Mass spectrum and decay widths of charmoniumlike mesons: A diabatic approach with complex scaling

Zi-Zhao Zhang and Bo-Chao Liu*

  • MOE Key Laboratory for Nonequilibrium Synthesis and Modulation of Condensed Matter, School of Physics, Xi’an Jiaotong University, Xi’an 710049, China

  • *Contact author: liubc@xjtu.edu.cn
PDF

Phys. Rev. D 114, 074021 – Published 9 October, 2026

DOI: https://doi.org/10.1103/jkrp-twgc

Abstract

In this work, we extend our previous diabatic framework for the charmoniumlike spectrum below 4.3 GeV by introducing the complex scaling method. Unlike the previous framework, the present approach explicitly incorporates couplings to the meson-meson continuum, comprehensively accounting for its contributions to the physical states. Consequently, it allows bound and resonant states to be treated on an equal footing, enabling the direct extraction of decay widths from complex energy eigenvalues without introducing any additional free parameters. Using the obtained solutions, we calculate the channel weights and complex root-mean-square radii (rrms) to elucidate their internal structures. Specifically, we find that the χc1(3872), ψ(4040), and ψ(4230) states exhibit significant molecular characteristics. Furthermore, we propose the X(3940) as a candidate for a JPC=1++ state and discuss the nature of the χc0(2P) resonance in detail.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (80)

