Enhanced superresolution by entanglement of the unified quantum wave function

Abdelali Sajia and Xiao-Feng Qian*

  • *Contact author: xqian6@stevens.edu
PDF

Phys. Rev. Research 7, 033219 – Published 4 September, 2025

DOI: https://doi.org/10.1103/pt7n-5gmr

Abstract

When two point sources are separated by less than the Abbe-Rayleigh limit, conventional resolution methods fail to distinguish whether there is one source or two. Consequently, it becomes nearly impossible to resolve important relative properties of the two sources, such as mutual coherence, relative phase, and brightness contrast. In this regime, the incoming composite quantum signal must be treated as a single entity described by an overall quantum wave function. In this study, we explore the superresolution of such two-point sources by examining a special wave property, i.e., entanglement between spatial degree of freedom (DoF) and remaining DoFs (both internal and external). Remarkably, we find that increasing this inter-DoF entanglement enhances the precision of superresolution, as quantified by the quantum Fisher information (QFI) in single-parameter estimation. Moreover, we show that this entanglement reliably ensures a nonvanishing QFI in two-parameter estimation, highlighting its role as a valuable resource for quantum superresolution.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (45)

  1. E. Abbe, Beiträge zur Theorie des Mikroskops und der mikroskopischen Wahrnehmung, Arch. Mikrosk. Anat., 9, 413 (1873).
  2. L. Rayleigh, XXXI. Investigations in optics, with special reference to the spectroscope, London, Edinburgh, Dublin Philos. Mag. J. Sci. 8, 261 (1879).
  3. J. W. Rayleigh, On the theory of optical images, with special reference to the microscope, The London, Edinburgh, Dublin Philos. Mag. J. Sci. 42, 167 (1896).
  4. M. Born and E. Wolf, Principles of Optics (Cambridge University Press, Cambridge, 1999).
  5. T. A. Klar, S. Jakobs, M. Dyba, A. Egner, and S. W. Hell, Fluorescence microscopy with diffraction resolution barrier broken by stimulated emission, Proc. Natl. Acad. Sci. USA 97, 8206 (2000).
  6. M. G. Gustafsson, Surpassing the lateral resolution limit by a factor of two using structured illumination microscopy, J. Microsc. 198, 82 (2000).
  7. E. Betzig, G. H. Patterson, R. Sougrat, O. W. Lindwasser, S. Olenych, J. S. Bonifacino, M. W. Davidson, J. Lippincott-Schwartz, and H. F. Hess, Imaging intracellular fluorescent proteins at nanometer resolution, Science 313, 1642 (2006).
  8. M. J. Rust, M. Bates, and X. Zhuang, Sub-diffractionlimit imaging by stochastic optical reconstruction microscopy (STORM), Nat. Methods 3, 793 (2006).
  9. M. Tsang, Quantum limits to optical point-source localization, Optica 2, 646 (2015).
  10. R. Nair and M. Tsang, Far-field superresolution of thermal electromagnetic sources at the quantum limit, Phys. Rev. Lett. 117, 190801 (2016).
  11. M. Tsang, R. Nair, and X.-M. Lu, Quantum theory of superresolution for two incoherent optical point sources, Phys. Rev. X 6, 031033 (2016).
  12. M. Paúr, B. Stoklasa, Z. Hradil, L. L. Sánchez-Soto, and J. Řehaček, Achieving the ultimate optical resolution, Optica 3, 1144 (2016).
  13. J. Řehaček, Z. Hradil, B. Stoklasa, M. Paúr, J. Grover, A. Krzic, and L. L. Sánchez-Soto, Multiparameter quantum metrology of incoherent point sources: Towards realistic superresolution, Phys. Rev. A 96, 062107 (2017).
  14. W. Larson and B. E. Saleh, Resurgence of Rayleigh’s curse in the presence of partial coherence, Optica 5, 1382 (2018).
  15. M. Parniak, S. Borówka, K. Boroszko, W. Wasilewski, K. Banaszek, and R. Demkowicz-Dobrzański, Beating the Rayleigh limit using two-photon interference, Phys. Rev. Lett. 121, 250503 (2018).
  16. Z. Hradil, J. Řehaček, L. Sánchez-Soto, and B.-G. Englert, Quantum Fisher information with coherence, Optica 6, 1437 (2019).
  17. Y. Zhou, J. Yang, J. D. Hassett, S. Mohammad Hashemi Rafsanjani, M. Mirhosseini, A. Nick Vamivakas, A. N. Jordan, Z. Shi, and R. W. Boyd, Quantum-limited estimation of the axial separation of two incoherent point sources, Optica 6, 534 (2019).
