Off forward non-s-channel helicity conserving contributions to exclusive vector quarkonium production from the spin dependent BFKL Pomeron

Sanjin Benić1,* and Adrian Dumitru2,3,†

  • *Contact author: sanjinb@phy.hr
  • †Contact author: adrian.dumitru@baruch.cuny.edu
PDF

Phys. Rev. D 112, 034025 – Published 25 August, 2025

DOI: https://doi.org/10.1103/7t3g-d4wr

Abstract

A novel contribution to off forward, exclusive vector quarkonium production, γ(*)+p→V+p, at high energy is derived which corresponds to a t-channel exchange of a Balitsky-Fadin-Kuraev-Lipatov (BFKL) hard Pomeron, with a helicity flip of the proton. This “spin-dependent BFKL Pomeron” is required in a consistent expansion in powers of the momentum transfer t≈−Δ⊥2 beyond first order. The spin-dependent Pomeron violates s-channel helicity conservation at O(Δ⊥2), and beyond. Expanding to leading twist only, it corresponds to generalized parton distributions Eg(x,t) for vanishing skewness. We derive explicit expressions for the eikonal BFKL amplitudes, to all orders in dipole size times momentum transfer, for all helicity configurations of the particles in the initial and final states. We also provide numerical estimates of the helicity flip two gluon exchange amplitude at moderate x from a light cone quark model of the proton. The spin dependent BFKL Pomeron could, in principle, be discovered via double spin asymmetries in e+p→e+p+J/ψ with a transversely polarized proton and longitudinally polarized electron in the initial state.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (65)

