Acceleration noise induced decoherence in Stern-Gerlach interferometers for gravity experiments

Van Swinderen Institute for Particle Physics and Gravity, University of Groningen, 9747 AG Groningen, The Netherlands

^*Contact author: mengzhi.wu@rug.nl

Phys. Rev. Research 8, 023115 – Published 4 May, 2026

DOI: https://doi.org/10.1103/9bzl-lfnq

Abstract

Stern-Gerlach interferometer (SGI) is a kind of matter-wave interferometer driven by magnetic field and has been proposed for various gravity experiments. Stochastic noises can lead to decoherence problems of SGI via various mechanisms. In this paper, I will theoretically study several mechanisms including dephasing, contrast loss, and position localization decoherence. I will first present a rigorous proof that the dephasing behaves as a linear response to the noise, with a transfer function given by the Fourier transform of the unperturbed classical trajectories. Then I will demonstrate that stochastic acceleration noise only induces dephasing to the witness operator constructed in spin space, while it does not lead to contrast loss or position localization decoherence due to common mode cancellation. In contrast, higher-order noise can induce both contrast loss and position localization decoherence, contributing a decay factor proportional to the noise power spectrum density at the intrinsic frequency, which can be physically interpreted as the resonance between the noise and test mass. Based on the result, I apply the framework to analyze two typical noise sources, magnetic field noise and quadratic noise.

Physics Subject Headings (PhySH)

Article Text

References (76)

