Topological Phase Transitions and Their Thermodynamic Fate in Arbitrary-S Classical Pyrochlore Spin Ice

Sena Watanabe1,*, Yukitoshi Motome1,†, and Haruki Watanabe2,3,4,1,‡

  • *Contact author: watanabe-sena397@g.ecc.u-tokyo.ac.jp
  • †Contact author: motome@ap.t.u-tokyo.ac.jp
  • ‡Contact author: hwatanabe@ust.hk
PDF

Phys. Rev. X 16, 041016 – Published 14 October, 2026

DOI: https://doi.org/10.1103/bkkq-q1v9

Abstract

We develop a self-contained theoretical framework that classifies the topological phases and critical phenomena of classical pyrochlore magnets with arbitrary spin S, subject to competing exchange and single-ion anisotropies. We work first in the monopole-free (ice-rule) limit. In the small-w regime, where the single-ion term favors low spin amplitudes, dualities reveal a dichotomy: Integer spins exhibit a continuous 3D XY deconfinement transition, whereas half-integer spins remain in a U(1) Coulomb liquid without any transition. In the large-w regime, where the local spin amplitudes are maximized (|Sz|=S), the macroscopic flux is quantized to multiples of 2S. By mapping the defect structure to topological loop gases, we prove that the compatibility between the physical ice rule and the modular Z2S flux conservation holds at the vertex level if and only if S≤3/2. For S=3/2, this maps the system to the three-state Potts model, whose symmetry-allowed cubic invariant drives a first-order transition. For S≥2, no mapping to a discrete clock model exists. Using a decomposition of the partition function, we show that the only processes sensitive to the discrete Z2S structure carry exponentially small statistical weight and correspond to irrelevant operators at the 3D XY fixed point, so the deconfinement transition is of the 3D XY type. Finally, incorporating thermal monopoles, we show that they act as a symmetry-breaking effective magnetic field that severs defect strings. Consequently, the continuous transitions are rounded into crossovers, whereas the first-order S=3/2 transition is predicted to survive at finite temperatures, terminating at a critical end point. Classical Monte Carlo simulations for S up to 7/2 corroborate the predicted crossover behavior at the accessible temperatures; these temperatures lie above the estimated critical end point, so the predicted survival of the S=3/2 first-order transition remains to be tested directly.

View figure in article

Physics Subject Headings (PhySH)

Popular Summary

Spin ice magnets famously host particles that behave like magnetic monopoles, but the standard picture treats each moment as a two-way switch pointing into or out of its tetrahedron, leaving open what happens when moments can take intermediate values. We settle this by mapping the problem onto simpler, well-understood statistical models, which lets us classify every phase and transition for any spin size. One value stands out: S=3/2 magnets alone switch abruptly between two distinct liquid states, while all others change smoothly. At any nonzero temperature, thermally created monopoles snip the string-like defects that keep these liquids apart, blurring the smooth transitions into gradual crossovers; the abrupt S=3/2 transition, however, survives and ends at a critical point that requires no magnetic field. Since higher-spin versions of these magnets are now being grown, and artificial arrays can imitate them, our predictions give experimenters specific signatures to hunt for.

Article Text

Supplemental Material

References (74)

