Evaluating the contribution of slow recombination in localized subgap states to the excess quasiparticle population in ordered superconductors

Eva Gurra1,2,*, Douglas A. Bennett1, Shannon M. Duff1, Michael R. Vissers1, and Joel N. Ullom1,2,†

  • *Contact author: eva.gurra@colorado.edu
  • †Contact author: joel.ullom@nist.gov
PDF

Phys. Rev. Research 8, L012053 – Published 5 March, 2026

DOI: https://doi.org/10.1103/v181-yd74

Abstract

An excess density of quasiparticles is widely observed in superconducting films. This excess causes performance degradation in a variety of superconducting devices, including decoherence in qubits. In this Letter, we evaluate the hypothesis of Bespalov et al. [Phys. Rev. Lett. 117, 117002 (2016)] that the quasiparticle excess is caused by anomalously slow recombination at low quasiparticle densities due to localization in subgap states. We probe the density of states in aluminum and niobium films using current-voltage measurements of tunnel junctions and extract upper bounds on the energy scales of the subgap states and gap smearing. With these parameters, we evaluate the density-dependent recombination times calculated by Bespalov et al. and find that slow recombination is not predicted to occur at observed quasiparticle densities in aluminum- and niobium-based superconducting devices. These results suggest that the quasiparticle excess in ordered superconductors is primarily due to nonthermal sources of quasiparticle generation and not slow recombination.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (53)

