Classification of four-quark operators with ΔF≤2 under flavor symmetry and their renormalization in a gauge-invariant scheme

G. Spanoudes1,*, M. Costa2,†,∥, K. Mitsidi1,‡,¶, and H. Panagopoulos1,§

  • *Contact author: spanoudes.gregoris@ucy.ac.cy
  • †Contact author: marios.costa@cut.ac.cy
  • ‡Contact author: kmitsidi@tudelft.nl
  • §Contact author: haris@ucy.ac.cy
  • ∥Present address: Department of Mechanical Engineering and Material Science and Engineering, Cyprus University of Technology, Limassol, CY-3036, Cyprus.
  • Present address: Faculty of Applied Sciences, Delft University of Technology, Lorentzweg 1, 2628 CK, Delft, The Netherlands.
PDF

Phys. Rev. D 113, 034504 – Published 13 February, 2026

DOI: https://doi.org/10.1103/h9p1-6cbw

Abstract

In this paper we study a complete set of scalar and pseudoscalar four-quark operators, with a particular emphasis on their renormalization within a gauge-invariant renormalization scheme (GIRS). We focus on operators that do not mix with lower-dimensional operators by virtue of their transformation properties under the flavor-symmetry group. This class includes all ΔF=2 operators, as well as their partners that transform under the same irreducible representations of the flavor group. These encompass a substantial subset of ΔF=1 and ΔF=0 operators. The present analysis provides a detailed classification of all four-quark operators, exploring their Fierz identities, symmetry properties, and mixing patterns. Different variants of GIRS are explored, including a “democratic” version that treats all mixing operators uniformly. For selected variants, which exhibit smaller mixing effects, we present the conversion matrices from GIRS to the MS¯ scheme at next-to-leading order.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (54)

