Complete classification of domain wall solutions in the Z2-symmetric 2HDM

Richard A. Battye*, Steven J. Cotterill†, and Adam K. Thomasson‡

  • *Contact author: richard.battye@manchester.ac.uk
  • †Contact author: steven.cotterill@manchester.ac.uk
  • ‡Contact author: adam.thomasson@manchester.ac.uk
PDF

Phys. Rev. D 112, 115015 – Published 4 December, 2025

DOI: https://doi.org/10.1103/p1sq-38cc

Abstract

We present a complete classification of domain wall solutions in the two-Higgs-doublet model (2HDM) with a global Z2 symmetry, categorized as superconducting, CP-violating, or neither, depending on the scalar particle masses and the ratio of the two Higgs doublets’ vacuum expectation values. We demonstrate that any domain wall solution can be reduced to depend on only six of the eight general field components, with further field reductions possible within different regions of the parameter space. Furthermore, we show that the superconducting solutions can be used to construct stable, current-carrying domain walls in two spatial dimensions. Similarly, the CP-violating solutions allow for two-dimensional configurations where CP symmetry is locally broken on the Z2-symmetric wall, which could provide an out-of-equilibrium environment for CP-violating processes to occur.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (50)

  1. T. W. B. Kibble, Topology of cosmic domains and strings, J. Phys. A 9, 1387 (1976).
  2. A. Vilenkin and E. P. S. Shellard, Cosmic Strings and Other Topological Defects, Cambridge Monographs on Mathematical Physics (Cambridge University Press, Cambridge, England, 1994).
  3. Ya. B. Zel’Dovich, I. Yu. Kobzarev, and L. B. Okun, Cosmological consequences of a spontaneous breakdown of a discrete symmetry, J. Exp. Theor. Phys. 40, 1 (1974).
  4. S. E. Larsson, S. Sarkar, and P. L. White, Evading the cosmological domain wall problem, Phys. Rev. D 55, 5129 (1997).
  5. B. Cyr, S. Cotterill, and R. Battye, Near-peak spectrum of gravitational waves from collapsing domain walls, arXiv:2504.02076.
  6. T. Hiramatsu, M. Kawasaki, and K. Saikawa, Gravitational waves from collapsing domain walls, J. Cosmol. Astropart. Phys. 05 (2010) 032.
  7. H. M. Hodges, Domain walls with bound Bose condensates, Phys. Rev. D 37, 3052 (1988).
  8. R. A. Battye and P. M. Sutcliffe, Kinky vortons, Nucl. Phys. B805, 287 (2008).
  9. T. D. Lee, A theory of spontaneous t violation, Phys. Rev. D 8, 1226 (1973).
  10. G. Branco, P. Ferreira, L. Lavoura, M. Rebelo, M. Sher, and J. P. Silva, Theory and phenomenology of two-Higgs-doublet models, Phys. Rep. 516, 1102 (2012).
  11. A. Pilaftsis and C. E. Wagner, Higgs bosons in the minimal supersymmetric standard model with explicit CP violation, Nucl. Phys. B553, 342 (1999).
  12. V. Keus, S. F. King, S. Moretti, and K. Yagyu, CP violating two-Higgs-doublet model: Constraints and LHC predictions, J. High Energy Phys. 04 (2016) 124.
  13. A. G. Cohen, D. B. Kaplan, and A. E. Nelson, Progress in electroweak baryogenesis, Annu. Rev. Nucl. Part. Sci. 43, 27 (1993).
  14. L. Fromme, S. J. Huber, and M. Seniuch, Baryogenesis in the two-Higgs doublet model, J. High Energy Phys. 11 (2006) 038.
  15. B. Grzadkowski, O. M. Ogreid, and P. Osland, Natural multi-Higgs model with dark matter and CP violation, Phys. Rev. D 80, 055013 (2009).
  16. G. Dorsch, S. Huber, T. Konstandin, and J. No, A second Higgs doublet in the early Universe: Baryogenesis and gravitational waves, J. Cosmol. Astropart. Phys. 05 (2017) 052.
  17. D. A. Camargo, M. D. Campos, T. B. de Melo, and F. S. Queiroz, A two Higgs doublet model for dark matter and neutrino masses, Phys. Lett. B 795, 319326 (2019).
  18. R. A. Battye, G. D. Brawn, and A. Pilaftsis, Vacuum topology of the two Higgs doublet model, J. High Energy Phys. 08 (2011) 020.
  19. N. Chen, T. Li, Z. Teng, and Y. Wu, Collapsing domain walls in the two-Higgs-doublet model and deep insights from the EDM, J. High Energy Phys. 10 (2020) 081.
