Exploratory calculation of $K_{L} \to μ^{+} μ^{-}$ decay from lattice QCD at physical pion mass

Peter Boyle ^1,2, En-Hung Chao ³, Norman Christ ³, Ceran Hu ³, Luchang Jin ⁴, and Yidi Zhao ³

¹Physics Department, Brookhaven National Laboratory, Upton, New York 11973, USA
²School of Physics and Astronomy, The University of Edinburgh, Edinburgh EH9 3FD, United Kingdom
³Physics Department, Columbia University, New York City, New York 10027, USA
⁴Physics Department, University of Connecticut, Storrs, Connecticut 06269-3046, USA

Phys. Rev. D 113, 074523 – Published 30 April, 2026

DOI: https://doi.org/10.1103/22hn-ymsd

Abstract

We compute the complex, long-distance two-photon-exchange amplitude which contributes to the rare $K_{L} \to μ^{+} μ^{-}$ decay from lattice QCD. We use a $24^{3} \times 64$ physical-pion-mass gauge field ensemble at an inverse lattice spacing of 1.023 GeV and a ${QED}_{\infty}$ -based formalism. Our implementation strategies for all five non-SU(3)-flavor-suppressed diagram topologies are given in detail. We achieve a 25% statistical precision on the dispersive part of this long-distance amplitude. This calculation is carried out with $2 + 1$ quark flavors and therefore requires the addition of counterterms to compensate for the absence of the Glashow-Iliopoulos-Maiani mechanism. These counterterms are not included in the current calculation and will be the subject of a second paper. Although a direct comparison to experiment cannot yet be made because of those omitted counterterms, the present exploratory calculation allows one to identify principal sources of statistical uncertainty in this calculation. The precision of our results is limited by the reconstruction of the physical contribution of the $η$ intermediate state, for which various strategies are tested and compared.

Physics Subject Headings (PhySH)

Article Text

References (56)

