Constrain the $χ_{c J} \to D^{()} {\bar{D}}^{()}$ effective couplings via the $X (3872) \to π^{0} χ_{c J}$ decays

Zhao-Sai Jia^1,2, Gang Li ^1,*, and Zhen-Hua Zhang ^3,†

¹College of Physics and Engineering, Qufu Normal University, Qufu 273165, China
²CAS Key Laboratory of Theoretical Physics, Institute of Theoretical Physics, Chinese Academy of Sciences, Beijing 100190, China
³Center for High Energy Physics, Peking University, Beijing 100871, China

^*Contact author: gli@qfnu.edu.cn
^†Contact author: zhhzhang@pku.edu.cn

Phys. Rev. D 112, 074035 – Published 27 October, 2025

DOI: https://doi.org/10.1103/51z1-qls5

Abstract

Hidden-charm decays provide irreplaceable platforms for probing the structures of charmoniumlike states, such as $X (3872)$ , $Y (4260)$ , and $Z_{c} (3900)$ , and their heavy-quark-symmetry partners. In the hadronic molecular scenario, these hidden-charm decays are dominated by intermediate meson loops (IMLs), and the couplings of $χ_{c J} \to D^{(*)} {\bar{D}}^{(*)}$ are essential building blocks of the amplitudes for the pionic and radiative transitions of the charmoniumlike states to the $χ_{c J}$ and $h_{c}$ states, e.g., $X (3872) \to π^{0} χ_{c J}, π π χ_{c J}, γ χ_{c J}$ , and $Y (4260) \to π^{0} h_{c}, η h_{c}$ . These couplings cannot be extracted from the partial decay widths of the $χ_{c J}$ directly and only have estimated values from the vector meson dominance (VMD) model. Utilizing the recent precise determination of the pole position and the isospin breaking properties of the $X (3872)$ , we give an estimation on the upper bounds of the absolute values of the $χ_{c J} \to D^{(*)} {\bar{D}}^{(*)}$ couplings. Our results show that the VMD model may overestimate the $χ_{c J} \to D^{(*)} {\bar{D}}^{(*)}$ couplings considering the $X (3872)$ as a $D {\bar{D}}^{*}$ hadronic molecule with a binding energy about tens of keV. These upper limits can be used and tested in other hidden-charm transitions of the charmoniumlike states to the $χ_{c J}$ and $h_{c}$ .

Physics Subject Headings (PhySH)

Article Text

References (67)

