New 4D lattice QCD equation of state: Extended density coverage from a generalized T′ expansion

Ahmed Abuali1, Szabolcs Borsányi2, Zoltán Fodor3,4,2,5,6, Johannes Jahan1,*, Micheal Kahangirwe1, Paolo Parotto7, Attila Pásztor5, Claudia Ratti1, Hitansh Shah1 et al.

Seth A. Trabulsi8

  • *Contact author: jahan.johannes@gmail.com
PDF

Phys. Rev. D 112, 054502 – Published 9 September, 2025

DOI: https://doi.org/10.1103/2dmh-26yh

Abstract

We present a new equation of state for QCD in which the temperature T and the three chemical potentials for baryon number μB, electric charge μQ, and strangeness μS can be varied independently. This result is based on a generalization of the T′ expansion scheme, thanks to which the diagonal μB extrapolation was pushed up to a baryo-chemical potential μB/T∼3.5 for the first time. This considerably extended the coverage of the Taylor expansion, limited to μB/T<2.5–3. As a consequence, we are able to offer a substantially larger coverage of the four-dimensional QCD phase diagram as well, compared to previously available Taylor expansion results. Our findings are based on new continuum estimated lattice data on the full set of second- and fourth-order fluctuations.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (52)

  1. Y. Aoki, G. Endrodi, Z. Fodor, S. D. Katz, and K. K. Szabo, The order of the quantum chromodynamics transition predicted by the standard model of particle physics, Nature (London) 443, 675 (2006).
  2. Y. Aoki, Z. Fodor, S. D. Katz, and K. K. Szabo, The QCD transition temperature: Results with physical masses in the continuum limit, Phys. Lett. B 643, 46 (2006).
  3. Y. Aoki, S. Borsanyi, S. Durr, Z. Fodor, S. D. Katz, S. Krieg, and K. K. Szabo, The QCD transition temperature: Results with physical masses in the continuum limit II., J. High Energy Phys. 06 (2009) 088.
  4. S. Borsanyi, Z. Fodor, C. Hoelbling, S. D. Katz, S. Krieg, C. Ratti, and K. K. Szabo (Wuppertal-Budapest Collaboration), Is there still any Tc mystery in lattice QCD? Results with physical masses in the continuum limit III, J. High Energy Phys. 09 (2010) 073.
  5. A. Bazavov et al., The chiral and deconfinement aspects of the QCD transition, Phys. Rev. D 85, 054503 (2012).
  6. A. Bazavov et al. (HotQCD Collaboration), Chiral crossover in QCD at zero and non-zero chemical potentials, Phys. Lett. B 795, 15 (2019).
  7. S. Borsanyi, Z. Fodor, J. N. Guenther, R. Kara, S. D. Katz, P. Parotto, A. Pasztor, C. Ratti, and K. K. Szabo, QCD crossover at finite chemical potential from lattice simulations, Phys. Rev. Lett. 125, 052001 (2020).
  8. M. G. Alford, A. Schmitt, K. Rajagopal, and T. Schäfer, Color superconductivity in dense quark matter, Rev. Mod. Phys. 80, 1455 (2008).
  9. S. Borsanyi, Z. Fodor, S. Katz, S. Krieg, C. Ratti, and K. Szabo, Freeze-out parameters: Lattice meets experiment, Phys. Rev. Lett. 111, 062005 (2013).
  10. A. Bazavov et al. (HotQCD Collaboration), Equation of state in (2+1)-flavor QCD, Phys. Rev. D 90, 094503 (2014).
  11. S. Borsanyi, Z. Fodor, J. N. Guenther, P. Parotto, A. Pasztor, C. Ratti, V. Vovchenko, and C. H. Wong, Lattice QCD constraints on the critical point from an improved precision equation of state, arXiv:2502.10267.
  12. A. Alexandru, M. Faber, I. Horvath, and K.-F. Liu, Lattice QCD at finite density via a new canonical approach, Phys. Rev. D 72, 114513 (2005).
  13. A. Li, A. Alexandru, K.-F. Liu, and X. Meng, Finite density phase transition of QCD with Nf=4 and Nf=2 using canonical ensemble method, Phys. Rev. D 82, 054502 (2010).
  14. S. Borsanyi, Z. Fodor, M. Giordano, S. D. Katz, D. Nogradi, A. Pasztor, and C. H. Wong, Lattice simulations of the QCD chiral transition at real baryon density, Phys. Rev. D 105, L051506 (2022).
