Families of localized modes of Bose-Einstein condensates enabled by incommensurate optical lattice and photon-atom interactions

Pedro S. Gil and Vladimir V. Konotop*

  • Departamento de Física and Centro de Física Teórica e Computacional, Faculdade de Ciências, Universidade de Lisboa, Campo Grande, Edifício C8, Lisboa 1749-016, Portugal

  • *Contact author: vvkonotop@ciencias.ulisboa.pt
PDF

Phys. Rev. Research 8, 013194 – Published 19 February, 2026

DOI: https://doi.org/10.1103/5hcq-tfjz

Abstract

We consider a Bose-Einstein condensate (BEC) loaded into a one-dimensional optical cavity under the combined action of an external potential and atom-cavity coupling with mutually incommensurate periods. Such configuration enables the localization of matter waves even in the absence of two-body interactions. We study families of localized modes within the mean-field approximation for red and blue detunings from atomic and cavity resonances in relatively shallow quasiperiodic lattices, beyond the validity of the tight-binding approximation. The parameter regimes supporting localization of atomic wave packets are identified. The system exhibits two types of bistability manifested as distinct photon numbers under otherwise identical conditions. One type arises from the coexistence of multiple families of localized modes, typical of conservative nonlinear systems, while the other stems from the multivalued dependence of the families on system parameters, characteristic of systems exhibiting hysteresis. BEC in a cavity may also display pseudodegeneracy, understood as the existence of two distinct atomic-density distributions corresponding to the same atomic and photon numbers (although different chemical potentials). The stability of the localized modes is analyzed. It is shown that, owing to the strong impact of long-range interactions on stability, a two-localized-mode configuration can operate as an xor logic gate.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (39)