A. Hosaka, T. Iijima, K. Miyabayashi, Y. Sakai, and S. Yasui, Exotic hadrons with heavy flavors: $X$ , $Y$ , $Z$ , and related states, Prog. Theor. Exp. Phys. 2016, 062C01 (2016).
A. Esposito, A. Pilloni, and A. D. Polosa, Multiquark resonances, Phys. Rep. 668, 1 (2017).
F.-K. Guo, C. Hanhart, U.-G. Meißner, Q. Wang, Q. Zhao, and B.-S. Zou, Hadronic molecules, Rev. Mod. Phys. 90, 015004 (2018); 94, 029901(E) (2022).
S. L. Olsen, T. Skwarnicki, and D. Zieminska, Nonstandard heavy mesons and baryons: Experimental evidence, Rev. Mod. Phys. 90, 015003 (2018).
M. Karliner, J. L. Rosner, and T. Skwarnicki, Multiquark states, Annu. Rev. Nucl. Part. Sci. 68, 17 (2018).
Y. S. Kalashnikova and A. V. Nefediev, $X (3872)$ in the molecular model, Phys. Usp. 62, 568 (2019).
N. Brambilla, S. Eidelman, C. Hanhart, A. Nefediev, C.-P. Shen, C. E. Thomas, A. Vairo, and C.-Z. Yuan, The $X Y Z$ states: Experimental and theoretical status and perspectives, Phys. Rep. 873, 1 (2020).
L. Meng, B. Wang, G.-J. Wang, and S.-L. Zhu, Chiral perturbation theory for heavy hadrons and chiral effective field theory for heavy hadronic molecules, Phys. Rep. 1019, 1 (2023).
M.-Z. Liu, Y.-W. Pan, Z.-W. Liu, T.-W. Wu, J.-X. Lu, and L.-S. Geng, Three ways to decipher the nature of exotic hadrons: Multiplets, three-body hadronic molecules, and correlation functions, Phys. Rep. 1108, 1 (2025).
J.-H. Chen, J. Chen, F.-K. Guo, Y.-G. Ma, C.-P. Shen, Q.-Y. Shou, Q. Shou, Q. Wang, J.-J. Wu, and B.-S. Zou, Production of exotic hadrons in $p p$ and nuclear collisions, Nucl. Sci. Tech. 36, 55 (2025).
Z.-G. Wang, Review of the QCD sum rules for exotic states, Front. Phys. (Beijing) 21, 016300 (2026).
S. Dubynskiy and M. B. Voloshin, Pionic transitions from $X (3872)$ to $χ_{c J}$ , Phys. Rev. D 77, 014013 (2008).
S. Fleming and T. Mehen, Hadronic decays of the $X (3872)$ to $χ_{c J}$ in effective field theory, Phys. Rev. D 78, 094019 (2008).
G. Li and X.-H. Liu, Investigating possible decay modes of Y(4260) under $D_{1} (2420) \bar{D} + c . c .$ molecular state ansatz, Phys. Rev. D 88, 094008 (2013).
T. Mehen, Hadronic loops versus factorization in effective field theory calculations of $X (3872) \to χ_{c J} π^{0}$ , Phys. Rev. D 92, 034019 (2015).
M. Ablikim et al. (BESIII Collaboration), Observation of the decay $X (3872) \to π^{0} χ_{c 1} (1 P)$ , Phys. Rev. Lett. 122, 202001 (2019).
V. Bhardwaj et al. (Belle Collaboration), Search for $X (3872)$ and $X (3915)$ decay into $χ_{c 1} π^{0}$ in $B$ decays at Belle, Phys. Rev. D 99, 111101 (2019).
Z.-Y. Zhou, M.-T. Yu, and Z. Xiao, Decays of $X (3872)$ to $χ_{c J} π^{0}$ and $J / ψ π^{+} π^{-}$ , Phys. Rev. D 100, 094025 (2019).
Q. Wu, D.-Y. Chen, and T. Matsuki, A phenomenological analysis on isospin-violating decay of $X (3872)$ , Eur. Phys. J. C 81, 193 (2021).
Z.-G. Wang, Decipher the width of the $X (3872)$ via the QCD sum rules, Phys. Rev. D 109, 014017 (2024).
M. Ablikim et al. (BESIII Collaboration), Search for the decay $χ_{c 1} (3872) \to π^{+} π^{-} χ_{c 1}$ , Phys. Rev. D 109, L071101 (2024).
N. N. Achasov and G. N. Shestakov, Toward an estimate of the amplitude $X (3872) \to π^{0} χ_{c 1} (1 P)$ , Phys. Rev. D 109, 036028 (2024).
M. Ablikim et al. (BESIII Collaboration), Search for $X (3872) \to π^{0} π^{0} χ_{c 1, 2}$ , Phys. Rev. D 110, 072015 (2024).
