Magic State Injection with Erasure Qubits

Shoham Jacoby1,2,*, Yotam Vaknin1,2, Alex Retzker1,2, and Arne L. Grimsmo1

  • *Contact author: shohamjac@gmail.com
PDF

PRX Quantum 6, 040323 – Published 4 November, 2025

DOI: https://doi.org/10.1103/5q1v-ry3y

Abstract

Erasure qubits constitute a promising approach for tackling the daunting resources required for fault-tolerant quantum computing. By heralding of erasure errors, both the error-correction threshold and the sub-threshold scaling of the logical error rate are significantly improved. While previous research has focused primarily on fault-tolerant quantum memories, we extend this investigation to magic state injection—a critical yet resource-intensive component of fault-tolerant quantum computation. We show that, after postselection on erasures, the logical error rate of the injected magic state is set by the residual Pauli error, while the space-time overhead is only marginally increased as compared with the case of non-erasure qubits with a similar noise strength. These conclusions hold both for injection into the surface code and for injection and cultivation on the color code. For the former, we show that most of the gains can be achieved by the use of just three strategically placed erasure qubits in the surface code patch, independent of the patch size. For the latter, in contrast, it is beneficial to have all the qubits in the cultivation patch be erasure qubits. Our results for cultivation suggest that algorithmically relevant logical error rates may be within reach without magic state distillation for erasure rates ≲4×10−3 and residual Pauli error rates of ∼10−4.

View figure in article

Physics Subject Headings (PhySH)

Popular Summary

Quantum error correction is a key ingredient in building large-scale, fault-tolerant quantum computers. A critical step in this process is the generation of special quantum states known as magic states, which enable operations that cannot be performed directly on encoded qubits. Current methods for generating them—such as injection, cultivation, and distillation—are effective but come with significant resource overhead.

In this work, we propose an approach that uses erasure qubits—qubits that can flag when an error has occurred. By post-selecting on these heralded erasure events during magic state generation, we can dramatically suppress the effect of the dominant noise source.

This decouples the logical error rate from the erasure noise itself, leaving only the much smaller residual Pauli error rate. As a result, the fidelity of the produced magic states improves significantly—enough to reduce the number of distillation rounds needed. This, in turn, leads to a substantial reduction in overhead.

We show that most of these advantages are achievable even when just three erasure qubits are used, making this approach compatible with near-term experimental systems. Our results suggest that incorporation of erasure detection into quantum devices could significantly reduce the cost of generating magic states, ultimately reducing the overhead required for fault-tolerant quantum computing.

Article Text

References (53)

