Far-field heat transfer and monochromatic thermal currents in a cylindrical nonreciprocal cavity

Guillem Masdemont, Julien Legendre*, and Georgia T. Papadakis†

  • *Contact author: julien.legendre@icfo.eu
  • †Contact author: georgia.papadakis@icfo.eu
PDF

Phys. Rev. Research 8, 023293 – Published 15 June, 2026

DOI: https://doi.org/10.1103/5bbx-qx7v

Abstract

Breaking Kirchhoff's law of thermal radiation yields opportunities in one-way radiative thermal transport and circuitry. We investigate its consequences in the far-field regime in cylindrical cavities, by employing a specular ray-tracing algorithm. At thermal equilibrium, we show that violation of Kirchhoff's law yields nonvanishing heat rectification coefficients within different sections of the cavity, which can be tuned for perfect rectification and circulation, while internal monochromatic currents vanish due to the intrinsic coupling between emission and absorption at specular surfaces. This constraint is lifted under nonequilibrium conditions, where rotational heat fluxes within the cavity can be precisely controlled by appropriately combining reciprocal and nonreciprocal materials. These findings open avenues for thermal management and provide design principles for nonreciprocal photonic devices.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (55)

  1. G. Kirchhoff, Ueber das Verhältniss zwischen dem Emissionsvermögen und dem Absorptionsvermögen der Körper für Wärme und Licht, Ann. Phys. (NY) 185, 275 (1860).
  2. L. Zhu and S. Fan, Near-complete violation of detailed balance in thermal radiation, Phys. Rev. B 90, 220301 (2014).
  3. Z. M. Zhang, X. Wu, and C. Fu, Validity of Kirchhoff's law for semitransparent films made of anisotropic materials, J. Quant. Spectrosc. Radiat. Transfer 245, 106904 (2020).
  4. Y. Park, V. S. Asadchy, B. Zhao, C. Guo, J. Wang, and S. Fan, Violating Kirchhoff's law of thermal radiation in semitransparent structures, ACS Photon. 8, 2417 (2021).
  5. D. E. Fernandes and M. G. Silveirinha, Enhancing the directional violation of Kirchhoff's law of thermal radiation with a nonreciprocal wire medium, Phys. Rev. Appl. 20, 054028 (2023).
  6. S. Yang, M. Liu, C. Zhao, S. Fan, and C.-W. Qiu, Nonreciprocal thermal photonics, Nat. Photon. 18, 412 (2024).
  7. Z. Zhang and L. Zhu, Nonreciprocal thermal photonics for energy conversion and radiative heat transfer, Phys. Rev. Appl. 18, 027001 (2022).
  8. A. Pusch, J. M. Gordon, A. Mellor, J. J. Krich, and N. J. Ekins-Daukes, Fundamental efficiency bounds for the conversion of a radiative heat engine's own emission into work, Phys. Rev. Appl. 12, 064018 (2019).
  9. M. Giteau, M. F. Picardi, and G. T. Papadakis, Thermodynamic performance bounds for radiative heat engines, Phys. Rev. Appl. 20, L061003 (2023).
  10. M. Giteau, M. F. Picardi, and G. T. Papadakis, Fundamental limitations of thermoradiative energy conversion, PRX Energy 4, 043001 (2025).
  11. M. A. Green, Time-asymmetric photovoltaics, Nano Lett. 12, 5985 (2012).
  12. S. J. Ghalekohneh and B. Zhao, Nonreciprocal solar thermophotovoltaics, Phys. Rev. Appl. 18, 034083 (2022).
  13. Y. Park, B. Zhao, and S. Fan, Reaching the ultimate efficiency of solar energy harvesting with a nonreciprocal multijunction solar cell, Nano Lett. 22, 448 (2022).
