Alignment and anisotropy of stresses in disordered granular media

Aashish K. Gupta1,*, Christopher Ness1,†, and Sina Haeri1,2,‡

  • *Contact author: aashish.gupta@ed.ac.uk
  • †Contact author: chris.ness@ed.ac.uk
  • ‡Contact author: s.haeri@hrwallingford.com
PDF

Phys. Rev. E 112, 055422 – Published 24 November, 2025

DOI: https://doi.org/10.1103/db23-mlhw

Abstract

Characterizing the degeneracy of local stress states is a central challenge in obtaining the complete statistical mechanics of disordered media. Here, we introduce a minimal force-balance model for isolated granular clusters to probe the structure of the stress space through principal stress orientation and stress anisotropy. We further show that when complemented by physically motivated pairwise constraints, the model produces predictions for the stress alignment in packings of repulsive hard spheres. We compare these predictions against simulation data for grains in hopper and simple shear flows, finding qualitative agreement. This demonstrates the promise of modeling bulk athermal disordered systems through the combinatorics of few primitive geometric motifs.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (27)

  1. S. F. Edwards and R. Oakeshott, Theory of powders, Physica A 157, 1080 (1989).
  2. F. Lechenault, F. Da Cruz, O. Dauchot, and E. Bertin, Free volume distributions and compactivity measurement in a bidimensional granular packing, J. Stat. Mech. (2006) P07009.
  3. S. McNamara, P. Richard, S. Kiesgen De Richter, G. Le Caër, and R. Delannay, Measurement of granular entropy, Phys. Rev. E 80, 031301 (2009).
  4. T. Aste and T. Di Matteo, Emergence of gamma distributions in granular materials and packing models, Phys. Rev. E 77, 021309 (2008).
  5. C. Song, P. Wang, and H. A. Makse, A phase diagram for jammed matter, Nature (London) 453, 629 (2008).
  6. R. Hihinashvili and R. Blumenfeld, Statistical-mechanical characteristics of dense planar granular systems, Granular Matter 14, 277 (2012).
  7. S. Henkes and B. Chakraborty, Statistical mechanics framework for static granular matter, Phys. Rev. E 79, 061301 (2009).
  8. D. Bi, S. Henkes, K. E. Daniels, and B. Chakraborty, The statistical physics of athermal materials, Annu. Rev. Condens. Matter Phys. 6, 63 (2015).
  9. R. Blumenfeld and S. F. Edwards, On granular stress statistics: Compactivity, angoricity, and some open issues, J. Phys. Chem. B 113, 3981 (2009).
  10. E. S. Bililign, J. E. Kollmer, and K. E. Daniels, Protocol dependence and state variables in the force-moment ensemble, Phys. Rev. Lett. 122, 038001 (2019).
  11. J. S. Rey, J. D. Muñoz, and W. F. Oquendo, A procedure to join the force and volume ensemble statistical descriptions of granular media, in EPJ Web of Conferences (EDP Sciences, Les Ulis, France, 2021), Vol. 249, p. 14002.
  12. V. Baranau and U. Tallarek, Estimating angoricity and granular equations of state for monodisperse packings of frictional hard spheres in a wide range of densities, Phys. Rev. E 109, 044904 (2024).
  13. J. Peters, M. Muthuswamy, J. Wibowo, and A. Tordesillas, Characterization of force chains in granular material, Phys. Rev. E 72, 041307 (2005).
  14. S. Kim and K. Kamrin, Power-law scaling in granular rheology across flow geometries, Phys. Rev. Lett. 125, 088002 (2020).
  15. N. Oyama, H. Mizuno, and K. Saitoh, Avalanche interpretation of the power-law energy spectrum in three-dimensional dense granular flow, Phys. Rev. Lett. 122, 188004 (2019).
  16. J. Hong, J.-Y. Ji, and H. Kim, Power laws in nonlinear granular chain under gravity, Phys. Rev. Lett. 82, 3058 (1999).
  17. C. Narteau, S. Byrdina, P. Shebalin, and D. Schorlemmer, Common dependence on stress for the two fundamental laws of statistical seismology, Nature (London) 462, 642 (2009).
  18. F. Meng, L. N. Y. Wong, and H. Zhou, Power law relations in earthquakes from microscopic to macroscopic scales, Sci. Rep. 9, 10705 (2019).
  19. P. A. Cundall and O. D. Strack, A discrete numerical model for granular assemblies, Géotechnique 29, 47 (1979).
  20. C. Kloss, C. Goniva, A. Hager, S. Amberger, and S. Pirker, Models, algorithms and validation for opensource DEM and CFD–DEM, Prog. Comput. Fluid Dyn. 12, 140 (2012).
  21. O. Ejtehadi, A. K. Gupta, S. Khajepor, and S. Haeri, Force-chain finder: A software tool for the recursive detection of force-chains in granular materials via minor principal stress, Comput. Phys. Commun. 297, 109070 (2024).
  22. The recursive force-chain algorithm is hosted at https://github.com/Particles-Research/Force_Chain_Finder_Public.
  23. G. Lois, A. Lemaître, and J. M. Carlson, Spatial force correlations in granular shear flow. II. Theoretical implications, Phys. Rev. E 76, 021303 (2007).
  24. T. Unger, J. Kertész, and D. E. Wolf, Force indeterminacy in the jammed state of hard disks, Phys. Rev. Lett. 94, 178001 (2005).
  25. S. McNamara, R. García-Rojo, and H. Herrmann, Indeterminacy and the onset of motion in a simple granular packing, Phys. Rev. E 72, 021304 (2005).
  26. R. P. Behringer and B. Chakraborty, The physics of jamming for granular materials: A review, Rep. Prog. Phys. 82, 012601 (2019).
  27. A. K. Gupta, C. Ness, and S. Haeri, Alignment and anisotropy data (2025), GitHub repository, available at https://github.com/aashish-k-gupta/alignment-and-anisotropy-data.
