Robust bilinear-noise-optimal control for gravitational-wave detectors: A mixed LQG and H∞ approach

Ian A. O. MacMillan* and Lee P. McCuller

  • *Contact author: macmillan@caltech.edu
PDF

Phys. Rev. D 113, 082001 – Published 13 April, 2026

DOI: https://doi.org/10.1103/wm9p-zmxc

Abstract

At its lowest frequencies, LIGO is limited by noise in its many degrees of freedom of suspended optics, which, in turn, introduce noise in the interferometer through their feedback control systems. Nonlinear interactions are a dominant source of low-frequency noise, mixing noise from multiple degrees of freedom. The lowest-order form is bilinear noise, in which the noise from two feedback-controlled subsystems multiplies to mask gravitational waves. Bilinear couplings require control trade-offs that simultaneously balance high- and low-frequency noise. Currently, there is no known lower limit to bilinear control noise. Here, we develop benchmark cost functions for bilinear noise and associated figures of merit. Linear-quadratic-Gaussian (LQG) control then establishes aggressive feedback that saturates the lower bounds on the cost functions. We then develop a mixed LQG and H∞ approach to directly compute stable, robust, and optimal feedback, using the LIGO’s alignment control system as an example. Direct computations are fast while ensuring a global optimum. By calculating optimal robust control, it is possible to construct the lower bound on control noise along the Pareto front of practical controllers for LIGO. This method can be used to drastically improve control noise in existing observatories as well as to set subsystem control noise requirements for next-generation detectors with parametrized design.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (48)

  1. B. P. Abbott, R. Abbott, T. Abbott, M. Abernathy, F. Acernese, K. Ackley, C. Adams, T. Adams, P. Addesso, R. Adhikari et al., Observation of gravitational waves from a binary black hole merger, Phys. Rev. Lett. 116, 061102 (2016).
  2. A. Buikema, C. Cahillane, G. Mansell, C. Blair, R. Abbott, C. Adams, R. Adhikari, A. Ananyeva, S. Appert, K. Arai et al., Sensitivity and performance of the advanced LIGO detectors in the third observing run, Phys. Rev. D 102, 062003 (2020).
  3. E. Capote et al., Advanced LIGO detector performance in the fourth observing run, Phys. Rev. D 111, 062002 (2025).
  4. R. Abbott, T. Abbott, S. Abraham, F. Acernese, K. Ackley, A. Adams, C. Adams, R. Adhikari, V. Adya, C. Affeldt et al., GWTC-2: Compact binary coalescences observed by LIGO and Virgo during the first half of the third observing run, Phys. Rev. X 11, 021053 (2021).
  5. R. Abbott et al. (LIGO Scientific Collaboration, Virgo Collaboration, and KAGRA Collaboration), GWTC-3: Compact binary coalescences observed by LIGO and Virgo during the second part of the third observing run, Phys. Rev. X 13, 041039 (2023).
  6. R. Abbott, T. Abbott, S. Abraham, F. Acernese, K. Ackley, A. Adams, C. Adams, R. Adhikari, V. Adya, C. Affeldt et al., Tests of general relativity with binary black holes from the second LIGO-Virgo gravitational-wave transient catalog, Phys. Rev. D 103, 122002 (2021).
  7. R. Abbott et al. (The LIGO Scientific Collaboration, the Virgo Collaboration, and the KAGRA Collaboration), Tests of general relativity with GWTC-3, Phys. Rev. D 112, 084080 (2025).
  8. E. D. Hall, K. Kuns, J. R. Smith, Y. Bai, C. Wipf, S. Biscans, R. X. Adhikari, K. Arai, S. Ballmer, L. Barsotti et al., Gravitational-wave physics with cosmic explorer: Limits to low-frequency sensitivity, Phys. Rev. D 103, 122004 (2021).
  9. L. S. Finn and D. F. Chernoff, Observing binary inspiral in gravitational radiation: One interferometer, Phys. Rev. D 47, 2198 (1993).
  10. L. McCuller, Wield iirrational, https://github.com/wieldphysics/wield-iirrational (2023).
  11. Y. Nakatsukasa, O. Sète, and L. N. Trefethen, The AAA algorithm for rational approximation, SIAM J. Sci. Comput. 40, A1494 (2018).
  12. M. Athans and E. Tse, A direct derivation of the optimal linear filter using the maximum principle, IEEE Trans. Autom. Control 12, 690 (1967).
  13. J. Doyle, K. Glover, P. Khargonekar, and B. Francis, State-space solutions to standard H2 and H∞ control problems, IEEE Trans. Autom. Control 34, 831 (1989).
  14. J. Doyle, Guaranteed margins for LQG regulators, IEEE Trans. Autom. Control 23, 756 (1978).
  15. K. Zhou, J. C. Doyle, and K. Glover, Robust and Optimal Control (Prentice Hall, Englewood Cliffs, NJ, 1996).
  16. K. Glover and J. C. Doyle, State-space formulae for all stabilizing controllers that satisfy an H∞-norm bound and relations to relations to risk sensitivity, Systems and Control Letters 11, 167 (1988).
  17. D. Bernstein and W. Haddad, LQG control with an H∞ performance bound: A Riccati equation approach, IEEE Trans. Autom. Control 34, 293 (1989).
  18. W. Haddad and D. Bernstein, Generalized Riccati equations for the full- and reduced-order mixed-norm H2/H∞ standard problem, in Proceedings of the 28th IEEE Conference on Decision and Control, Vol. 1 (1989), pp. 397–402.
  19. V. Ionescu and M. Weiss, The l2-control problem for time-varying discrete systems, Systems and Control Letters 18, 371 (1992).