  14. M. F. Picardi, V. I. Moerbeek, M. Pascale, and G. T. Papadakis, Nonreciprocity in transmission mode with planar structures for arbitrarily polarized light, Opt. Mater. Express 14, 2201 (2024).
  15. Z. Omair, G. Scranton, L. M. Pazos-Outón, T. P. Xiao, A. S. Myles, V. Ganapati, P. F. Peterson, J. Holzrichter, H. Atwater, and E. Yablonovitch, Ultraefficient thermophotovoltaic power conversion by band-edge spectral filtering, Proc. Natl. Acad. Sci. USA 116, 15356 (2019).
  16. E. Nefzaoui, J. Drevillon, and K. Joulain, Selective emitters design and optimization for thermophotovoltaic applications, J. Appl. Phys. 111, 084316 (2012).
  17. H. Fang, L. Zhou, L. Xu, S. Dang, S. De Wolf, and Q. Gan, Radiative cooling for vertical solar panels, iScience 27, 108806 (2024).
  18. P. Ben-Abdallah, Photon thermal Hall effect, Phys. Rev. Lett. 116, 084301 (2016).
  19. P. Ben-Abdallah, Inverse spin thermal Hall effect in nonreciprocal photonic systems, Phys. Rev. Lett. 134, 113804 (2025).
  20. C. Guo, Y. Guo, and S. Fan, Relation between photon thermal Hall effect and persistent heat current in nonreciprocal radiative heat transfer, Phys. Rev. B 100, 205416 (2019).
  21. A. Ott, S.-A. Biehs, and P. Ben-Abdallah, Anomalous photon thermal Hall effect, Phys. Rev. B 101, 241411 (2020).
  22. Y. Guo and S. Fan, Single gyrotropic particle as a heat engine, ACS Photon. 8, 1623 (2021).
  23. L. Zhu and S. Fan, Persistent directional current at equilibrium in nonreciprocal many-body near field electromagnetic heat transfer, Phys. Rev. Lett. 117, 134303 (2016).
  24. L. Zhu, Y. Guo, and S. Fan, Theory of many-body radiative heat transfer without the constraint of reciprocity, Phys. Rev. B 97, 094302 (2018).
  25. S.-A. Biehs and I. Latella, On persistent energy currents at equilibrium in non-reciprocal systems, J. Quant. Spectrosc. Radiat. Transfer 347, 109660 (2025).
  26. L. Fan, Y. Guo, G. T. Papadakis, B. Zhao, Z. Zhao, S. Buddhiraju, M. Orenstein, and S. Fan, Nonreciprocal radiative heat transfer between two planar bodies, Phys. Rev. B 101, 085407 (2020).
  27. R. M. Abraham Ekeroth, P. Ben-Abdallah, J. C. Cuevas, and A. García-Martín, Anisotropic thermal magnetoresistance for an active control of radiative heat transfer, ACS Photon. 5, 705 (2018).
  28. B. Zhao, Y. Shi, J. Wang, Z. Zhao, N. Zhao, and S. Fan, Near-complete violation of Kirchhoff's law of thermal radiation with a 0.3  T magnetic field, Opt. Lett. 44, 4203 (2019).
  29. K. J. Shayegan, B. Zhao, Y. Kim, S. Fan, and H. A. Atwater, Nonreciprocal infrared absorption via resonant magneto-optical coupling to InAs, Sci. Adv. 8, eabm4308 (2022).
  30. B. Zhao, C. Guo, C. A. C. Garcia, P. Narang, and S. Fan, Axion-field-enabled nonreciprocal thermal radiation in Weyl semimetals, Nano Lett. 20, 1923 (2020).
  31. Y. Tsurimaki, X. Qian, S. Pajovic, F. Han, M. Li, and G. Chen, Large nonreciprocal absorption and emission of radiation in type-I Weyl semimetals with time reversal symmetry breaking, Phys. Rev. B 101, 165426 (2020).
  32. C. Guo, B. Zhao, D. Huang, and S. Fan, Radiative thermal router based on tunable magnetic Weyl semimetals, ACS Photon. 7, 3257 (2020).
  33. B. Zhao, J. Wang, Z. Zhao, C. Guo, Z. Yu, and S. Fan, Nonreciprocal thermal emitters using metasurfaces with multiple diffraction channels, Phys. Rev. Appl. 16, 064001 (2021).
