Twin satellites and ring bubbles from coalescing magnetically levitated air bubbles in water

N. Sampara1, G. Hunter-Brown1, K. A. Baldwin2, M. M. Scase3, and R. J. A. Hill1,*

  • *Contact author: richard.hill@nottingham.ac.uk
PDF

Phys. Rev. Fluids 11, 043605 – Published 22 April, 2026

DOI: https://doi.org/10.1103/fr1q-m1j9

Abstract

We investigate the ejection of satellite bubbles during the coalescence of two air bubbles in water. Using magnetic levitation we suspend the bubbles, with diameters in the range 3–15 mm, in a stable, neutrally buoyant state, free from mechanical constraints. Our experiments reveal the simultaneous ejection of twin satellite bubbles from the poles of the bubble formed from the coalescence of equal-sized precursors. More generally, we find that the number and size of the ejected satellites are dependent on the initial size ratio of the precursor bubble pair. Numerical simulations, which agree well with our experiments, show that satellite production is governed by the combined effect of two distinct processes: the arrival of a capillary wave crest at a pole and the rapid retraction of that polar region. We propose a timing model that successfully predicts the range of size ratios for which single, double, or no satellites are formed. Our analysis also offers insight into the absence of satellite ejection in similarly sized liquid drop coalescence. Furthermore, we report the experimental observation of toroidal bubble ejection from precursor bubbles with approximately 2:1 diameter ratios, and we show that the formation of these toroidal bubbles is also governed by our timing model.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (42)

