Three-Dimensional Electronic Structures in Superconducting Ruddlesden-Popper Bilayer Nickelate Films

Yueying Li1,2,*, Lizhi Xu1,*, Wei Lv1,*, Zihao Nie1, Zechao Wang1, Yu Miao3, Jianchang Shen3, Guangdi Zhou1,2, Wenhua Song1 et al.

Heng Wang1,2, Haoliang Huang1,2, Junfeng He3, Jin-Feng Jia1,2,4, Peng Li1,2,†, Qi-Kun Xue1,2,5,‡, and Zhuoyu Chen1,2,§

  • *These authors contributed equally to this work.
  • †Contact author: lipeng@quantumsc.cn
  • ‡Contact author: xueqk@sustech.edu.cn
  • §Contact author: chenzhuoyu@sustech.edu.cn
PDF

Phys. Rev. X 16, 031016 – Published 24 July, 2026

DOI: https://doi.org/10.1103/466c-8sl4

Abstract

Beyond the quasi-two-dimensional (2D) paradigm of cuprates, the role of the third dimension of the Ruddlesden-Popper bilayer nickelates is essential to decoding their superconducting mechanism. Here, using angle-resolved photoemission spectroscopy (ARPES) with varied photon energies, we systematically investigate the electronic band structures in three dimensions for superconducting (La,Pr,Sm)3Ni2O7/SrLaAlO4 thin films (superconducting onset temperature Tconset∼48  K) transferred via a cryogenic ultrahigh vacuum (UHV) suitcase. We reveal an orbital-dependent dimensionality: While the dx2−y2-dominant bands exhibit a quasi-2D character, the dz2-dominant band displays a finite kz dispersion. Finite energy gaps are identified on all observed bands across multiple high-symmetry directions. Systematic temperature-dependent analysis characterizes the superconducting nature of the gap on the dz2-derived band, revealing a large gap Δ∼18  meV and a ratio 2Δ/kBTc∼8 exceeding the weak-coupling BCS limit. The suppression of spectral weight near the Fermi level persists above the superconducting transition temperature. Ubiquitous vertical spectral features evidence the presence of electron interactions. These results underscore the role of the dz2 orbital and correlations, placing constraints on theoretical models for nickelate superconductivity.

View figure in article

Physics Subject Headings (PhySH)

Popular Summary

Determining the microscopic mechanism that drives high-temperature superconductivity in Ruddlesden-Popper nickelates is a persistent challenge due to ongoing debates regarding the dimensionality of their electronic states and the precise roles of specific atomic orbitals. We addressed this controversy by using angle-resolved photoemission spectroscopy combined with a cryogenic vacuum sample transfer technique to map the complete three-dimensional electronic structure of superconducting bilayer nickelate thin films. Our measurements explicitly reveal a prominent out-of-plane dispersion for the dz2-derived electronic band, establishing its intrinsic three-dimensional character. We further identified finite, nodeless superconducting gaps across all observed bands, with a large gap ratio that signals a strong-coupling pairing regime possibly driven by electron correlations. Our work establishes an experimental foundation that guides future theoretical and experimental exploration of unconventional superconductivity.

Article Text

Supplemental Material

References (50)