  20. This is well known in the control systems community, but less well known in the GW interferometer control commissioning community.

  21. A. Varga, On computing 2-norms of transfer function matrices, in 1992 American Control Conference (1992), pp. 1054–1056, 10.23919/ACC.1992.4792246.
  22. A. C. Antoulas, 6. Sylvester and Lyapunov equations, in Approximation of Large-Scale Dynamical Systems, Advances in Design and Control, (Society for Industrial and Applied Mathematics, 2005), pp. 173–204, 10.1137/1.9780898718713.
  23. S. J. Hammarling, Numerical solution of the stable non-negative definite Lyapunov equation Lyapunov equation, IMA J. Numer. Anal. 2, 303 (1982).
  24. A. Laub, A Schur method for solving algebraic Riccati equations, IEEE Trans. Autom. Control 24, 913 (1979).
  25. A. J. Laub, Invariant subspace methods for the numerical solution of Riccati equations, in The Riccati Equation, Communications and Control Engineering Series, edited by S. Bittanti, A. J. Laub, and J. C. Willems (Springer, Berlin, Heidelberg, 1991), pp. 163–196, 10.1007/978-3-642-58223-3_7.
  26. P. Van Dooren, A generalized eigenvalue approach for solving Riccati equations, SIAM J. Sci. Stat. Comput. 2, 121 (1981).
  27. R. James, J. Langou, and B. R. Lowery, On matrix balancing and eigenvector computation, arXiv:1401.5766.
  28. B. N. Parlett and C. Reinsch, Balancing a matrix for calculation of eigenvalues and eigenvectors, Numer. Math. 13, 293 (1969).
  29. M. Şuşcă, V. Mihaly, M. Stănese, and P. Dobra, Iterative refinement procedure for solutions to algebraic Riccati equations, in 2020 IEEE International Conference on Automation, Quality and Testing, Robotics (2020), pp. 1–5, 10.1109/AQTR49680.2020.9130027.
  30. A. Varga, Computation of irreducible generalized state-space realizations, Kybernetika 26, 89 (1990), https://dml.cz/handle/10338.dmlcz/124686.
  31. A. Varga and K. H. Fasol, A new square-root balancing-free stochastic truncation model reduction algorithm, IFAC Proceedings Volumes series 12th Triennal Wold Congress of the International Federation of Automatic Control. Volume 1 Theory, Sydney, Australia, 18–23 July, 26, 469 (1993), 10.1016/S1474-6670(17)49168-3.
  32. P. Benner, V. Mehrmann, V. Sima, S. Van Huffel, and A. Varga, SLICOT: A subroutine library in systems and control theory, in Applied and Computational Control, Signals, and Circuits: Volume 1, edited by B. N. Datta (Birkhäuser, Boston, MA, 1999), pp. 499–539, 10.1007/978-1-4612-0571-5_10.
  33. M. G. Safonov, D. J. N. Limebeer, and R. Y. Chiang, Simplifying the H∞ theory via loop-shifting, matrix-pencil and descriptor concepts, Int. J. Control 50, 2467 (1989).
  34. D. Lemonnier and P. Van Dooren, Balancing regular matrix pencils, SIAM J. Matrix Anal. Appl. 28, 253 (2006).
  35. R. C. Ward, Balancing the generalized eigenvalue problem, SIAM J. Sci. Stat. Comput. 2, 141 (1981).
  36. Y. Liu and B. Anderson, Singular perturbation approximation of balanced systems, in Proceedings of the 28th IEEE Conference on Decision and Control, Vol. 2 (1989), pp. 1355–1360, 10.1109/CDC.1989.70360.
  37. N. A. Bruinsma and M. Steinbuch, A fast algorithm to compute the H∞-norm of a transfer function matrix, Systems and Control Letters 14, 287 (1990).