  1. J. Preskill, Reliable quantum computers, Proc. R. Soc. London. Series A: Math. Phys. Eng. Sci. 454, 385 (1998).
  2. B. M. Terhal, Quantum error correction for quantum memories, Rev. Mod. Phys. 87, 307 (2015).
  3. S. Bravyi, and A. Kitaev, Universal quantum computation with ideal Clifford gates and noisy ancillas, Phys. Rev. A 71, 022316 (2005).
  4. S. Bravyi, and J. Haah, Magic-state distillation with low overhead, Phys. Rev. A–At., Mol. Opt. Phys. 86, 052329 (2012).
  5. D. Horsman, A. G. Fowler, S. Devitt, and R. V. Meter, Surface code quantum computing by lattice surgery, New J. Phys. 14, 123011 (2012).
  6. A. G. Fowler, M. Mariantoni, J. M. Martinis, and A. N. Cleland, Surface codes: Towards practical large-scale quantum computation, Phys. Rev. A 86, 032324 (2012).
  7. D. Litinski, Magic state distillation: Not as costly as you think, Quantum 3, 205 (2019).
  8. C. Gidney, N. Shutty, and C. Jones, Magic state cultivation: growing t states as cheap as CNOT gates, ArXiv:2409.17595.
  9. Y. Li, A magic state’s fidelity can be superior to the operations that created it, New J. Phys. 17, 023037 (2015).
  10. L. Lao, and B. Criger, in Proceedings of the 19th ACM International Conference on Computing Frontiers (Association for Computing Machinery, New York, United States, 2022), p. 113.
  11. C. Gidney, Cleaner magic states with hook injection, ArXiv:2302.12292.
  12. S. Singh, A. S. Darmawan, B. J. Brown, and S. Puri, High-fidelity magic-state preparation with a biased-noise architecture, Phys. Rev. A 105, 052410 (2022).
  13. C. Chamberland, and K. Noh, Very low overhead fault-tolerant magic state preparation using redundant ancilla encoding and flag qubits, Npj Quantum Inf. 6, 91 (2020).
  14. H. Bombín, M. Pant, S. Roberts, and K. I. Seetharam, Fault-tolerant postselection for low-overhead magic state preparation, PRX Quantum 5, 010302 (2024).
  15. Y. Wu, S. Kolkowitz, S. Puri, and J. D. Thompson, Erasure conversion for fault-tolerant quantum computing in alkaline earth Rydberg atom arrays, Nat. Commun. 13, 4657 (2022).
  16. A. Kubica, A. Haim, Y. Vaknin, H. Levine, F. Brandão, and A. Retzker, Erasure qubits: Overcoming the t1 limit in superconducting circuits, Phys. Rev. X 13, 041022 (2023).
  17. M. Kang, W. C. Campbell, and K. R. Brown, Quantum error correction with metastable states of trapped ions using erasure conversion, PRX Quantum 4, 020358 (2023).
  18. J. D. Teoh, P. Winkel, H. K. Babla, B. J. Chapman, J. Claes, S. J. de Graaf, J. W. O. Garmon, W. D. Kalfus, Y. Lu, A. Maiti, K. Sahay, N. Thakur, T. Tsunoda, S. H. Xue, L. Frunzio, S. M. Girvin, S. Puri, and R. J. Schoelkopf, Dual-rail encoding with superconducting cavities, Proc. Natl. Acad. Sci. 120, e2221736120 (2023).
  19. S. Ma, G. Liu, P. Peng, B. Zhang, S. Jandura, J. Claes, A. P. Burgers, G. Pupillo, S. Puri, and J. D. Thompson, High-fidelity gates and mid-circuit erasure conversion in an atomic qubit, Nature 622, 279 (2023).
  20. P. Scholl, A. L. Shaw, R. B.-S. Tsai, R. Finkelstein, J. Choi, and M. Endres, Erasure conversion in a high-fidelity Rydberg quantum simulator, Nature 622, 273 (2023).
  21. A. Koottandavida, I. Tsioutsios, A. Kargioti, C. R. Smith, V. R. Joshi, W. Dai, J. D. Teoh, J. C. Curtis, L. Frunzio, R. J. Schoelkopf et al., Erasure detection of a dual-rail qubit encoded in a double-post superconducting cavity, Phys. Rev. Lett. 132, 180601 (2024).
  22. H. Levine et al., Demonstrating a long-coherence dual-rail erasure qubit using tunable transmons, Phys. Rev. X 14, 011051 (2024).
  23. S. B. Bravyi, and A. Y. Kitaev, Quantum codes on a lattice with boundary, arXiv:quant-ph/9811052.
  24. E. Dennis, A. Kitaev, A. Landahl, and J. Preskill, Topological quantum memory, J. Math. Phys. 43, 4452 (2002).
  25. A. Y. Kitaev, Fault-tolerant quantum computation by anyons, Ann. Phys. 303, 2 (2003).
  26. S. Gu, Y. Vaknin, A. Retzker, and A. Kubica, Optimizing quantum error correction protocols with erasure qubits, ArXiv:2408.00829.
  27. A. G. Fowler, Analytic asymptotic performance of topological codes, Phys. Rev. A 87, 040301 (2013).
