Bistability and charge-density blowup in the onset of drop Quincke rotation

Gunnar G. Peng1 and Ory Schnitzer2

PDF

Phys. Rev. Fluids 10, L081701 – Published 12 August, 2025

DOI: https://doi.org/10.1103/t3m2-8295

Abstract

Particles in a sufficiently strong electric field spontaneously rotate, provided that charge relaxation is slower in the particle than in the suspending fluid. It has long been known that drops also exhibit such “Quincke rotation,” with the electrohydrodynamic flow induced by electrical shear stresses at the interface leading to an increased critical field. However, the hysteretic onset of this instability, observed for sufficiently low-viscosity drops, has so far eluded theoretical understanding—including simulations that have struggled in this regime owing to charge-density steepening driven by surface convection. Here, we conduct a numerical study of the leaky-dielectric model in a simplified two-dimensional setting involving a circular drop, considering arbitrary viscosity ratios and field strengths. As the viscosity of the drop is decreased relative to the suspending fluid, the pitchfork bifurcation marking the onset of drop rotation is found to transition from supercritical to subcritical, giving rise to a field-strength interval of bistability. In this subcritical regime, the critical field is always large enough that, at the bifurcation, the symmetric base-state solution exhibits equatorial charge-density blowup singularities of the type recently described by Peng et al. [Phys. Rev. Fluids 9, 083701 (2024)]. As the rotation speed increases along the initially unstable solution branch from the bifurcation, the singularities gradually shift from the equator and ultimately disperse once the rotational component of the flow is strong enough to eliminate the surface stagnation points.

View figure in article

Physics Subject Headings (PhySH)

Article Text

Supplemental Material

References (45)

