Characterizing topology at nonzero temperature: Topological invariants and indicators in the extended Su-Schrieffer-Heeger model

Julia D. Hannukainen and Nigel R. Cooper

PDF

Phys. Rev. Research 8, 033080 – Published 20 July, 2026

DOI: https://doi.org/10.1103/pwkc-lqq6

Abstract

We compare three complementary diagnostics for mixed Gaussian states at nonzero temperature, focusing on the Su-Schrieffer-Heeger (SSH) chain and its inversion-symmetric extension. While the ensemble geometric phase, a mixed-state generalization of the Zak phase, remains well defined at nonzero temperature, the modulus of the corresponding expectation value vanishes in the thermodynamic limit, limiting its practical use. To develop diagnostics suitable for large systems, we introduce local twist operators acting on neighboring sites, whose expectation values provide local indicators of the underlying topological phase. The topological phase is identified from the relative magnitude of these expectation values, which only requires measuring two local expectation values at nonzero temperature, together with one additional nonlocal expectation value when next-nearest-neighbor hopping is included. In addition, we generalize the local chiral marker to mixed Gaussian states, fully determined by its single-particle correlation matrix, with a nonzero purity gap in their effective single-particle Hamiltonian. The presence of a purity gap ensures that the correlation matrix can be flattened to an effective projector. Evaluating the chiral marker with respect to the band-flattened correlation matrix yields a real-space topological invariant that coincides with the winding number in the zero-temperature limit. The ensemble geometric phase, the local twist operators, and the local chiral marker provide complementary methods to characterize topology in the SSH chain beyond pure states.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (65)