  15. S. Borsanyi, Z. Fodor, M. Giordano, J. N. Guenther, S. D. Katz, A. Pasztor, and C. H. Wong, Equation of state of a hot-and-dense quark gluon plasma: Lattice simulations at real μB vs extrapolations, Phys. Rev. D 107, L091503 (2023).
  16. P. de Forcrand and O. Philipsen, The QCD phase diagram for small densities from imaginary chemical potential, Nucl. Phys. B642, 290 (2002).
  17. M. D’Elia and M.-P. Lombardo, Finite density QCD via imaginary chemical potential, Phys. Rev. D 67, 014505 (2003).
  18. C. Bonati, M. D’Elia, M. Mariti, M. Mesiti, F. Negro, and F. Sanfilippo, Curvature of the chiral pseudocritical line in QCD: Continuum extrapolated results, Phys. Rev. D 92, 054503 (2015).
  19. M. D’Elia, G. Gagliardi, and F. Sanfilippo, Higher order quark number fluctuations via imaginary chemical potentials in Nf=2+1 QCD, Phys. Rev. D 95, 094503 (2017).
  20. J. Gunther, R. Bellwied, S. Borsanyi, Z. Fodor, S. D. Katz, A. Pasztor, and C. Ratti, The QCD equation of state at finite density from analytical continuation, EPJ Web Conf. 137, 07008 (2017).
  21. C. Bonati, M. D’Elia, F. Negro, F. S anfilippo, and K. Zambello, Curvature of the pseudocritical line in QCD: Taylor expansion matches analytic continuation, Phys. Rev. D 98, 054510 (2018).
  22. S. Borsanyi, Z. Fodor, J. N. Guenther, S. K. Katz, K. K. Szabo, A. Pasztor, I. Portillo, and C. Ratti, Higher order fluctuations and correlations of conserved charges from lattice QCD, J. High Energy Phys. 10 (2018) 205.
  23. R. Bellwied, S. Borsanyi, Z. Fodor, J. Guenther, S. D. Katz, C. Ratti, and K. K. Szabo, The QCD phase diagram from analytic continuation, Phys. Lett. B 751, 559 (2015).
  24. D. Bollweg, F. Karsch, S. Mukherjee, and C. Schmidt, Higher order cumulants of net baryon-number distributions at n on-zero μB, Nucl. Phys. A1005, 121835 (2021).
  25. D. Bollweg, J. Goswami, O. Kaczmarek, S. Karsch, F. and Mukherjee, P. Petreczky, C. Schmidt, and P. Scior (HotQCD Collaboration), Taylor expansions and Padé approximants for cumulants of con served charge fluctuations at nonvanishing chemical potentials, Phys. Rev. D 105, 074511 (2022).
  26. H. T. Ding, O. Kaczmarek, F. Karsch, P. Petreczky, M. Sarkar, C. Schmidt, and S. Sharma, Curvature of the chiral phase transition line from the magnetic equation of state of (2+1)-flavor QCD, Phys. Rev. D 109, 114516 (2024).
  27. D. Bollweg, D. A. Clarke, J. Goswami, O. Kaczmarek, F. Karsch, S. Mukherjee, P. Petreczky, C. Schmidt, and S. Sharma (HotQCD Collaboration), Equation of state and speed of sound of (2+1)-flavor QCD in strangeness-neutral matter at nonvanishing net baryon-number density, Phys. Rev. D 108, 014510 (2023).
  28. S. Borsányi, Z. Fodor, J. N. Guenther, R. Kara, S. D. Katz, P. Parotto, A. Pásztor, C. Ratti, and K. K. Szabó, Lattice QCD equation of state at finite chemical potential from an alternative expansion scheme, Phys. Rev. Lett. 126, 232001 (2021).
  29. S. Borsanyi, J. N. Guenther, R. Kara, Z. Fodor, P. Parotto, A. Pasztor, C. Ratti, and K. K. Szabo, Resummed lattice QCD equation of state at finite baryon density: Strangeness neutrality and beyond, Phys. Rev. D 105, 114504 (2022).
  30. R. Wen, S. Yin, and W.-j. Fu, Estimates on the convergence of expansions at finite baryon chemical potentials, Phys. Rev. D 110, 016008 (2024).
  31. M. Kahangirwe, I. Gonzalez, J. A. Muñoz, C. Ratti, and V. Vovchenko, Convergence properties of T′ expansion scheme: Hadron resonance gas and cluster expansion model, Phys. Rev. D 111, 094034 (2025).
