Fast numerical evaluation of dark matter direct detection event rates

Sebastian Sassi*, Aula Al-Adulrazzaq†, Matti Heikinheimo‡, and Kimmo Tuominen§

  • *Contact author: sebastian.k.sassi@helsinki.fi
  • †Contact author: aula.al-adulrazzaq@helsinki.fi
  • ‡Contact author: matti.heikinheimo@helsinki.fi
  • §Contact author: kimmo.i.tuominen@helsinki.fi
PDF

Phys. Rev. D 112, 043003 – Published 1 August, 2025

DOI: https://doi.org/10.1103/jzmc-r2k6

Abstract

The mathematical expression for the dark matter nuclear recoil event rate in a detector consists of a six-dimensional integral over the velocity distribution of dark matter in the detector frame and over the recoil momentum of the nucleus. While a significant part of this integral can be solved in closed form under traditional assumptions of the standard halo model and/or isotropic detector response, analysis of alternate assumptions is conventionally impeded by the inefficiency of multidimensional numerical integration methods. In this work, we introduce a novel, fast, and efficient algorithm for direct detection event rate computations. This algorithm takes advantage of a closed-form expression for the Radon transform of three-dimensional Zernike functions, which are used as basis functions for the velocity distribution. We demonstrate an implementation of this algorithm zebradm, which is typically faster than an optimized numerical integration approach by a factor between 102 and 104.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (40)

