Hadroproduction data support tetraquark hypothesis for χc1(3872)

Wai Kin Lai1,2,* and Hee Sok Chung3,†

  • *Contact author: samlai2357@gmail.com
  • †Contact author: heesokchung@gwnu.ac.kr
PDF

Phys. Rev. D 112, 054005 – Published 4 September, 2025

DOI: https://doi.org/10.1103/lkff-d2ph

Abstract

We show that the recently proposed tetraquark hypothesis for the nature of the χc1(3872) results in a formalism for inclusive production rates that has no unknown parameters. We employ this formalism to compute hadroproduction rates of χc1(3872) at the Large Hadron Collider, which agree with measured prompt and nonprompt cross sections. Thus, we find that the tetraquark hypothesis for χc1(3872) is well supported by hadroproduction data.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (62)

  1. S. K. Choi et al. (Belle Collaboration), Observation of a narrow charmonium-like state in exclusive B±→K±π+π−J/ψ decays, Phys. Rev. Lett. 91, 262001 (2003).
  2. D. Acosta et al. (CDF Collaboration), Observation of the narrow state X(3872)→J/ψπ+π− in p¯p collisions at s=1.96  TeV, Phys. Rev. Lett. 93, 072001 (2004).
  3. V. M. Abazov et al. (D0 Collaboration), Observation and properties of the X(3872) decaying to J/ψπ+π− in pp¯ collisions at s=1.96  TeV, Phys. Rev. Lett. 93, 162002 (2004).
  4. B. Aubert et al. (BABAR Collaboration, Study of the B→J/ψK−π+π− decay and measurement of the B→X(3872)K− branching fraction, Phys. Rev. D 71, 071103 (2005).
  5. M. Gell-Mann, A schematic model of baryons and mesons, Phys. Lett. 8, 214 (1964).
  6. G. Zweig, An SU(3) model for strong interaction symmetry and its breaking. Version 1, 10.17181/CERN-TH-401 (1964).
  7. R. Aaij et al. (LHCb Collaboration), Determination of the X(3872) meson quantum numbers, Phys. Rev. Lett. 110, 222001 (2013).
  8. R. Aaij et al. (LHCb Collaboration), Quantum numbers of the X(3872) state and orbital angular momentum in its ρ0Jψ decay, Phys. Rev. D 92, 011102 (2015).
  9. T. Barnes and S. Godfrey, Charmonium options for the X(3872), Phys. Rev. D 69, 054008 (2004).
  10. N. A. Tornqvist, Isospin breaking of the narrow charmonium state of Belle at 3872-MeV as a deuson, Phys. Lett. B 590, 209 (2004).
  11. M. B. Voloshin, Interference and binding effects in decays of possible molecular component of X(3872), Phys. Lett. B 579, 316 (2004).
  12. F. E. Close and P. R. Page, The D*0D¯0 threshold resonance, Phys. Lett. B 578, 119 (2004).
  13. C.-Y. Wong, Molecular states of heavy quark mesons, Phys. Rev. C 69, 055202 (2004).
  14. E. Braaten and M. Kusunoki, Low-energy universality and the new charmonium resonance at 3870-MeV, Phys. Rev. D 69, 074005 (2004).
  15. E. S. Swanson, Short range structure in the X(3872), Phys. Lett. B 588, 189 (2004).
  16. F. E. Close and S. Godfrey, Charmonium hybrid production in exclusive B meson decays, Phys. Lett. B 574, 210 (2003).
  17. B. A. Li, Is X(3872) a possible candidate of hybrid meson, Phys. Lett. B 605, 306 (2005).
  18. L. Maiani, F. Piccinini, A. D. Polosa, and V. Riquer, Diquark-antidiquarks with hidden or open charm and the nature of X(3872), Phys. Rev. D 71, 014028 (2005).
  19. E. J. Eichten, K. Lane, and C. Quigg, B meson gateways to missing charmonium levels, Phys. Rev. Lett. 89, 162002 (2002).
  20. E. J. Eichten, K. Lane, and C. Quigg, Charmonium levels near threshold and the narrow state X(3872)→π+π−J/ψ, Phys. Rev. D 69, 094019 (2004).
