B. Nagler, J. H. Eggert, and R. F. Smith, Unexpected observation of disorder and multiple phase-transition pathways in shock-compressed Zr, Phys. Rev. Lett. 133, 096101 (2024).
  14. P. G. Heighway, S. Singh, M. G. Gorman, D. McGonegle, J. H. Eggert, and R. F. Smith, Diffuse scattering from dynamically compressed single-crystal zirconium following the pressure-induced α→ω phase transition, Phys. Rev. B 110, 054113 (2024).
  15. M. M. Budzevich, V. V. Zhakhovsky, C. T. White, and I. I. Oleynik, Evolution of shock-induced orientation-dependent metastable states in crystalline aluminum, Phys. Rev. Lett. 109, 125505 (2012).
  16. Y. Shen, S. B. Jester, T. Qi, and E. J. Reed, Nanosecond homogeneous nucleation and crystal growth in shock-compressed SiO2, Nat. Mater. 15, 60 (2016).
  17. Z. Ye, R. F. Smith, M. Millot, M. Sims, D. Tsapetis, M. D. Shields, S. Singh, A. Hari, and J. K. Wicks, Shock equation of state experiments in MgO up to 1.5 TPa and the effects of optical depth on temperature determination, J. Appl. Phys. 136, 105904 (2024).
  18. R. M. Bolis, G. Morard, T. Vinci, A. Ravasio, E. Bambrink, M. Guarguaglini, M. Koenig, R. Musella, F. Remus, J. Bouchet, N. Ozaki, K. Miyanishi, T. Sekine, Y. Sakawa, T. Sano, R. Kodama, F. Guyot, and A. Benuzzi-Mounaix, Decaying shock studies of phase transitions in MgO−SiO2 systems: Implications for the super-Earths’ interiors, Geophys. Res. Lett. 43, 9475 (2016).
  19. S. Root, L. Shulenburger, R. W. Lemke, D. H. Dolan, T. R. Mattsson, and M. P. Desjarlais, Shock response and phase transitions of MgO at planetary impact conditions, Phys. Rev. Lett. 115, 1 (2015).
  20. F. Soubiran and B. Militzer, Anharmonicity and phase diagram of magnesium oxide in the megabar regime, Phys. Rev. Lett. 125, 1 (2020).
  21. S. Zhang, R. Paul, S. Hu, and M. A. Morales, Toward an accurate equation of state and B1-B2 phase boundary for magnesium oxide up to terapascal pressures and electron-volt temperatures, Phys. Rev. B 107, 224109 (2023).
  22. J. Bouchet, F. Bottin, V. Recoules, F. Remus, G. Morard, R. M. Bolis, and A. Benuzzi-Mounaix, Ab initio calculations of the B1-B2 phase transition in MgO, Phys. Rev. B 99, 1 (2019).
  23. P. M. Celliers and M. Millot, Imaging velocity interferometer system for any reflector (visar) diagnostics for high energy density sciences, Rev. Sci. Instrum. 94, 011101 (2023).
  24. M. C. Gregor, R. Boni, A. Sorce, J. Kendrick, C. A. McCoy, D. N. Polsin, T. R. Boehly, P. M. Celliers, G. W. Collins, D. E. Fratanduono, J. H. Eggert, and M. Millot, Absolute calibration of the OMEGA streaked optical pyrometer for temperature measurements of compressed materials, Rev. Sci. Instrum. 87, 114903 (2016).
  25. See Supplemental Material at http://link.aps.org/supplemental/10.1103/vt45-32bb for additional details of the experimental configuration, data analysis, and uncertainty calculations, which includes Refs. [26–49].
  26. D. J. Erskine, J. Eggert, P. Celliers, and D. Hicks, Ghost fringe removal techniques using lissajous data presentation, Rev. Sci. Instrum. 87, 033106 (2016).
  27. M. G. Gorman, S. J. Ali, P. M. Celliers, J. L. Peebles, D. J. Erskine, J. M. McNaney, J. H. Eggert, and R. F. Smith, Measurement of shock roughness due to phase plate speckle imprinting relevant for x-ray diffraction experiments on 3rd and 4th generation light sources, J. Appl. Phys. 132 (2022).
  28. D. E. Fratanduono, T. R. Boehly, P. M. Celliers, M. A. Barrios, J. H. Eggert, R. F. Smith, D. G. Hicks, G. W. Collins, and D. D. Meyerhofer, The direct measurement of ablation pressure driven by 351-nm laser radiation, J. Appl. Phys. 110, 073110 (2011).