  1. H. Czerski, A candidate mechanism for exciting sound during bubble coalescence, J. Acoust. Soc. Am. 129, EL83 (2011).
  2. M. Ohnishi, H. Azuma, and J. Straub, Study on secondary bubble creation induced by bubble coalescence, Adv. Space Res. 24, 1331 (1999).
  3. L. Li and Y. T. Kang, Effects of bubble coalescence and breakup on CO2 absorption performance in nanoabsorbents, J. CO2 Util. 39, 101170 (2020).
  4. G. Besagni, F. Inzoli, and T. Ziegenhein, Two-phase bubble columns: A comprehensive review, ChemEngineering 2, 13 (2018).
  5. R. L. Stover, C. W. Tobias, and M. M. Denn, Bubble coalescence dynamics, AIChE J. 43, 2385 (1997).
  6. K. Wang, P. Pei, Z. Ma, H. Chen, H. Xu, D. Chen, and H. Xing, Growth of oxygen bubbles during recharge process in zinc-air battery, J. Power Sources 296, 40 (2015).
  7. K. L. Tse, T. Martin, C. M. McFarlane, and A. W. Nienow, Small bubble formation via a coalescence dependent break-up mechanism, Chem. Eng. Sci. 58, 275 (2003).
  8. F. H. Zhang and S. T. Thoroddsen, Satellite generation during bubble coalescence, Phys. Fluids 20, 022104 (2008).
  9. F. H. Zhang, M. J. Thoraval, S. T. Thoroddsen, and P. Taborek, Partial coalescence from bubbles to drops, J. Fluid Mech. 782, 209 (2015).
  10. A. M. Soto, T. Maddalena, A. Fraters, D. Van Der Meer, and D. Lohse, Coalescence of diffusively growing gas bubbles, J. Fluid Mech. 846, 143 (2018).
  11. S. T. Thoroddsen, T. G. Etoh, K. Takehara, and N. Ootsuka, On the coalescence speed of bubbles, Phys. Fluids 17, 071703 (2005).
  12. G. Hunter-Brown, N. Sampara, M. M. Scase, and R. J. A. Hill, The nonlinear free-decay oscillations of a magnetically levitated air bubble in water produced by coalescence, Phys. Rev. Fluids 10, 083601 (2025).
  13. F. H. Zhang, E. Q. Li, and S. T. Thoroddsen, Satellite formation during coalescence of unequal size drops, Phys. Rev. Lett. 102, 104502 (2009).
  14. E. Beaugnon and R. Tournier, Levitation of organic materials, Nature (London) 349, 470 (1991).
  15. M. A. Weilert, D. L. Whitaker, H. J. Maris, and G. M. Seidel, Magnetic levitation and noncoalescence of liquid helium, Phys. Rev. Lett. 77, 4840 (1996).
  16. E. Beaugnon, D. Fabregue, D. Billy, J. Nappa, and R. Tournier, Dynamics of magnetically levitated droplets, Physica B 294-295, 715 (2001).
  17. R. J. A. Hill and L. Eaves, Vibrations of a diamagnetically levitated water droplet, Phys. Rev. E 81, 056312 (2010).
  18. K. A. Baldwin, S. L. Butler, and R. J. A. Hill, Artificial tektites: An experimental technique for capturing the shapes of spinning drops, Sci. Rep. 5, 7660 (2015).
  19. L. Liao and R. J. A. Hill, Shapes and fissility of highly charged and rapidly rotating levitated liquid drops, Phys. Rev. Lett. 119, 114501 (2017).
  20. I. Sanskriti, D. Kim, and J. Twamley, Shape deformation of magnetically levitated fluid droplets, arXiv:2308.10503.
  21. E. Beaugnon and R. Tournier, Levitation of water and organic substances in high static magnetic fields, J. Phys. III France 1, 1423 (1991).
  22. M. V. Berry and A. K. Geim, Of flying frogs and levitrons, Eur. J. Phys. 18, 307 (1997).
  23. G. Pichavant, B. Cariteau, D. Chatain, V. Nikolayev, and D. Beysens, Magnetic compensation of gravity: Experiments with oxygen, Microgravity Sci. Technol. 21, 129 (2009).
  24. J. Duplat and A. Mailfert, On the bubble shape in a magnetically compensated gravity environment, J. Fluid Mech. 716, R11 (2013).
  25. This is a slightly different concentration to the one used in Ref. [12].
  26. C. Kittel, Introduction to Solid State Physics (John Wiley & Sons, New York, NY, 1996).
  27. P. Novotný and O. Söhnel, Densities of binary aqueous solutions of 306 inorganic substances, J. Chem. Eng. Data 33, 49 (1988).
  28. We use the symbol D for the density here to avoid confusing it with the radius of the bubble neck, ρ, introduced later.
  29. J. Padova, Ion-solvent interaction in mixed solvents. II The viscosity of electrolytes in mixed solvents, J. Chem. Phys. 38, 2635 (1963).
  30. H. Lamb, Hydrodynamics, 6th edition (Cambridge University Press, Cambridge, UK, 1932).
  31. S. Popinet, An accurate adaptive solver for surface-tension-driven interfacial flows, J. Comput. Phys. 228, 5838 (2009).
  32. S. Popinet, A quadtree-adaptive multigrid solver for the Serre–Green–Naghdi equations, J. Comput. Phys. 302, 336 (2015).
  33. See Supplemental Material at http://link.aps.org/supplemental/10.1103/fr1q-m1j9 for a high-speed video of the coalescence shown in Fig. 2.
  34. J. A. Tsamopoulos and R. A. Brown, Nonlinear oscillations of inviscid drops and bubbles, J. Fluid Mech. 127, 519 (1983).
  35. F. Blanchette and T. P. Bigioni, Partial coalescence of drops at liquid interfaces, Nat. Phys. 2, 254 (2006).
  36. J. D. Paulsen, R. Carmigniani, A. Kannan, J. C. Burton, and S. R. Nagel, Coalescence of bubbles and drops in an outer fluid, Nat. Commun. 5, 3182 (2014).
  37. R. Chen, H. W. Yu, J. Zeng, and L. Zhu, General power-law temporal scaling for unequal-size microbubble coalescence, Phys. Rev. E 101, 023106 (2020).
  38. S. Zhou, Y. Cao, R. Chen, T. Sun, K. Fezzaa, H. Yu, and L. Zhu, Study on coalescence dynamics of unequal-sized microbubbles captive on solid substrate, Exp. Therm. Fluid Sci. 98, 362 (2018).
  39. J. Eggers, J. R. Lister, and H. A. Stone, Coalescence of liquid drops, J. Fluid Mech. 401, 293 (1999).
  40. A. Menchaca-Rocha, A. Martinez-Davalos, R. Nunez, S. Popinet, and S. Zaleski, Coalescence of liquid drops by surface tension, Phys. Rev. E 63, 046309 (2001).
  41. M. Wu, T. Cubaud, and C.-M. Ho, Scaling law in liquid drop coalescence driven by surface tension, Phys. Fluids 16, L51 (2004).
  42. H. Deka, G. Biswas, S. Chakraborty, and A. Dalal, Coalescence dynamics of unequal sized drops, Phys. Fluids 31, 012105 (2019).
