From fluttering to drifting: Inertialess sedimentation of an achiral particle

Christian Vaquero-Stainer1,2, Tymoteusz Miara2, Anne Juel2, Matthias Heil3, and Draga Pihler-Puzović2

PDF

Phys. Rev. Fluids 11, 034102 – Published 10 March, 2026

DOI: https://doi.org/10.1103/scj8-6lpf

Abstract

There has been much recent interest in the chiral motion of achiral particles that sediment in a viscous fluid in a regime where inertial effects can be neglected. This occurs in a broad range of applications such as those involving biological objects like algae, ultrathin graphene flakes, or colloidal suspensions. It is known that particles with two planes of symmetry can be categorized as “settlers,” “drifters,” or “flutterers,” where the latter sediment along chiral trajectories despite their achiral shapes. Previous work investigated the sedimentation of circular disks bent into a U-shape and identified them as “flutterers.” In this work we analyze the change in behavior of such particles when we break one of their symmetries by pinching the disks isometrically along their axis, a shape change that can arise during the sedimentation of thin elastic sheets. The “fluttering” behavior is found to be robust to such shape changes, with the trajectories now evolving toward helical paths. However, the behavior changes when the degree of pinching becomes too strong, at which point the particles become “drifters” which sediment steadily without rotation. We establish criteria for the transition between the two types of behavior and confirm our predictions in experiments. Finally, we discuss the implications of our observations for the dispersion of dilute suspensions made of such particles.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (34)