  29. L. Hansen, D. Fratanduono, S. Zhang, D. Hicks, T. Suer, Z. Sprowal, M. Hu!, X. Gong, B. Henderson, B. Polsin et al., Melting of magnesium oxide up to two terapascals using double-shock compression, Phys. Rev. B 104, 014106 (2021).
  30. M. Millot, Identifying and discriminating phase transitions along decaying shocks with line imaging doppler interferometric velocimetry and streaked optical pyrometry, Phys. Plasmas 23, 014503 (2016).
  31. S. Brygoo, M. Millot, P. Loubeyre, A. E. Lazicki, S. Hamel, T. Qi, P. M. Celliers, F. Coppari, J. H. Eggert, D. E. Fratanduono et al., Analysis of laser shock experiments on precompressed samples using a quartz reference and application to warm dense hydrogen and helium, J. Appl. Phys. 118, 195901 (2015).
  32. J. H. Eggert, D. G. Hicks, P. M. Celliers, D. K. Bradley, R. S. McWilliams, R. Jeanloz, J. E. Miller, T. R. Boehly, and G. W. Collins, Melting temperature of diamond at ultrahigh pressure, Nat. Phys. 6, 40 (2010).
  33. F. Soubiran and B. Militzer, Electrical conductivity and magnetic dynamos in magma oceans of Super-Earths, Nat. Commun. 9, (2018).
  34. J. T. Larsen and S. M. Lane, HYADES—A plasma hydrodynamics code for dense plasma studies, J. Quant. Spectrosc. Radiat. Transfer 51, 179 (1994).
  35. Z. Ye, Investigations of magnesium oxide under extreme pressure and temperature conditions, Ph.D. thesis, Johns Hopkins University, 2023.
  36. C. A. McCoy, M. C. Marshall, D. N. Polsin, D. E. Fratanduono, P. M. Celliers, D. D. Meyerhofer, and T. R. Boehly, Hugoniot, sound velocity, and shock temperature of MgO to 2300 GPa, Phys. Rev. B 100, 014106 (2019).
  37. M. S. Vassiliou and T. J. Ahrens, Hugoniot equation of state of periclase to 200 GPa, Geophys. Res. Lett. 8, 729 (1981).
  38. M. D. Knudson and M. P. Desjarlais, Adiabatic release measurements in α-quartz between 300 and 1200 GPa: Characterization of α-quartz as a shock standard in the multimegabar regime, Phys. Rev. B 88, 184107 (2013).
  39. L. Schifferle, S. Speziale, and S. S. Lobanov, High-pressure evolution of the refractive index of MgO up to 140 GPa, J. Appl. Phys. 132 (2022).
  40. J. R. Rygg et al., X-ray diffraction at the national ignition facility, Rev. Sci. Instrum. 91, 043902 (2020).
  41. F. Coppari, R. Smith, D. Thorn, J. Rygg, D. Liedahl, R. Kraus, A. Lazicki, M. Millot, and J. Eggert, Optimized x-ray sources for x-ray diffraction measurements at the Omega Laser Facility, Rev. Sci. Instrum. 90, 125113 (2019).
  42. M. Millot, Diamond melting in shock compression experiments at 1 TPa pressures, Nat. Phys. 1 (2026), 10.1038/s41567-026-03413-1.
  43. N. R. Barton, D. E. Boyce, and P. R. Dawson, Pole figure inversion using finite elements over Rodrigues space, Textures Microstruct. 35, 372532 (2002).
  44. J. V. Bernier, M. P. Miller, and D. E. Boyce, A novel optimization-based pole-figure inversion method: comparison with WIMV and maximum entropy methods, J. Appl. Crystallogr. 39, 697 (2006).
  45. S. Singh, D. E. Boyce, J. V. Bernier, and N. R. Barton, Discrete spherical harmonic functions for texture representation and analysis, J. Appl. Crystallogr. 53, 1299 (2020).
  46. S. D. Jacobsen, J. F. Lin, R. J. Angel, G. Shen, V. B. Prakapenka, P. Dera, H.-k. Mao, and R. J. Hemley, X-ray diffraction study of wüstite and magnesiowüstite at lower-mantle pressures, J. Synchrotron Radiat. 12, 577 (2005).