  1. Y. Aoki et al. (Flavour Lattice Averaging Group (FLAG) Collaboration), FLAG review 2024, arXiv:2411.04268.
  2. M. Ciuchini, E. Franco, V. Lubicz, G. Martinelli, I. Scimemi, and L. Silvestrini, Next-to-leading order QCD corrections to ΔF=2 effective Hamiltonians, Nucl. Phys. B523, 501 (1998).
  3. G. Buchalla, A. J. Buras, and M. E. Lautenbacher, Weak decays beyond leading logarithms, Rev. Mod. Phys. 68, 1125 (1996).
  4. A. Donini, V. Gimenez, L. Giusti, and G. Martinelli, Renormalization group invariant matrix elements of ΔS=2 and ΔI=3/2 four fermion operators without quark masses, Phys. Lett. B 470, 233 (1999).
  5. A. J. Buras, M. Misiak, and J. Urban, Two loop QCD anomalous dimensions of flavor changing four quark operators within and beyond the standard model, Nucl. Phys. B586, 397 (2000); B1002, 116529(E) (2024).
  6. S. Aoki and Y. Kuramashi, The lattice Lambda parameter in domain wall QCD, Phys. Rev. D 68, 034507 (2003).
  7. R. Frezzotti and G. C. Rossi, Chirally improving Wilson fermions. II. Four-quark operators, J. High Energy Phys. 10 (2004) 070.
  8. M. Guagnelli, J. Heitger, C. Pena, S. Sint, and A. Vladikas (ALPHA Collaboration), Non-perturbative renormalization of left-left four-fermion operators in quenched lattice QCD, J. High Energy Phys. 03 (2006) 088.
  9. Y. Aoki, Z. Fodor, S. D. Katz, and K. K. Szabo, The QCD transition temperature: Results with physical masses in the continuum limit, Phys. Lett. B 643, 46 (2006).
  10. Y. Nakamura and Y. Kuramashi, Perturbative renormalization factors for generic ΔS=2 four-quark operators in domain-wall QCD with improved gauge action, Phys. Rev. D 73, 094502 (2006).
  11. M. Constantinou, P. Dimopoulos, R. Frezzotti, V. Lubicz, H. Panagopoulos, A. Skouroupathis, and F. Stylianou, Perturbative renormalization factors and O(a2) corrections for lattice 4-fermion operators with improved fermion/gluon actions, Phys. Rev. D 83, 074503 (2011).
  12. P. A. Boyle, N. Garron, and R. J. Hudspith (RBC Collaboration and UKQCD Collaboration), Neutral kaon mixing beyond the standard model with nf=2+1 chiral fermions, Phys. Rev. D 86, 054028 (2012).
  13. Y. Taniguchi, Perturbative renormalization factors of four-quark operators for improved Wilson fermion action and Iwasaki gauge action, J. High Energy Phys. 04 (2012) 143.
  14. N. Carrasco et al. (ETM Collaboration), B-physics computations from Nf=2 tmQCD, Proc. Sci. LATTICE2013 (2014) 382.
  15. N. Carrasco, P. Dimopoulos, R. Frezzotti, V. Lubicz, G. C. Rossi, S. Simula, and C. Tarantino (ETM Collaboration), ΔS=2 and ΔC=2 bag parameters in the standard model and beyond from Nf=2+1+1 twisted-mass lattice QCD, Phys. Rev. D 92, 034516 (2015).
  16. P. Dimopoulos, G. Herdoíza, M. Papinutto, C. Pena, D. Preti, and A. Vladikas (ALPHA Collaboration), Non-perturbative renormalisation and running of BSM four-quark operators in Nf=2 QCD, Eur. Phys. J. C 78, 579 (2018).
  17. G. Martinelli, M. Naviglio, S. Simula, and L. Vittorio, |Vcb|, lepton flavor universality and SU(3)F symmetry breaking in Bs→Ds(*)ℓνℓ decays through unitarity and lattice QCD, Phys. Rev. D 106, 093002 (2022).
  18. G. Martinelli, S. Simula, and L. Vittorio, Exclusive semileptonic B→πℓνℓ and Bs→Kℓνℓ decays through unitarity and lattice QCD, J. High Energy Phys. 08 (2022) 022.
  19. M. Constantinou, M. Costa, H. Herodotou, H. Panagopoulos, and G. Spanoudes, Gauge-invariant renormalization of four-quark operators, Phys. Rev. D 110, 074506 (2024).
  20. J. Lin, W. Detmold, and S. Meinel, Position-space renormalization schemes for four-quark operators in HQET, J. High Energy Phys. 07 (2024) 188.
  21. M. Di Carlo, F. Erben, and M. T. Hansen, Long distance contributions to neutral D-meson mixing from lattice QCD, J. High Energy Phys. 07 (2025) 229.
  22. R. Frezzotti, N. Tantalo, G. Gagliardi, V. Lubicz, G. Martinelli, C. T. Sachrajda, F. Sanfilippo, S. Simula, and L. Silvestrini, Theoretical framework for lattice QCD computations of B→Kℓ+ℓ− and B¯s→ℓ+ℓ−γ decays rates, including contributions from “Charming Penguins”, arXiv:2508.03655.
  23. R. Gupta, D. Daniel, G. W. Kilcup, A. Patel, and S. R. Sharpe, The kaon B parameter with Wilson fermions, Phys. Rev. D 47, 5113 (1993).
  24. D. Becirevic, P. Boucaud, V. Gimenez, V. Lubicz, G. Martinelli, and M. Papinutto, Matrix elements of Delta S=2 operators with Wilson fermions, Nucl. Phys. B, Proc. Suppl. 106, 326 (2002).
  25. Y. Aoki et al., Continuum limit of BK from 2+1 flavor domain wall QCD, Phys. Rev. D 84, 014503 (2011).
  26. M. Constantinou et al. (ETM Collaboration), BK-parameter from Nf=2 twisted mass lattice QCD, Phys. Rev. D 83, 014505 (2011).
  27. J. Aebischer, C. Bobeth, A. J. Buras, and J. Kumar, SMEFT ATLAS of ΔF=2 transitions, J. High Energy Phys. 12 (2020) 187.