  1. L. Balents, Spin liquids in frustrated magnets, Nature (London) 464, 199 (2010).
  2. L. Savary and L. Balents, Quantum spin liquids: A review, Rep. Prog. Phys. 80, 016502 (2017).
  3. J. Knolle and R. Moessner, A field guide to spin liquids, Annu. Rev. Condens. Matter Phys. 10, 451 (2019).
  4. C. Broholm, R. J. Cava, S. A. Kivelson, D. G. Nocera, M. R. Norman, and T. Senthil, Quantum spin liquids, Science 367, eaay0668 (2020).
  5. M. J. Harris, S. T. Bramwell, D. F. McMorrow, T. Zeiske, and K. W. Godfrey, Geometrical frustration in the ferromagnetic pyrochlore Ho2Ti2O7, Phys. Rev. Lett. 79, 2554 (1997).
  6. S. T. Bramwell and M. J. P. Gingras, Spin ice state in frustrated magnetic pyrochlore materials, Science 294, 1495 (2001).
  7. A. P. Ramirez, A. Hayashi, R. J. Cava, R. Siddharthan, and B. S. Shastry, Zero-point entropy in ‘spin ice’, Nature (London) 399, 333 (1999).
  8. C. Castelnovo, R. Moessner, and S. L. Sondhi, Magnetic monopoles in spin ice, Nature (London) 451, 42 (2008).
  9. R. G. Melko, B. C. den Hertog, and M. J. P. Gingras, Long-range order at low temperatures in dipolar spin ice, Phys. Rev. Lett. 87, 067203 (2001).
  10. L. Pauling, The structure and entropy of ice and of other crystals with some randomness of atomic arrangement, J. Am. Chem. Soc. 57, 2680 (1935).
  11. M. Hermele, M. P. A. Fisher, and L. Balents, Pyrochlore photons: The U(1) spin liquid in a S=1/2 three-dimensional frustrated magnet, Phys. Rev. B 69, 064404 (2004).
  12. S. V. Isakov, K. Gregor, R. Moessner, and S. L. Sondhi, Dipolar spin correlations in classical pyrochlore magnets, Phys. Rev. Lett. 93, 167204 (2004).
  13. C. L. Henley, Power-law spin correlations in pyrochlore antiferromagnets, Phys. Rev. B 71, 014424 (2005).
  14. C. L. Henley, The “Coulomb phase” in frustrated systems, Annu. Rev. Condens. Matter Phys. 1, 179 (2010).
  15. T. Fennell, P. P. Deen, A. R. Wildes, K. Schmalzl, D. Prabhakaran, A. T. Boothroyd, R. J. Aldus, D. F. McMorrow, and S. T. Bramwell, Magnetic Coulomb phase in the spin ice Ho2Ti2O7, Science 326, 415 (2009).
  16. J. Pandey and K. Damle, S=1 pyrochlore magnets with competing anisotropies: A tale of two Coulomb phases, Z2 flux confinement and XY-like transitions, arXiv:2512.11623.
  17. S. Kundu and K. Damle, Flux fractionalization transition in anisotropic S=1 antiferromagnets and dimer-loop models, Phys. Rev. X 15, 011018 (2025).
  18. S. Watanabe, Y. Motome, and H. Watanabe, Dualities and topological classification of the S=1 pyrochlore spin ice, arXiv:2603.03852.
  19. J. Pandey, S. Kundu, and K. Damle, Z3 confined and deconfined Coulomb liquids in Seff=3/2 pyrochlore magnets, arXiv:2602.23041.
  20. M. E. Brooks-Bartlett, S. T. Banks, L. D. C. Jaubert, A. Harman-Clarke, and P. C. W. Holdsworth, Magnetic-moment fragmentation and monopole crystallization, Phys. Rev. X 4, 011007 (2014).
  21. S. Petit, E. Lhotel, S. Guitteny, O. Florea, J. Robert, P. Bonville, I. Mirebeau, J. Ollivier, H. Mutka, E. Ressouche, C. Decorse, M. Ciomaga Hatnean, and G. Balakrishnan, Observation of magnetic fragmentation in spin ice, Nat. Phys. 12, 746 (2016).
  22. J. Rehn, A. Sen, and R. Moessner, Fractionalized Z2 classical Heisenberg spin liquids, Phys. Rev. Lett. 118, 047201 (2017).
  23. S. Watanabe, Y. Motome, and H. Watanabe, Continuous crossover between high-pressure ice phases VII and X driven by monopole screening: A model study, Phys. Rev. B 114, 094108 (2026).
  24. L. Berchialla, G. M. Macauley, F. Museur, T. Wang, A. Kleibert, P. M. Derlet, and L. J. Heyderman, Realizing Blume-Capel degrees of freedom with toroidal moments in a ruby artificial spin ice, ACS Nano 20, 3423 (2026).
  25. See Supplemental Material at http://link.aps.org/supplemental/10.1103/bkkq-q1v9 for the phase diagram in the (w,T/J) plane, detailed derivations of the large-w expansions, the clock-model high-temperature expansion, the correspondences to the Potts and XY models, the decomposition framework, and the Bethe-Peierls estimates, which includes Refs. [26–28].