  21. C. Bignamini, B. Grinstein, F. Piccinini, A. D. Polosa, and C. Sabelli, Is the X(3872) production cross section at tevatron compatible with a hadron molecule interpretation?, Phys. Rev. Lett. 103, 162001 (2009).
  22. S. Chatrchyan et al. (CMS Collaboration), Measurement of the X(3872) production cross section via decays to J/ψπ+π− in pp collisions at s=7  TeV, J. High Energy Phys. 04(2013) 154.
  23. M. Aaboud et al. (ATLAS Collaboration), Measurements of ψ(2S) and X(3872)→J/ψπ+π− production in pp collisions at s=8  TeV with the ATLAS detector, J. High Energy Phys. 01 (2017) 117.
  24. R. Aaij et al. (LHCb Collaboration), Measurement of χc1(3872) production in proton-proton collisions at s= 8 and 13 TeV, J. High Energy Phys. 01 (2022) 131.
  25. P. Artoisenet and E. Braaten, Production of the X(3872) at the tevatron and the LHC, Phys. Rev. D 81, 114018 (2010).
  26. M. Butenschoen, Z.-G. He, and B. A. Kniehl, NLO NRQCD disfavors the interpretation of X(3872) as χc1(2P), Phys. Rev. D 88, 011501 (2013).
  27. C. Meng, Y.-J. Gao, and K.-T. Chao, B→ χc1(1P,2P)K decays in QCD factorization and X(3872), Phys. Rev. D 87, 074035 (2013).
  28. C. Meng, H. Han, and K.-T. Chao, X(3872) and its production at hadron colliders, Phys. Rev. D 96, 074014 (2017).
  29. B. Grinstein, L. Maiani, and A. D. Polosa, Radiative decays of X(3872) discriminate between the molecular and compact interpretations, Phys. Rev. D 109, 074009 (2024).
  30. E. Braaten and R. Bruschini, Exotic hidden-heavy hadrons and where to find them, Phys. Lett. B 863, 139386 (2025).
  31. N. Brambilla, A. Mohapatra, T. Scirpa, and A. Vairo, The nature of χc1(3872) and Tcc+(3875), arXiv:2411.14306.
  32. M. Born and R. Oppenheimer, Zur Quantentheorie der Molekeln, Ann. Phys. (Berlin) 389, 457 (1927).
  33. K. J. Juge, J. Kuti, and C. J. Morningstar, Ab initio study of hybrid b¯g b mesons, Phys. Rev. Lett. 82, 4400 (1999).
  34. E. Braaten, C. Langmack, and D. H. Smith, Born-Oppenheimer approximation for the XYZ mesons, Phys. Rev. D 90, 014044 (2014).
  35. M. Berwein, N. Brambilla, J. Tarrús Castellà, and A. Vairo, Quarkonium hybrids with nonrelativistic effective field theories, Phys. Rev. D 92, 114019 (2015).
  36. R. Oncala and J. Soto, Heavy quarkonium hybrids: Spectrum, decay and mixing, Phys. Rev. D 96, 014004 (2017).
  37. N. Brambilla, W. K. Lai, J. Segovia, J. Tarrús Castellà, and A. Vairo, Spin structure of heavy-quark hybrids, Phys. Rev. D 99, 014017 (2019); 101, 099902(E) (2020).
  38. N. Brambilla, W. K. Lai, J. Segovia, and J. Tarrús Castellà, QCD spin effects in the heavy hybrid potentials and spectra, Phys. Rev. D 101, 054040 (2020).
  39. L. Maiani, A. D. Polosa, and V. Riquer, Hydrogen bond of QCD, Phys. Rev. D 100, 014002 (2019).
  40. M. Berwein, N. Brambilla, A. Mohapatra, and A. Vairo, Hybrids, tetraquarks, pentaquarks, doubly heavy baryons, and quarkonia in Born-Oppenheimer effective theory, Phys. Rev. D 110, 094040 (2024).
  41. G. T. Bodwin, E. Braaten, and G. P. Lepage, Rigorous QCD analysis of inclusive annihilation and production of heavy quarkonium, Phys. Rev. D 51, 1125 (1995); 55, 5853(E) (1997).
  42. M. Beneke, F. Maltoni, and I. Z. Rothstein, QCD analysis of inclusive B decay into charmonium, Phys. Rev. D 59, 054003 (1999).