  28. S. Bravyi, and A. Vargo, Simulation of rare events in quantum error correction, Phys. Rev. A 88, 062308 (2013).
  29. F. H. E. Watson, and S. D. Barrett, Logical error rate scaling of the toric code, New J. Phys. 16, 093045 (2014).
  30. N. Mehta, J. D. Teoh, T. Noh, A. Agrawal, A. Anderson, B. Birdsall, A. Brahmbhatt, W. Byrd, M. Cacioppo, A. Cabrera et al., Bias-preserving and error-detectable entangling operations in a superconducting dual-rail system, ArXiv:2503.10935.
  31. S. J. de Graaf, S. H. Xue, B. J. Chapman, J. D. Teoh, T. Tsunoda, P. Winkel, J. W. Garmon, K. M. Chang, L. Frunzio, S. Puri et al., A mid-circuit erasure check on a dual-rail cavity qubit using the joint-photon number-splitting regime of circuit qed, Npj Quantum Inf. 11, 1 (2025).
  32. P. Scholl, A. L. Shaw, R. B.-S. Tsai, R. Finkelstein, J. Choi, and M. Endres, Erasure conversion in a high-fidelity Rydberg quantum simulator, Nature 622, 273 (2023).
  33. B. Eastin, and E. Knill, Restrictions on transversal encoded quantum gate sets, Phys. Rev. Lett. 102, 110502 (2009).
  34. D. Horsman, A. G. Fowler, S. Devitt, and R. Van Meter, Surface code quantum computing by lattice surgery, New J. Phys. 14, 123011 (2012).
  35. This can be understood by consideration of the initialization of the magic state as some physical pulse with specific time and amplitude that can in principle rotate to any arbitrary angle. Any error in the rotation angle would result in some overlap of the state on a non-magic state that cannot be identified without distillation.
  36. In dual-rail qubits, erasure decay can occur from both logical states |0L⟩ and |1L⟩, unlike in a transmon, where decay occurs only when the qubit is in |1⟩. This means that when averaging is done over the computational basis, the effective erasure rate is larger relative to that for a single-mode qubit with the same physical decay rates.
  37. E. Knill, Fault-tolerant postselected quantum computation: Threshold analysis, ArXiv:quant-ph/0404104.
  38. C. Gidney, Inplace access to the surface code Y basis, Quantum 8, 1310 (2024).
  39. K. Chang, S. Singh, J. Claes, K. Sahay, J. Teoh, and S. Puri, Surface code with imperfect erasure checks, ArXiv:2408.00842.
  40. E. Dennis, Toward fault-tolerant quantum computation without concatenation, Phys. Rev. A 63, 052314 (2001).
  41. H. Goto, Step-by-step magic state encoding for efficient fault-tolerant quantum computation, Sci. Rep. 4, 7501 (2014).
  42. H. Goto, Minimizing resource overheads for fault-tolerant preparation of encoded states of the Steane code, Sci. Rep. 6, 19578 (2016).
  43. T. Itogawa, Y. Takada, Y. Hirano, and K. Fujii, Efficient magic state distillation by zero-level distillation, PRX Quantum 6 (2025).
  44. Y. Hirano, T. Itogawa, and K. Fujii, in 2024 IEEE International Conference on Quantum Computing and Engineering (QCE) (IEEE, 2024), pp. 843–853.
  45. R. S. Gupta, N. Sundaresan, T. Alexander, C. J. Wood, S. T. Merkel, M. B. Healy, M. Hillenbrand, T. Jochym-O’Connor, J. R. Wootton, T. J. Yoder et al., Encoding a magic state with beyond break-even fidelity, Nature 625, 259 (2024).
  46. Y. Vaknin, S. Jacoby, A. Grimsmo, and A. Retzker, Efficient magic state cultivation on the surface code, ArXiv:2502.01743.
  47. Z.-H. Chen, M.-C. Chen, C.-Y. Lu, and J.-W. Pan, Efficient magic state cultivation on RP2, ArXiv:2503.18657.
  48. S. Jacoby, Y. Vaknin, A. Retzker, and A. L. Grimsmo, Data for “Magic state injection with erasure qubits”, 2025, https://doi.org/10.5281/zenodo.15874462.
  49. C. Gidney, Stim: a fast stabilizer circuit simulator, Quantum 5, 497 (2021).
  50. O. Higgott, PyMatching: A Python package for decoding quantum codes with minimum-weight perfect matching, ACM Trans. Quantum Comput. 3, 1 (2022).
  51. E. Knill, R. Laflamme, and W. H. Zurek, Resilient quantum computation, Science 279, 342 (1998).
  52. F. Motzoi, J. M. Gambetta, P. Rebentrost, and F. K. Wilhelm, Simple pulses for elimination of leakage in weakly nonlinear qubits, Phys. Rev. Lett. 103, 110501 (2009).
  53. J. Ghosh, A. G. Fowler, and M. R. Geller, Surface code with decoherence: An analysis of three superconducting architectures, Phys. Rev. A 86, 062318 (2012).