  1. G. G. Stokes, On the effect of the internal friction of fluids on the motion of pendulums, Trans. Cambridge Philos. 9, 8 (1851).
  2. C. Weber, M. Carlen, G. Dietler, E. J. Rawdon, and A. Stasiak, Sedimentation of macroscopic rigid knots and its relation to gel electrophoretic mobility of DNA knots, Sci. Rep. 3, 1091 (2013).
  3. U. Khan, A. O'Neill, H. Porwal, P. May, K. Nawaz, and J. N. Coleman, Size selection of dispersed, exfoliated graphene flakes by controlled centrifugation, Carbon 50, 470 (2012).
  4. E. Huseby, J. Gissinger, F. Candelier, N. Pujara, G. Verhille, B. Mehlig, and G. A. Voth, Helical ribbons: Simple chiral sedimentation, Phys. Rev. Fluids 10, 024101 (2025).
  5. E. E. Keaveny, S. W. Walker, and M. J. Shelley, Optimization of chiral structures for microscale propulsion, Nano Lett. 13, 531 (2013).
  6. M. Doi and M. Makino, Motion of micro-particles of complex shape, Prog. Polym. Sci. 30, 876 (2005).
  7. B. Marchetti, V. Raspa, A. Lindner, O. du Roure, L. Bergougnoux, E. Guazzelli, and C. Duprat, Deformation of a flexible fiber settling in a quiescent viscous fluid, Phys. Rev. Fluids 3, 104102 (2018).
  8. M. Peltomäki and G. Gompper, Sedimentation of single red blood cells, Soft Matter 9, 8346 (2013).
  9. S. B. Field, M. Klaus, M. G. Moore, and F. Nori, Chaotic dynamics of falling disks, Nature (London) 388, 252 (1997).
  10. H. Brenner, The Stokes resistance of an arbitrary particle, Chem. Eng. Sci. 18, 1 (1963).
  11. J. Happel and H. Brenner, Low Reynolds Number Hydrodynamics (Martinus Nijhoff Publishers, Leiden, Netherlands, 1983), Vol. 1.
  12. W. H. Mitchell and S. E. Spagnolie, Sedimentation of spheroidal bodies near walls in viscous fluids: Glancing, reversing, tumbling and sliding, J. Fluid Mech. 772, 600 (2015).
  13. I. R. Thorp and J. R. Lister, Motion of a non-axisymmetric particle in viscous shear flow, J. Fluid Mech. 872, 532 (2019).
  14. J. Wang, E. J. Tozzi, M. D. Graham, and D. J. Klingenberg, Flipping, scooping, and spinning: Drift of rigid curved nonchiral fibers in simple shear flow, Phys. Fluids 24, 123304 (2012).
  15. R. Chajwa, N. Menon, and S. Ramaswamy, Kepler orbits in pairs of disks settling in a viscous fluid, Phys. Rev. Lett. 122, 224501 (2019).
  16. S. Jung, S. E. Spagnolie, K. Parikh, M. Shelley, and A-K. Tornberg, Periodic sedimentation in a Stokesian fluid, Phys. Rev. E 74, 035302(R) (2006).
  17. T. Salez and L. Mahadevan, Elastohydrodynamics of a sliding, spinning and sedimenting cylinder near a soft wall, J. Fluid Mech. 779, 181 (2015).
  18. M. Palusa, J. J. de Graaf, A. Brown, and A. Morozov, Sedimentation of a rigid helix in viscous media, Phys. Rev. Fluids 3, 124301 (2018).
  19. T. A. Witten and H. Diamant, A review of shaped colloidal particles in fluids: Anisotropy and chirality, Rep. Prog. Phys. 83, 116601 (2020).
  20. E. J. Tozzi, C. T. Scott, D. Vahey, and D. J. Klingenberg, Settling dynamics of asymmetric rigid fibers, Phys. Fluids 23 033301 (2011).
  21. N. Moreno, D. Vázquez-Cortés, and E. Fried, Sedimentation dynamics of triply twisted Möbius bands: Geometry versus topology, Phys. Rev. Res. 6, 033141 (2024).
  22. O. Gonzalez, A. B. A. Graf, and J. H. Maddocks, Dynamics of a rigid body in a Stokes fluid, J. Fluid Mech. 519, 133 (2004).
  23. D. Collins, R. J. Hamati, F. Candelier, K. Gustavsson, B. Mehlig, and G. A. Voth, Lord Kelvin's isotropic helicoid, Phys. Rev. Fluids 6, 074302 (2021).
  24. T. Miara, C. Vaquero-Stainer, D. Pihler-Puzović, M. Heil, and A. Juel, Dynamics of inertialess sedimentation of a rigid u-shaped disk, Commun. Phys. 7, 47 (2024).
  25. C. Vaquero-Stainer, T. Miara, A. Juel, D. Pihler-Puzović, and M. Heil, U-shaped disks in Stokes flow: Chiral sedimentation of a non-chiral particle, J. Fluid Mech. 999, A71 (2024).
  26. H. Joshi and R. Govindarajan, Sedimentation dynamics of bodies with two planes of symmetry, Phys. Rev. Lett. 134, 014002 (2025).
  27. M. Heil and A. L. Hazel, oomph-lib—An object-oriented multi-physics finite-element library, in Fluid-Structure Interaction, edited by M. Schäfer, and H.-J. Bungartz (Springer, Berlin, 2006), pp. 19–49; oomph-lib is available as open-source software at http://www.oomph-lib.org
  28. S. C. Gupta, Slow broad side motion of a flat plate in a viscous liquid, ZAMP 8, 257 (1957).
  29. J. P. Tannish and H. A. Stone, A general approach for the arbitrary motion of a circular disk in a Stokes flow, Chem. Eng. Commun. 148-150, 333 (1996).
  30. C. P. Vaquero-Stainer, The Sedimentation Dynamics of Thin, Rigid Disks: A Numerical Study with a Novel Semi-analytic Finite-element Method, Ph.D. thesis, University of Manchester, Manchester, UK (2022).
  31. T. Miara, Folding Flakes: The Deformation of Elastic Sheets in Viscous Flow, Ph.D. thesis, University of Manchester, Manchester, UK (2024).
  32. T. Miara, Experimental data avaiable at Github.Com/TymoteuszMiara/Dynamics-of-inertialess-sedimentation-of-a-pinched-u-shaped-disk.
  33. T. T. K. Chan, L. B. Esteban, S. G. Huisman, J. S. Shrimpton, and B. Ganapathisubramani, Settling of thin curved particles in quiescent fluid and turbulence, J. Fluid Mech. 922, A30 (2021).
  34. T. Miara, D. Pihler-Puzović, M. Heil, and A. Juel, Light-scattering reconstruction of transparent shapes using neural networks, arXiv:2311.02970.