M. Keil, S. Machluf, Y. Margalit, Z. Zhou, O. Amit, O. Dobkowski, Y. Japha, S. Moukouri, D. Rohrlich, Z. Binstock, Y. Bar-Haim, M. Givon, D. Groswasser, Y. Meir, and R. Folman, Stern-Gerlach Interferometry with the Atom Chip (Springer International Publishing, Cham, 2021), pp. 263–301.
M. W. Doherty, N. B. Manson, P. Delaney, F. Jelezko, J. Wrachtrup, and L. C. L. Hollenberg, The nitrogen-vacancy colour centre in diamond, Phys. Rep. 528, 1 (2013).
L. Zhao, X. Shen, L. Ji, and P. Huang, Inertial measurement with solid-state spins of nitrogen-vacancy center in diamond, Adv. Phys.: X 7, 2004921 (2022).
M. Scala, M. S. Kim, G. W. Morley, P. F. Barker, and S. Bose, Matter-wave interferometry of a levitated thermal nano-oscillator induced and probed by a spin, Phys. Rev. Lett. 111, 180403 (2013).
X.-Y. Chen and Z.-Q. Yin, High-precision gravimeter based on a nano-mechanical resonator hybrid with an electron spin, Opt. Express 26, 31577 (2018).
M. P. Ledbetter, K. Jensen, R. Fischer, A. Jarmola, and D. Budker, Gyroscopes based on nitrogen-vacancy centers in diamond, Phys. Rev. A 86, 052116 (2012).
A. Ajoy and P. Cappellaro, Stable three-axis nuclear-spin gyroscope in diamond, Phys. Rev. A 86, 062104 (2012).
S. Bose, A. Mazumdar, G. W. Morley, H. Ulbricht, M. Toroš, M. Paternostro, A. A. Geraci, P. F. Barker, M. S. Kim, and G. Milburn, Spin entanglement witness for quantum gravity, Phys. Rev. Lett. 119, 240401 (2017).
M.-Z. Wu, M. Toroš, S. Bose, and A. Mazumdar, Destructive interference and inertial noise in matter-wave interferometry, Phys. Rev. D 112, 062006 (2025).
M. Toroš, T. W. van de Kamp, R. J. Marshman, M. S. Kim, A. Mazumdar, and S. Bose, Relative acceleration noise mitigation for nanocrystal matter-wave interferometry: Applications to entangling masses via quantum gravity, Phys. Rev. Res. 3, 023178 (2021).
M. Schut, H. Bosma, M.-Z. Wu, M. Toroš, S. Bose, and A. Mazumdar, Dephasing due to electromagnetic interactions in spatial qubits, Phys. Rev. A 110, 022412 (2024).
M.-Z. Wu, M. Toroš, S. Bose, and A. Mazumdar, Inertial torsion noise in matter-wave interferometers for gravity experiments, Phys. Rev. D 111, 064004 (2025).
T. Zhou, R. Rizaldy, M. Schut, and A. Mazumdar, Spin contrast, finite temperature, and noise in matter-wave interferometers, Phys. Rev. A 112, 012613 (2025).
S. N. Moorthy, A. Geraci, S. Bose, and A. Mazumdar, Magnetic noise in macroscopic quantum spatial superpositions, Phys. Rev. A 112, 022416 (2025).
E. Joos and H. D. Zeh, The emergence of classical properties through interaction with the environment, Z. Phys. B 59, 223 (1985).
O. Romero-Isart, Quantum superposition of massive objects and collapse models, Phys. Rev. A 84, 052121 (2011).
O. Romero-Isart, Coherent inflation for large quantum superpositions of levitated microspheres, New J. Phys. 19, 123029 (2017).
H. Pino, J. Prat-Camps, K. Sinha, B. P. Venkatesh, and O. Romero-Isart, On-chip quantum interference of a superconducting microsphere, Quantum Sci. Technol. 3, 025001 (2018).
M. Roda-Llordes, A. Riera-Campeny, D. Candoli, P. T. Grochowski, and O. Romero-Isart, Macroscopic quantum superpositions via dynamics in a wide double-well potential, Phys. Rev. Lett. 132, 023601 (2024).