  47. M. Gorman, C. Wu, R. Smith, L. Benedict, C. Prisbrey, W. Schill, S. Bonev, Z. Long, P. Soderlind, D. Braun et al., Ramp compression of tantalum to multiterapascal pressures: Constraints of the thermal equation of state to 2.3 TPa and 5000 K, Phys. Rev. B 107, 014109 (2023).
  48. A. R. Oganov and P. I. Dorogokupets, All-electron and pseudopotential study of MgO: Equation of state, anharmonicity, and stability, Phys. Rev. B 67, 224110 (2003).
  49. Z. Wu, R. M. Wentzcovitch, K. Umemoto, B. Li, K. Hirose, and J.-C. Zheng, Pressure-volume-temperature relations in MgO: An ultrahigh pressure-temperature scale for planetary sciences applications, J. Geophys. Res. 113, B06204 (2008).
  50. J. R. Rygg, J. H. Eggert, A. E. Lazicki, F. Coppari, J. A. Hawreliak, D. G. Hicks, R. F. Smith, C. M. Sorce, T. M. Uphaus, B. Yaakobi, and G. W. Collins, Powder diffraction from solids in the terapascal regime, Rev. Sci. Instrum. 83, 113904 (2012).
  51. S. P. Marsh, LASL Shock Hugoniot Data (Univ of California Press, California, 1980).
  52. K. Miyanishi, Y. Tange, N. Ozaki, T. Kimura, T. Sano, Y. Sakawa, T. Tsuchiya, and R. Kodama, Laser-shock compression of magnesium oxide in the warm-dense-matter regime, Phys. Rev. E 92, 023103 (2015).
  53. T. S. Duffy, R. J. Hemley, and H. K. Mao, Equation of state and shear strength at multimegabar pressures: Magnesium oxide to 227 GPa, Phys. Rev. Lett. 74, 1371 (1995).
  54. D. E. Fratanduono, J. H. Eggert, M. C. Akin, R. Chau, and N. C. Holmes, A novel approach to Hugoniot measurements utilizing transparent crystals, J. Appl. Phys. 114, 043518 (2013).
  55. G. R. Fowles, Shock wave compression of hardened and annealed 2024 aluminum, J. Appl. Phys. 32, 1475 (1961).
  56. R. Hill, The Mathematical Theory of Plasticity (Oxford University Press, New York, 1950).
  57. M. Millot, N. Dubrovinskaia, A. Černok, S. Blaha, L. Dubrovinsky, D. G. Braun, P. M. Celliers, G. W. Collins, J. H. Eggert, and R. Jeanloz, Shock compression of stishovite and melting of silica at planetary interior conditions, Science 347, 418 (2015).
  58. S.-N. Luo and T. J. Ahrens, Shock-induced superheating and melting curves of geophysically important minerals, Phys. Earth Planet. Interiors 143, 369 (2004).
  59. O. Fat’yanov and P. Asimow, Melting of B1-phase MgO from simultaneous true radiative shock temperature and sound speed measurements to 250 GPa on samples preheated to 2300 K, J. Geophys. Res. 129, e2024JB029137 (2024).
  60. A. Boujibar, P. Driscoll, and Y. Fei, Super-Earth internal structures and initial thermal states, J. Geophys. Res. 125, e2019JE006124 (2020).
  61. R. Kraus, F. Coppari, D. Fratanduono, R. Smith, A. Lazicki, C. Wehrenberg, J. Eggert, J. Rygg, and G. Collins, Melting of tantalum at multimegabar pressures on the nanosecond timescale, Phys. Rev. Lett. 126, 255701 (2021).
  62. L. X. Benedict, K. P. Driver, S. Hamel, B. Militzer, T. Qi, A. A. Correa, A. Saul, and E. Schwegler, Multiphase equation of state for carbon addressing high pressures and temperatures, Phys. Rev. B 89, 224109 (2014).
  63. R. G. Kraus, R. J. Hemley, S. J. Ali, J. L. Belof, L. X. Benedict, J. Bernier, D. Braun, R. Cohen, G. W. Collins, F. Coppari et al., Measuring the melting curve of iron at super-Earth core conditions, Science 375, 202 (2022).
  64. Y. Fei, C. T. Seagle, J. P. Townsend, C. A. McCoy, A. Boujibar, P. Driscoll, L. Shulenburger, and M. D. Furnish, Melting and density of MgSiO3 determined by shock compression of bridgmanite to 1254 GPa, Nat. Commun. 12, 876 (2021).