  1. N. Aghanim et al. (Planck Collaboration), Planck 2018 results. VI. Cosmological parameters, Astron. Astrophys. 641, A6 (2020); 652, C4(E) (2021).
  2. P. Asadi et al., Early-universe model building, arXiv:2203.06680.
  3. N. W. Evans, C. A. J. O’Hare, and C. McCabe, Refinement of the standard halo model for dark matter searches in light of the Gaia sausage, Phys. Rev. D 99, 023012 (2019).
  4. N. Bozorgnia, A. Fattahi, C. S. Frenk, A. Cheek, D. G. Cerdeno, F. A. Gómez, R. J. J. Grand, and F. Marinacci, The dark matter component of the Gaia radially anisotropic substructure, J. Cosmol. Astropart. Phys. 07 (2020) 036.
  5. A. Smith-Orlik et al., The impact of the Large Magellanic Cloud on dark matter direct detection signals, J. Cosmol. Astropart. Phys. 10 (2023) 070.
  6. J. Reynoso-Cordova, N. Bozorgnia, and M.-C. Piro, The Large Magellanic Cloud: Expanding the low-mass parameter space of dark matter direct detection, J. Cosmol. Astropart. Phys. 12 (2024) 037.
  7. L. Stanic, M. Eberlein, S. Linchakovskyy, C. Magnoli, M. Mesiura, L. Morf, P. Saha, and E. Vasiliev, Dark matter particle flux in a dynamically self-consistent Milky Way model, arXiv:2502.08805.
  8. F. Kadribasic, N. Mirabolfathi, K. Nordlund, A. E. Sand, E. Holmström, and F. Djurabekova, Directional sensitivity in light-mass dark matter searches with single-electron resolution ionization detectors, Phys. Rev. Lett. 120, 111301 (2018).
  9. S. Griffin, S. Knapen, T. Lin, and K. M. Zurek, Directional detection of light dark matter with polar materials, Phys. Rev. D 98, 115034 (2018).
  10. T. Trickle, Z. Zhang, K. M. Zurek, K. Inzani, and S. M. Griffin, Multi-channel direct detection of light dark matter: Theoretical framework, J. High Energy Phys. 03 (2020) 036.
  11. M. Heikinheimo, K. Nordlund, K. Tuominen, and N. Mirabolfathi, Velocity dependent dark matter interactions in single-electron resolution semiconductor detectors with directional sensitivity, Phys. Rev. D 99, 103018 (2019).
  12. A. Coskuner, T. Trickle, Z. Zhang, and K. M. Zurek, Directional detectability of dark matter with single phonon excitations: Target comparison, Phys. Rev. D 105, 015010 (2022).
  13. B. Campbell-Deem, S. Knapen, T. Lin, and E. Villarama, Dark matter direct detection from the single phonon to the nuclear recoil regime, Phys. Rev. D 106, 036019 (2022).
  14. C. Stratman and T. Lin, Daily modulation of low-energy nuclear recoils from sub-GeV dark matter, Phys. Rev. D 111, 043030 (2025).
  15. S. Sassi, A. Dinmohammadi, M. Heikinheimo, N. Mirabolfathi, K. Nordlund, H. Safari, and K. Tuominen, Solar neutrinos and dark matter detection with diurnal modulation, Phys. Rev. D 104, 063037 (2021).
  16. M. Heikinheimo, K. Nordlund, S. Sassi, and K. Tuominen, Probing the dark matter velocity distribution via daily modulation, Phys. Rev. D 109, 103010 (2024).
  17. N. Canterakis, 3d Zernike moments and Zernike affine invariants for 3d image analysis and recognition, in Proceedings of the 11th Scandinavian Conference on Image Analysis (Dansk Selskab for Automatisk Genkendelse af Mønstre, 1997), pp. 85–93.
  18. S. K. Lee, Harmonics in the dark-matter sky: Directional detection in the Fourier-Bessel basis, J. Cosmol. Astropart. Phys. 03 (2014) 047.
  19. B. Lillard, Wavelet-harmonic integration methods, Phys. Rev. D 111, 123006 (2025).
  20. B. Lillard, Partial rate matrix for dark matter scattering, Phys. Rev. Lett. 134, 221003 (2025).
  21. A. K. Louis, Orthogonal function series expansions and the null space of the radon transform, SIAM J. Math. Anal. 15, 621 (1984).
  22. A. J. E. M. Janssen, Generalized 3D Zernike functions for analytic construction of band-limited line-detecting wavelets, arXiv:1510.04837.
  23. D. S. M. Alves, S. El Hedri, and J. G. Wacker, Dark matter in 3D, J. High Energy Phys. 03 (2016) 149.
  24. B. J. Kavanagh, Parametrizing the local dark matter speed distribution: A detailed analysis, Phys. Rev. D 89, 085026 (2014).
  25. A. H. G. Peter, V. Gluscevic, A. M. Green, B. J. Kavanagh, and S. K. Lee, WIMP physics with ensembles of direct-detection experiments, Phys. Dark Universe 5–6, 45 (2014).
  26. S. Sassi, zebradm, https://github.com/sebsassi/zebradm (2025).
  27. S. Sassi, zest, https://github.com/sebsassi/zest (2025).
  28. R. Catena, T. Emken, M. Matas, N. A. Spaldin, and E. Urdshals, Crystal responses to general dark matter-electron interactions, Phys. Rev. Res. 3, 033149 (2021).
  29. P. Gondolo, Recoil momentum spectrum in directional dark matter detectors, Phys. Rev. D 66, 103513 (2002).
  30. A. L. Fitzpatrick, W. Haxton, E. Katz, N. Lubbers, and Y. Xu, The effective field theory of dark matter direct detection, J. Cosmol. Astropart. Phys. 02 (2013) 004.
  31. N. Anand, A. L. Fitzpatrick, and W. C. Haxton, Weakly interacting massive particle-nucleus elastic scattering response, Phys. Rev. C 89, 065501 (2014).
  32. R. Catena, T. Emken, N. A. Spaldin, and W. Tarantino, Atomic responses to general dark matter-electron interactions, Phys. Rev. Res. 2, 033195 (2020); 7, 019001(E) (2025).
  33. F. Mayet et al., A review of the discovery reach of directional dark matter detection, Phys. Rep. 627, 1 (2016).
  34. K. Niu and C. Tian, Zernike polynomials and their applications, J. Opt. 24, 123001 (2022).
  35. R. J. Mathar, Karhunen-Loeve basis functions of kolmogorov turbulence in the sphere, Baltic Astron. 17, 383 (2008).
  36. A.-W. Deng and C.-Y. Gwo, A stable algorithm computing high-order 3d Zernike moments and shape reconstructions, in Proceedings of the 2020 4th International Conference on Digital Signal Processing, ICDSP ’20 (Association for Computing Machinery, New York, NY, USA, 2020), pp. 38–42.
  37. OEIS Foundation Inc., The on-line encyclopedia of integer sequences (2025), https://oeis.org/A002623.
  38. N. Schaeffer, Efficient spherical harmonic transforms aimed at pseudospectral numerical simulations, Geochem. Geophys. Geosyst. 14, 751 (2013).
  39. M. A. Wieczorek and M. Meschede, shtools: Tools for working with spherical harmonics, Geochem. Geophys. Geosyst. 19, 2574 (2018).
  40. A. Genz and A. Malik, Remarks on algorithm 006: An adaptive algorithm for numerical integration over an n-dimensional rectangular region, J. Comput. Appl. Math. 6, 295 (1980).
