Three-dimensional and selective displacement sensing of a levitated nanoparticle via spatial mode decomposition

Thomas J. Dinter1, Reece Roberts1,2, Thomas Volz1,2, Mikolaj K. Schmidt1,2, and Cyril Laplane1,2,3,*,†

  • *Present address: School of Physics, The University of Sydney, Sydney, NSW 2006, Australia.
  • †Contact author: cyril.laplane@sydney.edu.au
PDF

Phys. Rev. Research 8, 023220 – Published 28 May, 2026

DOI: https://doi.org/10.1103/9mnc-ddvw

Abstract

We propose and experimentally demonstrate a detection method that significantly improves the precision of real-time measurement of the three-dimensional (3D) displacement of a levitated dipolar scatterer. Our technique relies on spatial mode sorting of the light scattered by the levitated object, allowing us to selectively extract the position information of all translational degrees of freedom with minimal losses. To this end, we collect all the light backscattered from a levitated nanoparticle using a parabolic mirror and couple it into a spatial mode sorter. We measure displacement sensitivities (Simp,x,Simp,y,Simp,z)=(1.7,2.4,1.0)×10−14m/Hz below the zero-point motion (xzpm,yzpm,zzpm)=(2.2,2.4,1.6)×10−12m of the levitated particle considered here. In the regime where environmental decoherence is not limited by gas collision, we estimate that our method can reach measurement efficiencies of (ηtotx,ηtoty,ηtotz)=(0.13,0.18,0.33)>19, which would enable the 3D motional quantum ground state of a levitated optomechanical system.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (39)