  65. D. Fratanduono, M. Millot, R. Kraus, D. Spaulding, G. Collins, P. Celliers, and J. Eggert, Thermodynamic properties of MgSiO3 at super-Earth mantle conditions, Phys. Rev. B 97, 214105 (2018).
  66. A. B. Belonoshko, S. Arapan, R. Martonak, and A. Rosengren, MgO phase diagram from first principles in a wide pressure-temperature range, Phys. Rev. B 81, 054110 (2010).
  67. M. Buerger, Phase Transformations in Solids (Wiley, New York, 1951), Chap. 6.
  68. H. T. Stokes and D. M. Hatch, Procedure for obtaining microscopic mechanisms of reconstructive phase transitions in crystalline solids, Phys. Rev. B 65, 144114 (2002).
  69. B. Hyde and M. O’Keeffe, Phase Transitions, edited by L. E. Cross (Pergamon Press, Oxford, 1973).
  70. M. Watanabe, M. Tokonami, and N. Morimoto, The transition mechanism between the CsCl-type and NaCl-type structures in CsCl, Acta Crystallogr. A 33, 294 (1977).
  71. G. A. Lyzenga, T. J. Ahrens, and A. C. Mitchell, Shock temperatures of SiO2 and their geophysical implications, J. Geophys. Res. 88, 2431 (1983).
  72. V. I. Levitas, B. F. Henson, L. B. Smilowitz, and B. W. Asay, Solid-solid phase transformation via virtual melting significantly below the melting temperature, Phys. Rev. Lett. 92, 235702 (2004).
  73. T. Liu, L. Chen, W. Li, Z. Liu, J. Zhang, X. Zhang, X. Zhang, S. Zhu, and X. Hou, Orientation-dependent phase transition pathways of single-crystal nickel over large shock range, Int. J. Mech. Sci. 261, 108689 (2024).
  74. Q. An, S.-N. Luo, L.-B. Han, L. Zheng, and O. Tschauner, Melting of Cu under hydrostatic and shock wave loading to high pressures, J. Phys. Condens. Matter 20, 095220 (2008).
  75. R. Ravelo, B. L. Holian, T. C. Germann, and P. Lomdahl, Directional-dependence in shock-induced melting of fcc metals, AIP Conf. Proc. 845, 270 (2006).
  76. M. Yang and H. Sun, Early melting of tantalum carbide under anisotropic stresses: An ab initio molecular dynamics study, Phys. Rev. B 107, 104101 (2023).
  77. K. G. Holland and T. J. Ahrens, Melting of (Mg,Fe)2SiO4 at the core-mantle boundary of the earth, Science 275, 1623 (1997).
  78. D. G. Hicks, T. R. Boehly, J. H. Eggert, J. E. Miller, P. M. Celliers, and G. W. Collins, Dissociation of liquid silica at high pressures and temperatures, Phys. Rev. Lett. 97, 025502 (2006).
  79. K. Umemoto, R. M. Wentzcovitch, and P. B. Allen, Dissociation of MgSiO3 in the cores of gas giants and terrestrial exoplanets, Science 311, 983 (2006).
  80. K. Umemoto, R. M. Wentzcovitch, S. Wu, M. Ji, C.-Z. Wang, and K.-M. Ho, Phase transitions in MgSiO3 post-perovskite in super-earth mantles, Earth Planet. Sci. Lett. 478, 40 (2017).
  81. B. Boates and S. A. Bonev, Demixing instability in dense molten MgSiO3 and the phase diagram of MgO, Phys. Rev. Lett. 110, 135504 (2013).
  82. H. F. Wilson and B. Militzer, Rocky core solubility in Jupiter and giant exoplanets, Phys. Rev. Lett. 108, 111101 (2012).
  83. B. Militzer and W. B. Hubbard, Ab initio equation of state for hydrogen–helium mixtures with recalibration of the giant-planet mass–radius relation, Astrophys. J. 774, 148 (2013).
  84. D. Cebulla and R. Redmer, Ab initio simulations of MgO under extreme conditions, Phys. Rev. B 89, 1 (2014).
  85. H. Abu-Farsakh, I. Al-Qasir, and A. Qteish, Fundamental properties and phase stability of B1 and B2 phases of MgO over a wide range of pressures and temperatures: A first-principles study, Comput. Mater. Sci. 154, 159 (2018).
  86. A. R. Oganov, M. J. Gillan, and G. D. Price, Ab initio lattice dynamics and structural stability of MgO, J. Chem. Phys. 118, 10174 (2003).