  26. R. Kikuchi, A theory of cooperative phenomena, Phys. Rev. 81, 988 (1951).
  27. J. S. Yedidia, W. T. Freeman, and Y. Weiss, Generalized belief propagation, Advances in Neural Information Processing Systems NIPS 2000 (MIT Press, 2001), pp. 689–695.
  28. S. M. Chester, W. Landry, J. Liu, D. Poland, D. Simmons-Duffin, N. Su, and A. Vichi, Carving out OPE space and precise O(2) model critical exponents, J. High Energy Phys. 06 (2020) 142.
  29. I. A. Ryzhkin, Magnetic relaxation in rare-earth oxide pyrochlores, J. Exp. Theor. Phys. 101, 481 (2005).
  30. M. J. P. Gingras and P. A. McClarty, Quantum spin ice: A search for gapless quantum spin liquids in pyrochlore magnets, Rep. Prog. Phys. 77, 056501 (2014).
  31. M. Blume, Theory of the first-order magnetic phase change in UO2, Phys. Rev. 141, 517 (1966).
  32. H. W. Capel, On the possibility of first-order phase transitions in Ising systems of triplet ions with zero-field splitting, Physica 32, 966 (1966).
  33. C. Castelnovo and C. Chamon, Topological order in a three-dimensional toric code at finite temperature, Phys. Rev. B 78, 155120 (2008).
  34. L. D. C. Jaubert, M. J. Harris, T. Fennell, R. G. Melko, S. T. Bramwell, and P. C. W. Holdsworth, Topological-sector fluctuations and Curie-law crossover in spin ice, Phys. Rev. X 3, 011014 (2013).
  35. D. A. Huse, W. Krauth, R. Moessner, and S. L. Sondhi, Coulomb and liquid dimer models in three dimensions, Phys. Rev. Lett. 91, 167004 (2003).
  36. R. Savit, Duality in field theory and statistical systems, Rev. Mod. Phys. 52, 453 (1980).
  37. J. B. Kogut, An introduction to lattice gauge theory and spin systems, Rev. Mod. Phys. 51, 659 (1979).
  38. J. V. José, L. P. Kadanoff, S. Kirkpatrick, and D. R. Nelson, Renormalization, vortices, and symmetry-breaking perturbations in the two-dimensional planar model, Phys. Rev. B 16, 1217 (1977).
  39. C. Dasgupta and B. I. Halperin, Phase transition in a lattice model of superconductivity, Phys. Rev. Lett. 47, 1556 (1981).
  40. P. M. Chaikin and T. C. Lubensky, Principles of Condensed Matter Physics (Cambridge University Press, Cambridge, England, 1995).
  41. S. Watanabe, Y. Motome, and H. Watanabe, Precision Monte Carlo determination of the critical temperature for the antiferromagnetic XY model on a diamond lattice, J. Phys. Soc. Jpn. 95, 085002 (2026).
  42. A. Nahum, J. T. Chalker, P. Serna, M. Ortuño, and A. M. Somoza, 3D loop models and the CPn−1 sigma model, Phys. Rev. Lett. 107, 110601 (2011).
  43. F. J. Wegner, Duality in generalized Ising models and phase transitions without local order parameters, J. Math. Phys. (N.Y.) 12, 2259 (1971).
  44. E. Fradkin and S. H. Shenker, Phase diagrams of lattice gauge theories with Higgs fields, Phys. Rev. D 19, 3682 (1979).
  45. F. Y. Wu, The Potts model, Rev. Mod. Phys. 54, 235 (1982).
  46. H. W. J. Blöte and R. H. Swendsen, First-order phase transitions and the three-state Potts model, Phys. Rev. Lett. 43, 799 (1979).
  47. R. J. Baxter, Exactly Solved Models in Statistical Mechanics (Academic Press, London, 1982).
  48. M. Hasenbusch, Monte Carlo study of an improved clock model in three dimensions, Phys. Rev. B 100, 224517 (2019).
  49. J. Lou, A. W. Sandvik, and L. Balents, Emergence of U(1) symmetry in the 3D XY model with Zq anisotropy, Phys. Rev. Lett. 99, 207203 (2007).
  50. H. Shao, W. Guo, and A. W. Sandvik, Monte Carlo renormalization flows in the space of relevant and irrelevant operators: Application to three-dimensional clock models, Phys. Rev. Lett. 124, 080602 (2020).
  51. Z. Nussinov and G. Ortiz, Autocorrelations and thermal fragility of anyonic loops in topologically quantum ordered systems, Phys. Rev. B 77, 064302 (2008).
  52. S.-T. Zhou, M. Cheng, T. Rakovszky, C. von Keyserlingk, and T. D. Ellison, Finite-temperature quantum topological order in three dimensions, Phys. Rev. Lett. 135, 040402 (2025).