D. Ambrose et al. (E871 Collaboration), Improved branching ratio measurement for the decay $K_{L}^{0} \to μ^{+} μ^{-}$ , Phys. Rev. Lett. 84, 1389 (2000).
R. L. Workman et al. (Particle Data Group Collaboration), Review of particle physics, Prog. Theor. Exp. Phys. 2022, 083C01 (2022).
M. Gorbahn and U. Haisch, Charm quark contribution to $K_{L} \to μ^{+} μ^{-}$ at next-to-next-to-leading, Phys. Rev. Lett. 97, 122002 (2006).
B. R. Martin, E. De Rafael, and J. Smith, Neutral kaon decays into lepton pairs, Phys. Rev. D 2, 179 (1970).
G. D’Ambrosio, G. Isidori, and J. Portoles, Can we extract short distance information from B( $K_{L} \to μ^{+} μ^{-}$ ), Phys. Lett. B 423, 385 (1998).
M. Knecht, S. Peris, M. Perrottet, and E. de Rafael, Decay of pseudoscalars into lepton pairs and large N(c) QCD, Phys. Rev. Lett. 83, 5230 (1999).
G. Isidori and R. Unterdorfer, On the short distance constraints from $K_{L, S} \to μ^{+} μ^{-}$ , J. High Energy Phys. 01 (2004) 009,
M. Hoferichter, B.-L. Hoid, and J. R. de Elvira, Improved standard-model prediction for $K_{L} \to ℓ^{+} ℓ^{-}$ , J. High Energy Phys. 04 (2023) 071.
T. Blum, N. Christ, M. Hayakawa, T. Izubuchi, L. Jin, and C. Lehner, Lattice calculation of hadronic light-by-light contribution to the muon anomalous magnetic moment, Phys. Rev. D 93, 014503 (2016).
T. Blum, N. Christ, M. Hayakawa, T. Izubuchi, L. Jin, C. Jung, C. Lehner, and C. Tu (RBC, UKQCD Collaborations), Hadronic light-by-light contribution to the muon anomaly from lattice QCD with infinite volume QED at physical pion mass, Phys. Rev. D 111, 014501 (2025).
N. Asmussen, E.-H. Chao, A. Gérardin, J. R. Green, R. J. Hudspith, H. B. Meyer, and A. Nyffeler, Hadronic light-by-light scattering contribution to the muon $g - 2$ from lattice QCD: Semi-analytical calculation of the QED kernel, J. High Energy Phys. 04 (2022) 040.
E.-H. Chao, R. J. Hudspith, A. Gérardin, J. R. Green, H. B. Meyer, and K. Ottnad, Hadronic light-by-light contribution to $(g - 2)_{μ}$ from lattice QCD: A complete calculation, Eur. Phys. J. C 81, 651 (2021).
E.-H. Chao, R. J. Hudspith, A. Gérardin, J. R. Green, and H. B. Meyer, The charm-quark contribution to light-by-light scattering in the muon ( $g - 2$ ) from lattice QCD, Eur. Phys. J. C 82, 664 (2022).
N. H. Christ, X. Feng, L. Jin, C. Tu, and Y. Zhao, Calculating the two-photon contribution to $π^{0} \to e^{+} e^{-}$ decay amplitude, Proc. Sci. LATTICE2019 (2020) 097 [arXiv:2001.05642].
N. H. Christ, X. Feng, L. Jin, C. Tu, and Y. Zhao, Lattice QCD calculation of the two-photon contributions to $K_{L} \to μ^{+} μ^{-}$ and $π^{0} \to e^{+} e^{-}$ decays, Proc. Sci. LATTICE2019 (2020) 128.
N. Christ, X. Feng, L. Jin, C. Tu, and Y. Zhao, Lattice QCD calculation of $π^{0} \to e^{+} e^{-}$ decay, Phys. Rev. Lett. 130, 191901 (2023).
E.-H. Chao and N. Christ, Calculating the two-photon exchange contribution to $K_{L} \to μ^{+} μ^{-}$ decay, Phys. Rev. D 110, 054514 (2024).
Z. Bai, N. H. Christ, T. Izubuchi, C. T. Sachrajda, A. Soni, and J. Yu, $K_{L} - K_{S}$ mass difference from lattice QCD, Phys. Rev. Lett. 113, 112003 (2014).
Y. Huo, N. H. Christ, and B. Wang, Enhanced lattice QCD studies on $ϵ_{K}$ and $Δ M_{K}$ , Proc. Sci. LATTICE2024 (2025) 239.
N. H. Christ, X. Feng, G. Martinelli, and C. T. Sachrajda, Effects of finite volume on the $K_{L} - K_{S}$ mass difference, Phys. Rev. D 91, 114510 (2015).
X.-Y. Tuo and X. Feng, Finite-volume formalism for physical processes with an electroweak loop integral, Phys. Rev. D 112, 034512 (2025).
G. Isidori, G. Martinelli, and P. Turchetti, Rare kaon decays on the lattice, Phys. Lett. B 633, 75 (2006).
G. Buchalla, A. J. Buras, and M. E. Lautenbacher, Weak decays beyond leading logarithms, Rev. Mod. Phys. 68, 1125 (1996).
C. Lehner and C. Sturm, Matching factors for Delta $S = 1$ four-quark operators in RI/SMOM schemes, Phys. Rev. D 84, 014001 (2011).
T. Blum, P. A. Boyle, D. Hoying, T. Izubuchi, L. Jin, C. Jung, C. Kelly, C. Lehner, A. Soni, and M. Tomii (RBC, UKQCD Collaborations), $Δ I = 3 / 2$ and $Δ I = 1 / 2$ channels of $K \to π π$ decay at the physical point with periodic boundary conditions, Phys. Rev. D 108, 094517 (2023).
N. H. Christ, X. Feng, A. Portelli, and C. T. Sachrajda (RBC, UKQCD Collaborations), Prospects for a lattice computation of rare kaon decay amplitudes: $K \to π ℓ^{+} ℓ^{-}$ decays, Phys. Rev. D 92, 094512 (2015).
