Size effects in fluctuation-based damage mechanics in the semigrand canonical ensemble

Ariel Attias1, Zdeněk P. Bažant2, and Franz-Josef Ulm1,*

  • *Contact author: ulm@mit.edu
PDF

Phys. Rev. E 114, 045504 – Published 15 October, 2026

DOI: https://doi.org/10.1103/nxng-f58v

Abstract

We present results of a fluctuation-based investigation of size effects on damage and fracture of quasibrittle materials and structures. Set within the semigrand canonical (ΔμVT) ensemble, we find that size effects of geometrically similar structures are a system property rather than a material property. We reach this conclusion by considering damage and fracture as thermodynamic equilibrium states accessible through Monte Carlo simulations, and develop stress-strain curves and damage isotherms based on ensemble averaging, considering both short-range and long-range bond interactions. We suggest that, to preserve the probability distribution of damage and fracture states for geometrically similar structures, a scaling of the thermodynamic variables of the ΔμVT- ensemble needs to be considered, including a scaling of the bath potential, Δμ∝λ−d−1, for the system's size dilation λ, considering the geometric dimension d of the fracture surface. Derived from mere thermodynamic equilibrium conditions in the fluctuation-based damage approach, we show that such scaling allows the transition between strength theories (d=0) and linear elastic fracture mechanics (LEFM), for which the strength scales as σN∝λ−1/2, for all geometries and types of bond interactions. The rationalization of size effects within the realm of statistical mechanics opens venues toward a large range of engineering applications involving damage-prone materials and structures, from concrete bridges and high-rise buildings to hydraulic fracturing of gas shale and damage of hard and soft biological tissues.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (52)