  1. L. N. Lipatov, Reggeization of the vector meson and the vacuum singularity in nonAbelian gauge theories, Sov. J. Nucl. Phys. 23, 338 (1976).
  2. E. A. Kuraev, L. N. Lipatov, and V. S. Fadin, The pomeranchuk singularity in nonAbelian gauge theories, Sov. Phys. JETP 45, 199 (1977).
  3. I. I. Balitsky and L. N. Lipatov, The pomeranchuk singularity in quantum chromodynamics, Sov. J. Nucl. Phys. 28, 822 (1978).
  4. A. H. Mueller, Soft gluons in the infinite momentum wave function and the BFKL pomeron, Nucl. Phys. B415, 373 (1994).
  5. I. P. Ivanov, N. N. Nikolaev, and A. A. Savin, Diffractive vector meson production at HERA: From soft to hard QCD, Phys. Part. Nucl. 37, 1 (2006).
  6. J. Nemchik, N. N. Nikolaev, and B. G. Zakharov, Scanning the BFKL pomeron in elastic production of vector mesons at HERA, Phys. Lett. B 341, 228 (1994).
  7. E. V. Kuraev, N. N. Nikolaev, and B. G. Zakharov, Diffractive vector mesons beyond the s channel helicity conservation, JETP Lett. 68, 696 (1998).
  8. R. Boussarie, Y. Hatta, L. Szymanowski, and S. Wallon, Probing the gluon sivers function with an unpolarized target: GTMD distributions and the Odderons, Phys. Rev. Lett. 124, 172501 (2020).
  9. Y. Hagiwara, Y. Hatta, R. Pasechnik, and J. Zhou, Spin-dependent Pomeron and Odderon in elastic proton-proton scattering, Eur. Phys. J. C 80, 427 (2020).
  10. Y. Hatta and J. Zhou, Small-x evolution of the gluon GPD Eg, Phys. Rev. Lett. 129, 252002 (2022).
  11. S. Agrawal, N. Vasim, and R. Abir, Spin-flip gluon generalized transverse-momentum-dependent parton distribution F1,2 at small x, Phys. Rev. D 109, 074039 (2024).
  12. S. Chekanov et al. (ZEUS Collaboration), Exclusive photoproduction of J/ψ mesons at HERA, Eur. Phys. J. C 24, 345 (2002).
  13. H1 Collaboration, Elastic J/ψ production at HERA, Eur. Phys. J. C 46, 585 (2006).
  14. S. Acharya et al. (ALICE Collaboration), First polarisation measurement of coherently photoproduced J/ψ in ultra-peripheral Pb-Pb collisions at sNN=5.02  TeV, arXiv:2304.10928.
  15. L. Massacrier (ALICE Collaboration), Coherent J/ψ photoproduction and polarization in peripheral Pb-Pb collisions with ALICE, in Proceedings of the 58th Rencontres de Moriond on QCD and High Energy Interactions (2024), arXiv:2407.09707.
  16. J. D. Brandenburg, H. Duan, Z. Tu, R. Venugopalan, and Z. Xu, Entanglement enabled intensity interferometry in ultrarelativistic ultraperipheral nuclear collisions, Phys. Rev. Res. 7, 013131 (2025).
  17. L. Adamczyk et al. (STAR Collaboration), Single spin asymmetry AN in polarized proton-proton elastic scattering at s=200  GeV, Phys. Lett. B 719, 62 (2013).
  18. H. Mäntysaari, K. Roy, F. Salazar, and B. Schenke, Gluon imaging using azimuthal correlations in diffractive scattering at the electron-ion collider, Phys. Rev. D 103, 094026 (2021).
  19. H. Kowalski, L. Motyka, and G. Watt, Exclusive diffractive processes at HERA within the dipole picture, Phys. Rev. D 74, 074016 (2006).
  20. N. Armesto and A. H. Rezaeian, Exclusive vector meson production at high energies and gluon saturation, Phys. Rev. D 90, 054003 (2014).
  21. H. Mäntysaari, F. Salazar, and B. Schenke, Energy dependent nuclear suppression from gluon saturation in exclusive vector meson production, Phys. Rev. D 109, L071504 (2024).
  22. D. Boer and C. Setyadi, Probing gluon GTMDs through exclusive coherent diffractive processes, Eur. Phys. J. C 83, 890 (2023).
  23. J. Penttala and C. Royon, Gluon saturation effects in exclusive heavy vector meson photoproduction, Phys. Lett. B 864, 139394 (2025).
  24. Y. Hatta, B.-W. Xiao, and F. Yuan, Gluon tomography from deeply virtual Compton scattering at small-x, Phys. Rev. D 95, 114026 (2017).
  25. A. Dumitru, H. Mäntysaari, and R. Paatelainen, Color charge correlations in the proton at NLO: Beyond geometry based intuition, Phys. Lett. B 820, 136560 (2021).
  26. C.-W. Hwang, Study of quark distribution amplitudes of 1S and 2S heavy quarkonium states, Eur. Phys. J. C 62, 499 (2009).
  27. J. Koempel, P. Kroll, A. Metz, and J. Zhou, Exclusive production of quarkonia as a probe of the GPD E for gluons, Phys. Rev. D 85, 051502 (2012).
  28. O. Bessidskaia Bylund, M. Defurne, and P. A. M. Guichon, Recoil proton polarization: A new discriminative observable for deeply virtual Compton scattering, Phys. Rev. D 107, 014020 (2023).
  29. A. E. Dorokhov, N. I. Kochelev, and Y. A. Zubov, Proton spin within nonperturbative QCD, Int. J. Mod. Phys. A 08, 603 (1993).
  30. N. I. Kochelev, The Pauli form-factor of the quark induced by instantons, Phys. Lett. B 565, 131 (2003).
  31. N. Kochelev, H.-J. Lee, B. Zhang, and P. Zhang, Gluonic structure of the constituent quark, Phys. Lett. B 757, 420 (2016).
  32. B. Zhang, A. Radzhabov, N. Kochelev, and P. Zhang, Pauli form factor of quark and nontrivial topological structure of the QCD, Phys. Rev. D 96, 054030 (2017).
  33. E. Shuryak and I. Zahed, Hadronic structure on the light front. I. Instanton effects and quark-antiquark effective potentials, Phys. Rev. D 107, 034023 (2023).
  34. E. Shuryak and I. Zahed, Hadronic structure on the light front. IV. Heavy and light baryons, Phys. Rev. D 107, 034026 (2023).