  1. L. Sun, et al., Measurements of quasiparticle tunneling dynamics in a band-gap-engineered transmon qubit, Phys. Rev. Lett. 108, 230509 (2012).
  2. D. Ristè, et al., Millisecond charge-parity fluctuations and induced decoherence in a superconducting transmon qubit, Nat. Commun. 4, 1913 (2013).
  3. C. D. Wilen, et al., Correlated charge noise and relaxation errors in superconducting qubits, Nature (London) 594, 369 (2021).
  4. A. P. Vepsäläinen, et al., Impact of ionizing radiation on superconducting qubit coherence, Nature (London) 584, 551 (2020).
  5. P. J. deVisser, D. J. Goldie, P. Diener, S. Withington, J. J. A. Baselmans, and T. M. Klapwijk, Evidence of a nonequilibrium distribution of quasiparticles in the microwave response of a superconducting aluminum resonator, Phys. Rev. Lett. 112, 047004 (2014).
  6. L. Grünhaupt, et al., Loss mechanisms and quasiparticle dynamics in superconducting microwave resonators made of thin-film granular aluminum, Phys. Rev. Lett. 121, 117001 (2018).
  7. L. Cardani, et al., Reducing the impact of radioactivity on quantum circuits in a deep-underground facility, Nat. Commun. 12, 2733 (2021).
  8. P. K. Day, et al., A broadband superconducting detector suitable for use in large arrays, Nature (London) 425, 817 (2003).
  9. P. J. de Visser, J. J. A. Baselmans, P. Diener, S. J. C. Yates, A. Endo, and T. M. Klapwijk, Number fluctuations of sparse quasiparticles in a superconductor, Phys. Rev. Lett. 106, 167004 (2011).
  10. K. Karatsu, et al., Mitigation of cosmic ray effect on microwave kinetic inductance detector arrays, Appl. Phys. Lett. 114, 032601 (2019).
  11. D. J. Temples, et al., Performance of a phonon-mediated kinetic inductance detector at the NEXUS cryogenic facility, Phys. Rev. Appl. 22, 044045 (2024).
  12. K. Serniak, M. Hays, G. de Lange, S. Diamond, S. Shankar, L. D. Burkhart, L. Frunzio, M. Houzet, and M. H. Devoret, Hot nonequilibrium quasiparticles in transmon qubits, Phys. Rev. Lett. 121, 157701 (2018).
  13. O. P. Saira, A. Kemppinen, V. F. Maisi, and J. P. Pekola, Vanishing quasiparticle density in a hybrid Al/Cu/Al single-electron transistor, Phys. Rev. B 85, 012504 (2012).
  14. T. Connolly, P. D. Kurilovich, S. Diamond, H. Nho, C. G. L. Bottcher, L. I. Glazman, V. Fatemi, and M. H. Devoret, Coexistence of nonequilibrium density and equilibrium energy distribution of quasiparticles in a superconducting qubit, Phys. Rev. Lett. 132, 217001 (2024).
  15. A. D. Córcoles, et al., Protecting superconducting qubits from radiation, Appl. Phys. Lett. 99, 181906 (2011).
  16. R. Barends, et al., Minimizing quasiparticle generation from stray infrared light in superconducting quantum circuits, Appl. Phys. Lett. 99, 113507 (2011).
  17. R. T. Gordon, et al., Environmental radiation impact on lifetimes and quasiparticle tunneling rates of fixed-frequency transmon qubits, Appl. Phys. Lett. 120, 074002 (2022).
  18. C. H. Liu, et al., Quasiparticle poisoning of superconducting qubits from resonant absorption of pair-breaking photons, Phys. Rev. Lett. 132, 017001 (2024).
  19. R. Anthony-Petersen, et al., A stress-induced source of phonon bursts and quasiparticle poisoning, Nat. Commun. 15, 6444 (2024).
  20. M. McEwen, et al., Resolving catastrophic error bursts from cosmic rays in large arrays of superconducting qubits, Nat. Phys. 18, 107 (2022).
  21. D. Gusenkova, et al., Operating in a deep underground facility improves the locking of gradiometric fluxonium qubits at the sweet spots, Appl. Phys. Lett. 120, 054001 (2022).
  22. J. W. Fowler, et al., Spectroscopic measurements and models of energy deposition in the substrate of quantum circuits by natural ionizing radiation, PRX Quantum 5, 040323 (2024).
  23. B. Loer, et al., Abatement of ionizing radiation for superconducting quantum devices, J. Instrum. 19, P09001 (2024).
  24. A. Bespalov, M. Houzet, J. S. Meyer, and Y. V. Nazarov, Theoretical model to explain excess of quasiparticles in superconductors, Phys. Rev. Lett. 117, 117002 (2016).
  25. A. I. Larkin and Yu N. Ovchinnikov, Density of states in inhomogeneous superconductors, Sov. Phys. JETP 34, 1144 (1972), [Zh. Eksp. Teor. Fiz. 61, 2147 (1972)].
  26. A. V. Balatsky, et al., Impurity-induced states in conventional and unconventional superconductors, Rev. Mod. Phys. 78, 373 (2006).
  27. M. V. Feigel’man and M. A. Skvortsov, Universal broadening of the Bardeen-Cooper-Schrieffer coherence peak of disordered superconducting films, Phys. Rev. Lett. 109, 147002 (2012).