A. Riera-Campeny, M. Roda-Llordes, P. T. Grochowski, and O. Romero-Isart, Wigner analysis of particle dynamics and decoherence in wide nonharmonic potentials, Quantum 8, 1393 (2024).
B.-G. Englert, J. Schwinger, and M. O. Scully, Is spin coherence like humpty-dumpty? I. Simplified treatment, Found. Phys. 18, 1045 (1988).
J. Schwinger, M. O. Scully, and B.-G. Englert, Is spin coherence like Humpty-Dumpty? II. General theory, Z. Phys. D 10, 135 (1988).
M. O. Scully, B.-G. Englert, and J. Schwinger, Spin coherence and Humpty-Dumpty. III. The effects of observation, Phys. Rev. A 40, 1775 (1989).
J. Jing, T. Yu, C.-H. Lam, J. Q. You, and L.-A. Wu, Control relaxation via dephasing: A quantum-state-diffusion study, Phys. Rev. A 97, 012104 (2018).
P. Krantz, M. Kjaergaard, F. Yan, T. P. Orlando, S. Gustavsson, and W. D. Oliver, A quantum engineer's guide to superconducting qubits, Appl. Phys. Rev. 6, 021318 (2019).
L. Chirolli and G. Burkard, Decoherence in solid-state qubits, Adv. Phys. 57, 225 (2008).
M.-Z. Wu, M. Toroš, S. Bose, and A. Mazumdar, Quantum gravitational sensor for space debris, Phys. Rev. D 107, 104053 (2023).
M. Schlosshauer, Decoherence: The quantum-to-classical transition, The Frontiers Collection (Springer Berlin, Heidelberg, 2007).
N. G. Van Kampen, A cumulant expansion for stochastic linear differential equations. II, Physica 74, 239 (1974).
N. G. Van Kampen, Stochastic differential equations, Phys. Rep. 24, 171 (1976).
Y. Margalit, O. Dobkowski, Z. Zhou, O. Amit, Y. Japha, S. Moukouri, D. Rohrlich, A. Mazumdar, S. Bose, C. Henkel, and R. Folman, Realization of a complete Stern-Gerlach interferometer: Toward a test of quantum gravity, Sci. Adv. 7, eabg2879 (2021).
Y. Japha, Unified model of matter-wave-packet evolution and application to spatial coherence of atom interferometers, Phys. Rev. A 104, 053310 (2021).
Y. Japha and R. Folman, Quantum uncertainty limit for stern-gerlach interferometry with massive objects, Phys. Rev. Lett. 130, 113602 (2023).
C. Henkel and R. Folman, Internal decoherence in nano-object interferometry due to phonons, AVS Quantum Sci. 4, 025602 (2022).
R. Zhou, Q. Xiang, and A. Mazumdar, Spin-dependent force and inverted harmonic potential for rapid creation of macroscopic quantum superpositions, Phys. Rev. A 111, 052207 (2025).
Y. B. Band and Y. Japha, Tuning the adiabaticity of spin dynamics in diamond nitrogen vacancy centers, J. Phys.: Condens. Matter 34, 255503 (2022).
X. Rong, J. Geng, F. Shi, Y. Liu, K. Xu, W. Ma, F. Kong, Z. Jiang, Y. Wu, and J. Du, Experimental fault-tolerant universal quantum gates with solid-state spins under ambient conditions, Nat. Commun. 6, 8748 (2015).
J. S. Pedernales, G. W. Morley, and M. B. Plenio, Motional dynamical decoupling for interferometry with macroscopic particles, Phys. Rev. Lett. 125, 023602 (2020).
W. B. Riesenfeld, An exact quantum theory of the time-dependent harmonic oscillator and of a charged particle in a time-dependent electromagnetic field, J. Math. Phys. 10, 1458 (1969).
H. R. Lewis and P. G. L. Leach, A direct approach to finding exact invariants for one-dimensional time-dependent classical Hamiltonians, J. Math. Phys. 23, 2371 (1982).
S. S. Mizrahi, The geometrical phase: An approach through the use of invariants, Phys. Lett. A 138, 465 (1989).
J. Guerrero and F. F. López-Ruiz, On the Lewis–Riesenfeld (Dodonov–Man’ko) invariant method, Phys. Scr. 90, 074046 (2015).