J. Tu, Lattice QCD simulations towards strong and weak coupling limits, Ph.D. thesis, Columbia U., 2020.
T. Blum, N. Christ, M. Hayakawa, T. Izubuchi, L. Jin, C. Jung, and C. Lehner, Hadronic light-by-light scattering contribution to the muon anomalous magnetic moment from lattice QCD, Phys. Rev. Lett. 124, 132002 (2020).
G. McGlynn, Algorithmic improvements for weak coupling simulations of domain wall fermions, Proc. Sci. LATTICE2015 (2016) 019.
H. Yin and R. D. Mawhinney, Improving DWF simulations: The force gradient integrator and the Möbius accelerated DWF solver, Proc. Sci. LATTICE2011 (2011) 051 [arXiv:1111.5059].
E.-H. Chao, Progress on $K_{L} \to μ^{+} μ^{-}$ from lattice QCD, in 12th International Workshop on the CKM Unitarity Triangle (2024), arXiv:2403.18885.
C. W. Bernard, T. Draper, A. Soni, H. D. Politzer, and M. B. Wise, Application of chiral perturbation theory to $K \to 2$ pi decays, Phys. Rev. D 32, 2343 (1985).
P. A. Boyle, Conserved currents and results from $2 + 1 f$ dynamical Mobius DWF simulations at the physical point, Proc. Sci. LATTICE2014 (2015) 087.
B. Blossier, M. Della Morte, G. von Hippel, T. Mendes, and R. Sommer, On the generalized eigenvalue method for energies and matrix elements in lattice field theory, J. High Energy Phys. 04 (2009) 094,
D. Gomez Dumm and A. Pich, Long distance contributions to the $K_{L} \to μ^{+} μ^{-}$ decay width, Phys. Rev. Lett. 80, 4633 (1998).
G. Buchalla and A. J. Buras, The rare decays $K^{+} \to π^{+} ν \bar{ν}$ and $K_{L} \to μ^{+} μ^{-}$ beyond leading logarithms, Nucl. Phys. B412, 106 (1994).
X. Feng, L. Jin, and M. J. Riberdy, Lattice QCD calculation of the pion mass splitting, Phys. Rev. Lett. 128, 052003 (2022).
G. Buchalla and A. J. Buras, Two loop large $m_{t}$ electroweak corrections to $K \to π ν \bar{ν}$ for arbitrary Higgs boson mass, Phys. Rev. D 57, 216 (1998).
I. Montvay and G. Munster, Quantum fields on a lattice, Cambridge Monographs on Mathematical Physics (Cambridge University Press, Cambridge, England, 1997).
C. Gattringer and C. B. Lang, Quantum Chromodynamics on the Lattice, Vol. 788 (Springer, Berlin, 2010).
P. A. Boyle, G. Cossu, A. Yamaguchi, and A. Portelli, Grid: A next generation data parallel C++ QCD library, Proc. Sci. LATTICE2015 (2016) 023.
A. Yamaguchi, P. Boyle, G. Cossu, G. Filaci, C. Lehner, and A. Portelli, Grid: OneCode and FourAPIs, Proc. Sci. LATTICE2021 (2022) 035 [arXiv:2203.06777].
C. Jung, Overview of Columbia Physics System (CPS), Proc. Sci. LATTICE2013 (2014) 417.
R. G. Edwards and B. Joo (SciDAC, LHPC, and UKQCD Collaborations), The Chroma software system for lattice QCD, Nucl. Phys. B, Proc. Suppl. 140, 832 (2005).
QDP++, https://github.com/usqcd-software/qdpxx/tree/master.
T. Blum et al. (RBC, UKQCD Collaborations), Domain wall QCD with physical quark masses, Phys. Rev. D 93, 074505 (2016).
Y. Zhao, Lattice calculation of the $π^{0} \to e^{+} e^{-}$ and the $K_{L} \to γ γ$ decays, Ph.D. thesis, Columbia U., 2022.
J. Foley, K. Jimmy Juge, A. O’Cais, M. Peardon, S. M. Ryan, and J.-I. Skullerud, Practical all-to-all propagators for lattice QCD, Comput. Phys. Commun. 172, 145 (2005).
L. Giusti, P. Hernandez, M. Laine, P. Weisz, and H. Wittig, Low-energy couplings of QCD from current correlators near the chiral limit, J. High Energy Phys. 04 (2004) 013.
J. Bijnens, P. Dhonte, and F. Borg, $K \to 3$ pi decays in chiral perturbation theory, Nucl. Phys. B648, 317 (2003).
S. Weinberg, New test for $Δ I = \frac{1}{2}$ in $K +$ decay, Phys. Rev. Lett. 4, 87 (1960); Phys. Rev. Lett.4, 585(E) (1960).
J. Wess and B. Zumino, Consequences of anomalous Ward identities, Phys. Lett. 37B, 95 (1971).
E. Witten, Global aspects of current algebra, Nucl. Phys. B223, 422 (1983).
M. J. Savage, M. E. Luke, and M. B. Wise, The rare decays $π^{0} \to e^{+} e^{-}$ , $η \to e^{+} e^{-}$ and $η \to μ^{+} μ^{-}$ in chiral perturbation theory, Phys. Lett. B 291, 481 (1992).
S. Scherer and M. R. Schindler, A Primer for Chiral Perturbation Theory, Vol. 830 (Springer Berlin, Heidelberg, 2012).
M. Hoferichter, B.-L. Hoid, B. Kubis, and J. Lüdtke, Improved standard-model prediction for $π^{0} \to e^{+} e^{-}$ , Phys. Rev. Lett. 128, 172004 (2022).
