Quasinormal modes from numerical relativity with Bayesian inference

Richard Dyer1,* and Christopher J. Moore1,2,3,†

  • *Contact author: richard.dyer@ast.cam.ac.uk
  • †Contact author: christopher.moore@ast.cam.ac.uk
PDF

Phys. Rev. D 113, 104031 – Published 13 May, 2026

DOI: https://doi.org/10.1103/pb4k-ng6l

Abstract

Numerical relativity (NR) enables the study of physics in strong and dynamical gravitational fields and provides predictions for the gravitational wave signals produced by merging black holes. Despite the impressive accuracy of modern codes, the resulting waveforms inevitably contain numerical uncertainties. Quantifying these uncertainties is important, especially for studies probing subdominant or nonlinear effects around the merger and ringdown. This paper describes a flexible Gaussian process model for the numerical uncertainties in all the spherical-harmonic waveform modes across a state-of-the-art catalog of NR waveforms and a highly efficient procedure for sampling the posteriors of quasinormal mode models without the need for expensive Markov chain Monte Carlo. The Gaussian process model is used to define a likelihood function which allows many Bayesian data analysis techniques—already widely used in the analysis of experimental gravitational wave data—to be applied to NR waveforms as well. The efficacy of this approach is demonstrated by applying it to the analysis of quasinormal modes in Cauchy characteristic evolved waveforms.

View figure in article

Physics Subject Headings (PhySH)

See Also

Quasinormal Mode Content of Binary Black Hole Ringdowns

Richard Dyer and Christopher J. Moore
Phys. Rev. Lett. 136, 191403 (2026)

Article Text

References (71)

