Extending the capillary wave model to include the effect of bending rigidity: X-ray reflectivity and diffuse scattering

Chen Shen (沈辰)^1,*, Honghu Zhang (张洪湖)², Beate Klösgen ^1,3, and Benjamin M. Ocko ^2,†

¹Deutsches Elektronen-Synchrotron DESY, Notkestraße 85, 22607 Hamburg, Germany
²National Synchrotron Light Source II, Brookhaven National Laboratory, Upton, New York 11973, USA
³Department of Physics, Chemistry and Pharmacy & PhyLife, University of Southern Denmark, Campusvej 55, 5230 Odense, Denmark

^*Contact author: chen.shen@desy.de
^†Contact author: ocko@bnl.gov

Phys. Rev. Research 7, 043016 – Published 3 October, 2025

DOI: https://doi.org/10.1103/znt1-fmx6

Abstract

The surface roughness of a thin film at a liquid interface exhibits contributions of thermally excited fluctuations. This thermal roughness depends on temperature ( $T$ ), surface tension ( $γ$ ), and elastic material properties, specifically the bending modulus ( $κ$ ) of the film. A nonzero $κ$ suppresses the thermal roughness at small length scales compared to an interface with zero $κ$ , as expressed by the power spectral density of the thermal roughness. The description of the x-ray scattering of the standard capillary wave model (CWM), which is valid for zero $κ$ , is extended to include the effect of $κ$ . The extended CWM (eCWM) provides a single analytical form for both the specular x-ray reflectivity (XRR) and the diffuse scattering around the specular reflection, and recovers the expression of the CWM at its zero $κ$ limit. This theoretical approach enables the use of single-shot grazing incidence x-ray off-specular scattering (GIXOS) measurements for characterizing the structure of thin films on a liquid surface. The eCWM analysis approach decouples the thermal roughness factor from the surface scattering signal, providing direct access to the intrinsic surface-normal structure of the film and its bending modulus. Moreover, the eCWM facilitates the calculation of reflectivity at any desired resolution (pseudo-XRR approach). The transformation into pseudo-XRR provides the benefit of using widely available XRR software to perform GIXOS analysis. The extended range of the vertical scattering vector ( $Q_{z}$ ) available with the GIXOS pseudo-XRR approach allows for a higher spatial resolution than with conventional XRR. Experimental results are presented for various lipid systems, showing strong agreement between conventional specular XRR and pseudo-XRR methods. This agreement validates the proposed approach and highlights its utility for analyzing soft, thin films.