  1. S. Haroche and J.-M. Raimond, Exploring the Quantum: Atoms, Cavities, and Photons (Oxford University Press, Oxford, UK, 2006).
  2. H. Ritsch, P. Domokos, F. Brennecke, and T. Esslinger, Cold atoms in cavity-generated dynamical optical potentials, Rev. Mod. Phys. 85, 553 (2013).
  3. F. Mivehvar, F. Piazza, T. Donner, and H. Ritsch, Cavity QED with quantum gases: New paradigms in many-body physics, Adv. Phys. 70, 1 (2021).
  4. L. Zhou, H. Pu, K. Zhang, X.-D. Zhao, and W. Zhang, Cavity-induced switching between localized and extended states in a noninteracting Bose-Einstein condensate, Phys. Rev. A 84, 043606 (2011).
  5. K. Rojan, R. Kraus, T. Fogarty, H. Habibian, A. Minguzzi, and G. Morigi, Localization transition in the presence of cavity backaction, Phys. Rev. A 94, 013839 (2016).
  6. J. Major, G. Morigi, and J. Zakrzewski, Single-particle localization in dynamical potentials, Phys. Rev. A 98, 053633 (2018).
  7. H. Habibian, A. Winter, S. Paganelli, H. Rieger, and G. Morigi, Bose-glass phases of ultracold atoms due to cavity backaction, Phys. Rev. Lett. 110, 075304 (2013).
  8. G. Roati, C. D’Errico, L. Fallani, M. Fattori, C. Fort, M. Zaccanti, G. Modugno, M. Modugno, and M. Inguscio, Anderson localization of a non-interacting Bose–Einstein condensate, Nature (London) 453, 895 (2008).
  9. B. Deissler, M. Zaccanti, G. Roati, C. D’Errico, M. Fattori, M. Modugno, G. Modugno, and M. Inguscio, Delocalization of a disordered bosonic system by repulsive interactions, Nat. Phys. 6, 354 (2010).
  10. H. P. Lüschen, S. Scherg, T. Kohlert, M. Schreiber, P. Bordia, X. Li, S. Das Sarma, and I. Bloch, Single-particle mobility edge in a one-dimensional quasi-periodic optical lattice, Phys. Rev. Lett. 120, 160404 (2018).
  11. Y. Wang, J.-H. Zhang, Y. Li, J. Wu, W. Liu, F. Mei, Y. Hu, L. Xiao, J. Ma, C. Chin, and S. Jia, Observation of interaction-induced mobility edge in an atomic Aubry-André wire, Phys. Rev. Lett. 129, 103401 (2022).
  12. S. Aubry and G. André, Analyticity breaking and Anderson localization in incommensurate lattices, Ann. Israel Phys. Soc 3, 18 (1980).
  13. J. Fröhlich, T. Spencer, and P. Wittwer, Localization for a class of one dimensional quasi-periodic Schrödinger operators, Commun. Math. Phys. 132, 5 (1990).
  14. S. Surace Jr., The Schrödinger equation with a quasi-periodic potential, Trans. Am Math. Soc. 320, 321 (1990).
  15. R. B. Diener, G. A. Georgakis, J. Zhong, M. Raizen, and Q. Niu, Transition between extended and localized states in a one-dimensional incommensurate optical lattice, Phys. Rev. A 64, 033416 (2001).
  16. J. Biddle and S. Das Sarma, Predicted mobility edges in one-dimensional incommensurate optical lattices: An exactly solvable model of Anderson localization, Phys. Rev. Lett. 104, 070601 (2010).
  17. M. Modugno, Exponential localization in one-dimensional quasi-periodic optical lattices, New J. Phys. 11, 033023 (2009).
  18. H. C. Prates, D. A. Zezyulin, and V. V. Konotop, Bose-Einstein condensates in quasi-periodic lattices: Bosonic Josephson junction, self-trapping, and multimode dynamics, Phys. Rev. Res. 4, 033219 (2022).
  19. V. V. Konotop, Dimers and discrete breathers in Bose-Einstein condensates in a quasi-periodic potential, Phys. Rev. Res. 6, 033113 (2024).
  20. S. Gupta, K. L. Moore, K. W. Murch, and D. M. Stamper-Kurn, Cavity nonlinear optics at low photon numbers from collective atomic motion, Phys. Rev. Lett. 99, 213601 (2007).
  21. S. H. Kazemi, S. Ghanbari, and M. Mahmoudi, Controllable optical bistability in a cavity optomechanical system with a Bose–Einstein condensate, Laser Phys. 26, 055502 (2016).
  22. M. Diver, G. R. M. Robb, and G.-L. Oppo, Nonlinear and chaotic dynamics of a Bose-Einstein condensate in an optical cavity, Phys. Rev. A 89, 033602 (2014).
  23. D. A. Abanin, E. Altman, I. Bloch, and M. Serbyn, Colloquium: Many-body localization, thermalization, and entanglement, Rev. Mod. Phys. 91, 021001 (2019).
  24. P. Kubala, P. Sierant, G. Morigi, and J. Zakrzewski, Ergodicity breaking with long-range cavity-induced quasi-periodic interactions, Phys. Rev. B 103, 174208 (2021).
  25. H. Yin, J. Hu, A.-C. Ji, G. Juzeliũnas, X.-J. Liu, and Q. Sun, Localization driven superradiant instability, Phys. Rev. Lett. 124, 113601 (2020).
  26. F. Brennecke, S. Ritter, T. Donner, and T. Esslinger, Cavity optomechanics with a Bose-Einstein condensate, Science 322, 235 (2008).
  27. D. Nagy, G. Szirmai, and P. Domokos, Self-organization of a Bose-Einstein condensate in an optical cavity, Eur. Phys. J. D 48, 127 (2008).
  28. A. Jaouadi, N. Gaaloul, B. V. de Lesegno, M. Telmini, L. Pruvost, and E. Charron, Bose-Einstein condensation in dark power-law laser traps, Phys. Rev. A 82, 023613 (2010).
  29. A. L. Gaunt, T. F. Schmidutz, I. Gotlibovych, R. P. Smith, and Z. Hadzibabic, Bose-Einstein condensation of atoms in a uniform potential, Phys. Rev. Lett. 110, 200406 (2013).
  30. N. Navon, R. P. Smith, and Z. Hadzibabic, Quantum gases in optical boxes, Nat. Phys. 17, 1334 (2021).
  31. A. Öttl, S. Ritter, M. Köhl, and T. Esslinger, Hybrid apparatus for Bose-Einstein condensation and cavity quantum electrodynamics: Single atom detection in quantum degenerate gases, Rev. Sci. Instrum. 77, 063118 (2006).
  32. K. Baumann, C. Guerlin, F. Brennecke, and T. Esslinger, Dicke quantum phase transition with a superfluid gas in an optical cavity, Nature (London) 464, 1301 (2010).
  33. D. A. Steck, Rubidium 87 D line data, revision 2.3.4, 2025, http://steck.us/alkalidata.
  34. A. J. Kollár, A. T. Papageorge, K. Baumann, M. A. Armen, and B. L. Lev, An adjustable-length cavity and Bose–Einstein condensate apparatus for multimode cavity QED, New J. Phys. 17, 043012 (2015).
  35. H. Keßler, J. Klinder, M. Wolke, and A. Hemmerich, Optomechanical atom-cavity interaction in the sub-recoil regime, New J. Phys. 16, 053008 (2014).
  36. Z. Gao, V. V. Konotop, R. Peng, Z. Xu, Z. Yang, and F. Ye, Low-dimensional compact states in 3D moiré lattices, Nat. Commun. 16, 6306 (2025).
  37. M. F. de la Ripelle, The potential harmonic expansion method, Ann. Phys. (NY) 147, 281 (1983).
  38. T. K. Das and B. Chakrabarti, Potential harmonics expansion method for trapped interacting bosons: Inclusion of two-body correlation, Phys. Rev. A 70, 063601 (2004).
  39. https://doi.org/10.54499/2023.13176.PEX.