  1. Y. Wang, K. Jiang, J. Ying, T. Wu, J. Cheng, J. Hu, and X. Chen, Recent progress in nickelate superconductors, Natl. Sci. Rev. 12, nwaf373 (2025).
  2. Z. Chen and H. Huang, The nickelate bridge between cuprate and iron-based superconductivity, Quantum Front. 4, 17 (2025).
  3. Y. F. Yang, G.-M. Zhang, and F.-C. Zhang, Interlayer valence bonds and two-component theory for high-Tc superconductivity of La3Ni2O7 under pressure, Phys. Rev. B 108, L201108 (2023).
  4. Y. Gu, C. Le, Z. Yang, X. Wu, and J. Hu, Effective model and pairing tendency in the bilayer Ni-based superconductor La3Ni2O7, Phys. Rev. B 111, 174506 (2025).
  5. Y.-B. Liu, J.-W. Mei, F. Ye, W.-Q. Chen, and F. Yang, s±-wave pairing and the destructive role of apical-oxygen deficiencies in La3Ni2O7 under pressure, Phys. Rev. Lett. 131, 236002 (2023).
  6. C. Yue et al., Correlated electronic structures and unconventional superconductivity in bilayer nickelate heterostructures, Natl. Sci. Rev. 12, nwaf253 (2025).
  7. Z.-Y. Shao, C. Lu, M. Liu, Y.-B. Liu, Z. Pan, C. Wu, and F. Yang, Pairing without γ-pocket in the La3Ni2O7 thin film, arXiv:2507.20287.
  8. K. Ushio, S. Kamiyama, Y. Hoshi, R. Mizuno, M. Ochi, K. Kuroki, and H. Sakakibara, Theoretical study on ambient pressure superconductivity in La3Ni2O7 thin films: Structural analysis, model construction, and robustness of s±-wave pairing, arXiv:2506.20497v3.
  9. H. Sun et al., Signatures of superconductivity near 80 K in a nickelate under high pressure, Nature (London) 621, 493 (2023).
  10. Y. Zhang et al., High-temperature superconductivity with zero resistance and strange-metal behaviour in La3Ni2O7−δ, Nat. Phys. 20, 1269 (2024).
  11. N. Wang et al., Bulk high-temperature superconductivity in pressurized tetragonal La2PrNi2O7, Nature (London) 634, 579 (2024).
  12. Q. Li, Y.-J. Zhang, Z.-N. Xiang, Y. Zhang, X. Zhu, and H.-H. Wen, Signature of superconductivity in pressurized La4Ni3O10, Chin. Phys. Lett. 41, 017401 (2024).
  13. Y. Zhu et al., Superconductivity in pressurized trilayer La4Ni3O10−δ single crystals, Nature (London) 631, 531 (2024).
  14. M. Zhang et al., Superconductivity in trilayer nickelate La4Ni3O10 under pressure, Phys. Rev. X 15, 021005 (2025).
  15. M. Shi et al., Pressure induced superconductivity in hybrid Ruddlesden-Popper La5Ni3O11 single crystals, Nat. Phys. 21, 1780 (2025).
  16. C. Huang, J. Li, X. Huang, H. Zhang, D. Hu, M. Huo, X. Chen, Z. Chen, H. Sun, and M. Wang. Superconductivity in monolayer-trilayer phase of La3Ni2O7 under high pressure, arXiv:2510.12250v1.
  17. E. K. Ko et al., Signatures of ambient pressure superconductivity in thin film La3Ni2O7, Nature (London) 638, 935 (2025).
  18. G. Zhou et al., Ambient-pressure superconductivity onset above 40 K in (La,Pr)3Ni2O7 films, Nature (London) 640, 641 (2025).
  19. B. Hao et al., Superconductivity in Sr-doped La3Ni2O7 thin films, Nat. Mater. 24, 1756 (2025).
  20. P. Li et al., Angle-resolved photoemission spectroscopy of superconducting (La,Pr)3Ni2O7/SrLaAlO4 heterostructures, Natl. Sci. Rev. 12, nwaf205 (2025).
  21. J. Shen et al., Nodeless superconducting gap and electron-boson coupling in (La,Pr,Sm)3Ni2O7 films, Science eadw8329 (2026).
  22. B. Y. Wang et al., Electronic structure of compressively strained thin film La2PrNi2O7, arXiv:2504.16372.
  23. W. Sun et al., Observation of superconductivity-induced leading-edge gap in Sr-doped La3Ni2O7 thin films, arXiv:2507.07409.
  24. Z. Nie et al., Superconductivity and electronic structures of nickelate thin film superstructures, Nature (London) 652, 628 (2026).
  25. Z. Luo, X. Hu, M. Wang, W. Wú, and D.-X. Yao, Bilayer two-orbital model of La3Ni2O7 under pressure, Phys. Rev. Lett. 131, 126001 (2023).
  26. Q.-G. Yang, D. Wang, and Q.-H. Wang, Possible s±-wave superconductivity in La3Ni2O7, Phys. Rev. B 108, L140505 (2023).
  27. F. Lechermann, J. Gondolf, S. Bötzel, and I. M. Eremin, Electronic correlations and superconducting instability in La3Ni2O7 under high pressure, Phys. Rev. B 108, L201121 (2023).
