Reciprocal symmetry and Koba-Nielsen-Olesen scaling violation in proton-proton collisions

Mustapha Ouchen* and Alex Prygarin†

  • *Contact author: mustapha.ouchen@ariel.ac.il
  • †Contact author: alexanderpr@ariel.ac.il
PDF

Phys. Rev. D 114, 016004 – Published 6 July, 2026

DOI: https://doi.org/10.1103/11kp-cmgr

Abstract

We analyze the charged particle multiplicity distributions in p−p collisions and discuss the violation of the Koba-Nielsen-Olesen (KNO) scaling. We extract the deviations from the leading exponential behavior of the KNO scaled probability and identify a reciprocal symmetry z↔1/z in the KNO violating corrections observed in the ATLAS and CMS data at s=7,8,13  TeV. The symmetry imposes a local constraint on the multiplicity distribution at n=⟨n⟩, namely P′(⟨n⟩)=−P(⟨n⟩)/⟨n⟩, which we verify directly in the data. We use this constraint to extract the entanglement entropy from the well-measured region n≃⟨n⟩, avoiding the large uncertainties associated with the distribution tail.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (25)

  1. Z. Koba, H. B. Nielsen, and P. Olesen, Scaling of multiplicity distributions in high-energy hadron collisions, Nucl. Phys. B40, 317 (1972).
  2. A. M. Polyakov, A similarity hypothesis in the strong interactions. I. Multiple hadron production in e+e− annihilation, Sov. Phys. JETP 32, 296 (1971).
  3. G. Aad et al. (ATLAS Collaboration), Charged-particle distributions in s=13  TeV pp interactions measured with the ATLAS detector at the LHC, Phys. Lett. B 758, 67 (2016).
  4. Y. Kulchitsky and P. Tsiareshka, Study of the KNO scaling in pp collisions at s from 0.9 to 13 TeV using results of the ATLAS at the LHC, Eur. Phys. J. C 82, 462 (2022).
  5. V. Khachatryan et al. (CMS Collaboration), Charged particle multiplicities in pp interactions at s=0.9, 2.36, and 7 TeV, J. High Energy Phys. 01 (2011) 079.
  6. D. E. Kharzeev and E. M. Levin, Deep inelastic scattering as a probe of entanglement, Phys. Rev. D 95, 114008 (2017).
  7. D. E. Kharzeev and E. M. Levin, Deep inelastic scattering as a probe of entanglement: Confronting experimental data, Phys. Rev. D 104, L031503 (2021).
  8. D. E. Kharzeev, Quantum information approach to high energy interactions, Phil. Trans. R. Soc. A 380, 20210063 (2022).
  9. Z. Tu, D. E. Kharzeev, and T. Ullrich, Einstein-Podolsky-Rosen paradox and quantum entanglement at subnucleonic scales, Phys. Rev. Lett. 124, 062001 (2020).
  10. V. Andreev et al. (H1 Collaboration), Measurement of charged particle multiplicity distributions in DIS at HERA and its implication to entanglement entropy of partons, Eur. Phys. J. C 81, 212 (2021).
  11. M. Hentschinski and K. Kutak, Evidence for the maximally entangled low x proton in deep inelastic scattering from H1 data, Eur. Phys. J. C 82, 111 (2022).
  12. M. Hentschinski, K. Kutak, and R. Straka, Maximally entangled proton and charged hadron multiplicity in deep inelastic scattering, Eur. Phys. J. C 82, 1147 (2022).
  13. M. Hentschinski, D. E. Kharzeev, K. Kutak, and Z. Tu, Probing the onset of maximal entanglement inside the proton in diffractive deep inelastic scattering, Phys. Rev. Lett. 131, 241901 (2023).
  14. M. Hentschinski, D. E. Kharzeev, K. Kutak, and Z. Tu, QCD evolution of entanglement entropy, Rep. Prog. Phys. 87, 120501 (2024).
  15. M. Hentschinski, H. Jung, and K. Kutak, Entanglement entropy, Monte Carlo event generators, and soft gluons DIScovery, Phys. Rev. D 113, 054024 (2026).
  16. K. Kutak and M. Praszałowicz, Entropy, purity and gluon cascades at high energies with recombinations and transitions to vacuum, Eur. Phys. J. C 85, 1215 (2025).
  17. K. Kutak and S. Lökös, Entropy and multiplicity of hadrons in the high energy limit within dipole cascade models, Phys. Rev. D 112, 096017 (2025).
  18. L. S. Moriggi, F. S. Navarra, and M. V. T. Machado, Universality of scaling entropy in charged hadron multiplicity distributions at the LHC, Phys. Rev. D 112, 074019 (2025).
  19. Y. Liu, M. A. Nowak, and I. Zahed, Universality of Koba–Nielsen–Olesen scaling in QCD at high energy and entanglement, arXiv:2302.01380.
  20. A. Dumitru and E. Petreska, KNO scaling from a nearly Gaussian action for small-x gluons, arXiv:1209.4105.
  21. A. H. Mueller, Soft gluons in the infinite-momentum wave function and the BFKL Pomeron, Nucl. Phys. B415, 373 (1994).
  22. M. Ouchen and A. Prygarin, Pomeron evolution, entanglement entropy and Abramovskii–Gribov–Kancheli cutting rules, Phys. Rev. D 112, 094027 (2025).
  23. V. A. Abramovsky, V. N. Gribov, and O. V. Kancheli, Character of inclusive spectra and fluctuations produced in inelastic processes by multi-Pomeron exchange, Yad. Fiz. 18, 595 (1973) [Sov. J. Nucl. Phys. 18, 308 (1974)].
  24. M. Ouchen and A. Prygarin, KNO scaling, memorylessness and maximal entanglement at universal fixed point, Nucl. Phys. B1025, 117381 (2026).
  25. O. K. Baker and D. E. Kharzeev, Thermal radiation and entanglement in proton-proton collisions at the LHC, Phys. Rev. D 98, 054007 (2018).