  1. U. Delić, M. Reisenbauer, K. Dare, D. Grass, V. Vuletić, N. Kiesel, and M. Aspelmeyer, Cooling of a levitated nanoparticle to the motional quantum ground state, Science 367, 892 (2020).
  2. L. Magrini, P. Rosenzweig, C. Bach, A. Deutschmann-Olek, S. G. Hofer, S. Hong, N. Kiesel, A. Kugi, and M. Aspelmeyer, Real-time optimal quantum control of mechanical motion at room temperature, Nature (London) 595, 373 (2021).
  3. F. Tebbenjohanns, M. L. Mattana, M. Rossi, M. Frimmer, and L. Novotny, Quantum control of a nanoparticle optically levitated in cryogenic free space, Nature (London) 595, 378 (2021).
  4. M. Kamba, R. Shimizu, and K. Aikawa, Optical cold damping of neutral nanoparticles near the ground state in an optical lattice, Opt. Express 30, 26716 (2022).
  5. D. C. Moore, A. D. Rider, and G. Gratta, Search for millicharged particles using optically levitated microspheres, Phys. Rev. Lett. 113, 251801 (2014).
  6. S. Bose, A. Mazumdar, G. W. Morley, H. Ulbricht, M. Toroš, M. Paternostro, A. A. Geraci, P. F. Barker, M. S. Kim, and G. Milburn, Spin entanglement witness for quantum gravity, Phys. Rev. Lett. 119, 240401 (2017).
  7. G. Afek, D. Carney, and D. C. Moore, Coherent scattering of low mass dark matter from optically trapped sensors, Phys. Rev. Lett. 128, 101301 (2022).
  8. E. Kilian, M. Rademacher, J. M. H. Gosling, J. H. Iacoponi, F. Alder, M. Toroš, A. Pontin, C. Ghag, S. Bose, T. S. Monteiro, and P. F. Barker, Dark matter searches with levitated sensors, AVS Quantum Sci. 6, 030503 (2024).
  9. M. Scala, M. S. Kim, G. W. Morley, P. F. Barker, and S. Bose, Matter-wave interferometry of a levitated thermal nano-oscillator induced and probed by a spin, Phys. Rev. Lett. 111, 180403 (2013).
  10. Y. Y. Fein, P. Geyer, P. Zwick, F. Kiałka, S. Pedalino, M. Mayor, S. Gerlich, and M. Arndt, Quantum superposition of molecules beyond 25 kDa, Nat. Phys. 15, 1242 (2019).
  11. M. Arndt and K. Hornberger, Testing the limits of quantum mechanical superpositions, Nat. Phys. 10, 271 (2014).
  12. J. Piotrowski, D. Windey, J. Vijayan, C. Gonzalez-Ballestero, A. de los Ríos Sommer, N. Meyer, R. Quidant, O. Romero-Isart, R. Reimann, and L. Novotny, Simultaneous ground-state cooling of two mechanical modes of a levitated nanoparticle, Nat. Phys. 19, 1009 (2023).
  13. A. Ranfagni, K. Børkje, F. Marino, and F. Marin, Two-dimensional quantum motion of a levitated nanosphere, Phys. Rev. Res. 4, 033051 (2022).
  14. F. Tebbenjohanns, M. Frimmer, and L. Novotny, Optimal position detection of a dipolar scatterer in a focused field, Phys. Rev. A 100, 043821 (2019).
  15. P. Maurer, C. Gonzalez-Ballestero, and O. Romero-Isart, Quantum theory of light interaction with a Lorenz-Mie particle: Optical detection and three-dimensional ground-state cooling, Phys. Rev. A 108, 033714 (2023).
  16. L. S. Madsen, M. Waleed, C. A. Casacio, A. Terrasson, A. B. Stilgoe, M. A. Taylor, and W. P. Bowen, Ultrafast viscosity measurement with ballistic optical tweezers, Nat. Photonics 15, 386 (2021).
  17. G. Li, T. Kuang, W. Xiong, X. Han, X. Chen, G. Xiao, Z. Tan, and H. Luo, Structured-light displacement detection method using split-waveplate for dual-beam optical tweezers, Opt. Express 31, 34459 (2023).
  18. Modular Photonics, LPMUX Series: Pioneering products for faster internet, https://www.modularphotonics.com/lpmux/ (2024).
  19. J. Gieseler, B. Deutsch, R. Quidant, and L. Novotny, Subkelvin parametric feedback cooling of a laser-trapped nanoparticle, Phys. Rev. Lett. 109, 103603 (2012).
  20. J. Vovrosh, M. Rashid, D. Hempston, J. Bateman, M. Paternostro, and H. Ulbricht, Parametric feedback cooling of levitated optomechanics in a parabolic mirror trap, J. Opt. Soc. Am. B 34, 1421 (2017).
  21. N. Riesen and J. D. Love, Ultra-broadband tapered mode-selective couplers for few-mode optical fiber networks, IEEE Photonics Technol. Lett. 25, 2501 (2013).
  22. S. Gross, N. Riesen, J. D. Love, and M. J. Withford, Three-dimensional ultra-broadband integrated tapered mode multiplexers, Laser Photon. Rev. 8, L81 (2014).
  23. J. Gieseler, L. Novotny, and R. Quidant, Thermal nonlinearities in a nanomechanical oscillator, Nat. Phys. 9, 806 (2013).
  24. V. Jain, J. Gieseler, C. Moritz, C. Dellago, R. Quidant, and L. Novotny, Direct measurement of photon recoil from a levitated nanoparticle, Phys. Rev. Lett. 116, 243601 (2016).
  25. R. E. Wagner and W. J. Tomlinson, Coupling efficiency of optics in single-mode fiber components, Appl. Opt. 21, 2671 (1982).
  26. A. N. Vamivakas, S. B. Ippolito, M. S. Swan, Ü. M. Dogan, E. R. Behringer, and B. B. Goldberg, Phase-sensitive detection of dipole radiation in a fiber-based high numerical aperture optical system, Opt. Lett. 32, 970 (2007).
  27. M. Rashid, M. Toroš, and H. Ulbricht, Wigner function reconstruction in levitated optomechanics, Quantum Meas. Quantum Metrol. 4, 17 (2017).
  28. H. M. Wiseman and G. J. Milburn, Quantum Measurement and Control (Cambridge University Press, Cambridge, UK, 2009).
  29. M. Rossi, D. Mason, J. Chen, Y. Tsaturyan, and A. Schliesser, Measurement-based quantum control of mechanical motion, Nature (London) 563, 53 (2018).
  30. A. A. Clerk, M. H. Devoret, S. M. Girvin, F. Marquardt, and R. J. Schoelkopf, Introduction to quantum noise, measurement, and amplification, Rev. Mod. Phys. 82, 1155 (2010).
  31. C. Flühmann, T. L. Nguyen, M. Marinelli, V. Negnevitsky, K. Mehta, and J. P. Home, Encoding a qubit in a trapped-ion mechanical oscillator, Nature (London) 566, 513 (2019).
  32. T. Navickas, R. J. MacDonell, C. H. Valahu, V. C. Olaya-Agudelo, F. Scuccimarra, M. J. Millican, V. G. Matsos, H. L. Nourse, A. D. Rao, M. J. Biercuk, C. Hempel, I. Kassal, and T. R. Tan, Experimental quantum simulation of chemical dynamics, J. Am. Chem. Soc. 147, 23566 (2025).
  33. Y. Liu, S. Singh, K. C. Smith, E. Crane, J. M. Martyn, A. Eickbusch, A. Schuckert, R. D. Li, J. Sinanan-Singh, M. B. Soley, T. Tsunoda, I. L. Chuang, N. Wiebe, and S. M. Girvin, Hybrid oscillator-qubit quantum processors: Instruction set architectures, abstract machine models, and applications, PRX Quantum 7, 010201 (2026).
  34. M. Ernzer, M. Bosch Aguilera, M. Brunelli, G.-L. Schmid, T. M. Karg, C. Bruder, P. P. Potts, and P. Treutlein, Optical coherent feedback control of a mechanical oscillator, Phys. Rev. X 13, 021023 (2023).
  35. T. M. Karg, B. Gouraud, P. Treutlein, and K. Hammerer, Remote Hamiltonian interactions mediated by light, Phys. Rev. A 99, 063829 (2019).
  36. M. E. Choi, C. M. Pluchar, W. He, S. Guha, and D. J. Wilson, Quantum-limited imaging of a nanomechanical resonator with a spatial mode sorter, Phys. Rev. Res. 7, L032031 (2025).
  37. M. A. Lieb and A. J. Meixner, A high numerical aperture parabolic mirror as imaging device for confocal microscopy, Opt. Express 8, 458 (2001).
  38. E. Hebestreit, M. Frimmer, R. Reimann, C. Dellago, F. Ricci, and L. Novotny, Calibration and energy measurement of optically levitated nanoparticle sensors, Rev. Sci. Instrum. 89, 033111 (2018).
  39. L. Dania, K. Heidegger, D. S. Bykov, G. Cerchiari, G. Araneda, and T. E. Northup, Position measurement of a levitated nanoparticle via interference with its mirror image, Phys. Rev. Lett. 129, 013601 (2022).
