Strain-stress relationships for coherent in-plane strain in heterostructures with monoclinic crystal systems: β-(AlxGa1−x)2O3 on (h0l)β-Ga2O3 as example

Mathias Schubert1,2,3,*, Rafał Korlacki1, Sina Khayam4, Yousra Traouli1, Preston Sorensen1, Alexis Papamichail5,6, and Vanya Darakchieva2,5,6,†

  • 1Department of Electrical and Computer Engineering, University of Nebraska-Lincoln, Lincoln, Nebraska 68588, USA
  • 2Terahertz Materials Analysis Center and Competence Center for III-N Technology, C3NiT—Janzèn, NanoLund and Solid State Physics, Lund University, 22100 Lund, Sweden
  • 3Wallenberg Initiative Materials Science for Sustainability (WISE), Department of Physics, Lund University, 22100, Lund, Sweden
  • 4Department of Mechanical and Materials Engineering, University of Nebraska-Lincoln, Lincoln, Nebraska 68588, USA
  • 5Competence Center for III-N Technology, C3NiT—Janzèn, Department of Physics, Chemistry and Biology (IFM), Linköping University, 58183 Linköping, Sweden
  • 6Wallenberg Initiative Materials Science for Sustainability (WISE), Department of Physics, Chemistry and Biology (IFM), Linköping University, SE-58183 Linköping, Sweden

PDF

Phys. Rev. Applied 24, 044075 – Published 23 October, 2025

DOI: https://doi.org/10.1103/5gx2-kn6m

Abstract

In this work, we derive the relationship between the states of strain and stress in pseudomorphic epitaxial layers on a substrate with differing equilibrium lattice parameters under symmetry-conserving conditions for the case of monoclinic crystal symmetry. We compare surface vectors across the template-epitaxial layer interface and impose conditions of a stress-free epitaxial layer. As a result, we demonstrate the theoretical existence of up to three possible unit cells that can establish on a given template. We demonstrate this approach for the special case of symmetry-conserving strain in a class of templates with (h0l) surface orientations. We use β-(AlxGa1−x)2O3 on (h0l)β-Ga2O3 as an example. We discuss the effects of the composition x and surface orientation on the formation of three elastically stable unit cells, their strain and stress tensors, unit-cell axes, unit-cell volumes, lattice spacings, elastic potential energies, and stress-free directions. The previous paradigm for epitaxial layer growth, where the only stress-free direction is perpendicular to the growing surface, is not generally valid for low-symmetry materials. In the example here, we find that, in addition to the stress-free growth direction for crystallographic planes with low Miller indices, two possible competing domains can exist with stress-free directions oblique to the surface of the template for almost all planes (h0l). We further demonstrate the effect of the orientation-dependent differently strained domains and calculate the strain-shifted anisotropic band-to-band transitions for β-(Al0.1Ga0.9)2O3 on (h0l)β-Ga2O3. We also provide examples of x-ray diffraction analyses, which may help guide the search for the occurrence of such differently strained unit cells in epitaxial layers grown by experiment, here taking the (2¯01) surface orientation as case for demonstration.
