Phase-subtractive interference and noise-resistant quantum imaging with two undetected photons

Chandler Tarrant and Mayukh Lahiri*

  • *Contact author: mlahiri@okstate.edu
PDF

Phys. Rev. Research 8, 033210 – Published 19 August, 2026

DOI: https://doi.org/10.1103/1ljx-h9x1

Abstract

We introduce and theoretically analyze a quantum interference phenomenon in which a two-photon interference pattern is created using four-photon quantum states generated by two independent sources and without detecting two of the photons. Contrary to the common perception, the interference pattern can be made fully independent of phases acquired by the photons detected to construct it. However, it still contains information about spatially dependent phases acquired by the two undetected photons. This phenomenon can be observed with both bosonic and fermionic particles. We show that the phenomenon can be harnessed to develop a quantum quantitative phase imaging technique that is immune to uncontrollable phase fluctuations in the interferometer and allows image acquisition without detecting the photons illuminating the object.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (54)

  1. D. M. Greenberger, M. A. Horne, and A. Zeilinger, Multiparticle interferometry and the superposition principle, Phys. Today 46(8), 22 (1993).
  2. A. Hochrainer, M. Lahiri, M. Erhard, M. Krenn, and A. Zeilinger, Quantum indistinguishability by path identity and with undetected photons, Rev. Mod. Phys. 94, 025007 (2022).
  3. X. Y. Zou, L. J. Wang, and L. Mandel, Induced coherence and indistinguishability in optical interference, Phys. Rev. Lett. 67, 318 (1991).
  4. L. J. Wang, X. Y. Zou, and L. Mandel, Induced coherence without induced emission, Phys. Rev. A 44, 4614 (1991).
  5. M. A. Horne, A. Shimony, and A. Zeilinger, Two-particle interferometry, Phys. Rev. Lett. 62, 2209 (1989).
  6. M. Lahiri, Many-particle interferometry and entanglement by path identity, Phys. Rev. A 98, 033822 (2018).
  7. K. Qian, K. Wang, L. Chen, Z. Hou, M. Krenn, S. Zhu, and X.-s. Ma, Multiphoton non-local quantum interference controlled by an undetected photon, Nat. Commun. 14, 1480 (2023).
  8. G. B. Lemos, V. Borish, G. D. Cole, S. Ramelow, R. Lapkiewicz, and A. Zeilinger, Quantum imaging with undetected photons, Nature (London) 512, 409 (2014).
  9. M. Lahiri, R. Lapkiewicz, G. B. Lemos, and A. Zeilinger, Theory of quantum imaging with undetected photons, Phys. Rev. A 92, 013832 (2015).
  10. B. Viswanathan, G. B. Lemos, and M. Lahiri, Position correlation enabled quantum imaging with undetected photons, Opt. Lett. 46, 3496 (2021).
  11. I. Kviatkovsky, H. M. Chrzanowski, and S. Ramelow, Mid-infrared microscopy via position correlations of undetected photons, Opt. Express 30, 5916 (2022).
  12. G. B. Lemos, M. Lahiri, S. Ramelow, R. Lapkiewicz, and W. Plick, Quantum imaging and metrology with undetected photons: Tutorial, J. Opt. Soc. Am. B 512, 409 (2022).
  13. J. Szuniewicz, S. Kurdziałek, S. Kundu, W. Zwolinski, R. Chrapkiewicz, M. Lahiri, and R. Lapkiewicz, Noise-resistant phase imaging with intensity correlation, Sci. Adv. 9, eadh5396 (2023).