  28. S. E. de Graaf, et al., Two-level systems in superconducting quantum devices due to trapped quasiparticles, Sci. Adv. 6, eabc5055 (2020).
  29. A. A. Abrikosov and L. P. Gor’kov, Contribution to the theory of superconducting alloys with paramagnetic impurities, Zh. Eksp. Teor. Fiz. 39, 1781 (1960).
  30. S. B. Kaplan, et al., Quasiparticle and phonon lifetimes in superconductors, Phys. Rev. B 14, 4854 (1976).
  31. Reference [1] assumes zero temperature so that QPs that settle into localized states do not delocalize. At finite temperatures, it can be assumed that there are interacting populations of localized and delocalized quasiparticles as in Ref. [7]. Consequently, Ref. [1] can be interpreted as an upper bound on the effect of slow recombination in localized states.
  32. J. S. Meyer and B. D. Simons, Gap fluctuations in inhomogeneous superconductors, Phys. Rev. B 64, 134516 (2001).
  33. J. S. Meyer, Mesoscopic phenomena driven by parallel magnetic fields, Ph.D. thesis, Universität zu Köln, 2001.
  34. G. C. O’Neil, P. J. Lowell, J. M. Underwood, and J. N. Ullom, Measurement and modeling of a large-area normal-metal/insulator/superconductor refrigerator with improved cooling, Phys. Rev. B 85, 134504 (2012).
  35. See Supplemental Material at http://link.aps.org/supplemental/10.1103/v181-yd74 for further information on measured devices.
  36. J. Hätinen, et al., Efficient electronic cooling by niobium-based superconducting tunnel junctions, Phys. Rev. Appl. 22, 064048 (2024).
  37. J. P. Pekola, V. F. Maisi, S. Kafanov, N. Chekurov, A. Kemppinen, Y. A. Pashkin, O. P. Saira, M. Mottonen, and J. S. Tsai, Environment-assisted tunneling as an origin of the Dynes density of states, Phys. Rev. Lett. 105, 026803 (2010).
  38. N. R. Groll, et al., Insight into bulk niobium superconducting RF cavities performances by tunneling spectroscopy.
  39. D. Bafia, et al., Investigating the anomalous frequency variations near Tc of Nb SRF cavities, in Proceedings of the 20th International Conference on RF Superconductivity (JACoW Publishing, Geneva, Switzerland, 2022), pp. 885–892.
  40. T. Noguchi, et al., Subgap tunneling current at low temperature in Nb/Al-AlN/Nb SIS junctions, IEEE Trans. Appl. Supercond. 21, 756 (2011).
  41. S. K. Tolpygo, et al., Properties of unshunted and resistively shunted Nb/AlOx-Al/Nb Josephson junctions with critical current densities from 0.1 to 1 mA/µm2, IEEE Trans. Appl. Supercond. 27, 1 (2017).
  42. R. C. Dynes, J. P. Garno, G. B. Hertel, and T. P. Orlando, Tunneling study of superconductivity near the metal-insulator transition, Phys. Rev. Lett. 53, 2437 (1984).
  43. A. Anferov, K. H. Lee, F. Zhao, J. Simon, and D. I. Schuster, Improved coherence in optically defined niobium trilayer-junction qubits, Phys. Rev. Appl. 21, 024047 (2024).
  44. A. Romanenko, R. Pilipenko, S. Zorzetti, D. Frolov, M. Awida, S. Belomestnykh, S. Posen, and A. Grassellino, Three-dimensional superconducting resonators at t=20 mk with photon lifetimes up to τ=2 s, Phys. Rev. Appl. 13, 034032 (2020).
  45. A. Dominjon, et al., Investigation of single-crystal niobium for microwave kinetic inductance detectors, J. Low Temp. Phys. 194, 404 (2019).
  46. S. Zhu, et al., High quality superconducting Nb co-planar resonators on sapphire substrate.
  47. R. Barends, et al., Niobium and tantalum high Q resonators for photon detectors, IEEE Trans. Appl. Supercond. 17, 263 (2007).
  48. T. Noguchi, et al., Characteristics of very high Q Nb superconducting resonators for microwave kinetic inductance detectors, IEEE Trans. Appl. Supercond. 29, 1 (2019).
  49. P. B. Fischer and G. Catelani, Excess quasiparticles and their dynamics in the presence of subgap states, Phys. Rev. B 112, L100507 (2025).
  50. R. Barends, S. van Vliet, J. J. A. Baselmans, S. J. C. Yates, J. R. Gao, and T. M. Klapwijk, Enhancement of quasiparticle recombination in Ta and Al superconductors by implantation of magnetic and nonmagnetic atoms, Phys. Rev. B 79, 020509(R) (2009).
  51. P. C. J. J. Coumou, et al., Microwave properties of superconducting atomic-layer deposited tin films, IEEE Trans. Appl. Supercond. 23, 7500404 (2013).
  52. S. A. H. de Rooij, R. Fermin, K. Kouwenhoven, T. Coppens, V. Murugesan, D. J. Thoen, J. Aarts, J. J. A. Baselmans, and P. J. de Visser, Recombination of localized quasiparticles in disordered superconductors, Nat. Commun. 16, 8465 (2025).
  53. M. A. Skvortsov and M. V. Feigel’man, Subgap states in disordered superconductors, J. Exp. Theor. Phys. 117, 487 (2013).