  53. C. Castelnovo, R. Moessner, and S. L. Sondhi, Debye-Hückel theory for spin ice at low temperature, Phys. Rev. B 84, 144435 (2011).
  54. D. J. P. Morris, D. A. Tennant, S. A. Grigera, B. Klemke, C. Castelnovo, R. Moessner, C. Czarnik, M. Meissner, K. C. Rule, J.-U. Hoffmann, K. Kiefer, S. Gerischer, D. Slobinsky, and R. S. Perry, Dirac strings and magnetic monopoles in the spin ice Dy2Ti2O7, Science 326, 411 (2009).
  55. L. D. C. Jaubert and P. C. W. Holdsworth, Signature of magnetic monopole and Dirac string dynamics in spin ice, Nat. Phys. 5, 258 (2009).
  56. C.-H. Chern and N. Nagaosa, Gauge field and the confinement-deconfinement transition in hydrogen-bonded ferroelectrics, Phys. Rev. Lett. 112, 247602 (2014).
  57. A. M. Polyakov, Quark confinement and topology of gauge theories, Nucl. Phys. B120, 429 (1977).
  58. F. Karsch and S. Stickan, The three-dimensional, three-state Potts model in an external field, Phys. Lett. B 488, 319 (2000).
  59. T. Wada, M. Kitazawa, and K. Kanaya, Locating critical points using ratios of Lee-Yang zeros, Phys. Rev. Lett. 134, 162302 (2025).
  60. V. N. Glazkov, M. E. Zhitomirsky, A. I. Smirnov, H.-A. Krug von Nidda, A. Loidl, C. Marin, and J.-P. Sanchez, Single-ion anisotropy in the gadolinium pyrochlores studied by electron paramagnetic resonance, Phys. Rev. B 72, 020409(R) (2005).
  61. N. A. Bogdanov, R. Maurice, I. Rousochatzakis, J. van den Brink, and L. Hozoi, Magnetic state of pyrochlore Cd2Os2O7 emerging from strong competition of ligand distortions and longer-range crystalline anisotropy, Phys. Rev. Lett. 110, 127206 (2013).
  62. S. Calder, J. G. Vale, N. A. Bogdanov, X. Liu, C. Donnerer, M. H. Upton, D. Casa, A. H. Said, M. D. Lumsden, Z. Zhao, J.-Q. Yan, D. Mandrus, S. Nishimoto, J. van den Brink, J. P. Hill, D. F. McMorrow, and A. D. Christianson, Spin-orbit-driven magnetic structure and excitation in the 5d pyrochlore Cd2Os2O7, Nat. Commun. 7, 11651 (2016).
  63. K. A. Ross, J. M. Brown, R. J. Cava, J. W. Krizan, S. E. Nagler, J. A. Rodriguez-Rivera, and M. B. Stone, Single-ion properties of the Seff=12 XY antiferromagnetic pyrochlores NaA′Co2F7 (A′=Ca2+,Sr2+), Phys. Rev. B 95, 144414 (2017).
  64. J. W. Krizan and R. J. Cava, NaCaNi2F7: A frustrated high-temperature pyrochlore antiferromagnet with S=1  Ni2+, Phys. Rev. B 92, 014406 (2015).
  65. M. B. Sanders, J. W. Krizan, K. W. Plumb, T. M. McQueen, and R. J. Cava, NaSrMn2F7, NaCaFe2F7, and NaSrFe2F7: Novel single crystal pyrochlore antiferromagnets, J. Phys. Condens. Matter 29, 045801 (2017).
  66. D. Reig-i-Plessis and A. M. Hallas, Frustrated magnetism in fluoride and chalcogenide pyrochlore lattice materials, Phys. Rev. Mater. 5, 030301 (2021).
  67. K. W. Plumb, H. J. Changlani, A. Scheie, S. Zhang, J. W. Krizan, J. A. Rodriguez-Rivera, Y. Qiu, B. Winn, R. J. Cava, and C. L. Broholm, Continuum of quantum fluctuations in a three-dimensional S=1 Heisenberg magnet, Nat. Phys. 15, 54 (2019).
  68. A. F. Goncharov, V. V. Struzhkin, M. S. Somayazulu, R. J. Hemley, and H.-k. Mao, Compression of ice to 210 gigapascals: Infrared evidence for a symmetric hydrogen-bonded phase, Science 273, 218 (1996).
  69. A. D. King, C. Nisoli, E. D. Dahl, G. Poulin-Lamarre, and A. Lopez-Bezanilla, Qubit spin ice, Science 373, 576 (2021).
  70. J. Shah, G. Nambiar, A. V. Gorshkov, and V. Galitski, Quantum spin ice in three-dimensional Rydberg atom arrays, Phys. Rev. X 15, 011025 (2025).
  71. A. Kitaev, Anyons in an exactly solved model and beyond, Ann. Phys. (Amsterdam) 321, 2 (2006).
  72. L. Savary and L. Balents, Coulombic quantum liquids in spin-1/2 pyrochlores, Phys. Rev. Lett. 108, 037202 (2012).
  73. N. Shannon, O. Sikora, F. Pollmann, K. Penc, and P. Fulde, Quantum ice: A quantum Monte Carlo study, Phys. Rev. Lett. 108, 067204 (2012).
  74. O. Benton, O. Sikora, and N. Shannon, Classical and quantum theories of proton disorder in hexagonal water ice, Phys. Rev. B 93, 125143 (2016).