  1. E. Berti, V. Cardoso, and A. O. Starinets, Classical Quantum Gravity 26, 163001 (2009).
  2. B. Carter, Phys. Rev. Lett. 26, 331 (1971).
  3. O. Dreyer, B. Kelly, B. Krishnan, L. S. Finn, D. Garrison, and R. Lopez-Aleman, Classical Quantum Gravity 21, 787 (2004).
  4. E. Berti, V. Cardoso, G. Carullo, and J. Abedi, arXiv:2505.23895.
  5. J. Aasi, B. P. Abbott, R. Abbott, and Abbott, Classical Quantum Gravity 32, 074001 (2015).
  6. F. Acernese, M. Agathos, K. Agatsuma, D. Aisa, and N. Allemandou, Classical Quantum Gravity 32, 024001 (2014).
  7. LIGO Scientific, Virgo, and KAGRA Collaborations, arXiv:2508.18082.
  8. B. P. Abbott, R. Abbott, T. D. Abbott, S. Abraham, F. Acernese, K. Ackley, and C. Adams, Living Rev. Relativity 23, 3 (2020).
  9. LIGO Scientific, Virgo, and KAGRA Collaborations et al., Phys. Rev. D 112, 084080 (2025).
  10. LIGO Scientific, Virgo, and KAGRA Collaborations et al., arXiv:2509.07348.
  11. LIGO Scientific, Virgo, and KAGRA Collaborations, Phys. Rev. Lett. 136, 041403 (2026).
  12. C. D. Capano, M. Cabero, J. Westerweck, J. Abedi, S. Kastha, A. H. Nitz, Y.-F. Wang, A. B. Nielsen, and B. Krishnan, Phys. Rev. Lett. 131, 221402 (2023).
  13. R. Cotesta, G. Carullo, E. Berti, and V. Cardoso, Phys. Rev. Lett. 129, 111102 (2022).
  14. E. Finch and C. J. Moore, Phys. Rev. D 106, 043005 (2022).
  15. A. Correia, Y.-F. Wang, J. Westerweck, and C. D. Capano, Phys. Rev. D 110, L041501 (2024).
  16. M. Isi, M. Giesler, W. M. Farr, M. A. Scheel, and S. A. Teukolsky, Phys. Rev. Lett. 123, 111102 (2019).
  17. M. Cabero, C. D. Capano, O. Fischer-Birnholtz, B. Krishnan, A. B. Nielsen, A. H. Nitz, and C. M. Biwer, Phys. Rev. D 97, 124069 (2018).
  18. M. Isi, W. M. Farr, M. Giesler, M. A. Scheel, and S. A. Teukolsky, Phys. Rev. Lett. 127, 011103 (2021).
  19. A. G. Abac et al., Phys. Rev. Lett. 135, 111403 (2025).
  20. M. Giesler, M. Isi, M. A. Scheel, and S. A. Teukolsky, Phys. Rev. X 9, 041060 (2019).
  21. G. B. Cook, Phys. Rev. D 102, 024027 (2020).
  22. L. Magaña Zertuche et al., Phys. Rev. D 105, 104015 (2022).
  23. L. M. Zertuche, L. Gao, E. Finch, and G. B. Cook, Classical Quantum Gravity 42, 197001 (2025).
  24. L. London, D. Shoemaker, and J. Healy, Phys. Rev. D 90, 124032 (2014).
  25. L. London, Phys. Rev. D 102, 084052 (2020).
  26. M. H.-Y. Cheung, E. Berti, V. Baibhav, and R. Cotesta, Phys. Rev. D 109, 044069 (2024).
  27. C. Pacilio, S. Bhagwat, F. Nobili, and D. Gerosa, Phys. Rev. D 110, 103037 (2024).
  28. R. Dyer and C. J. Moore, Phys. Rev. D 111, 024002 (2025).
  29. K. Mitman, M. Lagos, L. C. Stein, S. Ma, L. Hui, Y. Chen, N. Deppe, F. Hébert, L. E. Kidder, J. Moxon, M. A. Scheel, S. A. Teukolsky, W. Throwe, and N. L. Vu, Phys. Rev. Lett. 130, 081402 (2023).
  30. M. H.-Y. Cheung, V. Baibhav, E. Berti, V. Cardoso, G. Carullo, R. Cotesta, W. Del Pozzo, F. Duque, T. Helfer, E. Shukla, and K. W. K. Wong, Phys. Rev. Lett. 130, 081401 (2023).
  31. K. Takahashi and H. Motohashi, Classical Quantum Gravity 41, 195023 (2024).
  32. S. H. Völkel and A. Dhani, Phys. Rev. D 112, 084076 (2025).
  33. S. Ma, K. Mitman, L. Sun, N. Deppe, F. Hébert, L. E. Kidder, J. Moxon, W. Throwe, N. L. Vu, and Y. Chen, Phys. Rev. D 106, 084036 (2022).
  34. T. A. Clarke, M. Isi, P. D. Lasky, E. Thrane, M. Boyle, N. Deppe, L. E. Kidder, K. Mitman, J. Moxon, K. C. Nelli, W. Throwe, and N. L. Vu, Phys. Rev. D 109, 124030 (2024).
  35. J. Redondo-Yuste, G. Carullo, J. L. Ripley, E. Berti, and V. Cardoso, Phys. Rev. D 109, L101503 (2024).
  36. G. Carullo, J. Cosmol. Astropart. Phys. 10 (2024) 061.