  35. N. Miesch, E. Shuryak, and I. Zahed, Baryons and tetraquarks using instanton-induced interactions, Phys. Rev. D 109, 014022 (2024).
  36. A. Tarasov and R. Venugopalan, Role of the chiral anomaly in polarized deeply inelastic scattering. II. Topological screening and transitions from emergent axionlike dynamics, Phys. Rev. D 105, 014020 (2022).
  37. A. Tarasov and R. Venugopalan, Role of the chiral anomaly in polarized deeply inelastic scattering. III. Wess-Zumino-Witten contributions and chiral Ward identities for finite quark mass, Phys. Rev. D 111, 074027 (2025).
  38. F. Schlumpf, Relativistic constituent quark model of electroweak properties of baryons, Phys. Rev. D 47, 4114 (1993); 49, 6246(E) (1994).
  39. S. J. Brodsky and F. Schlumpf, Wave function independent relations between the nucleon axial coupling gA and the nucleon magnetic moments, Phys. Lett. B 329, 111 (1994).
  40. G. A. Miller, Charge density of the neutron, Phys. Rev. Lett. 99, 112001 (2007).
  41. X.-d. Ji, J.-P. Ma, and F. Yuan, Three quark light cone amplitudes of the proton and quark orbital motion dependent observables, Nucl. Phys. B652, 383 (2003).
  42. B. Pasquini, S. Cazzaniga, and S. Boffi, Transverse momentum dependent parton distributions in a light-cone quark model, Phys. Rev. D 78, 034025 (2008).
  43. B. Pasquini and F. Yuan, Sivers and Boer-Mulders functions in light-cone quark models, Phys. Rev. D 81, 114013 (2010).
  44. D. Chakrabarti, C. Mondal, A. Mukherjee, S. Nair, and X. Zhao, Gravitational form factors and mechanical properties of proton in a light-front quark-diquark model, Phys. Rev. D 102, 113011 (2020).
  45. P. Choudhary, B. Gurjar, D. Chakrabarti, and A. Mukherjee, Gravitational form factors and mechanical properties of the proton: Connections between distributions in 2D and 3D, Phys. Rev. D 106, 076004 (2022).
  46. S. Nair, C. Mondal, S. Xu, X. Zhao, A. Mukherjee, and J. P. Vary (BLFQ Collaboration), Gravitational form factors and mechanical properties of quarks in protons: A basis light-front quantization approach, Phys. Rev. D 110, 056027 (2024).
  47. A. Dumitru, G. A. Miller, and R. Venugopalan, Extracting many-body color charge correlators in the proton from exclusive DIS at large Bjorken x, Phys. Rev. D 98, 094004 (2018).
  48. A. Dumitru and T. Stebel, Multiquark matrix elements in the proton and three gluon exchange for exclusive ηc production in photon-proton diffractive scattering, Phys. Rev. D 99, 094038 (2019).
  49. A. Dumitru, V. Skokov, and T. Stebel, Subfemtometer scale color charge correlations in the proton, Phys. Rev. D 101, 054004 (2020).
  50. Y. Yang, T. Liu, and B.-Q. Ma, Six-dimensional light-front Wigner distributions of the proton, Eur. Phys. J. C 85, 504 (2025).
  51. A. Dumitru, H. Mäntysaari, and Y. Tawabutr, Polarized dipole scattering amplitudes meet the valence quark model, Phys. Rev. D 110, 054030 (2024).
  52. S. J. Brodsky and G. R. Farrar, Scaling laws for large momentum transfer processes, Phys. Rev. D 11, 1309 (1975).
  53. A. V. Belitsky, X.-d. Ji, and F. Yuan, A perturbative QCD analysis of the nucleon’s Pauli form-factor F2(Q2), Phys. Rev. Lett. 91, 092003 (2003).
  54. B. G. Zakharov, Quark—diquark model of nucleon and properties of Pomeron and Odderon NN scattering amplitudes in QCD born approximation. (In Russian), Sov. J. Nucl. Phys. 49, 860 (1989).
  55. B. Z. Kopeliovich and B. G. Zakharov, Spin—flip component of the Pomeron, Phys. Lett. B 226, 156 (1989).
  56. B.-Q. Ma and I. Schmidt, The quark orbital angular momentum in a light cone representation, Phys. Rev. D 58, 096008 (1998).
  57. L. Frankfurt, W. Koepf, and M. Strikman, Diffractive heavy quarkonium photoproduction and electroproduction in QCD, Phys. Rev. D 57, 512 (1998).
  58. D. Y. Ivanov, A. Schafer, L. Szymanowski, and G. Krasnikov, Exclusive photoproduction of a heavy vector meson in QCD, Eur. Phys. J. C 34, 297 (2004); 75, 75(E) (2015).
  59. J. P. Lansberg, L. Massacrier, L. Szymanowski, and J. Wagner, Single-transverse-spin asymmetries in exclusive photo-production of J/ψ in ultra-peripheral collisions in the fixed-target mode at the LHC and in the collider mode at RHIC, Phys. Lett. B 793, 33 (2019).
  60. E.-C. Aschenauer et al. (RHIC SPIN Collaboration), The RHIC cold QCD program, arXiv:2302.00605.
  61. C. Hadjidakis et al., A fixed-target programme at the LHC: Physics case and projected performances for heavy-ion, hadron, spin and astroparticle studies, Phys. Rep. 911, 1 (2021).
  62. A. Accardi et al. (LHCspin Collaboration), LHCspin: A polarized gas target for LHC, arXiv:2504.16034.
  63. J. Zhou, Transverse single spin asymmetries at small x and the anomalous magnetic moment, Phys. Rev. D 89, 074050 (2014).
  64. Y. V. Kovchegov and M. G. Santiago, Quark sivers function at small x: Spin-dependent odderon and the sub-eikonal evolution, J. High Energy Phys. 11 (2021) 200; 09 (2022) 186(E).
  65. S. Benic, A. Dumitru, L. Motyka, and T. Stebel, Gluon Sivers function from forward exclusive χc1 photoproduction on unpolarized protons, Phys. Rev. D 111, 054008 (2025).
