Optomechanical separation of transverse spin and orbital energy flows in liquid crystals
Phys. Rev. Research 8, 013235 – Published 3 March, 2026
DOI: https://doi.org/10.1103/59st-f1mb
Abstract
We report a nondissipative optomechanical approach to separate the spin and orbital components of transverse energy flows of light beams. Focusing on uniformly polarized paraxial fields, the method relies on detecting the radiation-pressure-induced reorientation of the optical axis in anisotropic media—specifically, liquid crystals. Within a perturbative analytical approach, we demonstrate the selective encoding of the transverse spin and orbital components of the Poynting vector into orthogonal orientational elastic modes, whose relative weights are mediated by the Gouy phase. The spatial distributions of spin and orbital momentum can therefore be retrieved without resorting to point-by-point measurements using absorbing or scattering probe particles. Analytical results are supported by a fully self-consistent numerical solution coupling Maxwell’s equations and Landau-de Gennes nematodynamics in three dimensions. This exact framework captures higher-order and nonparaxial effects beyond the analytical perturbative regime and allows us to validate the predicted Gouy-phase-mediated optomechanical response. These results establish a practical route toward optomechanical imaging of the internal momentum structure of light, fostering momentum-resolved optical metrology and light-matter interaction studies with structured beams.
Physics Subject Headings (PhySH)
Article Text
References (27)
- A. Y. Bekshaev and M. Soskin, Transverse energy flows in vectorial fields of paraxial beams with singularities, Opt. Commun. 271, 332 (2007).
- M. V. Berry, Optical currents, J. Opt. A: Pure Appl. Opt. 11, 094001 (2009).
- A. Bekshaev, K. Y. Bliokh, and M. Soskin, Internal flows and energy circulation in light beams, J. Opt. 13, 053001 (2011).
- K. Y. Bliokh, F. J. Rodríguez-Fortuño, F. Nori, and A. V. Zayats, Spin–orbit interactions of light, Nat. Photon. 9, 796 (2015).
- I. Toftul, S. Golat, F. J. Rodríguez-Fortuño, F. Nori, Y. Kivshar, and K. Y. Bliokh, Radiation forces and torques in optics and acoustics, Rev. Mod. Phys. (to be published).
- Y. Shen, H. Wang, and S. Fan, Free-space topological optical textures: Tutorial, Adv. Opt. Photon. 17, 295 (2025).
- J. D. Jackson, Classical Electrodynamics (John Wiley & Sons, Hoboken, NJ, 2021).
- B. Ghosh, A. Daniel, B. Gorzkowski, A. Y. Bekshaev, R. Lapkiewicz, and K. Y. Bliokh, Canonical and poynting currents in propagation and diffraction of structured light: Tutorial, J. Opt. Soc. Am. B 41, 1276 (2024).
- M. Antognozzi, C. Bermingham, R. Harniman, S. Simpson, J. Senior, R. Hayward, H. Hoerber, M. Dennis, A. Bekshaev, K. Bliokh, and F. Nori, Direct measurements of the extraordinary optical momentum and transverse spin-dependent force using a nano-cantilever, Nat. Phys. 12, 731 (2016).
- D. B. Ruffner and D. G. Grier, Optical forces and torques in nonuniform beams of light, Phys. Rev. Lett. 108, 173602 (2012).
- A. Y. Savchenko, N. V. Tabiryan, and B. Y. Zel’dovich, Transfer of momentum and torque from a light beam to a liquid, Phys. Rev. E 56, 4773 (1997).
- E. Brasselet, Singular optical manipulation of birefringent elastic media using nonsingular beams, Opt. Lett. 34, 3229 (2009).
- E. Brasselet, Singular optical reordering of liquid crystals using Gaussian beams, J. Opt. 12, 124005 (2010).
- L. Lucchetti, L. Criante, F. Bracalente, F. Aieta, and F. Simoni, Optical trapping induced by reorientational nonlocal effects in nematic liquid crystals, Phys. Rev. E 84, 021702 (2011).
- M. El Ketara, H. Kobayashi, and E. Brasselet, Sensitive vectorial optomechanical footprint of light in soft condensed matter, Nat. Photon. 15, 121 (2021).
- F. J. Belinfante, On the current and the density of the electric charge, the energy, the linear momentum and the angular momentum of arbitrary fields, Physica 7, 449 (1940).
- I. D. Toftul, K. Y. Bliokh, M. I. Petrov, and F. Nori, Acoustic radiation force and torque on small particles as measures of the canonical momentum and spin densities, Phys. Rev. Lett. 123, 183901 (2019).
- N. V. Tabiryan, A. V. Sukhov, and B. Y. Zel’dovich, Orientational optical nonlinearity of liquid crystals, Mol. Cryst. Liq. Cryst. 136, 1 (1986).
- M. Born and E. Wolf, Principles of Optics (Pergamon Press, Oxford, UK, 2005).
- M. Ravnik and S. Žumer, Landau-de Gennes of nematic liquid crystal colloids, Liq. Cryst. 36, 1201 (2009).
- A. Taflove, S. C. Hagness, and M. Piket-May, Computational Electromagnetics: The Finite-Difference Time-Domain Method, 3rd ed. (Elsevier, Amsterdam, 2005), Chap. 9, pp. 629–670.
- M. Čančula, M. Ravnik, and S. Žumer, Generation of vector beams with liquid crystal disclination lines, Phys. Rev. E 90, 022503 (2014).
- M. Čančula, M. Ravnik, I. Muševič, and S. Žumer, Liquid microlenses and waveguides from bulk nematic birefringent profiles, Opt. Express 24, 22177 (2016).
- J. P. Barton and D. R. Alexander, Fifth-order corrected electromagnetic field components for a fundamental Gaussian beam, J. Appl. Phys. 66, 2800 (1989).
- A. S. Zolot’ko, V. F. Kitaeva, N. Kroo, N. N. Sobolev, and L. Csillag, The effect of an optical field on the nematic phase of the liquid crystal ocbp, JETP Lett. 32, 158 (1980).
- B. Y. Zel’dovich, N. V. Tabiryan, and Y. S. Chilingaryan, Fredericks transitions induced by light fields, Sov. Phys. JETP 54, 32 (1981).
- E. Brasselet, A. Lherbier, and L. J. Dubé, Transverse nonlocal effects in optical reorientation of nematic liquid crystals, J. Opt. Soc. Am. B 23, 36 (2006).
