Solid-state analog of gravitational redshift: Transport signatures of massless Dirac fermions in tilted Dirac cone heterostructures

Marziyeh Karmand1, Mohsen Amini1,*, Morteza Soltani1, Ebrahim Ghanbari-Adivi1, and Seyed Akbar Jafari2

  • *Contact author: msn.amini@sci.ui.ac.ir
PDF

Phys. Rev. Research 7, 033140 – Published 11 August, 2025

DOI: https://doi.org/10.1103/f9h1-krjk

Abstract

A Dirac electron passing through a heterojunction with spatially variable tilt experiences an effective curved spacetime. In this work, we show how this experience is manifested in its conductance. We investigate the propagation of electron waves in a two-dimensional tilted Dirac cone heterostructure where tilt depends on the coordinate z along the junction. The resulting Dirac equation in an emergent curved spacetime for the spinor ψ(z) can be efficiently solved using a fourth-order Runge-Kutta numerical method by a transformation to a suitable spinor φ where the resulting Dirac cone looks locally upright. The spatial texture of the tilt induces oscillatory behaviors in key physical quantities such as the norm |φ(z)|2 of the wave function, polar and azimuthal angles Θ(z) and Φ(z) of the pseudospin, and the integrated transmission τ where oscillation wavelengths get shorter (longer) in stronger (weaker) tilt regions. Such an oscillatory behavior that is reminiscent of gigantic gravitational redshift is an indicator of an underlying spacetime metric that can be probed in tunneling experiments. We derive analytical approximations for the position-depdendent wave numbers Δkz(z) that explain the redshift patterns and corroborate it with numerical simulations. For a tilt bump spread over length scale ℓ, upon increasing ℓ, the amplitude of redshifted oscillations reduces whereas the number of peaks increases. The scale invariance of the Dirac equation allows us to probe these aspects of ℓ dependence by a voltage sweep in transmission experiments. Smooth variations of the tilt reduces impedance mismatch of the electron waves, thereby giving rise to very high transmission rates. This concept can be used in combination with a sigmoid-shaped tilt texture for a gigantic redshift or blueshift engineering of the transmitted waves, depending on whether the sigmoid is downswing or upswing.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (48)

