Ballistic Spin Valve in Graphene Realized via Electron Optics

Daniel Burrow1, Oktay Deveci1, Rares Dragomir1, Thomas Thomson2, and Ivan J. Vera-Marun1,*

  • 1Department of Physics and Astronomy, University of Manchester, Manchester M13 9PL, United Kingdom
  • 2Nano-Engineering and Spintronic Technologies (NEST), Department of Computer Science, University of Manchester, Manchester M13 9PL, United Kingdom

  • *Contact author: ivan.veramarun@manchester.ac.uk
PDF

Phys. Rev. X 16, 021029 – Published 7 May, 2026

DOI: https://doi.org/10.1103/nz6m-kb4l

Abstract

Graphene is an ideal platform for supporting ballistic, spin-coherent transport—crucial ingredients for spin-based quantum technologies. Here, we demonstrate a spin-dependent electron-optic mechanism that enables spin-transistor-like control of spin transport in a graphene spin valve, in the absence of spin-orbit coupling in the transport channel. Using transverse magnetic focusing in a high-mobility graphene device, we couple spin and orbital degrees of freedom through charge transfer doping and proximity exchange at ferromagnetic contacts. This coupling allows for gate-tunable modulation of both the amplitude and polarity of the spin signal, reminiscent of the functionality of a Datta-Das spin field-effect transistor. Measurements confirm that spin-coherent ballistic transport is observable up to room temperature. Our results demonstrate an operational principle for spintronic devices based on spin-dependent electron optics in low spin-orbit coupling materials such as graphene.

View figure in article

Physics Subject Headings (PhySH)

Popular Summary

Realizing practical spin-based transistors requires a material that simultaneously supports long-range ballistic electron transport and coherent spin manipulation, conventionally achieved through tunable spin-orbit coupling, a combination of properties that has proven difficult to achieve in a single system. We address this challenge by developing an ultraclean graphene spin valve encapsulated in hexagonal boron nitride, featuring one-dimensional magnetic contacts for spin injection and detection. Transverse magnetic focusing experiments reveal that ballistic electron transport is fundamentally spin dependent in this architecture and can be continuously manipulated using a back-gate voltage. We find that gate tunability arises from spin-dependent electron optics at the graphene-ferromagnet interfaces, where charge-transfer doping and proximity exchange coupling influence spin-polarized electron transport. These results demonstrate a route toward the realization of two-dimensional spintronic devices without the traditional requirement for strong spin-orbit coupling. Our work establishes a platform for achieving the spin coherence necessary for future quantum technologies and energy-efficient electronics.
