Retraction dynamics of a highly viscous liquid sheet

Taosif Ahsan1,2,*, Rodolfo Brandão3,4,*, Benny Davidovitch5, and Howard A. Stone4

  • *These authors contributed equally to this work.
PDF

Phys. Rev. Fluids 11, 014001 – Published 8 January, 2026

DOI: https://doi.org/10.1103/fnhn-7zmw

Abstract

We study the one-dimensional capillary-driven retraction of a finite planar liquid sheet in the asymptotic regime where both the initial length-to-thickness ratio l0/h0 and a characteristic Ohnesorge number, Oh, which is inversely related to the Reynolds number of the flow, are large. In this regime, the fluid domain decomposes into two regions: a thin-film region governed by one-dimensional mass and momentum equations and a small tip region near the free edge described by a self-similar Stokes flow. Asymptotic matching between these regions yields an effective boundary condition for the thin-film region, representing a balance between viscous and capillary forces at the free edge. We find that surface tension drives the thin-film flow only through this boundary condition, while the local momentum balance is dominated by viscous and inertial stresses. We show that the thin-film flow possesses a conserved quantity, reducing the governing equations to a one-dimensional free-boundary problem in which the sheet thickness satisfies the heat equation with time-dependent boundary conditions. The reduced problem depends on a single dimensionless parameter L=l0/(4h0Oh). Numerical solutions of the reduced model agree well with previous studies based on different formulations, including full Navier-Stokes simulations, and reveal that the sheet undergoes distinct retraction regimes depending on L and a dimensionless time after rupture T. We derive asymptotic approximations for the thickness profile, velocity profile, and retraction speed during the early and late stages of retraction. At early times, the retraction speed grows as T1/2, characteristic of diffusive processes, while at late times it decays as 1/T2 due to the finiteness of the sheet. Both results are consistent with previous findings. We also analyze an intermediate regime, not previously studied in detail, which arises for very long sheets (L≫1). During this phase, the retraction speed approaches the classical Taylor-Culick value, despite the sheet not exhibiting a large circular rim as in classical studies of film rupture. When T≈L, the speed undergoes a sudden deceleration, which we characterize numerically, going from the Taylor-Culick speed to that predicted by the late-time asymptotics.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (36)