  43. M. Cacciari, M. Greco, and P. Nason, The pT spectrum in heavy-flavour hadroproduction., J. High Energy Phys. 05 (1998) 007.
  44. M. Cacciari, S. Frixione, and P. Nason, The pT spectrum in heavy flavor photoproduction, J. High Energy Phys. 03 (2001) 006.
  45. L.-P. Wan and J.-X. Wang, fdchqhp: A Fortran package for heavy quarkonium hadroproduction, Comput. Phys. Commun. 185, 2939 (2014).
  46. H. S. Chung, U.-R. Kim, and J. Lee, Resummation of threshold double logarithms in hadroproduction of heavy quarkonium, Phys. Rev. Lett. 134, 071902 (2025).
  47. V. N. Gribov and L. N. Lipatov, Deep inelastic e p scattering in perturbation theory, Sov. J. Nucl. Phys. 15, 438 (1972).
  48. L. N. Lipatov, The parton model, and perturbation theory, Yad. Fiz. 20, 181 (1974) [Sov. J. Nucl. Phys. 20, 94 (1975)].
  49. Y. L. Dokshitzer, Calculation of the structure functions for deep inelastic scattering and e+e− annihilation by perturbation theory in quantum chromodynamics, Sov. Phys. JETP 46, 641 (1977).
  50. G. Altarelli and G. Parisi, Asymptotic freedom in parton language, Nucl. Phys. B126, 298 (1977).
  51. N. Brambilla, H. S. Chung, and A. Vairo, Inclusive hadroproduction of P-wave heavy quarkonia in potential nonrelativistic QCD, Phys. Rev. Lett. 126, 082003 (2021).
  52. N. Brambilla, H. S. Chung, and A. Vairo, Inclusive production of heavy quarkonia in pNRQCD, J. High Energy Phys. 09 (2021) 032.
  53. N. Brambilla, H. S. Chung, A. Vairo, and X.-P. Wang, Production and polarization of S-wave quarkonia in potential nonrelativistic QCD, Phys. Rev. D 105, L111503 (2022).
  54. N. Brambilla, H. S. Chung, A. Vairo, and X.-P. Wang, Inclusive production of J/ψ, ψ(2S), and ϒ states in pNRQCD, J. High Energy Phys. 03 (2023) 242.
  55. G. C. Nayak, J.-W. Qiu, and G. F. Sterman, Fragmentation, factorization and infrared poles in heavy quarkonium production, Phys. Lett. B 613, 45 (2005).
  56. S. Navas et al. (Particle Data Group), Review of particle physics, Phys. Rev. D 110, 030001 (2024).
  57. E. Braaten and S. Fleming, Color octet fragmentation and the psi-prime surplus at the Tevatron, Phys. Rev. Lett. 74, 3327 (1995).
  58. H. S. Chung, Review of quarkonium production: Status and prospects, Proc. Sci. Confinement2018 (2018) 007 [arXiv:1811.12098].
  59. H. S. Chung, Quarkonium production and polarization: Where do we stand?, EPJ Web Conf. 274, 01011 (2022).
  60. G. T. Bodwin, H. S. Chung, U.-R. Kim, and J. Lee, Fragmentation contributions to J/ψ production at the Tevatron and the LHC, Phys. Rev. Lett. 113, 022001 (2014).
  61. G. T. Bodwin, K.-T. Chao, H. S. Chung, U.-R. Kim, J. Lee, and Y.-Q. Ma, Fragmentation contributions to hadroproduction of prompt J/ψ, χcJ, and ψ(2S) states, Phys. Rev. D 93, 034041 (2016).
  62. A.-P. Chen, X.-B. Jin, Y.-Q. Ma, and C. Meng, Fragmentation function of g→ QQ¯(S31[8]) in soft gluon factorization and threshold resummation, J. High Energy Phys. 06 (2021) 046.

Outline

Information

Phys. Rev. D 112, 054005– Published 4 September, 2025
  • Received 14 May 2025
  • Accepted 13 August 2025
Crossmark - Check for updates button
Creative Commons Logo

Published by the American Physical Society under the terms of the Creative Commons Attribution 4.0 International license. Further distribution of this work must maintain attribution to the author(s) and the published article’s title, journal citation, and DOI. Funded by SCOAP3.