  1. X. Chen, Z.-C. Gu, and X.-G. Wen, Local unitary transformation, long-range quantum entanglement, wave function renormalization, and topological order, Phys. Rev. B 82, 155138 (2010).
  2. A. P. Schnyder, S. Ryu, A. Furusaki, and A. W. W. Ludwig, Classification of topological insulators and superconductors in three spatial dimensions, Phys. Rev. B 78, 195125 (2008).
  3. A. Kitaev, Periodic table for topological insulators and superconductors, AIP Conf. Proc. 1134, 22 (2009).
  4. S. Ryu, A. P. Schnyder, A. Furusaki, and A. W. W. Ludwig, Topological insulators and superconductors: Tenfold way and dimensional hierarchy, New J. Phys. 12, 065010 (2010).
  5. A. W. W. Ludwig, Topological phases: Classification of topological insulators and superconductors of non-interacting fermions, and beyond, Phys. Scr. T168, 014001 (2016).
  6. E. Cartan, Sur une classe remarquable d'espaces de Riemann, Bul. Soc. Math. France 54, 214 (1926).
  7. M. R. Zirnbauer, Riemannian symmetric superspaces and their origin in random matrix theory, J. Math. Phys. 37, 4986 (1996).
  8. A. Altland and M. R. Zirnbauer, Nonstandard symmetry classes in mesoscopic normal-superconducting hybrid structures, Phys. Rev. B 55, 1142 (1997).
  9. D. J. Thouless, M. Kohmoto, M. P. Nightingale, and M. den Nijs, Quantized Hall conductance in a two-dimensional periodic potential, Phys. Rev. Lett. 49, 405 (1982).
  10. M. Kohmoto, Topological invariant and the quantization of the Hall conductance, Ann. Phys. 160, 343 (1985).
  11. N. Read and D. Green, Paired states of fermions in two dimensions with breaking of parity and time-reversal symmetries and the fractional quantum Hall effect, Phys. Rev. B 61, 10267 (2000).
  12. S. Diehl, E. Rico, M. A. Baranov, and P. Zoller, Topology by dissipation in atomic quantum wires, Nat. Phys. 7, 971 (2011).
  13. C.-E. Bardyn, M. A. Baranov, C. V. Kraus, E. Rico, A. İmamoğlu, P. Zoller, and S. Diehl, Topology by dissipation, New J. Phys. 15, 085001 (2013).
  14. A. Rivas, O. Viyuela, and M. A. Martin-Delgado, Density-matrix Chern insulators: Finite-temperature generalization of topological insulators, Phys. Rev. B 88, 155141 (2013).
  15. J. C. Budich, P. Zoller, and S. Diehl, Dissipative preparation of Chern insulators, Phys. Rev. A 91, 042117 (2015).
  16. J. C. Budich and S. Diehl, Topology of density matrices, Phys. Rev. B 91, 165140 (2015).
  17. F. Iemini, D. Rossini, R. Fazio, S. Diehl, and L. Mazza, Dissipative topological superconductors in number-conserving systems, Phys. Rev. B 93, 115113 (2016).
  18. C.-E. Bardyn, L. Wawer, A. Altland, M. Fleischhauer, and S. Diehl, Probing the topology of density matrices, Phys. Rev. X 8, 011035 (2018).
  19. F. Tonielli, J. C. Budich, A. Altland, and S. Diehl, Topological field theory far from equilibrium, Phys. Rev. Lett. 124, 240404 (2020).
  20. G. Lindblad, On the generators of quantum dynamical semigroups, Commun. Math. Phys. 48, 119 (1976).
  21. V. Gorini, A. Kossakowski, and E. C. G. Sudarshan, Completely positive dynamical semigroups of N-level systems, J. Math. Phys. 17, 821 (1976).
  22. C. W. Gardiner and M. J. Collett, Input and output in damped quantum systems: Quantum stochastic differential equations and the master equation, Phys. Rev. A 31, 3761 (1985).
  23. A. Altland, M. Fleischhauer, and S. Diehl, Symmetry classes of open Fermionic quantum matter, Phys. Rev. X 11, 021037 (2021).
  24. Z.-M. Huang and S. Diehl, Interaction-induced topological phase transition at finite temperature, Phys. Rev. Lett. 134, 053002 (2025).
  25. A. Uhlmann, The “transition probability” in the state space of a *-algebra, Rep. Math. Phys. 9, 273 (1976).
  26. O. Viyuela, A. Rivas, and M. A. Martin-Delgado, Uhlmann phase as a topological measure for one-dimensional fermion systems, Phys. Rev. Lett. 112, 130401 (2014).
  27. O. Viyuela, A. Rivas, and M. A. Martin-Delgado, Two-dimensional density-matrix topological Fermionic phases: Topological Uhlmann numbers, Phys. Rev. Lett. 113, 076408 (2014).
  28. Z. Huang and D. P. Arovas, Topological indices for open and thermal systems via Uhlmann's phase, Phys. Rev. Lett. 113, 076407 (2014).
  29. M. V. Berry, Quantal phase factors accompanying adiabatic changes, Proc. R. Soc. London A 392, 45 (1984).
  30. B. Simon, Holonomy, the quantum adiabatic theorem, and Berry's phase, Phys. Rev. Lett. 51, 2167 (1983).
  31. F. Wilczek and A. Zee, Appearance of gauge structure in simple dynamical systems, Phys. Rev. Lett. 52, 2111 (1984).
  32. J. Zak, Berry's phase for energy bands in solids, Phys. Rev. Lett. 62, 2747 (1989).
  33. L. Wawer and M. Fleischhauer, Chern number and Berry curvature for Gaussian mixed states of fermions, Phys. Rev. B 104, 094104 (2021).
  34. L. Wawer and M. Fleischhauer, Z2 topological invariants for mixed states of fermions in time-reversal invariant band structures, Phys. Rev. B 104, 214107 (2021).
