Programming stability and stiffness in two-dimensional multistable structures

M. Bonthron, T. Pierce, and E. Tubaldi*

  • *Contact author: etubaldi@umd.edu
PDF

Phys. Rev. Research 8, 033084 – Published 21 July, 2026

DOI: https://doi.org/10.1103/z2s6-trnj

Abstract

Multistable structures can reconfigure and passively maintain their geometry, enabling adaptive materials with tunable properties and performance tailored to changes in conditions. This work presents a theoretical and an experimental framework for designing and analyzing two-dimensional multistable structures composed of interconnected elastically buckled beams in different arrangements. First, we develop an analytical model and use numerical continuation to identify stable and unstable equilibrium configurations. Then, experimental samples validate the analytically predicted stable states, yielding structures with asymmetric energy potentials and reconfigurable effective stiffness. This approach provides a foundation for programmable, modular mechanical metamaterials assembled from bistable building blocks.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (45)

  1. K. Bertoldi, V. Vitelli, J. Christensen, and M. Van Hecke, Flexible mechanical metamaterials, Nat. Rev. Mater. 2, 17066 (2017).
  2. A. Pandey, D. E. Moulton, D. Vella, and D. P. Holmes, Dynamics of snapping beams and jumping poppers, Europhys. Lett. 105, 24001 (2014).
  3. M. Gomez, D. E. Moulton, and D. Vella, Critical slowing down in purely elastic ‘snap-through’ instabilities, Nat. Phys. 13, 142 (2017).
  4. E. Gutierrez-Prieto, C. M. Meulblok, M. Van Hecke, and P. M. Reis, Dynamic drives allow independent control of material bits for targeted memory, Sci. Adv. 12, eaec1606 (2026).
  5. T. Chen, M. Pauly, and P. M. Reis, A reprogrammable mechanical metamaterial with stable memory, Nature (London) 589, 386 (2021).
  6. A. Abbasi, T. Chen, B. F. G. Aymon, and P. M. Reis, Leveraging the snap buckling of bistable magnetic shells to design a refreshable Braille dot, Adv. Mater. Technol. 9, 2301344 (2024).
  7. C. Zhou, H. Qing, H. Sun, F. Qi, Y. Hong, and J. Yin, Multistable thin-shell metastructures for multiresponsive reconfigurable metabots, Sci. Adv. 11, eadx4359 (2025).
  8. L. H. Dudte, E. Vouga, T. Tachi, and L. Mahadevan, Programming curvature using origami tessellations, Nat. Mater. 15, 583 (2016).
  9. D. Melancon, B. Gorissen, C. J. García-Mora, C. Hoberman, and K. Bertoldi, Multistable inflatable origami structures at the metre scale, Nature (London) 592, 545 (2021).
  10. T. Jules, A. Reid, K. E. Daniels, M. Mungan, and F. Lechenault, Delicate memory structure of origami switches, Phys. Rev. Res. 4, 013128 (2022).
  11. C. Wang, H. Guo, R. Liu, Z. Deng, Y. Chen, and Z. You, Reconfigurable origami-inspired multistable metamorphous structures, Sci. Adv. 10, eadk8662 (2024).
  12. J. D. Paulsen, Mechanical hysterons with tunable interactions of general sign, Nat. Commun. 17, 2799 (2026).
  13. M. Gomez, D. E. Moulton, and D. Vella, Passive control of viscous flow via elastic snap-through, Phys. Rev. Lett. 119, 144502 (2017).
  14. G. Arena, R. M. J. Groh, A. Brinkmeyer, R. Theunissen, P. M. Weaver, and A. Pirrera, Adaptive compliant structures for flow regulation, Proc. R. Soc. A 473, 20170334 (2017).
  15. Y. Liu, F. Pan, B. Ding, Y. Zhu, K. Yang, and Y. Chen, Multistable shape-reconfigurable metawire in 3D space, Extreme Mech. Lett. 50, 101535 (2022).
  16. K. Miura, Method of packaging and deployment of large membranes in space, Inst. Space Astronaut. Sci. Rep. 618, 1 (1985).
  17. J. Liu, M. Teunisse, G. Korovin, I. R. Vermaire, L. Jin, H. Bense, and M. Van Hecke, Controlled pathways and sequential information processing in serially coupled mechanical hysterons, Proc. Natl. Acad. Sci. USA 121, e2308414121 (2024).
  18. C. Sirote-Katz, D. Shohat, C. Merrigan, Y. Lahini, C. Nisoli, and Y. Shokef, Emergent disorder and mechanical memory in periodic metamaterials, Nat. Commun. 15, 4008 (2024).
  19. L. Ai, S. Yin, W. He, P. Zhang, and Y. Li, Easy-to-actuate multi-compatible truss structures with prescribed reconfiguration, Nat. Commun. 15, 4886 (2024).
