Kineclinic magnetogenesis in relativistic collisionless plasmas

Modhuchandra Laishram1, Suresh Basnet1, and Young Dae Yoon1,2,*

  • *Contact author: youngdae.yoon@apctp.org
PDF

Phys. Rev. Research 8, 023210 – Published 26 May, 2026

DOI: https://doi.org/10.1103/m1yq-q8xw

Abstract

The relativistic momentum equation of a collisionless plasma is reformulated to describe the time evolution of canonical vorticity. Compared to the nonrelativistic counterpart, an additional source term for canonical vorticity is identified, which embodies the misalignment between the fluid momentum and fluid velocity gradients. This kineclinic term breaks the frozen-in condition of canonical vorticity, thereby enabling the generation or dissipation of magnetic fields and vorticity. We verify the role of this effect through particle-in-cell simulations of a kineclinic flow. Kineclinicity is generically expected in relativistic plasma kinetic plasmas lacking a functional relationship between fluid momentum and fluid velocity.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (44)

  1. G. Anglada, L. F. Rodríguez, and C. Carrasco-González, Radio jets from young stellar objects, Astron. Astrophys. Rev. 26, 3 (2018).
  2. R. Blandford, D. Meier, and A. Readhead, Relativistic jets from active galactic nuclei, Annu. Rev. Astron. Astrophys. 57, 467 (2019).
  3. R. K. Joshi and I. Chattopadhyay, The morphology and dynamics of relativistic jets with relativistic equation of state, Astrophys. J. 948, 13 (2023).
  4. E. Liang, M. Boettcher, and I. Smith, Magnetic field generation and particle energization at relativistic shear boundaries in collisionless electron-positron plasmas, Astrophys. J. 766, L19 (2013).
  5. K.-I. Nishikawa, P. Hardee, B. Zhang, I. Duţan, M. Medvedev, E. J. Choi, K. W. Min, J. Niemiec, Y. Mizuno, A. Nordlund, J. T. Frederiksen, H. Sol, M. Pohl, and D. H. Hartmann, Magnetic field generation in a jet-sheath plasma via the kinetic Kelvin-Helmholtz instability, Ann. Geophys. 31, 1535 (2013).
  6. K.-I. Nishikawa, P. E. Hardee, I. Dutan, J. Niemiec, M. Medvedev, Y. Mizuno, A. Meli, H. Sol, B. Zhang, M. Pohl, and D. H. Hartmann, Magnetic field generation in core-sheath jets via the kinetic Kelvin-Helmholtz instability, Astrophys. J. 793, 60 (2014).
  7. H. Chen and F. Fiuza, Perspectives on relativistic electron–positron pair plasma experiments of astrophysical relevance using high-power lasers, Phys. Plasmas 30, 020601 (2023).
  8. E. N. Parker, Cosmical Magnetic Fields. Their Origin and Their Activity (Oxford University Press, Oxford, England, 1979).
  9. A. Bonafede, L. Feretti, M. Murgia, F. Govoni, G. Giovannini, D. Dallacasa, K. Dolag, and G. B. Taylor, The Coma cluster magnetic field from Faraday rotation measures, Astron. Astrophys. 513, A30 (2010).
  10. H. Takabe and Y. Kuramitsu, Recent progress of laboratory astrophysics with intense lasers, High Power Laser Sci. Eng. 9, e49 (2021).
  11. A. Brandenburg and K. Subramanian, Astrophysical magnetic fields and nonlinear dynamo theory, Physics Reports 417, 1 (2005).
  12. T. Vachaspati, Progress on cosmological magnetic fields, Rep. Prog. Phys. 84, 074901 (2021).
  13. K. Jedamzik and L. Pogosian, Relieving the Hubble tension with primordial magnetic fields, Phys. Rev. Lett. 125, 181302 (2020).
  14. A. Brandenburg, D. Sokoloff, and K. Subramanian, Current status of turbulent dynamo theory: From large-scale to small-scale dynamos, Space Sci. Rev. 169, 123 (2012).
  15. M. Zhou, V. Zhdankin, M. W. Kunz, N. F. Loureiro, and D. A. Uzdensky, Spontaneous magnetization of collisionless plasma, Proc. Natl. Acad. Sci. USA 119, e2119831119 (2022).
  16. L. M. Widrow, Origin of galactic and extragalactic magnetic fields, Rev. Mod. Phys. 74, 775 (2002).
  17. E. Garaldi, R. Pakmor, and V. Springel, Magnetogenesis around the first galaxies: The impact of different field seeding processes on galaxy formation, Mon. Not. R. Astron. Soc. 502, 5726 (2021).
  18. J. Mason, L. Malyshkin, S. Boldyrev, and F. Cattaneo, Magnetic dynamo action in random flows with zero and finite correlation times, Astrophys. J. 730, 86 (2011).
