Reshaping quantum device noise via repetition code circuits

Yue Ma*, Michael Hanks, Evdokia Gneusheva, and M. S. Kim†

  • *Contact author: y.ma16@imperial.ac.uk
  • †Contact author: m.kim@imperial.ac.uk
PDF

Phys. Rev. Research 7, 033262 – Published 17 September, 2025

DOI: https://doi.org/10.1103/16gx-m7kg

Abstract

Noise of a quantum processor can be an important resource for simulating open quantum dynamics. However, this requires characterizing the device noise and then transforming it into a target structure. Here, we take the first step toward this goal: We analytically and numerically study reshaping the noise associated with native trapped-ion two-qubit entangling gates via quantum circuits based on repetition codes, and demonstrate our findings on the IonQ Aria-1 quantum hardware. We investigate all the building blocks, including the quantum channels describing noisy two-qubit entangling gates, the compilation of the encoding circuits into native gates, and the propagation of two-qubit errors across ideal single-qubit gates.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (38)

  1. A. Montanaro, Quantum algorithms: An overview, npj Quantum Inf. 2, 15023 (2016).
  2. J. Preskill, Quantum computing in the NISQ era and beyond, Quantum 2, 79 (2018).
  3. A. K. Fedorov, N. Gisin, S. M. Beloussov, and A. I. Lvovsky, Quantum computing at the quantum advantage threshold: A down-to-business review, arXiv:2203.17181.
  4. P. W. Shor, Scheme for reducing decoherence in quantum computer memory, Phys. Rev. A 52, R2493 (1995).
  5. A. R. Calderbank and P. W. Shor, Good quantum error-correcting codes exist, Phys. Rev. A 54, 1098 (1996).
  6. A. Steane, Multiple-particle interference and quantum error correction, Proc. R. Soc. London Ser. A 452, 2551 (1996).
  7. R. Raussendorf, Key ideas in quantum error correction, Philos. Trans. R. Soc. A 370, 4541 (2012).
  8. E. T. Campbell, B. M. Terhal, and C. Vuillot, Roads towards fault-tolerant universal quantum computation, Nature (London) 549, 172 (2017).
  9. S. M. Girvin, Introduction to quantum error correction and fault tolerance, SciPost Phys. Lect. Notes 70 (2023).
  10. I. Georgescu, 25 years of quantum error correction, Nat. Rev. Phys. 2, 519 (2020).
  11. J. J. Wallman and J. Emerson, Noise tailoring for scalable quantum computation via randomized compiling, Phys. Rev. A 94, 052325 (2016).
  12. Y. Ma, M. Hanks, and M. S. Kim, Non-Pauli errors can be efficiently sampled in qudit surface codes, Phys. Rev. Lett. 131, 200602 (2023).
  13. A. G. Fowler, M. Mariantoni, J. M. Martinis, and A. N. Cleland, Surface codes: Towards practical large-scale quantum computation, Phys. Rev. A 86, 032324 (2012).
  14. P. W. Shor, Fault-tolerant quantum computation, in Proceedings of 37th Conference on Foundations of Computer Science (IEEE, Burlington, VT, USA, 1996), pp. 56–65.
  15. C. J. Trout, M. Li, M. Gutiérrez, Y. Wu, S.-T. Wang, L. Duan, and K. R. Brown, Simulating the performance of a distance-3 surface code in a linear ion trap, New J. Phys. 20, 043038 (2018).
  16. D. M. Debroy, M. Li, S. Huang, and K. R. Brown, Logical performance of 9 qubit compass codes in ion traps with crosstalk errors, Quantum Sci. Technol. 5, 034002 (2020).
  17. Z. Cai, R. Babbush, S. C. Benjamin, S. Endo, W. J. Huggins, Y. Li, J. R. McClean, and T. E. O'Brien, Quantum error mitigation, Rev. Mod. Phys. 95, 045005 (2023).
  18. J. D. Guimarães, J. Lim, M. I. Vasilevskiy, S. F. Huelga, and M. B. Plenio, Noise-assisted digital quantum simulation of open systems using partial probabilistic error cancellation, PRX Quantum 4, 040329 (2023).