  20. P. Ducarme, B. Weber, M. Van Hecke, and J. T. B. Overvelde, Exotic mechanical properties enabled by countersnapping instabilities, Proc. Natl. Acad. Sci. USA 122, e2423301122 (2025).
  21. J. L. Silverberg, A. A. Evans, L. McLeod, R. C. Hayward, T. Hull, C. D. Santangelo, and I. Cohen, Using origami design principles to fold reprogrammable mechanical metamaterials, Science 345, 647 (2014).
  22. J. Hua, H. Lei, C.-F. Gao, and D. Fang, A novel design of multistable metastructure with nonuniform cross section, J. Appl. Mech. 89, 051010 (2022).
  23. B. Zhang, Z. Meng, and Y. Wang, Thermally responsive multistable metanet with enhanced energy absorption capacity, Adv. Funct. Mater. 36, e10749 (2025).
  24. G. Librandi, E. Tubaldi, and K. Bertoldi, Programming nonreciprocity and reversibility in multistable mechanical metamaterials, Nat. Commun. 12, 3454 (2021).
  25. L. Jin and M. van Hecke, Dynamic avalanches: Rate-controlled switching and race conditions, Phys. Rev. Lett. 135, 218201 (2025).
  26. S. P. Timoshenko and J. M. Gere, Theory of Elastic Stability, 2nd ed. (Dover Publications, Mineola, NY, 2009).
  27. A. H. Nayfeh, W. Kreider, and T. J. Anderson, Investigation of natural frequencies and mode shapes of buckled beams, AIAA J. 33, 1121 (1995).
  28. A. H. Nayfeh and B. Balachandran, Modal interactions in dynamical and structural systems, Appl. Mech. Rev. 42, S175 (1989).
  29. G. Librandi, E. Tubaldi, and K. Bertoldi, Snapping of hinged arches under displacement control: Strength loss and nonreciprocity, Phys. Rev. E 101, 053004 (2020).
  30. B. Radisson and E. Kanso, Elastic snap-through instabilities are governed by geometric symmetries, Phys. Rev. Lett. 130, 236102 (2023).
  31. B. Radisson and E. Kanso, Dynamic behavior of elastic strips near shape transitions, Phys. Rev. E 107, 065001 (2023).
  32. M. Bonthron and E. Tubaldi, Dynamic behavior of bistable shallow arches: From intrawell to chaotic motion, J. Appl. Mech. 91, 021010 (2024).
  33. M. Bonthron and E. Tubaldi, Transition wave interference in multistable mechanical metamaterials, J. Appl. Mech. 92, 051005 (2025).
  34. N. Nadkarni, A. F. Arrieta, C. Chong, D. M. Kochmann, and C. Daraio, Unidirectional transition waves in bistable lattices, Phys. Rev. Lett. 116, 244501 (2016).
  35. See Supplemental Material at http://link.aps.org/supplemental/10.1103/z2s6-trnj for additional derivations, continuation analyses, numerical procedures, and supplementary results, which includes Refs. [42, 43, 44, 45].
  36. D. Saha, P. Glanville, and E. G. Karpov, Analysis of antichiral thermomechanical metamaterials with continuous negative thermal expansion properties, Materials 13, 2139 (2020).
  37. B. Lemkalli, Q. Ji, J. Zhang, R. Craster, J. Christensen, and M. Kadic, Nonreciprocal topological kink-wave propagation in mechanical metamaterials, arXiv:2602.04591.
  38. A. S. Meeussen, E. C. Oğuz, Y. Shokef, and M. Van Hecke, Topological defects produce exotic mechanics in complex metamaterials, Nat. Phys. 16, 307 (2020).
  39. H. J. Dankowicz and F. Schilder, Recipes for Continuation, Computational Science and Engineering Series No. 11 (Society for Industrial and Applied Mathematics, Philadelphia, PA, 2013).
  40. S. H. Kang, S. Shan, A. Košmrlj, W. L. Noorduin, S. Shian, J. C. Weaver, D. R. Clarke, and K. Bertoldi, Complex ordered patterns in mechanical instability induced geometrically frustrated triangular cellular structures, Phys. Rev. Lett. 112, 098701 (2014).
  41. M. Bonthron, T. Pierce, and E. Tubaldi, Repository Name Programming-Stability-and-Stiffness-in-2D-Multistable-Structures Initial Release, 2026.
  42. R. G. Budynas, K. J. Nisbett, J. K. Nisbett, and J. E. Shigley, Shigley's Mechanical Engineering Design, 10th ed. (Mcgraw-Hill series in mechanical engineering, New York, NY McGraw-Hill Education, 2015).
  43. W. H. Macaulay, Note on the deflection of beam, Messenger Math. 48, 129 (1919).
  44. M. Golubitsky, I. Stewart, and D. G. Schaeffer, Singularities and Groups in Bifurcation Theory, Applied Mathematical Sciences (Springer, New York, NY, 1988), Vol. 69.
  45. M. Bonthron and E. Tubaldi, Flow-induced snap through of bistable arches with generalized boundary conditions, J. Appl. Mech. 92, 101009 (2025).
