Improved constraints on pion fragmentation functions from simulated electron-ion collider data

Maryam Soleymaninia1,2,*, Hamzeh Khanpour3,4,1,†, Majid Azizi1,‡, and Hadi Hashamipour5,§

  • *Contact author: Maryam_Soleymaninia@ipm.ir
  • †Contact author: Hamzeh.Khanpour@cern.ch
  • ‡Contact author: Ma.Azizi@ipm.ir
  • §Contact author: Hadi.Hashamipour@lnf.infn.it
PDF

Phys. Rev. D 112, 054032 – Published 22 September, 2025

DOI: https://doi.org/10.1103/gm92-w63j

Abstract

We present a quantitative assessment of the anticipated impact of future Electron-Ion Collider (EIC) measurements on the extraction of parton-to-pion fragmentation functions (FFs). Our analysis combines simulated semi-inclusive deep-inelastic scattering (SIDIS) pseudo-data at EIC energies of 45 GeV and 140 GeV with existing single-inclusive electron-positron annihilation (SIA) and SIDIS experimental data. The pion fragmentation functions are determined at next-to-leading-order (NLO) accuracy using a perturbative quantum chromodynamics framework and a neural network parametrization. Uncertainties are rigorously estimated through Monte Carlo sampling, accounting for both experimental errors and variations in input parton distribution functions. Our results demonstrate that incorporating EIC pseudo-data reduces their uncertainties, especially at medium- to-large momentum fractions (z). This improvement is particularly pronounced for the gluon and selected quark FFs, highlighting the substantial role that EIC measurements will play in achieving high-precision extractions of FFs and informing future experimental and theoretical developments in collider physics.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (47)

