Qubit-Qudit Entanglement Transfer in Defect Centers with High-Spin Nuclei

Wolf-Rüdiger Hannes and Guido Burkard

PDF

PRX Quantum 7, 033007 – Published 7 July, 2026

DOI: https://doi.org/10.1103/bwcr-8rz5

Abstract

We propose a scheme for accumulating entanglement between long-lived qudits provided by central nuclear spins of defect centers. Assuming a generic setting, the electron spin of each node acts as the communication qubit and may be entangled with other nodes, e.g., through a spin-photon interface. The generally available Ising component of the hyperfine interaction is shown to facilitate repeated entanglement transfer onto memory qudits of arbitrary dimension d≤2I+1 with I the nuclear spin quantum number. When d is set to an integer power of two, maximal entanglement can be generated deterministically and without intermittent driving of nuclear spins. The scheme is applicable to several candidate systems, including the Ge73 germanium vacancy in diamond.

View figure in article

Physics Subject Headings (PhySH)

Popular Summary

A quantum network (“quantum internet”) requires local storage of quantum information (“quantum memory”), typically embodied by quantum two-level systems (qubits). Quantum memories with more than two distinguishable states (qudits) can store more information and become more strongly entangled among each other, thus boosting the performance of quantum networks. However, it is challenging to generate quantum entanglement between qudits, using qubits as a resource. We propose a solution to this problem for the case of solid-state defect centers featuring high-spin nuclei (e.g., the germanium-73 vacancy in diamond), acting as quantum memory nodes with ultra-long coherence. The electron spins of defects serve as qubits which can be entangled via their interaction with photons. The strong hyperfine coupling can be exploited to repeatedly and rapidly transfer entanglement from the electron spin onto the nuclear spin. The resulting states are an essential ingredient for qudit versions of quantum communication protocols in quantum networks.

Article Text

References (44)