N. N. Achasov and G. N. Shestakov, Tentative estimates of $B (X (3872) \to π^{0} π^{0} χ_{c 1})$ and $B (X (3872) \to π^{+} π^{-} χ_{c 1})$ , Phys. Rev. D 110, 016023 (2024).
S.-D. Liu, F. Wang, Z.-S. Jia, G. Li, X.-H. Liu, and J.-J. Xie, Pionic transitions of the spin-2 partner of $X (3872)$ to $χ_{c J}$ , Phys. Rev. D 110, 054048 (2024).
S.-D. Liu, Q. Wu, and G. Li, Hadronic decays of possible pseudoscalar $P$ -wave $D {\bar{D}}^{*} / \bar{D} D^{*}$ molecular state, Phys. Rev. D 112, 074002 (2025).
F.-K. Guo, C. Hanhart, G. Li, U.-G. Meissner, and Q. Zhao, Effect of charmed meson loops on charmonium transitions, Phys. Rev. D 83, 034013 (2011).
P. Colangelo, F. De Fazio, and T. N. Pham, Nonfactorizable contributions in $B$ decays to charmonium: The case of $B^{-} \to K^{-} h_{c}$ , Phys. Rev. D 69, 054023 (2004).
A. Deandrea, G. Nardulli, and A. D. Polosa, $J / ψ$ couplings to charmed resonances and to $π$ , Phys. Rev. D 68, 034002 (2003).
V. A. Novikov, L. B. Okun, M. A. Shifman, A. I. Vainshtein, M. B. Voloshin, and V. I. Zakharov, Charmonium and gluons: Basic experimental facts and theoretical introduction, Phys. Rep. 41, 1 (1978).
E. V. Veliev, H. Sundu, K. Azizi, and M. Bayar, Scalar quarkonia at finite temperature, Phys. Rev. D 82, 056012 (2010).
P. Colangelo, F. De Fazio, and T. N. Pham, $B^{-} \to K^{-} χ_{c 0}$ decay from charmed meson rescattering, Phys. Lett. B 542, 71 (2002).
J. M. Dias, T. Ji, X.-K. Dong, F.-K. Guo, C. Hanhart, U.-G. Meißner, Y. Zhang, and Z.-H. Zhang, Dispersive analysis of the isospin breaking in the $X (3872) \to J / ψ π^{+} π^{-}$ and $X (3872) \to J / ψ π^{+} π^{0} π^{-}$ decays, Phys. Rev. D 111, 014031 (2025).
T. Ji, X.-K. Dong, F.-K. Guo, C. Hanhart, and U.-G. Meißner, Precise determination of the properties of $X (3872)$ and of its isovector partner $W_{c 1}$ , arXiv:2502.04458.
M. Ablikim et al. (BESIII Collaboration), Coupled-channel analysis of the $χ_{c 1} (3872)$ line shape with BESIII data, Phys. Rev. Lett. 132, 151903 (2024).
R. Aaij et al. (LHCb Collaboration), Study of the $ψ_{2} (3823)$ and $χ_{c 1} (3872)$ states in $B^{+} \to (J ψ π^{+} π^{-}) K^{+}$ decays, J. High Energy Phys. 08 (2020) 123.
R. Aaij et al. (LHCb Collaboration), Observation of sizeable $ω$ contribution to $χ_{c 1} (3872) \to π^{+} π^{-} J / ψ$ decays, Phys. Rev. D 108, L011103 (2023).
S. Navas et al. (Particle Data Group), Review of particle physics, Phys. Rev. D 110, 030001 (2024).
S. K. Choi et al. (Belle Collaboration), Observation of a narrow charmonium-like state in exclusive $B^{\pm} \to K^{\pm} π^{+} π^{-} J / ψ$ decays, Phys. Rev. Lett. 91, 262001 (2003).
S. K. Choi et al. (Belle Collaboration), Bounds on the width, mass difference and other properties of $X (3872) \to π^{+} π^{-} J / ψ$ decays, Phys. Rev. D 84, 052004 (2011).
B. Aubert et al. (BABAR Collaboration), Search for a charged partner of the $X (3872)$ in the $B$ meson decay $B \to X^{-} K$ , $X^{-} \to J / ψ π^{-} π^{0}$ , Phys. Rev. D 71, 031501 (2005).
R. Aaij et al. (LHCb Collaboration), Determination of the $X (3872)$ meson quantum numbers, Phys. Rev. Lett. 110, 222001 (2013).
R. Aaij et al. (LHCb Collaboration), Quantum numbers of the $X (3872)$ state and orbital angular momentum in its $ρ^{0} J ψ$ decay, Phys. Rev. D 92, 011102 (2015).
R. Aaij et al. (LHCb Collaboration), Study of the lineshape of the $χ_{c 1} (3872)$ state, Phys. Rev. D 102, 092005 (2020).