  18. S. A. Wadood, K. Liang, Y. Zhou, J. Yang, M. A. Alonso, X.-F. Qian, T. Malhotra, S. M. H. Rafsanjani, A. N. Jordan, R. W. Boyd, and A. N. Vamivakas, Experimental demonstration of superresolution of partially coherent light sources using parity sorting, Opt. Express 29, 22034 (2021).
  19. K. Liang, S. A. Wadood, and A. N. Vamivakas, Coherence effects on estimating two-point separation, Optica 8, 243 (2021).
  20. K. Liang, S. A. Wadood, and A. N. Vamivakas, Quantum Fisher information for estimating N partially coherent point sources, Opt. Express 31, 2726 (2023).
  21. L. Santamaria, D. Pallotti, M. S. de Cumis, D. Dequa, and C. Lupo, Spatial-mode-demultiplexing for enhanced intensity and distance measurement, Opt. Express 31, 33930 (2023).
  22. C. Rouviére, D. Barral, A. Grateau, I. Karuseichyk, G. Sorelli, M. Walschaers, and N. Treps, Ultra-sensitive separation estimation of optical sources, Optica 11, 166 (2024).
  23. I. Karuseichyk, G. Sorelli, M. Walschaers, N. Treps, and M. Gessner, Resolving mutually-coherent point sources of light with arbitrary statistics, Phys. Rev. Res. 4, 043010 (2022).
  24. I. Karuseichyk, G. Sorelli, V. Shatokhin, M. Walschaers, and N. Treps, Exploiting separation-dependent coherence to boost optical resolution, Phys. Rev. A 109, 043524 (2024).
  25. M. Tsang, and R. Nair, Resurgence of Rayleigh’s curse in the presence of partial coherence: Comment, Optica 6, 400 (2019).
  26. W. Larson and B. E. Saleh, Resurgence of Rayleigh’s curse in the presence of partial coherence: Reply, Optica 6, 402 (2019).
  27. A. Sajia and X.-F. Qian, Super-resolution of two unbalanced point sources assisted by the entangled partner, Phys. Rev. Res. 4, 033244 (2022).
  28. C. Lupo and S. Pirandola, Ultimate precision bound of quantum and subwavelength imaging, Phys. Rev. Lett. 117, 190802 (2016).
  29. L. A. Rozema, J. D. Bateman, D. H. Mahler, R. Okamoto, A. Feizpour, A. Hayat, and A. M. Steinberg, Scalable spatial superresolution using entangled photons, Phys. Rev. Lett. 112, 223602 (2014).
  30. H. Zhang, W. Ye, Z. Liao, and X. H. Wang, Quantum superresolution for imaging two pointlike entangled photon sources, Phys. Rev. A 108, 033713 (2023).
  31. W. K. Wootters, Entanglement of formation of an arbitrary state of two qubits, Phys. Rev. Lett. 80, 2245 (1998).
  32. C. W. Helstrom, Quantum Detection and Estimation Theory (Academic Press, New York, 1976).
  33. D. R. M. Arvidsson-Shukur, N. Y. Halpern, H. V. Lepage, A. A. Lasek, C. H. W. Barnes, and S. Lloyd, Quantum advantage in postselected metrology, Nat. Commun. 11, 3775 (2020).
  34. J. Yang, S. Pang, Yiyu Zhou, and Andrew N. Jordan, Optimal measurements for quantum multiparameter estimation with general states, Phys. Rev. A 100, 032104 (2019).
  35. J. Liu, H. Yuan, X.-M. Lu, and X. Wang, Quantum Fisher information matrix and multiparameter estimation, J. Phys. A 53, 023001 (2020).
  36. A. N. Jordan and J. C. Howell, Fundamental limits on subwavelength range resolution, Phys. Rev. Appl. 20, 064046 (2023).
  37. M. A. Nielsen and I. L. Chuang, Quantum Computation and Quantum Information (Cambridge University Press, Cambridge, 2020).
  38. J. von Neumann, Mathematische Grundlagen der Quantenmechanik (Springer, Berlin, 1932).
  39. S. M. Kay, Fundamentals of Statistical Signal Processing: Estimation Theory (Prentice-Hall, Englewood Cliffs, NJ, 1993).
  40. J. Zmuidzinas, Cramér-Rao sensitivity limits for astronomical instruments: Implications for interferometer design, J. Opt. Soc. Am. A 20, 218 (2003).
  41. A. Fujiwara and H. Nagaoka, Quantum Fisher metric and estimation for pure state models, Phys. Lett. A 201, 119 (1995).
  42. P. Facchi, R. Kulkarni, V. I. Man’Ko, G. Marmo, E. C. G. Sudarshan and F. Ventriglia, Classical and quantum Fisher information in the geometrical formulation of quantum mechanics, Phys. Lett. A 374, 4801 (2010).
  43. Daniel F. V. James, Paul G. Kwiat, William J. Munro, and Andrew G. White, Measurement of qubits, Phys. Rev. A 64, 052312 (2001).
  44. G. G. Stokes, On the composition and resolution of streams of polarized light from different sources, Trans. Cambridge Philos. Soc. 9, 399 (1851).
  45. X.-F. Qian, T. Malhotra, A. N. Vamivakas, and J. H. Eberly, Coherence constraints and the last hidden optical coherence, Phys. Rev. Lett. 117, 153901 (2016).