  1. N. Bremond, C. Clanet, and E. Villermaux, Atomization of undulating liquid sheets, J. Fluid Mech. 585, 421 (2007).
  2. E. Villermaux, Fragmentation versus cohesion, J. Fluid Mech. 898, P1 (2020).
  3. L. Bourouiba, The fluid dynamics of disease transmission, Annu. Rev. Fluid Mech. 53, 473 (2021).
  4. D. S. Finnicum, S. J. Weinstein, and K. J. Ruschak, The effect of applied pressure on the shape of a two-dimensional liquid curtain falling under the influence of gravity, J. Fluid Mech. 255, 647 (1993).
  5. G. I. Taylor, The dynamics of thin sheets of fluid. III. Disintegration of fluid sheets, Proc. R. Soc. London A 253, 313 (1959).
  6. F. E. C. Culick, Comments on a ruptured soap film, J. Appl. Phys. 31, 1128 (1960).
  7. W. E. Ranz, Some experiments on the dynamics of liquid films, J. Appl. Phys. 30, 1950 (1959).
  8. W. R. McEntee and K. J. Mysels, Bursting of soap films. I. An experimental study, J. Phys. Chem. 73, 3018 (1969).
  9. G. Debrégeas, P. Martin, and F. Brochard-Wyart, Viscous bursting of suspended films, Phys. Rev. Lett. 75, 3886 (1995).
  10. G. Debrégeas, P.-G. de Gennes, and F. Brochard-Wyart, The life and death of “bare” viscous bubbles, Science 279, 1704 (1998).
  11. M. P. Brenner and D. Gueyffier, On the bursting of viscous films, Phys. Fluids 11, 737 (1999).
  12. M. Song and G. Tryggvason, The formation of thick borders on an initially stationary fluid sheet, Phys. Fluids 11, 2487 (1999).
  13. G. Sünderhauf, H. Raszillier, and F. Durst, The retraction of the edge of a planar liquid sheet, Phys. Fluids 14, 198 (2002).
  14. N. Savva and J. W. M. Bush, Viscous sheet retraction, J. Fluid Mech. 626, 211 (2009).
  15. H. Deka and J.-L. Pierson, Revisiting the Taylor-Culick approximation. II. Retraction of a viscous sheet, Phys. Rev. Fluids 5, 093603 (2020).
  16. L. Gordillo, G. Agbaglah, L. Duchemin, and C. Josserand, Asymptotic behavior of a retracting two-dimensional fluid sheet, Phys. Fluids 23, 122101 (2011).
  17. J. P. Munro, C. R. Anthony, O. A. Basaran, and J. R. Lister, Thin-sheet flow between coalescing bubbles, J. Fluid Mech. 773, R3 (2015).
  18. T. Erneux and S. H. Davis, Nonlinear rupture of free films, Phys. Fluids A 5, 1117 (1993).
  19. P. D. Howell, Models for thin viscous sheets, Eur. J. Appl. Math. 7, 321 (1996).
  20. F. T. Trouton, On the coefficient of viscous traction and its relation to that of viscosity, Proc. R. Soc. Lond. Ser. A 77, 426 (1906).
  21. E. J. Hinch, Perturbation Methods (Cambridge University Press, Cambridge, UK, 1991).
  22. We note that the (arguably nonintuitive) necessity to retain inertia in the limit Oh≫1 of highly viscous liquid is intimately related to the reduced dimensionality of the setup. Indeed, in an axial geometry (expanding hole), the viscous force, ∂x(h∂xv), in Eq. (2.5), is replaced by ∂r(hr−1(∂rrvr)), and a purely viscous solution is compatible with initial and boundary conditions, regardless of the value of l0/h0. This subtle relationship between the geometry and the role of inertia appears to have been overlooked in previous studies, e.g., Ref. [14].
  23. J. Ockendon, S. Howison, A. Lacey, and A. Movchan, Applied Partial Differential Equations (Oxford University Press, Oxford, 2015).
  24. J. Stefan, Über einige probleme der theorie der wärmeleitung, Wien. Ber. 98, 473 (1889).
  25. A. Kaye, Convected coordinates and elongational flow, J. Non-Newton. Fluid Mech. 40, 55 (1991).
  26. Y. M. Stokes and E. O. Tuck, The role of inertia in extensional fall of a viscous drop, J. Fluid Mech. 498, 205 (2004).
  27. B. H. Bradshaw-Hajek, Y. M. Stokes, and E. O. Tuck, Computation of extensional fall of slender viscous drops by a one-dimensional Eulerian method, SIAM J. Appl. Math. 67, 1166 (2007).
  28. J. J. Wylie, H. Huang, and R. M. Miura, Stretching of viscous threads at low reynolds numbers, J. Fluid Mech. 683, 212 (2011).
  29. M. Abramowitz and I. A. Stegun, Handbook of Mathematical Functions, 3rd ed. (Dover, New York,1965).
  30. J. Billingham, The initial surface tension–driven flow of a wedge of viscous fluid, SIAM J. Appl. Math. 66, 510 (2005).
  31. J. P. Munro and J. R. Lister, Capillary retraction of the edge of a stretched viscous sheet, J. Fluid Mech. 844, R1 (2018).
  32. C. Planchette, F. Marangon, W.-K. Hsiao, and G. Brenn, Breakup of asymmetric liquid ligaments, Phys. Rev. Fluids 4, 124004 (2019).
  33. J.-L. Pierson, J. Magnaudet, E. J. Soares, and S. Popinet, Revisiting the Taylor-Culick approximation: Retraction of an axisymmetric filament, Phys. Rev. Fluids 5, 073602 (2020).
  34. J. B. Keller, Breaking of liquid films and threads, Phys. Fluids 26, 3451 (1983).
  35. T. Ahsan, https://github.com/taosifahsan/Thin-Film-Simulations
  36. J. Eggers, Post-breakup solutions of Navier-Stokes and stokes threads, Phys. Fluids 26, 072104 (2014).