  1. S. Navas et al. (Particle Data Group), Phys. Rev. D 110, 030001 (2024).
  2. S. K. Choi et al. (Belle Collaboration), Phys. Rev. Lett. 91, 262001 (2003).
  3. K. Chilikin et al. (Belle Collaboration), Phys. Rev. D 95, 112003 (2017).
  4. G. L. Yu, Z. G. Wang, and Z. Y. Li, Chin. Phys. C 42, 043107 (2018).
  5. K. Abe et al. (Belle Collaboration), Phys. Rev. Lett. 98, 082001 (2007).
  6. R. Aaij et al. (LHCb Collaboration), Phys. Rev. Lett. 133, 131902 (2024).
  7. S. Uehara et al. (Belle Collaboration), Phys. Rev. Lett. 96, 082003 (2006).
  8. R. Aaij et al. (LHCb Collaboration), Phys. Rev. D 102, 112003 (2020).
  9. K. Abe et al. (Belle Collaboration), Phys. Rev. Lett. 94, 182002 (2005).
  10. M. Ablikim et al. (BESIII Collaboration), Phys. Rev. D 109, 092012 (2024).
  11. J. Z. Bai et al. (BES Collaboration), Phys. Rev. Lett. 84, 594 (2000).
  12. R. Aaij et al. (LHCb Collaboration), Phys. Rev. Lett. 127, 082001 (2021).
  13. E. Eichten, K. Gottfried, T. Kinoshita, J. B. Kogut, K. D. Lane, and T.-M. Yan, Phys. Rev. Lett. 34, 369 (1975); 36, 1276(E) (1976).
  14. E. Eichten, K. Gottfried, T. Kinoshita, K. D. Lane, and T. M. Yan, Phys. Rev. D 17, 3090 (1978).
  15. S. Godfrey and N. Isgur, Phys. Rev. D 32, 189 (1985).
  16. T. Barnes, S. Godfrey, and E. S. Swanson, Phys. Rev. D 72, 054026 (2005).
  17. E. Eichten, S. Godfrey, H. Mahlke, and J. L. Rosner, Rev. Mod. Phys. 80, 1161 (2008).
  18. R. Aaij et al. (LHCb Collaboration), Phys. Rev. Lett. 125, 242001 (2020).
  19. R. Aaij et al. (LHCb Collaboration), Phys. Rev. Lett. 131, 071901 (2023).
  20. N. Brambilla et al., Phys. Rep. 873, 1 (2020).
  21. H.-X. Chen, W. Chen, X. Liu, Y.-R. Liu, and S.-L. Zhu, Rep. Prog. Phys. 86, 026201 (2023).
  22. B.-Q. Li, C. Meng, and K.-T. Chao, Phys. Rev. D 80, 014012 (2009).
  23. Y. S. Kalashnikova, Phys. Rev. D 72, 034010 (2005).
  24. M. R. Pennington and D. J. Wilson, Phys. Rev. D 76, 077502 (2007).
  25. S. Ono and N. Törnqvist, Z. Phys. C 23, 59 (1984).
  26. M. Born and W. Heisenberg, Ann. Phys. (Berlin) 379, 1 (1924).
  27. G. S. Bali, Phys. Rep. 343, 1 (2001).
  28. J. Tarrus Castella, Phys. Rev. D 106, 094020 (2022).
  29. N. Brambilla, A. Mohapatra, T. Scirpa, and A. Vairo, Phys. Rev. D 114, 054049 (2026).
  30. R. Bruschini and P. González, Phys. Rev. D 102, 074002 (2020).
  31. M. Baer, Beyond Born-Oppenheimer: Electronic Nonadiabatic Coupling Terms and Conical Intersections (John Wiley & Sons, New York, 2006), 10.1002/0471780081.
  32. G. S. Bali, H. Neff, T. Duessel, T. Lippert, and K. Schilling (SESAM Collaboration), Phys. Rev. D 71, 114513 (2005).
  33. J. Bulava, B. Hörz, F. Knechtli, V. Koch, G. Moir, C. Morningstar, and M. Peardon, Phys. Lett. B 793, 493 (2019).
  34. R. Bruschini and P. González, Phys. Rev. D 103, 114016 (2021).
  35. R. Bruschini and P. González, Phys. Rev. D 104, 074025 (2021).
  36. R. Bruschini, J. High Energy Phys. 08 (2023) 219.
  37. R. Bruschini, Phys. Rev. D 110, 074033 (2024).
  38. E. Braaten and R. Bruschini, Phys. Lett. B 863, 139386 (2025).
  39. M. Berwein, N. Brambilla, A. Mohapatra, and A. Vairo, Phys. Rev. D 110, 094040 (2024).
  40. R. F. Lebed and S. R. Martinez, Phys. Rev. D 106, 074007 (2022).
  41. R. F. Lebed and S. R. Martinez, Phys. Rev. D 110, 074002 (2024).
  42. R. Bruschini and P. González, Phys. Rev. D 103, 074009 (2021).
  43. Z.-Z. Zhang, R. Li, and B.-C. Liu, Chin. Phys. C 49, 013102 (2025).
  44. J. Aguilar and J. M. Combes, Commun. Math. Phys. 22, 269 (1971).
  45. E. Balslev and J. M. Combes, Commun. Math. Phys. 22, 280 (1971).
  46. W.-L. Wu and S.-L. Zhu, Phys. Rev. D 111, 034044 (2025).
  47. M. Oka, S. Maeda, and Y.-R. Liu, Int. J. Mod. Phys. Conf. Ser. 49, 1960004 (2019).
  48. Q.-F. Song, Q.-F. Lü, D.-Y. Chen, and Y.-B. Dong, Phys. Rev. D 110, 074038 (2024).
  49. W. Lucha and F. F. Schöberl, Effective potential models for hadrons in Invited Lectures given at the International Summer School for Students on Development in Nuclear Theory and Particle Physics, Dubna, Russia (1995), arXiv:hep-ph/9601263.
  50. K. Heikkilä, N. A. Törnqvist, and S. Ono, Phys. Rev. D 29, 110 (1984).
  51. E. Hiyama, Y. Kino, and M. Kamimura, Prog. Part. Nucl. Phys. 51, 223 (2003).
  52. E. Hiyama and M. Kamimura, Front. Phys. (Beijing) 13, 132106 (2018).
  53. S. Aoyama, T. Myo, K. Katō, and K. Ikeda, Prog. Theor. Phys. 116, 1 (2006).
  54. Z.-Y. Lin, J.-B. Cheng, B.-L. Huang, and S.-L. Zhu, Phys. Rev. D 108, 114014 (2023).
  55. Q.-F. Song, Q.-F. Lü, and X. Xiong, Eur. Phys. J. C 85, 1026 (2025).
  56. W.-L. Wu, Y. Ma, Y.-K. Chen, L. Meng, and S.-L. Zhu, Phys. Rev. D 110, 094041 (2024).
  57. T. Myo, M. Odsuren, and K. Katō, Phys. Rev. C 104, 044306 (2021).
  58. M. Homma, T. Myo, and K. Kato, Prog. Theor. Phys. 97, 561 (1997).
  59. T. Berggren, Phys. Lett. 33B, 547 (1970).
  60. T. Berggren, Phys. Lett. B 373, 1 (1996).
  61. T. Myo, Y. Kikuchi, and K. Kato, Phys. Rev. C 84, 064306 (2011).
  62. T. Myo and K. Katō, Phys. Rev. C 107, 014301 (2023).
  63. Y. Shimizu, D. Suenaga, and M. Harada, Phys. Rev. D 93, 114003 (2016).
  64. R. L. Workman et al. (Particle Data Group), Prog. Theor. Exp. Phys. 2022, 083C01 (2022).
  65. W.-J. Deng, H. Liu, L.-C. Gui, and X.-H. Zhong, Phys. Rev. D 95, 034026 (2017).
  66. J. Bulava, F. Knechtli, V. Koch, C. Morningstar, and M. Peardon, Phys. Lett. B 854, 138754 (2024).
  67. N. A. Tornqvist, Phys. Lett. B 590, 209 (2004).
  68. F.-K. Guo, C. Hidalgo-Duque, J. Nieves, and M. Pavon Valderrama, Phys. Rev. D 88, 054007 (2013).
  69. E. Braaten and M. Kusunoki, Phys. Rev. D 69, 074005 (2004).
  70. E. S. Swanson, Phys. Lett. B 588, 189 (2004).
  71. D. Gamermann, J. Nieves, E. Oset, and E. Ruiz Arriola, Phys. Rev. D 81, 014029 (2010).
  72. P. G. Ortega, J. Segovia, D. R. Entem, and F. Fernandez, Phys. Rev. D 81, 054023 (2010).
  73. F.-K. Guo, C. Hanhart, U.-G. Meißner, Q. Wang, Q. Zhao, and B.-S. Zou, Rev. Mod. Phys. 90, 015004 (2018).
  74. N. Brambilla, A. Mohapatra, T. Scirpa, and A. Vairo, Phys. Rev. Lett. 135, 131902 (2025).
  75. Z.-Y. Zhou and Z. Xiao, Phys. Rev. D 96, 054031 (2017); 96, 099905(E) (2017).
  76. Z.-L. Man, C.-R. Shu, Y.-R. Liu, and H. Chen, Eur. Phys. J. C 84, 810 (2024).
  77. P. G. Ortega, J. Segovia, D. R. Entem, and F. Fernández, Phys. Lett. B 778, 1 (2018).
  78. Z.-Y. Zhou, Z. Xiao, and H.-Q. Zhou, Phys. Rev. Lett. 115, 022001 (2015).
  79. F.-K. Guo and U.-G. Meissner, Phys. Rev. D 86, 091501 (2012).
  80. M.-X. Duan, S.-Q. Luo, X. Liu, and T. Matsuki, Phys. Rev. D 101, 054029 (2020).