  19. M. Zhou, V. Zhdankin, M. W. Kunz, N. F. Loureiro, and D. A. Uzdensky, Magnetogenesis in a collisionless plasma: From Weibel instability to turbulent dynamo, Astrophys. J. 960, 12 (2024).
  20. A. Grassi, M. Grech, F. Amiranoff, F. Pegoraro, A. Macchi, and C. Riconda, Electron Weibel instability in relativistic counterstreaming plasmas with flow-aligned external magnetic fields, Phys. Rev. E 95, 023203 (2017).
  21. L. Biermann, Über den Ursprung der Magnetfelder auf Sternen und im interstellaren Raum, Z. Naturforsch. A 5, 65 (1950).
  22. E. S. Weibel, Spontaneously growing transverse waves in a plasma due to an anisotropic velocity distribution, Phys. Rev. Lett. 2, 83 (1959).
  23. A. Gruzinov, GRB: Magnetic fields, cosmic rays, and emission from first principles? arXiv:0803.1182.
  24. E. P. Alves, T. Grismayer, S. F. Martins, F. Fiúza, R. A. Fonseca, and L. O. Silva, Large-scale magnetic field generation via the kinetic Kelvin-Helmholtz instability in unmagnetized scenarios, Astrophys. J. 746, L14 (2012).
  25. T. Grismayer, E. P. Alves, R. A. Fonseca, and L. O. Silva, Theory of multidimensional electron-scale instabilities in unmagnetized shear flows, Plasma Phys. Control. Fusion 55, 124031 (2013).
  26. M. Laishram, G. S. Yun, and Y. D. Yoon, Magnetogenesis via the canonical battery effect, Phys. Rev. Res. 6, L032052 (2024).
  27. Y. D. Yoon and P. M. Bellan, The electron canonical battery effect in magnetic reconnection: Completion of the electron canonical vorticity framework, Phys. Plasmas 26, 100702 (2019).
  28. Y. D. Yoon and P. M. Bellan, A generalized two-fluid picture of non-driven collisionless reconnection and its relation to whistler waves, Phys. Plasmas 24, 052114 (2017).
  29. Y. D. Yoon and P. M. Bellan, An intuitive two-fluid picture of spontaneous 2D collisionless magnetic reconnection and whistler wave generation, Phys. Plasmas 25, 055704 (2018).
  30. S. You, A field theory approach to the evolution of canonical helicity and energy, Phys. Plasmas 23, 072108 (2016).
  31. J. V. D. Linden, J. Sears, T. Intrator, and S. You, Measurements of the canonical helicity of a gyrating kink, Phys. Rev. Lett. 121, 035001 (2018).
  32. E. N. Nerush, D. A. Serebryakov, and I. Y. Kostyukov, Weibel instability in hot plasma flows with the production of gamma-rays and electron–positron pairs, Astrophys. J. 851, 129 (2017).
  33. D. Kagan, L. Sironi, B. Cerutti, and D. Giannios, Relativistic magnetic reconnection in pair plasmas and its astrophysical applications, Space Sci. Rev. 191, 545 (2015).
  34. S. M. Mahajan, Temperature-transformed “minimal coupling”: Magnetofluid unification, Phys. Rev. Lett. 90, 035001 (2003).
  35. S. M. Mahajan and Z. Yoshida, Twisting space-time: Relativistic origin of seed magnetic field and vorticity, Phys. Rev. Lett. 105, 095005 (2010).
  36. Y. Kawazura, Z. Yoshida, and Y. Fukumoto, Relabeling symmetry in relativistic fluids and plasmas, J. Phys. A: Math. Theor. 47, 465501 (2014).
  37. J.-H. Gao, B. Qi, and S.-Y. Wang, Vorticity and magnetic field production in relativistic ideal fluids, Phys. Rev. D 90, 083001 (2014).
  38. A. H. Taub, Relativistic Rankine-Hugoniot equations, Phys. Rev. 74, 328 (1948).
  39. T. P. Wright and G. R. Hadley, Relativistic distribution functions and applications to electron beams, Phys. Rev. A 12, 686 (1975).
  40. M. Hesse and S. Zenitani, Dissipation in relativistic pair-plasma reconnection, Phys. Plasmas 14, 112102 (2007).
  41. M. Melzani, C. Winisdoerffer, R. Walder, D. Folini, J. M. Favre, S. Krastanov, and P. Messmer, Apar-t: Code, validation, and physical interpretation of particle-in-cell results, Astron. Astrophys. 558, A133 (2013).
  42. J. Derouillat, A. Beck, F. Pérez, T. Vinci, M. Chiaramello, A. Grassi, M. Flé, G. Bouchard, I. Plotnikov, N. Aunai, J. Dargent, C. Riconda, and M. Grech, Smilei: A collaborative, open-source, multi-purpose particle-in-cell code for plasma simulation, Comput. Phys. Commun. 222, 351 (2018).
  43. A. M. Anile, Relativistic Fluids and Magneto-Fluids (Cambridge University Press, Cambridge, England, 1989).
  44. M. Laishram, S. Basnet, and Y. D. Yoon, Kineclinic magnetogenesis PIC data, Version 1.0, [Dataset], Zenodo (2026), doi: 10.5281/zenodo.20304345.