P. A. Zyla et al. (Particle Data Group), Review of particle physics, Prog. Theor. Exp. Phys. 2020, 083C01 (2020).
A. Esposito, A. Glioti, D. Germani, and A. D. Polosa, A short review on the compositeness of the X(3872), Riv. Nuovo Cimento 48, 95 (2025).
K. Abe et al. (Belle Collaboration), Evidence for $X (3872) \to γ J / ψ$ and the sub-threshold decay $X (3872) \to ω J / ψ$ , in Proceedings of the 22nd International Symposium on Lepton-Photon Interactions at High Energy (LP 2005) (2005).
P. del Amo Sanchez et al. (BABAR Collaboration), Evidence for the decay $X (3872) \to J / ψ ω$ , Phys. Rev. D 82, 011101 (2010).
M. Ablikim et al. (BESIII Collaboration), Study of $e^{+} e^{-} \to γ ω J / ψ$ and Observation of $X (3872) \to ω J / ψ$ , Phys. Rev. Lett. 122, 232002 (2019).
M. Suzuki, The $X (3872)$ boson: Molecule or charmonium, Phys. Rev. D 72, 114013 (2005).
J. Abdallah et al. (DELPHI Collaboration), Search for single top production via FCNC at LEP at $\sqrt{s} = 189 - 208 GeV$ , Phys. Lett. B 590, 21 (2004).
C. Meng and K.-T. Chao, Decays of the $X (3872)$ and $χ_{c 1} (2 P)$ charmonium, Phys. Rev. D 75, 114002 (2007).
D. Gamermann and E. Oset, Isospin breaking effects in the $X (3872)$ resonance, Phys. Rev. D 80, 014003 (2009).
D. Gamermann, J. Nieves, E. Oset, and E. Ruiz Arriola, Couplings in coupled channels versus wave functions: application to the $X (3872)$ resonance, Phys. Rev. D 81, 014029 (2010).
K. Terasaki, $ω - ρ^{0}$ mixing as a possible origin of the hypothetical isospin non-conservation in the $X (3872) \to π^{+} π^{-} J / ψ$ decay, Prog. Theor. Phys. 122, 1285 (2010).
M. Karliner and H. J. Lipkin, Isospin violation in $X (3872)$ : Explanation from a new tetraquark model, arXiv:1008.0203.
N. Li and S.-L. Zhu, Isospin breaking, coupled-channel effects and diagnosis of $X (3872)$ , Phys. Rev. D 86, 074022 (2012).
N. Achasov, Electro-weak production of pseudovector C-even heavy quarkonia in electron-positron collisions on Belle II and BES III, EPJ Web Conf. 212, 02001 (2019).
L. Meng, G.-J. Wang, B. Wang, and S.-L. Zhu, Revisit the isospin violating decays of $X (3872)$ , Phys. Rev. D 104, 094003 (2021).
N. N. Achasov and G. N. Shestakov, Decay $X (3872) \to π^{0} π^{+} π^{-}$ and $S$ -wave $D^{0} {\bar{D}}^{0} \to π^{+} π^{-}$ scattering length, Phys. Rev. D 99, 116023 (2019).
J. H. Yin et al. (Belle Collaboration), Search for $X (3872) \to π^{+} π^{-} π^{0}$ at Belle, Phys. Rev. D 107, 052004 (2023).
Z.-H. Zhang, T. Ji, X.-K. Dong, F.-K. Guo, C. Hanhart, U.-G. Meißner, and A. Rusetsky, Predicting isovector charmonium-like states from $X (3872)$ properties, J. High Energy Phys. 08 (2024) 130.
F. Aceti, R. Molina, and E. Oset, The $X (3872) \to J / ψ γ$ decay in the $D {\bar{D}}^{*}$ molecular picture, Phys. Rev. D 86, 113007 (2012).
F. Aceti, R. Molina, and E. Oset, The $X (3872) \to J / ψ γ$ , $J / ψ π π$ and $J / ψ π π π$ decays in the $D {\bar{D}}^{*}$ molecular picture, Proc. Sci., QNP2012 (2012) 072.
H.-D. Cai, Z.-S. Jia, G. Li, and S.-D. Liu, Hidden charmed decays of $X (3872)$ within the $D {\bar{D}}^{*}$ molecular framework, Phys. Rev. D 111, 114024 (2025).
M. Albaladejo, F. K. Guo, C. Hidalgo-Duque, J. Nieves, and M. P. Valderrama, Decay widths of the spin-2 partners of the X(3872), Eur. Phys. J. C 75, 547 (2015).
J. Hu and T. Mehen, Chiral Lagrangian with heavy quark-diquark symmetry, Phys. Rev. D 73, 054003 (2006).