V. Aldaya, F. Cossío, J. Guerrero, and F. F. López-Ruiz, The quantum Arnold transformation, J. Phys. A: Math. Theor. 44, 065302 (2011).
M. J. Snadden, J. M. McGuirk, P. Bouyer, K. G. Haritos, and M. A. Kasevich, Measurement of the Earth's gravity gradient with an atom interferometer-based gravity gradiometer, Phys. Rev. Lett. 81, 971 (1998).
F. Sorrentino, Q. Bodart, L. Cacciapuoti, Y.-H. Lien, M. Prevedelli, G. Rosi, L. Salvi, and G. M. Tino, Sensitivity limits of a Raman atom interferometer as a gravity gradiometer, Phys. Rev. A 89, 023607 (2014).
Yu.-P. Wang, J.-Q. Zhong, X. Chen, R.-B. Li, D.-W. Li, L. Zhu, H.-W. Song, J. Wang, and M.-S. Zhan, Extracting the differential phase in dual atom interferometers by modulating magnetic fields, Opt. Commun. 375, 34 (2016).
V. Ivády, T. Simon, J. R. Maze, I. A. Abrikosov, and A. Gali, Pressure and temperature dependence of the zero-field splitting in the ground state of NV centers in diamond: A first-principles study, Phys. Rev. B 90, 235205 (2014).
R. J. Marshman, A. Mazumdar, R. Folman, and S. Bose, Constructing nano-object quantum superpositions with a Stern-Gerlach interferometer, Phys. Rev. Res. 4, 023087 (2022).
C. L. Degen, F. Reinhard, and P. Cappellaro, Quantum sensing, Rev. Mod. Phys. 89, 035002 (2017).
Y. Xu, Y. Chen, and X. Chen, Fast transport and splitting of spin-orbit-coupled spin-1 Bose-Einstein condensates, Phys. Rev. A 109, 063310 (2024).
M. T. Johnsson, G. K. Brennen, and J. Twamley, Macroscopic superpositions and gravimetry with quantum magnetomechanics, Sci. Rep. 6, 37495 (2016).
M. O. Scully and M. S. Zubairy, Quantum Optics (Cambridge University Press, Cambridge, 1997).
N. F. Ramsey, A new molecular beam resonance method, Phys. Rev. 76, 996 (1949).
This conclusion can be generalized to a generic matter-wave interferometer under a general noise. Suppose the interferometer is built up through a Lagrangian $L [x_{i} (t), {\dot{x}}_{i} (t)]$ and the noise is described by a Lagrangian $δ L [x_{i} (t), {\dot{x}}_{i} (t)]$ . Denote the ideal trajectory as $x_{i}^{0} (t)$ , and the ideal phase is $ϕ^{0} = \int L [x_{i}^{0}, {\dot{x}}_{i}^{0}] / ℏ d t$ . Then, the phase under noise at the leading order is $\begin{matrix} ϕ^{0} + δ ϕ & = \frac{1}{ℏ} \int L [x_{i}^{0} + δ x_{i}, {\dot{x}}_{i}^{0} + δ {\dot{x}}_{i}^{0}] + δ L [x_{i}^{0}, {\dot{x}}_{i}^{0}] d t \\ = \frac{1}{ℏ} \int L [x_{i}^{0}, {\dot{x}}_{i}^{0}] + \frac{\partial L}{\partial x_{i}} |_{(x_{i}^{0}, {\dot{x}}_{i}^{0})} δ x_{i} \\ + \frac{\partial L}{\partial {\dot{x}}_{i}} |_{(x_{i}^{0}, {\dot{x}}_{i}^{0})} δ {\dot{x}}_{i} + δ L [x_{i}^{0}, {\dot{x}}_{i}^{0}] d t . \end{matrix}$ According to the Euler-Lagrangian equation $\partial L / \partial x_{i} = d (\partial L / \partial {\dot{x}}_{i}) / d t$ , one can prove an identity $\begin{matrix} \frac{\partial L}{\partial x_{i}} {|_{(x_{i}^{0}, {\dot{x}}_{i}^{0})} δ x_{i} + \frac{\partial L}{\partial {\dot{x}}_{i}} |}_{(x_{i}^{0}, {\dot{x}}_{i}^{0})} δ {\dot{x}}_{i} = \frac{d}{d t} (\frac{\partial L}{\partial {\dot{x}}_{i}} |_{(x_{i}^{0}, {\dot{x}}_{i}^{0})} δ x_{i}) . \end{matrix}$ Thus, the phase fluctuation arising from the fluctuation of the trajectory $δ x_{i}$ and the velocity $δ {\dot{x}}_{i}$ is the integral of a total derivative. Then, one may read $δ ϕ = \int δ L [x_{i}^{0}, {\dot{x}}_{i}^{0}] / ℏ d t$ by neglecting this total derivative term. Note that the same conclusion has been proved by using Feynman's path integral method [76].