  20. M. Eto, M. Kurachi, and M. Nitta, Constraints on two Higgs doublet models from domain walls, Phys. Lett. B 785, 447 (2018).
  21. R. A. Battye, A. Pilaftsis, and D. G. Viatic, Domain wall constraints on two-Higgs-doublet models with z2 symmetry, Phys. Rev. D 102, 123536 (2020).
  22. R. A. Battye, A. Pilaftsis, and D. G. Viatic, Simulations of domain walls in two Higgs doublet models, J. High Energy Phys. 01 (2021) 105.
  23. K. H. Law and A. Pilaftsis, Charged and CP-violating kink solutions in the two-Higgs-doublet model, Phys. Rev. D 105, 056007 (2022).
  24. R. A. Battye and D. G. Viatic, Photon interactions with superconducting topological defects, Phys. Lett. B 823, 136730 (2021).
  25. M. Y. Sassi and G. Moortgat-Pick, Domain walls in the two-Higgs-doublet model and their charge and CP-violating interactions with standard model fermions, J. High Energy Phys. 04 (2024) 101.
  26. R. A. Battye, S. J. Cotterill, E. S. Andres, and A. K. Thomasson, Percolation of domain walls in the two-Higgs doublet model, Phys. Lett. B 862, 139311 (2025).
  27. R. A. Battye, J. A. Pearson, P. M. Sutcliffe, and S. Pike, Formation and evolution of kinky vortons, J. Cosmol. Astropart. Phys. 09 (2009) 039.
  28. R. A. Battye and P. M. Sutcliffe, Stability and the equation of state for kinky vortons, Phys. Rev. D 80, 085024 (2009).
  29. E. Witten, Superconducting strings, Nucl. Phys. B249, 557 (1985).
  30. R. Davis and E. Shellard, Cosmic vortons, Nucl. Phys. B323, 209 (1989).
  31. Y. Lemperiere and E. P. S. Shellard, Vorton existence and stability, Phys. Rev. Lett. 91, 141601 (2003).
  32. R. A. Battye and P. M. Sutcliffe, Vorton construction and dynamics, Nucl. Phys. B814, 180 (2009).
  33. R. A. Battye and S. J. Cotterill, Stable cosmic vortons in bosonic field theory, Phys. Rev. Lett. 127, 241601 (2021).
  34. R. A. Battye, S. J. Cotterill, and J. A. Pearson, A detailed study of the stability of vortons, J. High Energy Phys. 04 (2022) 005.
  35. I. P. Ivanov, Minkowski space structure of the Higgs potential in 2HDM, Phys. Rev. D 75, 035001 (2007); 76, 039902(E) (2007).
  36. I. P. Ivanov, Minkowski space structure of the Higgs potential in the two-Higgs-doublet model: II. Minima, symmetries, and topology, Phys. Rev. D 77, 015017 (2008).
  37. M. Maniatis, A. von Manteuffel, O. Nachtmann, and F. Nagel, Stability and symmetry breaking in the general two-Higgs-doublet model, Eur. Phys. J. C 48, 805823 (2006).
  38. R. A. Battye, S. J. Cotterill, and D. G. Viatic, Global monopoles in the two-Higgs-doublet-model, Phys. Lett. B 844, 138091 (2023).
  39. A. Arbey, F. Mahmoudi, O. Stl, and T. Stefaniak, Status of the charged Higgs boson in two Higgs doublet models, Eur. Phys. J. C 78, 182 (2018).
  40. R. L. Workman et al. (Particle Data Group), Review of particle physics, Prog. Theor. Exp. Phys. 2022, 083C01 (2022).
  41. H. Goldstein, C. P. Poole, and J. L. Safko, Classical Mechanics, 3rd ed. (Addison-Wesley, New York, 2002).
  42. L. D. Landau and E. M. Lifshitz, Mechanics, 3rd ed. (Butterworth-Heinemann, London, 1976).
  43. V. I. Arnold, Mathematical Methods of Classical Mechanics, 2nd ed. (Springer, New York, 1989).
  44. R. A. Battye and S. J. Cotterill, Spontaneous Hopf fibration in the two-Higgs-doublet model, Phys. Rev. Lett. 132, 061601 (2024).
  45. R. A. Battye and S. J. Cotterill, Superconducting strings in the two-Higgs doublet model, Phys. Lett. B 868, 139714 (2025).
  46. Y. Lemperiere and E. Shellard, On the behaviour and stability of superconducting currents, Nucl. Phys. B649, 511 (2003).
  47. B. Carter and X. Martin, Dynamic instability criterion for circular string loops, Ann. Phys. (N.Y.) 227, 151 (1993).
  48. R. A. Battye, S. J. Cotterill, and J. A. Pearson, A detailed study of the stability of vortons, J. High Energy Phys. 04 (2022) 005.
  49. R. A. Battye and S. J. Cotterill, Pinching instabilities in superconducting cosmic strings, Phys. Rev. D 107, 063534 (2023).
  50. A. D. Sakharov, Violation of CP invariance, C asymmetry, and baryon asymmetry of the universe, Pis’ma Zh. Eksp. Teor. Fiz. 5, 32 (1967).