  28. A. Suzuki, Y. Taniguchi, H. Suzuki, and K. Kanaya, Four quark operators for kaon bag parameter with gradient flow, Phys. Rev. D 102, 034508 (2020).
  29. A. Lenz, Lifetimes and heavy quark expansion, Int. J. Mod. Phys. A 30, 1543005 (2015).
  30. M. Neubert and C. T. Sachrajda, Spectator effects in inclusive decays of beauty hadrons, Nucl. Phys. B483, 339 (1997).
  31. F. Gabbiani, E. Gabrielli, A. Masiero, and L. Silvestrini, A complete analysis of FCNC and CP constraints in general SUSY extensions of the standard model, Nucl. Phys. B477, 321 (1996).
  32. R. Aaij et al. (LHCb Collaboration), Observation of charge–parity symmetry breaking in baryon decays, Nature (London) 643, 1223 (2025).
  33. T. Ishikawa, Y. Aoki, J. M. Flynn, T. Izubuchi, and O. Loktik, One-loop operator matching in the static heavy and domain-wall light quark system with O(a) improvement, J. High Energy Phys. 05 (2011) 040.
  34. M. Di Pierro and C. T. Sachrajda (UKQCD Collaboration), A lattice study of spectator effects in inclusive decays of B mesons, Nucl. Phys. B534, 373 (1998).
  35. M. Di Pierro, C. T. Sachrajda, and C. Michael (UKQCD Collaboration), An exploratory lattice study of spectator effects in inclusive decays of the Λb baryon, Phys. Lett. B 468, 143 (1999); 525, 360(E) (2002).
  36. V. Gimenez and J. Reyes, Calculation of the continuum lattice HQET matching for the complete basis of four fermion operators: Reanalysis of the B0−B0 mixing, Nucl. Phys. B545, 576 (1999).
  37. N. Ishizuka, K. I. Ishikawa, A. Ukawa, and T. Yoshié, Calculation of K→ππ decay amplitudes with improved Wilson fermion action in non-zero momentum frame in lattice QCD, Phys. Rev. D 98, 114512 (2018).
  38. G. Martinelli, C. Pittori, C. T. Sachrajda, M. Testa, and A. Vladikas, A general method for non-perturbative renormalization of lattice operators, Nucl. Phys. B445, 81 (1995).
  39. M. Costa, G. Panagopoulos, H. Panagopoulos, and G. Spanoudes, Gauge-invariant renormalization of the Gluino-Glue operator, Phys. Lett. B 816, 136225 (2021).
  40. M. Costa, I. Karpasitis, T. Pafitis, G. Panagopoulos, H. Panagopoulos, A. Skouroupathis, and G. Spanoudes, Gauge-invariant renormalization scheme in QCD: Application to fermion bilinears and the energy-momentum tensor, Phys. Rev. D 103, 094509 (2021).
  41. G. Bergner, M. Costa, H. Panagopoulos, S. Piemonte, I. Soler Calero, and G. Spanoudes, Nonperturbative renormalization of the supercurrent in N=1 supersymmetric Yang-Mills theory, Phys. Rev. D 107, 034502 (2023).
  42. V. Gimenez, L. Giusti, S. Guerriero, V. Lubicz, G. Martinelli, S. Petrarca, J. Reyes, B. Taglienti, and E. Trevigne, Non-perturbative renormalization of lattice operators in coordinate space, Phys. Lett. B 598, 227 (2004).
  43. K. G. Chetyrkin and A. Maier, Massless correlators of vector, scalar and tensor currents in position space at orders αs3 and αs4: Explicit analytical results, Nucl. Phys. B844, 266 (2011).
  44. K. Cichy, K. Jansen, and P. Korcyl, Non-perturbative renormalization in coordinate space for Nf=2 maximally twisted mass fermions with tree-level Symanzik improved gauge action, Nucl. Phys. B865, 268 (2012).
  45. M. Tomii and N. H. Christ, O(4)-symmetric position-space renormalization of lattice operators, Phys. Rev. D 99, 014515 (2019).
  46. A. Donini, V. Gimenez, G. Martinelli, M. Talevi, and A. Vladikas, Nonperturbative renormalization of lattice four fermion operators without power subtractions, Eur. Phys. J. C 10, 121 (1999).
  47. M. Papinutto, C. Pena, and D. Preti, On the perturbative renormalization of four-quark operators for new physics, Eur. Phys. J. C 77, 376 (2017); 78, 21(E) (2018).
  48. G. ’t Hooft and M. J. G. Veltman, Regularization and renormalization of gauge fields, Nucl. Phys. B44, 189 (1972).
  49. J. C. Collins, Renormalization: An Introduction to Renormalization, the Renormalization Group, and the Operator-Product Expansion (Cambridge University Press, Cambridge, England, 1984), 10.1017/CBO9780511622656.
  50. M. J. Dugan and B. Grinstein, On the vanishing of evanescent operators, Phys. Lett. B 256, 239 (1991).
  51. S. Herrlich and U. Nierste, Evanescent operators, scheme dependences and double insertions, Nucl. Phys. B455, 39 (1995).
  52. C. Lehner and C. Sturm, Matching factors for Delta S=1 four-quark operators in RI/SMOM schemes, Phys. Rev. D 84, 014001 (2011).
  53. M. Ciuchini, E. Franco, G. Martinelli, L. Reina, and L. Silvestrini, An upgraded analysis of epsilon-prime epsilon at the next-to-leading order, Z. Phys. C 68, 239 (1995).
  54. J. Bühler and P. Stoffer, One-loop matching of CP-odd four-quark operators to the gradient-flow scheme, J. High Energy Phys. 08 (2023) 194.
