Tree-level NLO corrections to inclusive ψ′ production in high energy factorization

A. A. Prokhorov1, S. P. Baranov2, A. V. Lipatov3, M. A. Malyshev3,4, and X. Chen5,6

PDF

Phys. Rev. D 112, 114022 – Published 15 December, 2025

DOI: https://doi.org/10.1103/454q-673t

Abstract

We consider inclusive ψ(2S) production in proton-proton collisions at collider energies in the framework of nonrelativistic QCD and high energy factorization beyond the low-order approximation. We utilize a matching scheme proposed earlier to merge the leading-order and tree-level next-to-leading-order (NLO) production amplitudes and now extend it to low transverse momenta and/or forward rapidities. With the improved scheme, we examine the possibility to simultaneously describe all unpolarized LHC data in the full kinematic range accessible to experimental measurements and try different transverse momentum-dependent gluon distributions in the proton. A global fit to the data is carried out to extract the color octet long-distance matrix elements for ψ(2S) mesons. We show that taking the NLO corrections into account leads to a better description of the data.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (83)

  1. N. Brambilla et al., Eur. Phys. J. C 71, 1534 (2011).
  2. J.-P. Lansberg, Phys. Rep. 889, 1 (2020).
  3. E. Chapon et al., Prog. Part. Nucl. Phys. 122, 103906 (2022).
  4. G. Bodwin, E. Braaten, and G. Lepage, Phys. Rev. D 51, 1125 (1995).
  5. P. Cho and A. K. Leibovich, Phys. Rev. D 53, 150 (1996).
  6. P. Cho and A. K. Leibovich, Phys. Rev. D 53, 6203 (1996).
  7. C. Chang, Nucl. Phys. B172, 425 (1980).
  8. R. Baier and R. Ruckl, Z. Phys. C 19, 251 (1983).
  9. E. L. Berger and D. L. Jones, Phys. Rev. D 23, 1521 (1981).
  10. V. D. Barger, W.-Y. Keung, and R. J. N. Phillips, Phys. Lett. 91B, 253 (1980).
  11. V. D. Barger, W.-Y. Keung, and R. J. N. Phillips, Z. Phys. C 6, 169 (1980).
  12. R. Gavai, D. Kharzeev, H. Satz, G. A. Schuler, K. Sridhar, and R. Vogt, Int. J. Mod. Phys. A 10, 3043 (1995).
  13. Y.-Q. Ma and R. Vogt, Phys. Rev. D 94, 114029 (2016).
  14. L. V. Gribov, E. M. Levin, and M. G. Ryskin, Phys. Rep. 100, 1 (1983); E. M. Levin, M. G. Ryskin, Yu. M. Shabelsky, and A. G. Shuvaev, Sov. J. Nucl. Phys. 53, 657 (1991).
  15. S. Catani, M. Ciafaloni, and F. Hautmann, Nucl. Phys. B366, 135 (1991); J. C. Collins and R. K. Ellis, B360, 3 (1991).
  16. E. A. Kuraev, L. N. Lipatov, and V. S. Fadin, Sov. Phys. JETP 44, 443 (1976), http://www.jetp.ras.ru/cgi-bin/e/index/e/44/3/p443?a=list; 45, 199 (1977), http://www.jetp.ras.ru/cgi-bin/e/index/e/45/2/p199?a=list; I. I. Balitsky and L. N. Lipatov, Sov. J. Nucl. Phys. 28, 822 (1978).
  17. M. Ciafaloni, Nucl. Phys. B296, 49 (1988); S. Catani, F. Fiorani, and G. Marchesini, Phys. Lett. B 234, 339 (1990); Nucl. Phys. B336, 18 (1990); G. Marchesini, B445, 49 (1995).
  18. R. Angeles-Martinez et al., Acta Phys. Pol. B 46, 2501 (2015).
  19. A. V. Lipatov, S. P. Baranov, and M. A. Malyshev, Phys. Part. Nucl. 55, 256 (2024).
  20. S. P. Baranov and A. V. Lipatov, Phys. Rev. D 100, 114021 (2019).
  21. S. P. Baranov and A. V. Lipatov, Eur. Phys. J. C 79, 621 (2019).
  22. S. P. Baranov and A. V. Lipatov, Eur. Phys. J. C 80, 1022 (2020).
  23. N. A. Abdulov and A. V. Lipatov, Eur. Phys. J. C 79, 830 (2019).
  24. N. A. Abdulov and A. V. Lipatov, Eur. Phys. J. C 80, 486 (2020).
  25. N. A. Abdulov and A. V. Lipatov, Eur. Phys. J. C 81, 1085 (2021).
  26. B. Gong, X. Q. Li, and J.-X. Wang, Phys. Lett. B 673, 197 (2009).
  27. M. Butenschön and B. A. Kniehl, Phys. Rev. D 84, 051501 (2011).
  28. Y.-Q. Ma, K. Wang, K.-T. Chao, and H.-F. Zhang, Phys. Rev. D 83, 111503 (2011).
  29. Y.-Q. Ma, K. Wang, and K.-T. Chao, Phys. Rev. D 84, 114001 (2011).
  30. G. T. Bodwin, H. S. Chung, U.-R. Kim, and J. Lee, Phys. Rev. Lett. 113, 022001 (2014).