  38. The solution presented here, adapted from [13], is less general than the solution to the LQG problem, given in Sec. 6c. The Glover-Doyle solution is more general, although it goes beyond the needs of most H∞ controllers [16, 39].

  39. J.-L. Hong and C.-C. Teng, A derivation of the Glover-Doyle algorithms for general H∞ control problems, Automatica 32, 581 (1996).
  40. P. M. Gahinet, Troubleshooting for state-space H∞ design, in 1992 American Control Conference (1992), pp. 634–638, 10.23919/ACC.1992.4792146.
  41. J. Doyle, K. Zhou, and B. Bodenheimer, Optimal control with mixed H2 and H∞ performance objectives, in 1989 American Control Conference (1989), pp. 2065–2070, 10.23919/ACC.1989.4790529.
  42. H.-H. Yeh, S. Banda, and B.-C. Chang, Necessary and sufficient conditions for mixed H2 and H∞ optimal control, IEEE Trans. Autom. Control 37, 355 (1992).
  43. P. Khargonekar and M. Rotea, Mixed H2/H∞ control: A convex optimization approach, IEEE Trans. Autom. Control 36, 824 (1991).
  44. M. Rotea and T. Iwasaki, Generalized H2/H∞ control: General formulas, in Proceedings of the 1995 34th IEEE Conference Decision Control, Vol. 3 (1995), pp. 3158–3163, 10.1109/CDC.1995.478633.
  45. M. A. Rotea and P. P. Khargonekar, Generalized H2/H∞ control, in Robust Control Theory, The IMA Volumes in Mathematics and Its Applications, edited by B. A. Francis and P. P. Khargonekar (Springer, New York, NY, 1995), pp. 81–103, 10.1007/978-1-4613-8451-9_5.
  46. V. Kapila and W. M. Haddad, H2 and mixed H2/H∞ stable stabilization, in Proceedings of the 34th Conference on Decision and Control (1995), Vol. 2, pp. 1911–1916.
  47. Y. W. Wang, W. M. Haddad, and D. S. Bernstein, Stable stabilization with H2 and H∞ performance constraints, J. Math. Syst. Estim. Control 6, 181 (1996), https://websites.umich.edu/~dsbaero/library/WangH2Hinfinity1.pdf.
  48. M. Athans, The matrix minimum principle, Inf. Control 11, 592 (1967).