  14. G. Thekkadath, D. England, F. Bouchard, Y. Zhang, M. Kim, and B. Sussman, Intensity interferometry for holography with quantum and classical light, Sci. Adv. 9, eadh1439 (2023).
  15. R. L. Pfleegor and L. Mandel, Interference of independent photon beams, Phys. Rev. 159, 1084 (1967).
  16. L. Mandel, Photon interference and correlation effects produced by independent quantum sources, Phys. Rev. A 28, 929 (1983).
  17. Z. Ou, Parametric down-conversion with coherent pulse pumping and quantum interference between independent fields, Quantum Semiclassical Opt.: J. Eur. Opt. Soc. Part B 9, 599 (1997).
  18. R. Chrapkiewicz, M. Jachura, K. Banaszek, and W. Wasilewski, Hologram of a single photon, Nat. Photonics 10, 576 (2016).
  19. Z.-Y. J. Ou, Multi-Photon Quantum Interference (Springer, New York, 2007), Vol. 43.
  20. T. B. Pittman, Y. H. Shih, D. V. Strekalov, and A. V. Sergienko, Optical imaging by means of two-photon quantum entanglement, Phys. Rev. A 52, R3429 (1995).
  21. A. Gatti, E. Brambilla, and L. Lugiato, Quantum imaging, Prog. Opt. 51, 251 (2008).
  22. K. W. C. Chan, M. N. O’Sullivan, and R. W. Boyd, Two-color ghost imaging, Phys. Rev. A 79, 033808 (2009).
  23. R. S. Aspden, D. S. Tasca, R. W. Boyd, and M. J. Padgett, EPR-based ghost imaging using a single-photon-sensitive camera, New J. Phys. 15, 073032 (2013).
  24. Y. Zhang, A. Sit, F. Bouchard, H. Larocque, F. Grenapin, E. Cohen, A. C. Elitzur, J. L. Harden, R. W. Boyd, and E. Karimi, Interaction-free ghost-imaging of structured objects, Opt. Express 27, 2212 (2019).
  25. S. P. Walborn, C. Monken, S. Pádua, and P. S. Ribeiro, Spatial correlations in parametric down-conversion, Phys. Rep. 495, 87 (2010).
  26. B. H. Liu, F. W. Sun, Y. X. Gong, Y. F. Huang, Z. Y. Ou, and G. C. Guo, Investigation of the role of indistinguishability in photon bunching and stimulated emission, Phys. Rev. A 79, 053846 (2009).
  27. M. Lahiri, A. Hochrainer, R. Lapkiewicz, G. B. Lemos, and A. Zeilinger, Nonclassicality of induced coherence without induced emission, Phys. Rev. A 100, 053839 (2019).
  28. L. Mandel and E. Wolf, Optical Coherence and Quantum Optics (Cambridge University Press, Cambridge, 1995).
  29. G. Popescu, Quantitative Phase Imaging of Cells and Tissues (McGraw-Hill, New York, 2011).
  30. I. Kviatkovsky, H. M. Chrzanowski, E. G. Avery, H. Bartolomaeus, and S. Ramelow, Microscopy with undetected photons in the mid-infrared, Sci. Adv. 6, eabd0264 (2020).
  31. M. A. Herráez, D. R. Burton, M. J. Lalor, and M. A. Gdeisat, Fast two-dimensional phase-unwrapping algorithm based on sorting by reliability following a noncontinuous path, Appl. Opt. 41, 7437 (2002).
  32. J. Mertz, Introduction to Optical Microscopy (Cambridge University Press, Cambridge, 2019).
  33. Y. Park, C. Depeursinge, and G. Popescu, Quantitative phase imaging in biomedicine, Nat. Photonics 12, 578 (2018).
  34. S. Mitchell, K. Roy, T. A. Zangle, and A. Hoffmann, Nongenetic origins of cell-to-cell variability in B lymphocyte proliferation, Proc. Natl. Acad. Sci. USA 115, E2888 (2018).
  35. M. Mir, Z. Wang, Z. Shen, M. Bednarz, R. Bashir, I. Golding, S. G. Prasanth, and G. Popescu, Optical measurement of cycle-dependent cell growth, Proc. Natl. Acad. Sci. USA 108, 13124 (2011).