  1. R. Abdul Khalek, V. Bertone, A. Khoudli, and E. R. Nocera (MAP (Multi-dimensional Analyses of Partonic distributions) Collaboration), Pion and kaon fragmentation functions at next-to-next-to-leading order, Phys. Lett. B 834, 137456 (2022).
  2. J. Gao, C. Liu, X. Shen, H. Xing, and Y. Zhao, Global analysis of fragmentation functions to charged hadrons with high-precision data from the LHC, Phys. Rev. D 110, 114019 (2024).
  3. M. Soleymaninia, H. Hashamipour, M. Salajegheh, H. Khanpour, H. Spiesberger, and U. G. Meißner, Determination of KS0 fragmentation functions including BESIII measurements and using neural networks, Phys. Rev. D 110, 014019 (2024).
  4. R. Abdul Khalek, J. J. Ethier, and J. Rojo (NNPDF Collaboration), Nuclear parton distributions from lepton-nucleus scattering and the impact of an electron-ion collider, Eur. Phys. J. C 79, 471 (2019).
  5. M. Klasen and K. Kovařík, Nuclear parton density functions from dijet photoproduction at the EIC, Phys. Rev. D 97, 114013 (2018).
  6. M. Klasen, K. Kovarik, and J. Potthoff, Nuclear parton density functions from jet production in DIS at an EIC, Phys. Rev. D 95, 094013 (2017).
  7. R. Abdul Khalek, U. D’Alesio, M. Arratia, A. Bacchetta, M. Battaglieri, M. Begel, M. Boglione, R. Boughezal, R. Boussarie, G. Bozzi et al., Snowmass 2021 White Paper: Electron ion collider for high energy physics, arXiv:2203.13199.
  8. R. Abdul Khalek, A. Accardi, J. Adam, D. Adamiak, W. Akers, M. Albaladejo, A. Al-bataineh, M. G. Alexeev, F. Ameli, P. Antonioli et al., Science requirements and detector concepts for the electron-ion collider: EIC Yellow Report, Nucl. Phys. A1026, 122447 (2022).
  9. M. Radici et al. (Electron-Ion Collider User Group Collaboration), The Electron-Ion Collider—A U.S. facility for the European community to explore the mysteries of the building blocks of matter, arXiv:2211.02785.
  10. Y. Zhou, C. Cocuzza, F. Delcarro, W. Melnitchouk, A. Metz, and N. Sato (Jefferson Lab Angular Momentum (JAM) Collaboration), Revisiting quark and gluon polarization in the proton at the EIC, Phys. Rev. D 104, 034028 (2021).
  11. R. A. Khalek, J. J. Ethier, E. R. Nocera, and J. Rojo, Self-consistent determination of proton and nuclear PDFs at the Electron Ion Collider, Phys. Rev. D 103, 096005 (2021).
  12. N. Armesto, T. Cridge, F. Giuli, L. Harland-Lang, P. Newman, B. Schmookler, R. Thorne, and K. Wichmann, Impact of inclusive electron ion collider data on collinear parton distributions, Phys. Rev. D 109, 054019 (2024).
  13. J. Jiménez-López, P. R. Newman, and K. Wichmann, Prospects for measurements of the longitudinal proton structure function FL at the Electron Ion Collider, Phys. Rev. D 111, 056014 (2025).
  14. T. Kutz, J. R. Pybus, D. W. Upton, C. Cotton, A. Deshpande, A. Deur, W. B. Li, D. Nguyen, M. Nycz, and X. Zheng, High precision measurements of αs at the future EIC, Phys. Rev. D 110, 074004 (2024).
  15. M. Azizi, M. Soleymaninia, H. Hashamipour, M. Salajegheh, H. Khanpour, and U. G. Meißner, Revisiting constraints on proton PDFs from HERA DIS, Drell-Yan, W and Z boson production, and projected EIC measurements, Phys. Rev. D 111, 034023 (2025).
  16. S. Cerci, Z. S. Demiroglu, A. Deshpande, P. R. Newman, B. Schmookler, D. Sunar Cerci, and K. Wichmann, Extraction of the strong coupling with HERA and EIC inclusive data, Eur. Phys. J. C 83, 1011 (2023).
  17. E. C. Aschenauer, I. Borsa, R. Sassot, and C. Van Hulse, Semi-inclusive deep-inelastic scattering, parton distributions and fragmentation functions at a future electron-ion collider, Phys. Rev. D 99, 094004 (2019).
  18. E. Moffat, W. Melnitchouk, T.  C. Rogers, and N. Sato (Jefferson Lab Angular Momentum (JAM) Collaboration), Simultaneous Monte Carlo analysis of parton densities and fragmentation functions, Phys. Rev. D 104, 016015 (2021).
  19. R. D. Ball et al. (NNPDF Collaboration), The path to proton structure at 1% accuracy, Eur. Phys. J. C 82, 428 (2022).
  20. R. A. Khalek, V. Bertone, and E. R. Nocera (MAP (Multi-dimensional Analyses of Partonic distributions) Collaboration), Determination of unpolarized pion fragmentation functions using semi-inclusive deep-inelastic-scattering data, Phys. Rev. D 104, 034007 (2021).
  21. https://github.com/MapCollaboration/MontBlanc
  22. R. D. Ball et al. (NNPDF Collaboration), The path to N3LO parton distributions, Eur. Phys. J. C 84, 659 (2024).