  28. Y.-F. Zhao and A. S. Botana, Electronic structure of Ruddlesden-Popper nickelates: Strain to mimic the effects pressure, Phys. Rev. B 111, 115154 (2025).
  29. Z. Fan, J.-F. Zhang, B. Zhan, D. Lv, X.-Y. Jiang, B. Normand, and T. Xiang, Superconductivity in nickelate and cuprate superconductors with strong bilayer coupling, Phys. Rev. B 110, 024514 (2024).
  30. K. Jiang, Z. Wang, and F.-C. Zhang, High-temperature superconductivity in La3Ni2O7, Chin. Phys. Lett. 41, 017402 (2024).
  31. H. Shi et al., The effect of carrier doping and thickness on the electronic structures of La3Ni2O7 thin films, Chin. Phys. Lett. 42, 080708 (2025).
  32. C. Lu, Z. Pan, F. Yang, and C. Wu, Interplay of two eg orbitals in superconducting La3Ni2O7 under pressure, Phys. Rev. B 110, 094509 (2024).
  33. G. Zhou et al., Gigantic-oxidative atomic-layer-by-layer epitaxy for artificially designed complex oxides, Natl. Sci. Rev. 12, nwae429 (2024).
  34. See Supplemental Material at http://link.aps.org/supplemental/10.1103/466c-8sl4 for detailed information on the experimental details, and data analysis, which includes Refs. [35,36].
  35. W. Lyu, Z. Nie, H. Wang, H. Huang, Q.-K. Xue, G. Zhou, and Z. Chen, Preparation and optimization of high-temperature superconducting Ruddlesden-Popper nickelate thin films, Acta Phys. Sin. 74, 227403 (2025).
  36. J. Kim et al., Defect engineering in A2BO4 thin films via surface-reconstructed LaSrAlO4 substrates, Small Methods 6, 2200880 (2022).
  37. Y. Miao et al., Electronic structures across the superconductor-insulator transition in Ruddlesden-Popper bilayer nickelate films, arXiv:2502.18068.
  38. A. Bansil, R. S. Markiewicz, C. Kusko, M. Lindroos, and S. Sahrakorpi, Matrix element and strong electron correlation effects in ARPES from cuprates, J. Phys. Chem. Solids 65, 1417 (2004).
  39. J. Yang et al., Orbital-dependent electron correlation in double-layer nickelate La3Ni2O7, Nat. Commun. 15, 4373 (2024).
  40. Y. Li et al., Electronic correlation and pseudogap-like behavior of high-temperature superconductor La3Ni2O7, Chin. Phys. Lett. 41, 087402 (2024).
  41. Y.-H. Cao, K.-Y. Jiang, H.-Y. Lu, D. Wang, and Q.-H. Wang, Strain-engineered electronic structure and superconductivity in La3Ni2O7 thin films, Sci. China Phys. Mech. Astron. 69, 247412 (2026).
  42. Z. Ouyang, R.-Q. He, and Z.-Y. Lu, Phase diagrams and two key factors to superconductivity of Ruddlesden-Popper nickelates, Phys. Rev. B 112, 045127 (2025).
  43. Z.-Y. Shao, Y.-B. Liu, M. Liu, and F. Yang, Band structure and pairing nature of La3Ni2O7 thin film at ambient pressure, Phys. Rev. B 112, 024506 (2025).
  44. C. Hu et al., Momentum-resolved visualization of electronic evolution in doping a Mott insulator, Nat. Commun. 12, 1356 (2021).
  45. J. Graf, G. H. Gweon, and A. Lanzara, Universal waterfall-like feature in the spectral function of high temperature superconductors, Physica (Amsterdam) 460-462C, 194 (2007).
  46. Y. Zhang, L.-F. Lin, A. Moreo, and E. Dagotto, Electronic structure, dimer physics, orbital-selective behavior, and magnetic tendencies in the bilayer nickelate superconductor La3Ni2O7 under pressure, Phys. Rev. B 108, L180510 (2023).
  47. P. Li et al., Revealing the electron-spin fluctuation coupling by photoemission in CaKFe4As4, Phys. Rev. X 15 (2025).
  48. T. Xie et al., Odd and even modes of neutron spin resonance in the bilayer iron-based superconductor CaKFe4As4, Phys. Rev. Lett. 120, 267003 (2018).
  49. H. Matsui, T. Sato, T. Takahashi, S. C. Wang, H. B. Yang, H. Ding, T. Fujii, T. Watanabe, and A. Matsuda, BCS-like bogoliubov quasiparticles in high-Tc superconductors observed by angle-resolved photoemission spectroscopy, Phys. Rev. Lett. 90, 217002 (2003).
  50. Q. Qin and Y. F. Yang, High-Tc superconductivity by mobilizing local spin singlets and possible route to higher Tc in pressurized La3Ni2O7, Phys. Rev. B 108, L140504 (2023).