  37. R. Dyer and C. J. Moore, companion Letter, Phys. Rev. Lett. 136, 191403 (2026).
  38. S. Ma, M. A. Scheel, J. Moxon, K. C. Nelli, N. Deppe, L. E. Kidder, W. Throwe, and N. L. Vu, Phys. Rev. D 112, 024003 (2025).
  39. N. Deppe et al., spectre v2024.09.29, 2024, 10.5281/zenodo.13858965.
  40. J. Moxon, M. A. Scheel, S. A. Teukolsky, N. Deppe, N. Vu, F. Hébert, L. E. Kidder, and W. Throwe, Phys. Rev. D 107, 064013 (2023).
  41. L. C. Stein, J. Open Source Software 4, 1683 (2019).
  42. C. E. Rasmussen and C. K. I. Williams, Gaussian Processes for Machine Learning (The MIT Press, Cambridge, MA, 2006).
  43. A. Kong, A note on importance sampling using standardized weights, The University of Chicago Technical Report No. 348, 1992.
  44. The sxs project, sxs Ext-CCE waveform database, 2024, https://data.black-holes.org/waveforms/extcce_catalog.html [Accessed: August 2024].
  45. M. Boyle et al., Classical Quantum Gravity 36, 195006 (2019).
  46. J. Moxon, M. A. Scheel, and S. A. Teukolsky, Phys. Rev. D 102, 044052 (2020).
  47. M. Boyle, D. Iozzo, and L. C. Stein, moble/scri: v1.2, 2020, 10.5281/zenodo.4041972.
  48. M. Boyle, Phys. Rev. D 87, 104006 (2013).
  49. M. Boyle, L. E. Kidder, S. Ossokine, and H. P. Pfeiffer, arXiv:1409.4431.
  50. M. Boyle, Phys. Rev. D 93, 084031 (2016).
  51. K. Mitman, M. Boyle, L. C. Stein, N. Deppe, L. E. Kidder, J. Moxon, H. P. Pfeiffer, M. A. Scheel, S. A. Teukolsky, W. Throwe, and N. L. Vu, Classical Quantum Gravity 41, 223001 (2024).
  52. K. Mitman et al., Phys. Rev. D 106, 084029 (2022).
  53. K. Mitman, I. Pretto, H. Siegel, M. A. Scheel, S. A. Teukolsky, M. Boyle, N. Deppe, L. E. Kidder, J. Moxon, K. C. Nelli, W. Throwe, and N. L. Vu, Phys. Rev. D 112, 064016 (2025).
  54. P. Hennig, M. A. Osborne, and M. Girolami, Proc. R. Soc. A 471, 20150142 (2015).
  55. E. Finch and C. J. Moore, Phys. Rev. D 103, 084048 (2021).
  56. A. Dhani, Phys. Rev. D 103, 104048 (2021).
  57. X. J. Forteza and P. Mourier, Phys. Rev. D 104, 124072 (2021).
  58. R. Dyer and C. J. Moore, Bayesian qnmfits methods figures, 2024, https://github.com/BGP-QNM-FITS/bgp_methods [Accessed: August 2024].
  59. C. R. Harris et al., Nature (London) 585, 357 (2020).
  60. P. Virtanen et al. (SciPy 1.0 Contributors), Nat. Methods 17, 261 (2020).
  61. J. D. Hunter, Comput. Sci. Eng. 9, 90 (2007).
  62. J. Bradbury, R. Frostig, P. Hawkins, M. J. Johnson, C. Leary, D. Maclaurin, G. Necula, A. Paszke, J. VanderPlas, S. Wanderman-Milne, and Q. Zhang, jax: Composable transformations of python + numpy programs (2018), http://github.com/jax-ml/jax.
  63. M. L. Waskom, J. Open Source Software 6, 3021 (2021).
  64. The Pandas Development Team, pandas-dev/pandas: pandas, 10.5281/zenodo.3509134 (2020).
  65. L. M. Zertuche and E. Finch, qnmfits, https://github.com/sxs-collaboration/qnmfits.
  66. M. Boyle, K. Mitman, M. Scheel, and L. Stein, The sxs package, 10.5281/zenodo.4034006(2021).
  67. R. Dyer and C. J. Moore, Bayesian qnmfits code, 2024, https://github.com/BGP-QNM-FITS/bgp_qnm_fits [Accessed: August 2024].
  68. H. Zhu, F. Pretorius, S. Ma, R. Owen, Y. Chen, N. Deppe, L. E. Kidder, M. Okounkova, H. P. Pfeiffer, M. A. Scheel, and L. C. Stein, Phys. Rev. D 110, 124028 (2024).
  69. N. Lu, S. Ma, O. J. Piccinni, L. Sun, and E. Finch, Phys. Rev. D 112, 064047 (2025).
  70. K. Mitman (private communication).
  71. M. Giesler, S. Ma, K. Mitman, N. Oshita, S. A. Teukolsky, M. Boyle, N. Deppe, L. E. Kidder, J. Moxon, K. C. Nelli, H. P. Pfeiffer, M. A. Scheel, W. Throwe, and N. L. Vu, Phys. Rev. D 111, 084041 (2025).