  1. L. M. Kachanov, On time to rupture in creep conditions [in Russian], izv, AN SSSR, O.T.N. 8, 26 (1958).
  2. Y. N. Rabotnov, Creep rupture, Applied Mechanics (Springer, Berlin Heidelberg, 1969), pp. 342–349.
  3. A. A. Griffith, VI. The phenomena of rupture and flow in solids, Phil. Trans. R. Soc. A 221, 163, (1921).
  4. J. Lemaitre and J.-L. Chaboche, Mechanics of Solid Materials, (Cambridge University Press, Cambridge, 1990).
  5. J. Mazars and G. Pijaudier-Cabot, Continuum damage theory—Application to concrete, J. Eng. Mech. 115, 345, (1989).
  6. J. Mazars and S. Grange, Damage and Cracking of Concrete Structures. From Theory to Practice (Wiley-ISTE, Hoboken, 2022).
  7. J. L. Chaboche, P. M. Lesne, and J. F. Maire, Continuum damage mechanics, anisotropy and damage deactivation for brittle materials like concrete and ceramic composites, Int. J. Damage Mech. 4, 5, (1995).
  8. V. Pensée, D. Kondo, and L. Dormieux, Micromechanical analysis of anisotropic damage in brittle materials, J. Eng. Mech. 128, 889 (2002).
  9. G. Drakoulas, C. Kokkinos, D. Fotiadis, S. Kokkinos, K. Loukas, A. N. Moulas, and A. Semertzioglou, Coupled FEA model with continuum damage mechanics for the degradation of polymer-based coatings on drug-eluting stents, in 2021 43rd Annual International Conference of the IEEE Engineering in Medicine & Biology Society (EMBC) (IEEE, Mexico, 2021), pp. 4319–4323.
  10. G. A. Holzapfel and B. Fereidoonnezhad, Modeling of damage in soft biological tissues, in Biomechanics of Living Organs (Academic Press, Oxford, 2017), Vol. 1, Chap. 5, pp. 101–123.
  11. Z. P. Bažant and T. B. Belytschko, Wave propagation in a strain-softening bar: Exact solution, J. Eng. Mech. 111, 381, (1985).
  12. G. Pijaudier-Cabot and Z. P. Bažant, Nonlocal damage theory, J. Eng. Mech. 113, 1512 (1987).
  13. M. Frémond and B. Nedjar, Damage, gradient of damage and principle of virtual power, Int. J. Solids Struct. 33, 1083, (1996).
  14. R. de Borst and C. V. Verhoosel, Gradient damage vs phase-field approaches for fracture: Similarities and differences, Comput. Methods Appl. Mech. Eng. 312, 78, (2016).
  15. G. A. Francfort and J.-J. Marigo, Revisiting brittle fracture as an energy minimization problem, J. Mech. Phys. Solids 46, 1319 (1998).
  16. S. A. Silling, Reformulation of elasticity theory for discontinuities and long-range forces, J. Mech. Phys. Solids 48, 175, (2000).
  17. P. Diehl, R. Lipton, T. Wick, and M. Tyagi, A comparative review of peridynamics and phase-field models for engineering fracture mechanics, Comput. Mech. 69, 1259 (2022).
  18. Z. P. Bažant, H. T. Nguyen, and A. A. Dönmez, Critical comparison of phase-field, peridynamics, and crack band model M7 in light of gap test and classical fracture tests, J. Appl. Mech. 89, 061008 (2022).
  19. Y. Zhang and Z. P. Bažant, Smooth crack band model—A computational paragon based on unorthodox continuum homogenization, J. Appl. Mech. 90, 041007 (2023).
  20. A. T. Nguyen, H. Xu, K. Matouš, and Z. P. Bažant, Smooth Lagrangian crack band model based on spress-sprain relation and Lagrange multiplier constraint of displacement gradient, J. Appl. Mech. 91, 031007 (2024).
  21. H. Xu, A. T. Nguyen, and Z. P. Bažant, Sprain energy consequences for damage localization and fracture mechanics, Proc. Natl. Acad. Sci. USA 121, e2410668121 (2024).
  22. Z. P. Bažant, Scaling of Structural Strength (CRC Press, Boca Raton, 2002).
  23. H. E. Daniels, The statistical theory of the strength of bundles of threads. I, Proc. R. Soc. A 183, 405 (1945).
  24. W. Weibull, A statistical theory of the strength of materials, Proc. Royal Academy Engrg Science, 15, 1 (1939).
  25. A. Hansen and P.C. Hemmer, Burst avalanches in bundles of fibers: Local versus global load-sharing, Phys. Lett. A 184, 394 (1994).
  26. S. Zapperi, P. Ray, H. E. Stanley, and A. Vespignani, First-order transition in the breakdown of disordered media, Phys. Rev. Lett. 78, 1408 (1997).
  27. L. de Arcangelis, S. Redner, and H. J. Herrmann, A random fuse model for breaking processes, J. Phys. Lett. 46, 585 (1985).
  28. D. Bonamy and E. Bouchaud, Failure of heterogeneous materials: A dynamic phase transition, Phys. Rep. 498, 1 (2011).
  29. M. J. Alava, P. K. V. V. Nukala, and S. Zapperi, Statistical models of fracture, Adv. Phys. 55, 349 (2006).
  30. S. Morel, J. Schmittbuhl, E. Bouchaud, and G. Valentin, Scaling of crack surfaces and implications for fracture mechanics, Phys. Rev. Lett. 85, 1678 (2000).
  31. S. Morel, E. Bouchaud, and G. Valentin, Size effect in fracture: Roughening of crack surfaces and asymptotic analysis, Phys. Rev. B 65, 104101 (2002).
  32. T. Mulla, S. Moeini, K. Ioannidou, R. J.-M. Pellenq, and F.-J. Ulm, Phase diagram of brittle fracture in the semi-grand-canonical ensemble, Phys. Rev. E 103, 013003 (2021).
  33. T. Mulla, R. J.-M. Pellenq, and F.-J. Ulm, Fluctuation-based fracture mechanics of heterogeneous materials, Phys. Rev. E 106, 065003 (2022).
  34. T. Alfrey and H. Mark, Statistical mechanics of binary mixtures, J. Chem. Phys. 10, 303 (1942).
  35. Y. Tang, A new method of semigrand canonical ensemble to calculate first-order phase transitions for binary mixtures, J. Chem. Phys. 136, 034505 (2012).
  36. D. Frenkel and B. Smit, Understanding Molecular Simulation: From Algorithms to Applications (Elsevier, San Diego, CA, 2023).
  37. C. Tien, Introduction to Adsorption (Elsevier, 2019), pp. 23–85.
  38. This analogy was formally made in Ref. [39] for brittle fracture, and led to the erroneous formulation of a brittle fracture model in the grand canonical ensemble. This was corrected in later work, recognizing the semigrand canonical ensemble as the appropriate ensemble for mass-preserving brittle fracture mechanics [32, 33].
  39. T. Al-Mulla, R. J.-M. Pellenq, and F.-J. Ulm, Griffith's postulate: Grand canonical Monte Carlo approach for fracture mechanics of solids, Eng. Fract. Mech. 199, 544 (2018).
  40. D. Nicholson and N. G. Parsonage, Computer Simulation and the Statistical Mechanics of Adsorption (Academic Press, 1982).
  41. D. Bitter, M. Poul, G. Schmitz, and S. M. Eich, Quantifying free energies through local composition fluctuations in binary solid solutions: A proof-of-concept study using atomistic embedded-atom simulations, Acta Mater. 268, 119781 (2024).
  42. M. D. Donohue and G. L. Aranovich, Classification of Gibbs adsorption isotherms, Adv. Colloid Interface Sci. 76–77, 137 (1998).
  43. Z. P. Bažant and B.-H Oh, Crack band theory for fracture of concrete, Mat. Constr. 16, 155 (1983).
  44. ASTM-E1290-02 e1, Standard Test Method for Crack-Tip Opening Displacement (CTOD) Fracture Toughness Measurement, (ASTM International, West Conshohocken, PA, 2002), url: https://standards.globalspec.com/std/3820824/astm-e1290-02e1.
  45. ASTM-D5045-14, Standard Test Methods for Plane-Strain Fracture Toughness and Strain Energy Release Rate of Plastic Materials (ASTM International, West Conshohocken, PA, 2022).
  46. G. I. Barenblatt, The Mathematical Theory of Equilibrium Cracks in Brittle Fracture (Elsevier, New York, NY, 1962), pp. 55–129.
  47. Z. P. Bažant and J. Planas, Fracture and Size Effect in Concrete and Other Quasibrittle Materials (Taylor & Francis Group, New York, 1998).
  48. G. I. Barenblatt, G. Isaakovich, Scaling, Self-Similarity, and Intermediate Asymptotics: Dimensional Analysis and Intermediate Asymptotics (Cambridge University Press, Cambridge, 1996).
  49. Z. P. Bazant, Reminiscences on four decades of struggle and progress in softening damage and size effect, Concr. J. 40, 16 (2002).
  50. B. Cotterell, The past, present, and future of fracture mechanics, Eng. Fract. Mech. 69, 533 (2002).
  51. S. G. Abaimov, Non-equilibrium statistical mechanics of non-equilibrium damage phenomena, arXiv:0905.0292.
  52. S. G. Abaimov, Non-equilibrium annealed damage phenomena: A path integral approach, Front. Phys. 5, 6 (2017).