  35. Z.-M. Huang, X.-Q. Sun, and S. Diehl, Topological gauge theory for mixed Dirac stationary states in all dimensions, Phys. Rev. B 106, 245204 (2022).
  36. Z.-M. Huang and S. Diehl, Mixed-state topological order parameters for symmetry-protected fermion matter, Phys. Rev. Res. 7, 033028 (2025).
  37. R. Resta, Quantum-mechanical position operator in extended systems, Phys. Rev. Lett. 80, 1800 (1998).
  38. P. Molignini and N. R. Cooper, Topological phase transitions at finite temperature, Phys. Rev. Res. 5, 023004 (2023).
  39. Y. Tada and M. Oshikawa, Many-body multipole index and bulk-boundary correspondence, Phys. Rev. B 108, 235150 (2023).
  40. W. P. Su, J. R. Schrieffer, and A. J. Heeger, Solitons in polyacetylene, Phys. Rev. Lett. 42, 1698 (1979).
  41. A. J. Heeger, S. Kivelson, J. R. Schrieffer, and W. P. Su, Solitons in conducting polymers, Rev. Mod. Phys. 60, 781 (1988).
  42. N. R. Cooper, J. Dalibard, and I. B. Spielman, Topological bands for ultracold atoms, Rev. Mod. Phys. 91, 015005 (2019).
  43. L. Li, Z. Xu, and S. Chen, Topological phases of generalized Su-Schrieffer-Heeger models, Phys. Rev. B 89, 085111 (2014).
  44. S.-L. Zhang and Q. Zhou, Two-leg Su-Schrieffer-Heeger chain with glide reflection symmetry, Phys. Rev. A 95, 061601(R) (2017).
  45. C. Li and A. E. Miroshnichenko, Extended SSH model: Non-local couplings and non-monotonous edge states, Physics 1, 2 (2019).
  46. J. D. Hannukainen, M. F. Martínez, J. H. Bardarson, and T. K. Kvorning, Local topological markers in odd spatial dimensions and their application to amorphous topological matter, Phys. Rev. Lett. 129, 277601 (2022).
  47. J. D. Hannukainen, M. F. Martínez, J. H. Bardarson, and T. K. Kvorning, Interacting local topological markers: A one-particle density matrix approach for characterizing the topology of interacting and disordered states, Phys. Rev. Res. 6, L032045 (2024).
  48. O. Penrose and L. Onsager, Bose-Einstein condensation and liquid helium, Phys. Rev. 104, 576 (1956).
  49. E. Koch and S. Goedecker, Locality properties and Wannier functions for interacting systems, Solid State Commun. 119, 105 (2001).
  50. S. Bera, H. Schomerus, F. Heidrich-Meisner, and J. H. Bardarson, Many-body localization characterized from a one-particle perspective, Phys. Rev. Lett. 115, 046603 (2015).
  51. S. Bera, T. Martynec, H. Schomerus, F. Heidrich-Meisner, and J. H. Bardarson, One-particle density matrix characterization of many-body localization, Ann. Phys. 529, 1600356 (2017).
  52. G. Kells, N. Moran, and D. Meidan, Localization enhanced and degraded topological order in interacting p-wave wires, Phys. Rev. B 97, 085425 (2018).
  53. M. Atala, M. Aidelsburger, J. T. Barreiro, D. Abanin, T. Kitagawa, E. Demler, and I. Bloch, Direct measurement of the Zak phase in topological Bloch bands, Nat. Phys. 9, 795 (2013).
  54. F. de Juan, A. Rüegg, and D.-H. Lee, Bulk-defect correspondence in particle-hole symmetric insulators and semimetals, Phys. Rev. B 89, 161117(R) (2014).
  55. C. W. Ling, M. Xiao, C. T. Chan, S. F. Yu, and K. H. Fung, Topological edge plasmon modes between diatomic chains of plasmonic nanoparticles, Opt. Express 23, 2021 (2015).
  56. R. D. King-Smith and D. Vanderbilt, Theory of polarization of crystalline solids, Phys. Rev. B 47, 1651 (1993).
  57. D. Vanderbilt and R. D. King-Smith, Electric polarization as a bulk quantity and its relation to surface charge, Phys. Rev. B 48, 4442 (1993).
  58. G. H. Wannier, The structure of electronic excitation levels in insulating crystals, Phys. Rev. 52, 191 (1937).
  59. L. W. Cheuk, M. A. Nichols, M. Okan, T. Gersdorf, V. V. Ramasesh, W. S. Bakr, T. Lompe, and M. W. Zwierlein, Quantum-gas microscope for Fermionic atoms, Phys. Rev. Lett. 114, 193001 (2015).
  60. E. Haller, J. Hudson, A. Kelly, D. A. Cotta, B. Peaudecerf, G. D. Bruce, and S. Kuhr, Single-atom imaging of fermions in a quantum-gas microscope, Nat. Phys. 11, 738 (2015).
  61. M. F. Parsons, F. Huber, A. Mazurenko, C. S. Chiu, W. Setiawan, K. Wooley-Brown, S. Blatt, and M. Greiner, Site-resolved imaging of Fermionic Li6 in an optical lattice, Phys. Rev. Lett. 114, 213002 (2015).
  62. C. Gross and I. Bloch, Quantum simulations with ultracold atoms in optical lattices, Science 357, 995 (2017).
  63. R. Bianco and R. Resta, Mapping topological order in coordinate space, Phys. Rev. B 84, 241106(R) (2011).
  64. T. L. M. Lezama, S. Bera, H. Schomerus, F. Heidrich-Meisner, and J. H. Bardarson, One-particle density matrix occupation spectrum of many-body localized states after a global quench, Phys. Rev. B 96, 060202(R) (2017).
  65. J. D. Hannukainen and N. R. Cooper, Research data supporting “Characterizing topology at nonzero temperature: Topological invariants and indicators in the extended Su–Schrieffer–Heeger model”, 2026, https://doi.org/10.17863/CAM.130445.

Outline

Information

Phys. Rev. Research 8, 033080– Published 20 July, 2026
  • Received 29 November 2025
  • Accepted 9 May 2026