  19. Y. Ma and M. S. Kim, Limitations of probabilistic error cancellation for open dynamics beyond sampling overhead, Phys. Rev. A 109, 012431 (2024).
  20. J. Leppäkangas, N. Vogt, K. R. Fratus, K. Bark, J. A. Vaitkus, P. Stadler, J.-M. Reiner, S. Zanker, and M. Marthaler, Quantum algorithm for solving open-system dynamics on quantum computers using noise, Phys. Rev. A 108, 062424 (2023).
  21. C. Bertrand, P. Besserve, M. Ferrero, and T. Ayral, Turning qubit noise into a blessing: Automatic state preparation and long-time dynamics for impurity models on quantum computers, Phys. Rev. B 111, 245159 (2025).
  22. A. Sørensen and K. Mølmer, Entanglement and quantum computation with ions in thermal motion, Phys. Rev. A 62, 022311 (2000).
  23. K. Mølmer and A. Sørensen, Multiparticle entanglement of hot trapped ions, Phys. Rev. Lett. 82, 1835 (1999).
  24. Y. Ma, M. C. Pace, and M. S. Kim, Unifying the Sørensen-Mølmer gate and the Milburn gate with an optomechanical example, Phys. Rev. A 106, 012605 (2022).
  25. Y. Wang, S. Crain, C. Fang, B. Zhang, S. Huang, Q. Liang, P. H. Leung, K. R. Brown, and J. Kim, High-fidelity two-qubit gates using a microelectromechanical-system-based beam steering system for individual qubit addressing, Phys. Rev. Lett. 125, 150505 (2020).
  26. C. Fang, Y. Wang, S. Huang, K. R. Brown, and J. Kim, Crosstalk suppression in individually addressed two-qubit gates in a trapped-ion quantum computer, Phys. Rev. Lett. 129, 240504 (2022).
  27. M. Kang, Y. Wang, C. Fang, B. Zhang, O. Khosravani, J. Kim, and K. R. Brown, Designing filter functions of frequency-modulated pulses for high-fidelity two-qubit gates in ion chains, Phys. Rev. Appl. 19, 014014 (2023).
  28. T. Lubinski, S. Johri, P. Varosy, J. Coleman, L. Zhao, J. Necaise, C. H. Baldwin, K. Mayer, and T. Proctor, Application-oriented performance benchmarks for quantum computing, IEEE Trans. Quantum Eng. 4, 1 (2023).
  29. K. Sun, M. Kang, H. Nuomin, G. Schwartz, D. N. Beratan, K. R. Brown, and J. Kim, Quantum simulation of spin-boson models with structured bath, Nat. Commun. 16, 4042 (2025).
  30. D. Maslov, Basic circuit compilation techniques for an ion-trap quantum machine, New J. Phys. 19, 023035 (2017).
  31. Getting started with native gates, https://ionq.com/docs/getting-started-with-native-gates, accessed 21 May 2024.
  32. C. Monroe, W. C. Campbell, L.-M. Duan, Z.-X. Gong, A. V. Gorshkov, P. W. Hess, R. Islam, K. Kim, N. M. Linke, G. Pagano et al., Programmable quantum simulations of spin systems with trapped ions, Rev. Mod. Phys. 93, 025001 (2021).
  33. M. Foss-Feig, G. Pagano, A. C. Potter, and N. Y. Yao, Progress in trapped-ion quantum simulation, Annu. Rev. Condens. Matter Phys. 16 (2024).
  34. Y. Nam, J.-S. Chen, N. C. Pisenti, K. Wright, C. Delaney, D. Maslov, K. R. Brown, S. Allen, J. M. Amini, J. Apisdorf et al., Ground-state energy estimation of the water molecule on a trapped-ion quantum computer, npj Quantum Inf. 6, 33 (2020).
  35. K. Wright, K. M. Beck, S. Debnath, J. Amini, Y. Nam, N. Grzesiak, J.-S. Chen, N. Pisenti, M. Chmielewski, C. Collins et al., Benchmarking an 11-qubit quantum computer, Nat. Commun. 10, 5464 (2019).
  36. See Supplemental Material at http://link.aps.org/supplemental/10.1103/16gx-m7kg for the technical details of using the IonQ Aria-1 quantum device, and the reshaping of noise with the three-qubit bit-flip repetition code on a superconducting qubit quantum device, the IQM Garnet.
  37. braket.circuits.gate module, https://amazon-braket-sdk-python.readthedocs.io/en/latest/_apidoc/braket.circuits.html, accessed 21 May 2024.
  38. E. B. Wilson, Probable inference, the law of succession, and statistical inference, J. Am. Stat. Assoc. 22, 209 (1927).