  23. M. Soleymaninia, H. Hashamipour, and H. Khanpour, Neural network QCD analysis of charged hadron fragmentation functions in the presence of SIDIS data, Phys. Rev. D 105, 114018 (2022).
  24. S. Forte, L. Garrido, J. I. Latorre, and A. Piccione, Neural network parametrization of deep inelastic structure functions, J. High Energy Phys. 05 (2002) 062.
  25. M. Soleymaninia, H. Hashamipour, H. Khanpour, S. Shoeibi, and A. Mohamaditabar, Study of nuclear corrections on the charged hadron fragmentation functions in a neural network global QCD analysis, Eur. Phys. J. Plus 139, 794 (2024).
  26. M. Cacciari, P. Nason, and C. Oleari, Crossing heavy-flavor thresholds in fragmentation functions, J. High Energy Phys. 10 (2005) 034.
  27. V. Bertone, S. Carrazza, N. P. Hartland, E. R. Nocera, and J. Rojo (NNPDF Collaboration), A determination of the fragmentation functions of pions, kaons, and protons with faithful uncertainties, Eur. Phys. J. C 77, 516 (2017).
  28. M. Ablikim et al. (BESIII Collaboration), Single inclusive π± and K± production in e+e− annihilation at center-of-mass energies from 2.000 to 3.671 GeV, arXiv:2502.16084.
  29. H. Bhatt, P. Bosted, S. Jia, W. Armstrong, D. Dutta, R. Ent, D. Gaskell, E. Kinney, H. Mkrtchyan, S. Ali et al., Flavor dependence of charged pion fragmentation functions, Phys. Lett. B 865, 139485 (2025).
  30. Y. L. Dokshitzer, Calculation of the structure functions for deep inelastic scattering and e+e− annihilation by perturbation theory in quantum chromodynamics., Sov. Phys. JETP 46, 641 (1977).
  31. V. N. Gribov and L. N. Lipatov, Deep inelastic e p scattering in perturbation theory, Sov. J. Nucl. Phys. 15, 438 (1972).
  32. G. Altarelli and G. Parisi, Asymptotic freedom in parton language, Nucl. Phys. B126, 298 (1977).
  33. D. Buskulic et al. (ALEPH Collaboration), Inclusive π±, K± and (pp−) differential cross-sections at the Z resonance, Z. Phys. C 66, 355 (1995).
  34. P. Abreu et al. (DELPHI Collaboration), π±, K±, p and p− production in Z0→qq−, Z0→bb−, Z0→uu−, dd−, ss−, Eur. Phys. J. C 5, 585 (1998).
  35. R. Akers et al. (OPAL Collaboration), Measurement of the production rates of charged hadrons in e+e− annihilation at the Z0, Z. Phys. C 63, 181 (1994).
  36. R. Brandelik et al. (TASSO Collaboration), Charged pion, kaon, proton and anti-proton production in high-energy e+e− annihilation, Phys. Lett. 94B, 444 (1980).
  37. M. Althoff et al. (TASSO Collaboration), Charged hadron composition of the final state in e+e− annihilation at high-energies, Z. Phys. C 17, 5 (1983).
  38. W. Braunschweig et al. (TASSO Collaboration), Pion, kaon and proton cross-sections in e+e− annihilation at 34-GeV and 44-GeV center-of-mass energy, Z. Phys. C 42, 189 (1989).
  39. M. Leitgab et al. (Belle Collaboration), Precision measurement of charged pion and kaon differential cross sections in e+e− annihilation at s=10.52 GeV, Phys. Rev. Lett. 111, 062002 (2013).
  40. R. Itoh et al. (TOPAZ Collaboration), Measurement of inclusive particle spectra and test of MLLA prediction in e+e− annihilation at s**(1/2) = 58-GeV, Phys. Lett. B 345, 335 (1995).
  41. J. P. Lees et al. (BABAR Collaboration), Production of charged pions, kaons, and protons in e+e− annihilations into hadrons at s=10.54  GeV, Phys. Rev. D 88, 032011 (2013).
  42. H. Aihara et al. (TPC/Two Gamma Collaboration), Charged hadron inclusive cross-sections and fractions in e+e− annihiliation s=29  GeV, Phys. Rev. Lett. 61, 1263 (1988).
  43. K. Abe et al. (SLD Collaboration), Production of π+, π−, K+, K−, p and p¯ in light (uds), c and b jets from Z0 decays, Phys. Rev. D 69, 072003 (2004).
  44. C. Adolph et al. (COMPASS Collaboration), Multiplicities of charged pions and charged hadrons from deep-inelastic scattering of muons off an isoscalar target, Phys. Lett. B 764, 1 (2017).
  45. A. Airapetian et al. (HERMES Collaboration), Multiplicities of charged pions and kaons from semi-inclusive deep-inelastic scattering by the proton and the deuteron, Phys. Rev. D 87, 074029 (2013).
  46. R. D. Ball et al. (NNPDF Collaboration), Parton distributions from high-precision collider data, Eur. Phys. J. C 77, 663 (2017).
  47. R. D. Ball et al. (NNPDF Collaboration), Determination of the theory uncertainties from missing higher orders on NNLO parton distributions with percent accuracy, Eur. Phys. J. C 84, 517 (2024).