J. Junca, A. Bertoldi, D. O. Sabulsky, G. Lefèvre, X. Zou, J.-B. Decitre, R. Geiger, A. Landragin, S. Gaffet, P. Bouyer, and B. Canuel, Characterizing Earth gravity field fluctuations with the MIGA antenna for future gravitational wave detectors, Phys. Rev. D 99, 104026 (2019).
Here, asymptotic behaviors of the sinc function have been used. That is, ${sinc}^{2} ((ω - ω_{0}) t / 2) = 1 + O (t^{2})$ for small $t$ , and ${sinc}^{2} ((ω - ω_{0}) t / 2) = 2 π δ (ω - ω_{0}) / t$ for large $t$ .
A. Uhlmann, The “transition probability” in the state space of a $*$ -algebra, Rep. Math. Phys. 9, 273 (1976).
L. Lami, J. S. Pedernales, and M. B. Plenio, Testing the quantumness of gravity without entanglement, Phys. Rev. X 14, 021022 (2024).
Here, the following identities are used: $\begin{matrix} \sqrt{{\hat{ρ}}_{id} (t)} & = {\hat{U}}_{id} (t) \sqrt{{\hat{ρ}}_{0}} {\hat{U}}_{id}^{†} (t), \\ {\hat{U}}_{id}^{†} (t) {\hat{U}}_{n} (t) & = \hat{D} (δ α (t) e^{i ω_{0} t}) e^{i δ ϕ (t)} . \end{matrix}$
To compute the ensemble average of $〈 x_{1} | {\hat{ρ}}_{n} (t) | x_{2} 〉$ , one can consider the Glauber's $P$ -representation [52] of the initial density matrix $\begin{matrix} {\hat{ρ}}_{0} = \int P (β) | β 〉 〈 β | d^{2} β . \end{matrix}$ According to the identity $\begin{matrix} \hat{D} (δ α (t)) | β 〉 = e^{i ϕ (β, δ α)} | β + δ α (t) 〉, \end{matrix}$ the matrix element of ${\hat{ρ}}_{n} (t)$ becomes $\begin{matrix} 〈 x_{1} | {\hat{ρ}}_{n} (t) | x_{2} 〉 = \int P (β) 〈 x_{1}^{'} (t) | β + δ α (t) 〉 〈 β + δ α (t) | x_{2}^{'} (t) 〉 d^{2} β . \end{matrix}$ Based on the wavefunction of a coherent state, one can obtain the ensemble average of the matrix element in the $P$ -representation satisfying $\begin{matrix} E [〈 x_{1}^{'} (t) | β + δ α (t) 〉 〈 β + δ α (t) | x_{2}^{'} (t) 〉] \\ = 〈 x_{1}^{'} (t) | β 〉 〈 β | x_{2}^{'} (t) 〉 e^{- \frac{m ω_{0}}{ℏ} σ_{α}^{2} (t) {(x_{1}^{'} (t) - x_{2}^{'} (t))}^{2}} . \end{matrix}$ Then, one can obtain the result (52).
If there is a biased magnetic field $B_{0} \neq 0$ , then the amplitudes $A_{\pm}$ defined in Eq. (31) are not opposite to each other. As a result, the trajectories $x_{1} (t)$ and $x_{- 1} (t)$ do not cancel each other. In this case, there is still a dephasing effect, and the transfer function takes a similar form as Eq. (32) but the factor $Δ A$ is replaced by $A_{+} + A_{-}$ .
Suppose the final states before squeezing are $| ψ_{+} 〉$ and $| ψ_{-} 〉$ . After applying the squeezing operator, their overlap becomes $\begin{matrix} 〈 ψ_{+} | {\hat{S}}^{†} (ρ) \hat{S} (ρ) | ψ_{-} 〉 = 〈 ψ_{+} | ψ_{-} 〉, \end{matrix}$ which remains unchanged because $\hat{S} (ρ)$ is unitary.