  32. M. Kahangirwe, S. A. Bass, E. Bratkovskaya, J. Jahan, P. Moreau, P. Parotto, D. Price, C. Ratti, O. Soloveva, and M. Stephanov, Finite density QCD equation of state: Critical point and lattice-based T′ expansion, Phys. Rev. D 109, 094046 (2024).
  33. P. Parotto, M. Bluhm, D. Mroczek, M. Nahrgang, J. Noronha-Hostler, K. Rajagopal, C. Ratti, T. Schäfer, and M. Stephanov, QCD equation of state matched to lattice data and exhibiting a critical point singularity, Phys. Rev. C 101, 034901 (2020).
  34. C. Plumberg et al., Conservation of B, S, and Q charges in relativistic viscous hydrodynamics solved with smoothed particle hydrodynamics, Phys. Rev. C 111, 044905 (2025).
  35. J. Noronha-Hostler, P. Parotto, C. Ratti, and J. M. Stafford, Lattice-based equation of state at finite baryon number, electric charge and strangeness chemical potentials, Phys. Rev. C 100, 064910 (2019).
  36. R. Dashen, S.-K. Ma, and H. J. Bernstein, S matrix formulation of statistical mechanics, Phys. Rev. 187, 345 (1969).
  37. A. Monnai, B. Schenke, and C. Shen, Equation of state at finite densities for QCD matter in nuclear collisions, Phys. Rev. C 100, 024907 (2019).
  38. A. Monnai, G. Pihan, B. Schenke, and C. Shen, Four-dimensional QCD equation of state with multiple chemical potentials, Phys. Rev. C 110, 044905 (2024).
  39. A. Bazavov et al. (HotQCD Collaboration), Fluctuations and Correlations of net baryon number, electric charge, and strangeness: A comparison of lattice QCD results with the hadron resonance gas model, Phys. Rev. D 86, 034509 (2012).
  40. H. T. Ding, S. Mukherjee, H. Ohno, P. Petreczky, and H. P. Schadler, Diagonal and off-diagonal quark number susceptibilities at high temperatures, Phys. Rev. D 92, 074043 (2015).
  41. A. Bazavov et al., The QCD equation of state to O(μB6) from lattice QCD, Phys. Rev. D 95, 054504 (2017).
  42. A. Bazavov et al. (HotQCD Collaboration), Equation of state in (2+1)-flavor QCD, Phys. Rev. D 90, 094503 (2014).
  43. S. Borsányi, Z. Fodor, J. N. Guenther, R. Kara, P. Parotto, A. Pásztor, L. Pirelli, and C. H. Wong, Chiral versus deconfinement properties of the QCD crossover: Differences in the volume and chemical potential dependence from the lattice, Phys. Rev. D 111, 014506 (2025).
  44. R. Bellwied, S. Borsanyi, Z. Fodor, S. D. Katz, A. Pasztor, C. Ratti, and K. K. Szabo, Fluctuations and correlations in high temperature QCD, Phys. Rev. D 92, 114505 (2015).
  45. P. Alba et al., Constraining the hadronic spectrum through QCD thermodynamics on the lattice, Phys. Rev. D 96, 034517 (2017).
  46. J. Jahan and P. Parotto, Continuum-estimated lattice susceptibilites of order 2 and 4, 10.5281/zenodo.16749145 (2025).
  47. S. Borsanyi, Z. Fodor, C. Hoelbling, S. D. Katz, S. Krieg, and K. K. Szabo, Full result for the QCD equation of state with 2+1 flavors, Phys. Lett. B 730, 99 (2014).
  48. J. Jahan, A. Abuali, M. Kahangirwe, P. Parotto, C. Ratti, and H. Shah, 4D T′ expansion scheme (4D-TExS) equation of state module, 10.5281/zenodo.16749256 (2025).
  49. MUSES Project Web site, https://musesframework.io/ (2024).
  50. T. A. Manning, MUSES Calculation Engine, 10.5281/zenodo.14721911 (2025).
  51. M. Reinke Pelicer et al., Building neutron stars with the MUSES calculation engine, Phys. Rev. D 111, 103037 (2025).
  52. www.gauss-centre.eu

Outline

Information

Phys. Rev. D 112, 054502– Published 9 September, 2025
  • Received 10 May 2025
  • Accepted 6 August 2025
Crossmark - Check for updates button
Creative Commons Logo

Published by the American Physical Society under the terms of the Creative Commons Attribution 4.0 International license. Further distribution of this work must maintain attribution to the author(s) and the published article’s title, journal citation, and DOI. Funded by SCOAP3.