  36. H. Majeed, T. H. Nguyen, M. E. Kandel, A. Kajdacsy-Balla, and G. Popescu, Label-free quantitative evaluation of breast tissue using spatial light interference microscopy (slim), Sci. Rep. 8, 6875 (2018).
  37. S. Uttam, H. V. Pham, J. LaFace, B. Leibowitz, J. Yu, R. E. Brand, D. J. Hartman, and Y. Liu, Early prediction of cancer progression by depth-resolved nanoscale mapping of nuclear architecture from unstained tissue specimensnanoscale nuclear architecture predicts cancer progression, Cancer Res. 75, 4718 (2015).
  38. D. A. Kalashnikov, A. V. Paterova, S. P. Kulik, and L. A. Krivitsky, Infrared spectroscopy with visible light, Nat. Photonics 10, 98 (2016).
  39. A. V. Paterova, S. M. Maniam, H. Yang, G. Grenci, and L. A. Krivitsky, Hyperspectral infrared microscopy with visible light, Sci. Adv. 6, eabd0460 (2020).
  40. S. Töpfer, M. Gilaberte Basset, J. Fuenzalida, F. Steinlechner, J. P. Torres, and M. Gräfe, Quantum holography with undetected light, Sci. Adv. 8, eabl4301 (2022).
  41. A. Vallés, G. Jiménez, L. J. Salazar-Serrano, and J. P. Torres, Optical sectioning in induced coherence tomography with frequency-entangled photons, Phys. Rev. A 97, 023824 (2018).
  42. A. V. Paterova, H. Yang, C. An, D. A. Kalashnikov, and L. A. Krivitsky, Tunable optical coherence tomography in the infrared range using visible photons, Quantum Sci. Technol. 3, 025008 (2018).
  43. A. Heuer, R. Menzel, and P. W. Milonni, Induced coherence, vacuum fields, and complementarity in biphoton generation, Phys. Rev. Lett. 114, 053601 (2015).
  44. A. Heuer, R. Menzel, and P. W. Milonni, Complementarity in biphoton generation with stimulated or induced coherence, Phys. Rev. A 92, 033834 (2015).
  45. M. Lahiri, R. Lapkiewicz, A. Hochrainer, G. B. Lemos, and A. Zeilinger, Characterizing mixed-state entanglement through single-photon interference, Phys. Rev. A 104, 013704 (2021).
  46. G. B. Lemos, R. Lapkiewicz, A. Hochrainer, M. Lahiri, and A. Zeilinger, One-photon measurement of two-photon entanglement, Phys. Rev. Lett. 130, 090202 (2023).
  47. S. Rajeev and M. Lahiri, Single-qubit measurement of two-qubit entanglement in generalized Werner states, Phys. Rev. A 108, 052410 (2023).
  48. M. Krenn, A. Hochrainer, M. Lahiri, and A. Zeilinger, Entanglement by path identity, Phys. Rev. Lett. 118, 080401 (2017).
  49. J. Kysela, M. Erhard, A. Hochrainer, M. Krenn, and A. Zeilinger, Path identity as a source of high-dimensional entanglement, Proc. Natl. Acad. Sci. USA 117, 26118 (2020).
  50. G. Zhang, C. Bian, L. Chen, Z. Ou, and W. Zhang, ‘which-way’ collective atomic spin excitation among atomic ensembles by photon indistinguishability, New J. Phys. 14, 063034 (2012).
  51. D. E. Bruschi, C. Sabín, and G. S. Paraoanu, Entanglement, coherence, and redistribution of quantum resources in double spontaneous down-conversion processes, Phys. Rev. A 95, 062324 (2017).
  52. R. Ghosh, C. K. Hong, Z. Y. Ou, and L. Mandel, Interference of two photons in parametric down conversion, Phys. Rev. A 34, 3962 (1986).
  53. C. Cohen-Tannoudji, B. Diu, and F. Laloë, Quantum Mechanics (Wiley, New York, NY, 1977), 1st ed.
  54. T. J. Herzog, J. G. Rarity, H. Weinfurter, and A. Zeilinger, Frustrated two-photon creation via interference, Phys. Rev. Lett. 72, 629 (1994).