  34. K. J. Shayegan, S. Biswas, B. Zhao, S. Fan, and H. A. Atwater, Direct observation of the violation of Kirchhoff's law of thermal radiation, Nat. Photon. 17, 891 (2023).
  35. B. Zhao, Radiation imbalance: New material emits better than it absorbs, Physics 18, 123 (2025).
  36. Z. Zhang, A. K. Dehaghi, P. Ghosh, and L. Zhu, Observation of strong nonreciprocal thermal emission, Phys. Rev. Lett. 135, 016901 (2025).
  37. K. J. Shayegan, J. S. Hwang, B. Zhao, A. P. Raman, and H. A. Atwater, Broadband nonreciprocal thermal emissivity and absorptivity, Light: Sci. Appl. 13, 176 (2024).
  38. B. Nabavi, S. Jafari Ghalekohneh, K. J. Shayegan, E. J. Tervo, H. Atwater, and B. Zhao, High-temperature strong nonreciprocal thermal radiation from semiconductors, ACS Photon. 12, 2767 (2025).
  39. L. Wang, F. J. García de Abajo, and G. T. Papadakis, Maximal violation of Kirchhoff's law in planar heterostructures, Phys. Rev. Res. 5, L022051 (2023).
  40. B. Do, S. Jafari Ghalekohneh, T. Adebiyi, B. Zhao, and R. Zhang, Automated design of nonreciprocal thermal emitters via Bayesian optimization, J. Quant. Spectrosc. Radiat. Transfer 331, 109260 (2025).
  41. J. A. Kong, Electromagnetic Wave Theory (John Wiley & Sons, New York, 1986).
  42. T. G. Mackay and A. Lakhtakia, The Transfer-Matrix Method in Electromagnetics and Optics (Springer, Cham, 2020).
  43. D. A. B. Miller, Z. Linxiao, and F. Shanhui, Universal modal radiation laws for all thermal emitters, Proc. Natl. Acad. Sci. USA 114, 4336 (2017).
  44. C. Khandekar, F. Khosravi, Z. Li, and Z. Jacob, New spin-resolved thermal radiation laws for nonreciprocal bianisotropic media, New J. Phys. 22, 123005 (2020).
  45. C. Guo, B. Zhao, and S. Fan, Adjoint Kirchhoff's law and general symmetry implications for all thermal emitters, Phys. Rev. X 12, 021023 (2022).
  46. J. A. Kong, Theorems of bianisotropic media, Proc. IEEE 60, 1036 (1972).
  47. L. Novotny and B. Hecht, Principles of Nano-Optics, 2nd ed. (Cambridge University Press, Cambridge, 2012).
  48. C. Yang, W. Cai, and Z. M. Zhang, Polarimetric analysis of thermal emission from both reciprocal and nonreciprocal materials using fluctuation electrodynamics, Phys. Rev. B 106, 245407 (2022).
  49. S. Jafari Ghalekohneh and B. Zhao, Perfect heat rectification and circulation with nonreciprocal radiative surfaces in the far field, Phys. Rev. Res. 7, 043150 (2025).
  50. Z. M. Zhang, Nano/Microscale Heat Transfer, Mechanical Engineering Series (Springer International Publishing, Cham, 2020).
  51. T. L. Bergman, Fundamentals of Heat and Mass Transfer (John Wiley & Sons, New York, 2011).
  52. M. Planck, The Theory of Heat Radiation (Dover Publications, New York, 1991).
  53. R. Ju, P.-C. Cao, D. Wang, M. Qi, L. Xu, S. Yang, C.-W. Qiu, H. Chen, and Y. Li, Nonreciprocal heat circulation metadevices, Adv. Mater. 36, 2309835 (2024).
  54. G. Masdemont, J. Legendre, and G. T. Papadakis, Far-field heat transfer and monochromatic thermal currents in a cylindrical nonreciprocal cavity, https://github.com/GuillemMasdemont/cylindrical-nonreciprocal-heat (2026).
  55. R. L. Burden and J. D. Faires, Numerical Analysis (Brooks/Cole, Cengage Learning, Boston, 2011).