  31. A. K. Likhoded, A. V. Luchinsky, and S. V. Poslavsky, Phys. Rev. D 90, 074021 (2014).
  32. H.-F. Zhang, L. Yu, S.-X. Zhang, and L. Jia, Phys. Rev. D 93, 054033 (2016).
  33. Y. Q. Ma, K. Wang, and K.-T. Chao, Phys. Rev. Lett. 106, 042002 (2011).
  34. B. Gong, J.-X. Wang, and H.-F. Zhang, Phys. Rev. D 83, 114021 (2011).
  35. K. Wang, Y.-Q. Ma, and K.-T. Chao, Phys. Rev. D 85, 114003 (2012).
  36. B. Gong, L.-P. Wan, J.-X. Wang, and H.-F. Zhang, Phys. Rev. Lett. 112, 032001 (2014).
  37. Y. Feng, B. Gong, L.-P. Wan, J.-X. Wang, and H.-F. Zhang, Chin. Phys. C 39, 123102 (2015).
  38. H. Han, Y.-Q. Ma, C. Meng, H.-S. Shao, Y.-J. Zhang, and K.-T. Chao, Phys. Rev. D 94, 014028 (2016).
  39. Y. Feng, B. Gong, C.-H. Chang, and J.-X. Wang, Chin. Phys. C 45, 013117 (2021).
  40. S. P. Baranov, Phys. Rev. D 93, 054037 (2016).
  41. S. P. Baranov, A. V. Lipatov, A. A. Prokhorov, and X. Chen, Eur. Phys. J. C 84, 348 (2024).
  42. H.-F. Zhang, Z. Sun, W.-L. Sang, and R. Li, Phys. Rev. Lett. 114, 092006 (2015).
  43. M. Butenschön, Z.-G. He, and B. A. Kniehl, Phys. Rev. Lett. 114, 092004 (2015).
  44. S. P. Baranov, Phys. Rev. D 83, 034035 (2011).
  45. M. Butenschön and B. A. Kniehl, Phys. Rev. D 107, 034003 (2023).
  46. CMS Collaboration, Phys. Lett. B 727, 381 (2013).
  47. CMS Collaboration, Phys. Lett. B 858, 139044 (2024).
  48. LHCb Collaboration, Eur. Phys. J. C 74, 2872 (2014).
  49. ATLAS Collaboration, Eur. Phys. J. C 78, 171 (2018).
  50. ATLAS Collaboration, Eur. Phys. J. C 76, 283 (2016).
  51. ATLAS Collaboration, Eur. Phys. J. C 84, 169 (2024).
  52. CMS Collaboration, Phys. Lett. B 790, 509 (2019).
  53. CMS Collaboration, Phys. Lett. B 114, 191802 (2015).
  54. CMS Collaboration, Phys. Lett. B 780, 251 (2018).
  55. LHCb Collaboration, Eur. Phys. J. C 80, 185 (2020).
  56. ALICE Collaboration, Eur. Phys. J. C 74, 2974 (2014).
  57. ALICE Collaboration, Eur. Phys. J. C 76, 184 (2016).
  58. ALICE Collaboration, Eur. Phys. J. C 77, 392 (2017).
  59. R. Maciula and A. Szczurek, Phys. Rev. D 100, 054001 (2019).
  60. A. V. Lipatov, M. A. Malyshev, and H. Jung, Phys. Rev. D 101, 034022 (2020).
  61. E. J. Eichten and C. Quigg, Phys. Rev. D 52, 1726 (1995).
  62. E. J. Eichten and C. Quigg, arXiv:1904.11542.
  63. H. Krasemann, Z. Phys. C 1, 189 (1979).
  64. G. Guberina, J. Kühn, R. Peccei, and R. Rückl, Nucl. Phys. B174, 317 (1980).
  65. L. N. Lipatov and M. I. Vyazovsky, Nucl. Phys. B597, 399 (2001).
  66. A. V. Bogdan and V. S. Fadin, Nucl. Phys. B740, 36 (2006).
  67. S. P. Baranov and A. Szcurek, Phys. Rev. D 77, 054016 (2008).
  68. E. Bycling and K. Kajantie, Particle Kinematics (John Wiley and Sons, New York, 1973).
  69. H. Jung, arXiv:hep-ph/0411287.
  70. F. Hautmann and H. Jung, Nucl. Phys. B883, 1 (2014).
  71. H.Jung, S. P. Baranov, M. Deak, A. Grebenyuk, F. Hautmann, M. Hentschinski, A. Knutsson, M. Krämer, K. Kutak, A. V. Lipatov, and N. P. Zotov, Eur. Phys. J. C 70, 1237 (2010).
  72. K. Golec-Biernat, L. Motyka, and T. Stebel, Phys. Rev. D 103, 034013 (2021).
  73. A. V. Lipatov, M. A. Malyshev, and H. Jung, Phys. Rev. D 100, 034028 (2019).
  74. A. V. Lipatov and M. A. Malyshev, Phys. Rev. D 103, 094021 (2001).
  75. A. V. Lipatov, G. I. Lykasov, and M. A. Malyshev, Phys. Lett. B 839, 137780 (2023).
  76. A. V. Lipatov and M. A. Malyshev, Phys. Rev. D 108, 014022 (2023).
  77. N. A. Abdulov et al., Eur. Phys. J. C 81, 752 (2021).
  78. A. V. Lipatov, M. A. Malyshev, and S. P. Baranov, Eur. Phys. J. C 80, 330 (2020).
  79. PDG Collaboration, Prog. Theor. Exp. Phys. 2022, 083C01 (2022).
  80. E. Braaten and J. Lee, Phys. Rev. D 67, 054007 (2003).
  81. M. G. Echevarria, J. High Energy Phys. 10 (2019) 144.
  82. S. Fleming, Y. Makris, and T. Mehen, J. High Energy Phys. 04 (2020) 122.
  83. L. Maxia, D. Boer, J. Bor, C. Pisano, and F. Yuan, J. High Energy Phys. 08 (2023) 105.