  1. L. Muechler, A. Alexandradinata, T. Neupert, and R. Car, Topological nonsymmorphic metals from band inversion, Phys. Rev. X 6, 041069 (2016).
  2. H. Isobe, Tilted Dirac cones in two dimensions, in Theoretical Study on Correlation Effects in Topological Matter (Springer, Singapore, 2017), pp. 63–81.
  3. A. Kobayashi, S. Katayama, Y. Suzumura, and H. Fukuyama, Massless fermions in organic conductor, J. Phys. Soc. Jpn. 76, 034711 (2007).
  4. A. Varykhalov, D. Marchenko, J. Sánchez-Barriga, E. Golias, O. Rader, and G. Bihlmayer, Tilted Dirac cone on w(110) protected by mirror symmetry, Phys. Rev. B 95, 245421 (2017).
  5. A. Lopez-Bezanilla and P. B. Littlewood, Electronic properties of 8Pmmn borophene, Phys. Rev. B 93, 241405(R) (2016).
  6. S.-H. Zhang, D.-F. Shao, Z.-A. Wang, J. Yang, W. Yang, and E. Y. Tsymbal, Tunneling valley Hall effect driven by tilted Dirac fermions, Phys. Rev. Lett. 131, 246301 (2023).
  7. Anisotropic longitudinal optical conductivities of tilted Dirac bands in 1t′−MoS2.
  8. S. H. Park, M. Sammon, E. Mele, and T. Low, Plasmonic gain in current biased tilted Dirac nodes, Nat. Commun. 13, 7667 (2022).
  9. Z. Jalali-Mola and S. A. Jafari, Tilt-induced kink in the plasmon dispersion of two-dimensional Dirac electrons, Phys. Rev. B 98, 195415 (2018).
  10. Z. Jalali-Mola and S. A. Jafari, Kinked plasmon dispersion in borophene-borophene and borophene-graphene double layers, Phys. Rev. B 98, 235430 (2018).
  11. Z. Torbatian, D. Novko, and R. Asgari, Hyperbolic plasmon modes in tilted Dirac cone phases of borophene, Phys. Rev. B 104, 075432 (2021).
  12. M. A. Mojarro, R. Carrillo-Bastos, and J. A. Maytorena, Hyperbolic plasmons in massive tilted two-dimensional Dirac materials, Phys. Rev. B 105, L201408 (2022).
  13. P. Sengupta, Y. Tan, E. Bellotti, and J. Shi, Anomalous heat flow in 8-Pmmn borophene with tilted Dirac cones, J. Phys.: Condens. Matter 30, 435701 (2018).
  14. T. Kawarabayashi, Y. Hatsugai, T. Morimoto, and H. Aoki, Generalization of chiral symmetry for tilted Dirac cones, Int. J. Mod. Phys. Conf. Ser. 11, 145 (2012).
  15. D. Ohki, M. Hirata, T. Tani, K. Kanoda, and A. Kobayashi, Chiral excitonic instability of two-dimensional tilted Dirac cones, Phys. Rev. Res. 2, 033479 (2020).
  16. Y. M. P. Gomes and R. O. Ramos, Tilted Dirac cone effects and chiral symmetry breaking in a planar four-fermion model, Phys. Rev. B 104, 245111 (2021).
  17. P.-L. Zhao and A.-M. Wang, Interplay between tilt, disorder, and Coulomb interaction in type-I Dirac fermions, Phys. Rev. B 100, 125138 (2019).
  18. M. A. Mojarro, R. Carrillo-Bastos, and J. A. Maytorena, Thermal difference reflectivity of tilted two-dimensional Dirac materials, Phys. Rev. B 108, L161401 (2023).
  19. G. C. Paul, S. F. Islam, and A. Saha, Fingerprints of tilted Dirac cones on the RKKY exchange interaction in 8-Pmmn borophene, Phys. Rev. B 99, 155418 (2019).
  20. D. Sinha, Spin transport and spin pump in graphene-like materials: Effects of tilted Dirac cone, Eur. Phys. J. B 92, 61 (2019).
  21. Y. Suzumura, I. Proskurin, and M. Ogata, Effect of tilting on the in-plane conductivity of Dirac electrons in organic conductor, J. Phys. Soc. Jpn. 83, 023701 (2014).
  22. G. E. Volovik and K. Zhang, Lifshitz transitions, type-II Dirac and weyl fermions, event horizon and all that, J. Low Temp. Phys. 189, 276 (2017).
  23. G. E. Volovik, Type-II Weyl semimetal versus gravastar, JETP Lett. 114, 236 (2021).
  24. L. Liang and T. Ojanen, Curved spacetime theory of inhomogeneous Weyl materials, Phys. Rev. Res. 1, 032006 (2019).
  25. M. Zubkov, Analogies between the black hole interior and the type II Weyl semimetals, Universe 4, 135 (2018).
  26. G. E. Volovik, Black hole and Hawking radiation by type-II Weyl fermions, JETP Lett. 104, 645 (2016).
  27. Y. Kedem, E. J. Bergholtz, and F. Wilczek, Black and white holes at material junctions, Phys. Rev. Res. 2, 043285 (2020).
  28. V. Könye, C. Morice, D. Chernyavsky, A. G. Moghaddam, J. van den Brink, and J. van Wezel, Horizon physics of quasi-one-dimensional tilted Weyl cones on a lattice, Phys. Rev. Res. 4, 033237 (2022).
  29. T. Farajollahpour and S. A. Jafari, Synthetic non-Abelian gauge fields and gravitomagnetic effects in tilted Dirac cone systems, Phys. Rev. Res. 2, 023410 (2020).
  30. K. Hashimoto and Y. Matsuo, Escape from black hole analogs in materials: Type-II Weyl semimetals and generic edge states, Phys. Rev. B 102, 195128 (2020).
  31. Y. Yekta, H. Hadipour, and S. A. Jafari, Tunning the tilt of the Dirac cone by atomic manipulations in 8Pmmn borophene, Commun. Phys. 6, 46 (2023).
  32. S. A. A. Ghorashi, J. F. Karcher, S. M. Davis, and M. S. Foster, Criticality across the energy spectrum from random artificial gravitational lensing in two-dimensional Dirac superconductors, Phys. Rev. B 101, 214521 (2020).
  33. N. Ogawa, R. Yoshimi, K. Yasuda, A. Tsukazaki, M. Kawasaki, and Y. Tokura, Zero-bias photocurrent in ferromagnetic topological insulator, Nat. Commun. 7, 12246 (2016).
  34. S. A. Jafari, Moving frame theory of zero-bias photocurrent on the surface of topological insulators, Phys. Rev. Res. 6, 033006 (2024).
  35. A. Einstein, Die Grundlage der allgemeinen Relativitätstheorie, Ann. Phys. 354, 769 (1916).
  36. L. Ryder, Introduction to General Relativity (Cambridge University Press, Cambridge, 2009).
  37. R. V. Pound and G. A. Rebka, Gravitational red-shift in nuclear resonance, Phys. Rev. Lett. 3, 439 (1959).
  38. R. Koç and H. Tütüncüler, Exact solution of position dependent mass Schrödinger equation by supersymmetric quantum mechanics, Ann. Phys. 515, 684 (2003).
  39. S. H. Mazharimousavi and M. Halilsoy, One dimensional Newton's equation with variable mass, arXiv:1308.2981.
  40. O. Rosas-Ortiz, Position-dependent mass systems: Classical and quantum pictures, in Geometric Methods in Physics XXXVIII (Springer International Publishing, Białowieża, Poland, 2020), pp. 351–361.
  41. A. Raoux, M. Polini, R. Asgari, A. R. Hamilton, R. Fazio, and A. H. MacDonald, Velocity-modulation control of electron-wave propagation in graphene, Phys. Rev. B 81, 073407 (2010).
  42. S. Joy, S. Khalid, and B. Skinner, Transparent mirror effect in twist-angle-disordered bilayer graphene, Phys. Rev. Res. 2, 043416 (2020).
  43. J. Yepez, Einstein's vierbein field theory of curved space, arXiv:1106.2037.
  44. E. Witten, Three lectures on topological phases of matter, La Rivista del Nuovo Cimento 39, 313 (2016).
  45. R. Al-Marzoog, A. Rezaei, Z. Noorinejad, M. Amini, E. Ghanbari-Adivi, and S. A. Jafari, Tilted Dirac cones in two-dimensional materials: Impact on electron transmission and pseudospin dynamics, Phys. Rev. B 110, 165427 (2024).
  46. G. Howard, The Physics of Waves (Benjamin Cummings, New Jersey, 1992).
  47. Y. Gong, T. Zhao, Y.-J. Rao, Y. Wu, and Y. Guo, A ray-transfer-matrix model for hybrid fiber Fabry-Perot sensor based on graded-index multimode fiber, Opt. Express 18, 15844 (2010).
  48. Y. Gong, W. Huang, Q.-F. Liu, Y. Wu, Y. Rao, G.-D. Peng, J. Lang, and K. Zhang, Graded-index optical fiber tweezers with long manipulation length, Opt. Express 22, 25267 (2014).