  1. I. Fernandez de Fuentes et al., Navigating the 16-dimensional Hilbert space of a high-spin donor qudit with electric and magnetic fields, Nat. Commun. 15, 1380 (2024).
  2. J. A. Gross, Designing codes around interactions: The case of a spin, Phys. Rev. Lett. 127, 010504 (2021).
  3. S. Lim, J. Liu, and A. Ardavan, Fault-tolerant qubit encoding using a spin-7/2 qudit, Phys. Rev. A 108, 062403 (2023).
  4. S. Lim and A. Ardavan, Designing quantum error correction codes for practical spin qudit systems, Phys. Rev. A 112, 022418 (2025).
  5. K. Nemoto, M. Trupke, S. J. Devitt, B. Scharfenberger, K. Buczak, J. Schmiedmayer, and W. J. Munro, Photonic quantum networks formed from NV− centers, Sci. Rep. 6, 26284 (2016).
  6. H. J. Briegel and R. Raussendorf, Persistent entanglement in arrays of interacting particles, Phys. Rev. Lett. 86, 910 (2001).
  7. R. Raussendorf and H. J. Briegel, A one-way quantum computer, Phys. Rev. Lett. 86, 5188 (2001).
  8. R. Raussendorf, J. Harrington, and K. Goyal, A fault-tolerant one-way quantum computer, Ann. Phys. (Amsterdam) 321, 2242 (2006).
  9. D. L. Zhou, B. Zeng, Z. Xu, and C. P. Sun, Quantum computation based on d-level cluster state, Phys. Rev. A 68, 062303 (2003).
  10. M. S. Tame, M. Paternostro, C. Hadley, S. Bose, and M. S. Kim, Decoherence-based exploration of d-dimensional one-way quantum computation: Information transfer and basic gates, Phys. Rev. A 74, 042330 (2006).
  11. D.-S. Wang, D. T. Stephen, and R. Raussendorf, Qudit quantum computation on matrix product states with global symmetry, Phys. Rev. A 95, 032312 (2017).
  12. C. Reimer et al., High-dimensional one-way quantum processing implemented on d-level cluster states, Nat. Phys. 15, 148 (2019).
  13. P.-J. Stas et al., Robust multi-qubit quantum network node with integrated error detection, Science 378, 557 (2022).
  14. C. M. Knaut et al., Entanglement of nanophotonic quantum memory nodes in a telecom network, Nature (London) 629, 573 (2024).
  15. C. Adambukulam, B. C. Johnson, A. Morello, and A. Laucht, Hyperfine spectroscopy and fast, all-optical arbitrary state initialization and readout of a single, ten-level Ge73 vacancy nuclear spin qudit in diamond, Phys. Rev. Lett. 132, 060603 (2024).
  16. A. Morello, J. J. Pla, P. Bertet, and D. N. Jamieson, Donor spins in silicon for quantum technologies, Adv. Quantum Technol. 3, 2000005 (2020).
  17. K. Nemoto, M. Trupke, S. J. Devitt, A. M. Stephens, B. Scharfenberger, K. Buczak, T. Nöebauer, M. S. Everitt, J. Schmiedmayer, and W. J. Munro, Photonic architecture for scalable quantum information processing in diamond, Phys. Rev. X 4, 031022 (2014).
  18. T. Giordani, L. Innocenti, A. Suprano, E. Polino, M. Paternostro, N. Spagnolo, F. Sciarrino, and A. Ferraro, Entanglement transfer, accumulation and retrieval via quantum-walk-based qubit–qudit dynamics, New J. Phys. 23, 023012 (2021).
  19. A. Delgado, L. Roa, J. C. Retamal, and C. Saavedra, Entanglement swapping via quantum state discrimination, Phys. Rev. A 71, 012303 (2005).
  20. Y. Fu, W. Liu, X. Ye, Y. Wang, C. Zhang, C.-K. Duan, X. Rong, and J. Du, Experimental investigation of quantum correlations in a two-qutrit spin system, Phys. Rev. Lett. 129, 100501 (2022).
  21. P. Koller, T. Astner, B. Tissot, G. Burkard, and M. Trupke, Strain-enabled control of the vanadium qudit in silicon carbide, Phys. Rev. Mater. 9, L043201 (2025).
  22. D. P. Franke, F. M. Hrubesch, M. Künzl, H.-W. Becker, K. M. Itoh, M. Stutzmann, F. Hoehne, L. Dreher, and M. S. Brandt, Interaction of strain and nuclear spins in silicon: Quadrupolar effects on ionized donors, Phys. Rev. Lett. 115, 057601 (2015).
  23. S. Asaad et al., Coherent electrical control of a single high-spin nucleus in silicon, Nature (London) 579, 205 (2020).
  24. X. Yu et al., Creation and manipulation of Schrödinger cat states of a nuclear spin qudit in silicon, arXiv:2405.15494v1.
  25. G. W. Morley, M. Warner, A. M. Stoneham, P. T. Greenland, J. van Tol, C. W. M. Kay, and G. Aeppli, The initialization and manipulation of quantum information stored in silicon by bismuth dopants, Nat. Mater. 9, 725 (2010).
  26. T. Zhong et al., Optically addressing single rare-earth ions in a nanophotonic cavity, Phys. Rev. Lett. 121, 183603 (2018).
  27. A. M. Dibos, M. Raha, C. M. Phenicie, and J. D. Thompson, Atomic source of single photons in the telecom band, Phys. Rev. Lett. 120, 243601 (2018).
  28. P. Siyushev et al., Coherent properties of single rare-earth spin qubits, Nat. Commun. 5, 3895 (2014).
  29. I. Nakamura, T. Yoshihiro, H. Inagawa, S. Fujiyoshi, and M. Matsushita, Spectroscopy of single Pr3+ ion in LaF3 crystal at 1.5 k, Sci. Rep. 4, 7364 (2014).
  30. T. Utikal, E. Eichhammer, L. Petersen, A. Renn, S. Götzinger, and V. Sandoghdar, Spectroscopic detection and state preparation of a single praseodymium ion in a crystal, Nat. Commun. 5, 3627 (2014).
  31. N. Friis, G. Vitagliano, M. Malik, and M. Huber, Entanglement certification from theory to experiment, Nat. Rev. Phys. 1, 72 (2019).
  32. S. Bose, V. Vedral, and P. L. Knight, Purification via entanglement swapping and conserved entanglement, Phys. Rev. A 60, 194 (1999).
  33. W.-R. Hannes, R. Finsterhoelzl, and G. Burkard, Fidelity of remotely entangled nuclear spin states in photon-connected multiqubit registers, Phys. Rev. A 110, 052436 (2024).
  34. M. S. Everitt, S. Devitt, W. J. Munro, and K. Nemoto, High-fidelity gate operations with the coupled nuclear and electron spins of a nitrogen-vacancy center in diamond, Phys. Rev. A 89, 052317 (2014).
  35. C. Tabares, E. Zohar, and A. González-Tudela, Tunable photon-mediated interactions between spin-1 systems, Phys. Rev. A 106, 033705 (2022).
  36. F. Omlor, B. Tissot, and G. Burkard, Entanglement generation using single-photon pulse reflection in realistic networks, Phys. Rev. A 111, 012612 (2025).

  37. In Ref. [17] the use of a rotating frame without transforming back effectively sets ξ=1/2.

  38. T. Kraft, C. Ritz, N. Brunner, M. Huber, and O. Gühne, Characterizing genuine multilevel entanglement, Phys. Rev. Lett. 120, 060502 (2018).
  39. S. Maity, L. Shao, Y.-I. Sohn, S. Meesala, B. Machielse, E. Bielejec, M. Markham, and M. Lončar, Spectral alignment of single-photon emitters in diamond using strain gradient, Phys. Rev. Appl. 10, 024050 (2018).
  40. B. Tissot and G. Burkard, Spin structure and resonant driving of spin-12 defects in SiC, Phys. Rev. B 103, 064106 (2021).
  41. B. Tissot and G. Burkard, Hyperfine structure of transition metal defects in SiC, Phys. Rev. B 104, 064102 (2021).
  42. B. Tissot, P. Udvarhelyi, A. Gali, and G. Burkard, Strain engineering for transition-metal defects in SiC, Phys. Rev. B 109, 054111 (2024).
  43. G. Wolfowicz, C. P. Anderson, B. Diler, O. G. Poluektov, F. J. Heremans, and D. D. Awschalom, Vanadium spin qubits as telecom quantum emitters in silicon carbide, Sci. Adv. 6, eaaz1192 (2020).
  44. R. Winkler, Spin-Orbit Coupling Effects in Two-Dimensional Electron and Hole Systems (Springer-Verlag, Berlin, 2003).