  1. G. Quincke, Ueber rotationen im constanten electrischen felde, Ann. Phys. (NY) 295, 417 (1896).
  2. J. R. Melcher and G. I. Taylor, Electrohydrodynamics: A review of the role of interfacial shear stresses, Annu. Rev. Fluid Mech. 1, 111 (1969).
  3. T. B. Jones, Quincke rotation of spheres, IEEE Trans. Ind. Appl. IA-20, 845 (1984).
  4. L. Lobry and E. Lemaire, Viscosity decrease induced by a dc electric field in a suspension, J. Electrost. 47, 61 (1999).
  5. A. Cēbers, Bistability and “negative” viscosity for a suspension of insulating particles in an electric field, Phys. Rev. Lett. 92, 034501 (2004).
  6. N. Pannacci, E. Lemaire, and L. Lobry, Rheology and structure of a suspension of particles subjected to Quincke rotation, Rheol Acta 46, 899 (2007).
  7. N. Pannacci, L. Lobry, and E. Lemaire, How insulating particles increase the conductivity of a suspension, Phys. Rev. Lett. 99, 094503 (2007).
  8. E. Lemaire, L. Lobry, N. Pannacci, and F. Peters, Viscosity of an electro-rheological suspension with internal rotations, J. Rheol. 52, 769 (2008).
  9. A. Bricard, J. Caussin, N. Desreumaux, O. Dauchot, and D. Bartolo, Emergence of macroscopic directed motion in populations of motile colloids, Nature (London) 503, 95 (2013).
  10. D. Das and D. Saintillan, Electrohydrodynamic interaction of spherical particles under Quincke rotation, Phys. Rev. E 87, 043014 (2013).
  11. G. E. Pradillo, H. Karani, and P. M. Vlahovska, Quincke rotor dynamics in confinement: Rolling and hovering, Soft Matter 15, 6564 (2019).
  12. D. Das and E. Lauga, Active particles powered by Quincke rotation in a bulk fluid, Phys. Rev. Lett. 122, 194503 (2019).
  13. M. Belovs and A. Cēbers, Quincke rotation driven flows, Phys. Rev. Fluids 5, 013701 (2020).
  14. G. Kokot, H. A. Faizi, G. E. Pradillo, A. Snezhko, and P. M. Vlahovska, Spontaneous self-propulsion and nonequilibrium shape fluctuations of a droplet enclosing active particles, Commrm. Phys. 5, 91 (2022).
  15. D. Das and D. Saintillan, On the absence of collective motion in a bulk suspension of spontaneously rotating dielectric particles, Soft Matter 19, 6825 (2023).
  16. A. Cēbers, E. Lemaire, and L. Lobry, Electrohydrodynamic instabilities and orientation of dielectric ellipsoids in low-conducting fluids, Phys. Rev. E 63, 016301 (2000).
  17. E. Lemaire and L. Lobry, Chaotic behavior in electro-rotation, Physica A 314, 663 (2002).
  18. F. Peters, L. Lobry, and E. Lemaire, Experimental observation of Lorenz chaos in the Quincke rotor dynamics, Chaos 15, 013102 (2005).
  19. J. K. Kabarowski, A. S. Khair, and R. N. Valani, Hydrodynamic memory and Quincke rotation, arXiv:2503.03420.
  20. S. Krause and P. Chandratreya, Electrorotation of deformable fluid droplets, J. Colloid Interface Sci. 206, 10 (1998).
  21. J.-W. Ha and S.-M. Yang, Electrohydrodynamics and electrorotation of a drop with fluid less conductive than that of the ambient fluid, Phys. Fluids 12, 764 (2000).
  22. P. F. Salipante and P. M. Vlahovska, Electrohydrodynamics of drops in strong uniform dc electric fields, Phys. Fluids 22, 112110 (2010).
  23. P. F. Salipante and P. M. Vlahovska, Electrohydrodynamic rotations of a viscous droplet, Phys. Rev. E 88, 043003 (2013).
  24. M. Ouriemi and P. M. Vlahovska, Electrohydrodynamic deformation and rotation of a particle-coated drop, Langmuir 31, 6298 (2015).
  25. G. Raju, N. Kyriakopoulos, and J. V. I. Timonen, Diversity of non-equilibrium patterns and emergence of activity in confined electrohydrodynamically driven liquids, Sci. Adv. 7, eabh1642 (2021).
  26. D. Das and D. Saintillan, Electrohydrodynamics of viscous drops in strong electric fields: Numerical simulations, J. Fluid Mech. 829, 127 (2017).
  27. M. Firouznia, S. H. Bryngelson, and D. Saintillan, A spectral boundary integral method for simulating electrohydrodynamic flows in viscous drops, J. Comput. Phys. 489, 112248 (2023).
  28. H. He, P. F. Salipante, and P. M. Vlahovska, Electrorotation of a viscous droplet in a uniform direct current electric field, Phys. Fluids 25, 032106 (2013).
  29. D. Das and D. Saintillan, A nonlinear small-deformation theory for transient droplet electrohydrodynamics, J. Fluid Mech. 810, 225 (2017).
  30. D. Das and D. Saintillan, A three-dimensional small-deformation theory for electrohydrodynamics of dielectric drops, J. Fluid Mech. 914, A22 (2021).
  31. J. A. Lanauze, L. M. Walker, and A. S. Khair, Nonlinear electrohydrodynamics of slightly deformed oblate drops, J. Fluid Mech. 774, 245 (2015).
  32. G. Taylor, Studies in electrohydrodynamics. I. The circulation produced in a drop by electrical field, Proc. R. Soc. London A 291, 159 (1966).
  33. M. Firouznia, M. J. Miksis, P. M. Vlahovska, and D. Saintillan, Instability of a planar fluid interface under a tangential electric field in a stagnation point flow, J. Fluid Mech. 931, A25 (2022).
  34. G. G. Peng, R. Brandao, E. Yariv, and O. Schnitzer, Equatorial blowup and polar caps in drop electroohydrodynamics, Phys. Rev. Fluids 9, 083701 (2024).
  35. J. Q. Feng, A 2D electrohydrodynamic model for electrorotation of fluid drops, J. Colloid Interface Sci. 246, 112 (2002).
  36. E. Yariv and I. Frankel, Electrohydrodynamic rotation of drops at large electric Reynolds numbers, J. Fluid Mech. 788, R2 (2016).
  37. See Supplemental Material at http://link.aps.org/supplemental/10.1103/t3m2-8295 for details regarding (i) the problem formulation, including integral relations, symmetries and reflection properties; (ii) the weak-field approximation; (iii) the numerical approach, including a derivation of an integral formulation of the problem; (iv) the double-fold transition region; and (v) the unstable translational-rotational states.
  38. D. A. Saville, Electrohydrodynamics: The Taylor–Melcher leaky dielectric model, Annu. Rev. Fluid Mech. 29, 27 (1997).
  39. O. Schnitzer and E. Yariv, The Taylor–Melcher leaky dielectric model as a macroscale electrokinetic description, J. Fluid Mech. 773, 1 (2015).
  40. Y. Mori and Y.-N. Young, From electrodiffusion theory to the electrohydrodynamics of leaky dielectrics through the weak electrolyte limit, J. Fluid Mech. 855, 67 (2018).
  41. M. Ma, M. R. Booty, and M. Siegel, A model for the electric field-driven flow and deformation of a drop or vesicle in strong electrolyte solutions, J. Fluid Mech. 943, A47 (2022).
  42. W. V. R. Malkus and G. Veronis, Surface electroconvection, Phys. Fluids 4, 13 (1961).
  43. D. C. Jolly and J. R. Melcher, Electroconvective instability in a fluid layer, Proc. R. Soc. London A 314, 269 (1970).
  44. M. Ouriemi and P. M. Vlahovska, Electrohydrodynamics of particle-covered drops, J. Fluid Mech. 751, 106 (2014).
  45. Q. Dong and A. Sau, Unsteady electrorotation of a viscous drop in a uniform electric field, Phys. Fluids 35, 047116 (2023).