The trick to compute the purity and the von Neumann entropy is to diagonalize ${\hat{ρ}}_{spin}$ . In particular, suppose the nonzero eigenvalues of ${\hat{ρ}}_{spin}$ are ${λ_{i}}$ , then the purity and the von Neumann entropy of ${\hat{ρ}}_{spin}$ are $\sum_{i} λ_{i}^{2}$ and $- \sum_{i} λ_{i} ln λ_{i}$ , respectively. For the density matrix ${\hat{ρ}}_{spin}$ with a decay factor $e^{- Γ_{tot}}$ on the off-diagonal terms, its eigenvalues are $λ_{1, 2} = (1 \pm e^{- Γ_{tot}}) / 2$ and $λ_{3} = 0$ . Especially, when the total decoherence factor $Γ_{tot}$ is very small, then the entropy can be approximated as $\begin{matrix} \begin{matrix} S & = - [\frac{1 + e^{- Γ_{tot}}}{2} ln \frac{1 + e^{- Γ_{tot}}}{2} + \frac{1 - e^{- Γ_{tot}}}{2} ln \frac{1 - e^{- Γ_{tot}}}{2}] \\ \approx \frac{1 + e^{- Γ_{tot}}}{2} \times \frac{1 - e^{- Γ_{tot}}}{2} + \frac{1 - e^{- Γ_{tot}}}{2} \times \frac{1 + e^{- Γ_{tot}}}{2} \\ = \frac{1}{2} (1 - e^{- 2 Γ_{tot}}) \approx Γ_{tot}, \end{matrix} \end{matrix}$ where the first approximated equation used an approximation $ln ((1 \pm e^{- Γ_{tot}}) / 2) \approx (- 1 \pm e^{Γ_{tot}}) / 2$ .
J. A. Barandes, The stochastic-quantum correspondence, Philos. Phys. 3, 8 (2025).
J. A. Barandes, The stochastic-quantum theorem, arXiv:2309.03085.
O. V. Ivakhnenko, S. N. Shevchenko, and F. Nori, Nonadiabatic Landau–Zener–Stückelberg–Majorana transitions, dynamics, and interference, Phys. Rep. 995, 1 (2023).
A. K. Dhara and S. V. Lawande, Feynman propagator for time-dependent Lagrangians possessing an invariant quadratic in momentum, J. Phys. A: Math. Gen. 17, 2423 (1984).
M. Kolodrubetz, D. Sels, P. Mehta, and A. Polkovnikov, Geometry and non-adiabatic response in quantum and classical systems, Phys. Rep. 697, 1 (2017).
J. M. Hogan, D. M. S. Johnson, and M. A. Kasevich, Light-pulse atom interferometry, in Atom Optics and Space Physics, edited by E. Arimondo, W. Ertmer, W. P. Schleich, and E. M. Rasel (IOS Press, Amsterdam, 2009), pp. 411–447.
E. H. Kerner, Note on the forced and damped oscillator in quantum mechanics, Can. J. Phys. 36, 371 (1958).
One can directly write $\begin{matrix} f (- ω^{*}) = S (- ω^{*}) \frac{1 - e^{- 2 π i N ω^{*} / ω_{0}}}{ω^{* 2} (ω^{* 2} - ω_{0}^{2})^{2}} . \end{matrix}$ It is obvious that $1 - e^{- 2 π i N ω^{*} / ω_{0}} = {(1 - e^{2 π i N ω / ω_{0}})}^{*}$ and $ω^{* 2} {(ω^{* 2} - ω_{0}^{2})}^{2} = {[ω^{2} {(ω^{2} - ω_{0}^{2})}^{2}]}^{*}$ . Besides, according to the properties $S (- ω) = S (ω)$ and $S (ω^{*}) = {[S (ω)]}^{*}$ , one can obtain $S (- ω^{*}) = {[S (ω)]}^{*}$ . Combining these equations, one may find $f (- ω^{*}) = {[f (ω)]}^{*}$ .
H.-P. Breuer and F. Petruccione, Quantum Master Equations, in The Theory of Open Quantum Systems (Oxford University Press, Oxford, 2007).
E. Torrontegui, S. Ibáñez, X. Chen, A. Ruschhaupt, D. Guéry-Odelin, and J. G. Muga, Fast atomic transport without vibrational heating, Phys. Rev. A 83, 013415 (2011).
V. P. Ermakov, Second-order differential equations. Conditions of integrability in finite form, Appl. Anal. and Discrete Math. 2, 123 (2008).
E. Pinney, The nonlinear differential equation $y^{''} + p (x) y + c / y^{3} = 0$ , Proc. Am. Math. Soc. 1, 681 (1950).
P. Storey and C. Cohen-Tannoudji, The Feynman path integral approach to atomic interferometry: A tutorial, J. Phys. II 4, 1999 (1994).

Phys. Rev. Research 8, 023115– Published 4 May, 2026

Vol. 8, Iss. 2 — May - July 2026

Received 14 May 2025
Accepted 2 April 2026

DOI: https://doi.org/10.1103/9bzl-lfnq

Published by the American Physical Society under the terms of the Creative Commons Attribution 4.0 International license. Further distribution of this work must maintain attribution to the author(s) and the published article's title, journal citation, and DOI.
