Effect of hyperdiffusion on rotating Rayleigh-Bénard convection

B. Davy*

C. J. Davies and J. E. Mound

S. M. Tobias

  • EPSRC Centre for Doctoral Training in Fluid Dynamics, University of Leeds, Leeds LS2 9JT, United Kingdom

  • *Contact author: scbd@leeds.ac.uk
PDF

Phys. Rev. Fluids 11, 013502 – Published 8 January, 2026

DOI: https://doi.org/10.1103/jvgr-d2mw

Abstract

We analyze the effect of a scale-dependent horizontal hyperdiffusivity in rotating Rayleigh-Bénard convection. The hyperdiffusion (HD) is parametrized by a cutoff wave number k0 and a growth rate q to limit its effects to the smaller scales, enabling simulations to be conducted at more rapid rotation rates and buoyancy forcing (as measured by the Ekman number Ek and Rayleigh number Ra, respectively) than in conventional direct numerical simulations (DNSs). We have performed 107 simulations spanning the ranges E=10−4--10−7 and Ra=106--7×1010 and directly compared HD and DNS heat transfer (measured by the Nusselt number Nu), flow speeds (quantified by the Péclet number Pe), force balances, and boundary layer thicknesses. We identify two different effects of HD that are particularly clear when k0 is below the dominant scale of the flow k⊥: At low supercriticality Rã, Nu, and Pe are increased compared to DNS due to a weakening of the rotational constraint; at high Rã, Nu and Pe are decreased compared to DNS owing to suppression of energy at scales greater than k⊥. The thermal boundary layer thickness changes in proportion to Nu, while the mechanical boundary layer thickness is marginally affected because it is determined by a vertical balance, whereas HD is applied horizontally. Heat transfer diagnostics are more strongly affected by HD than flow diagnostics, while changing k0 has a greater impact on solution behavior than changing q over the range of values studied. For all HD simulations with k0≥3k⊥, all diagnostics remain within the standard deviation of the DNS.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (62)

  1. G. A. Glatzmaier, Computer simulations of Jupiter's deep internal dynamics help interpret what Juno sees, Proc. Natl. Acad. Sci. USA 115, 6896 (2018).
  2. G. A. Glatzmaier and P. H. Roberts, A three-dimensional convective dynamo solution with rotating and finitely conducting inner core and mantle, Phys. Earth Planet. Inter. 91, 63 (1995).
  3. M. Heimpel, J. Aurnou, and J. Wicht, Simulation of equatorial and high-latitude jets on Jupiter in a deep convection model, Nature (London) 438, 193 (2005).
  4. H. Jones and J. Marshall, Convection with rotation in a neutral ocean: A study of open-ocean deep convection, J. Phys. Oceanogr. 23, 1009 (1993).
  5. G. I. Taylor, Experiments with rotating fluids, Proc. R. Soc. London Ser. A 100, 114 (1921).
  6. J. Proudman, On the motion of solids in a liquid possessing vorticity, Proc. R. Soc. London Ser. A 92, 408 (1916).
  7. S. Braginsky and V. Meytlis, Local turbulence in the earth's core, Geophys. Astrophys. Fluid Dyn. 55, 71 (1990).
  8. C. J. Davies, D. Gubbins, and P. K. Jimack, Scalability of pseudospectral methods for geodynamo simulations, Concurrency Comput. Pract. Exper. 23, 38 (2011).
  9. N. Schaeffer, D. Jault, H. C. Nataf, and A. Fournier, Turbulent geodynamo simulations: A leap towards earth's core, Geophys. J. Int. 211, 1 (2017).
  10. T. Schwaiger, T. Gastine, and J. Aubert, Force balance in numerical geodynamo simulations: A systematic study, Geophys. J. Int. 219, S101 (2019).
  11. J. E. Mound and C. J. Davies, Longitudinal structure of earth's magnetic field controlled by lower mantle heat flow, Nat. Geosci. 16, 380 (2023).
  12. H.-C. Nataf and N. Schaeffer, Turbulence in the core, in Treatise on Geophysics, 2nd ed., edited by G. Schubert (Elsevier, Amsterdam, 2015), Vol. 8, pp. 161–181.
  13. J. Aubert, Approaching earth's core conditions in high-resolution geodynamo simulations, Geophys. J. Int. 219, S137 (2019).
  14. M. Lesieur, O. Métais, and P. Comte, Large-Eddy Simulations of Turbulence (Cambridge University Press, Cambridge, 2005).
  15. Y. Shirian and A. Mani, Eddy diffusivity operator in homogeneous isotropic turbulence, Phys. Rev. Fluids 7, L052601 (2022).
  16. M. Hammond and D. S. Abbot, Numerical dissipation strongly affects the equatorial jet speed in simulations of hot Jupiter atmospheres, Mon. Not. R. Astron. Soc. 511, 2313 (2022).
  17. E. Grote, F. H. Busse, and A. Tilgner, Effects of hyperdiffusivities on dynamo simulations, Geophys. Res. Lett. 27, 2001 (2000).
  18. K. Zhang and C. A. Jones, The effect of hyperviscosity on geodynamo models, Geophys. Res. Lett. 24, 2869 (1997).
  19. J. Aubert, T. Gastine, and A. Fournier, Spherical convective dynamos in the rapidly rotating asymptotic regime, J. Fluid Mech. 813, 558 (2017).
  20. B. A. Buffett, A comparison of subgrid-scale models for large-eddy simulations of convection in the earth's core, Geophys. J. Int. 153, 753 (2003).
  21. M. Germano, A proposal for a redefinition of the turbulent stresses in the filtered Navier–Stokes equations, Phys. Fluids 29, 2323 (1986).
  22. H. Matsui and B. Buffett, Sub-grid scale model for dynamo simulations in a rotating plane layer model—Dealing with unstructured grids, in AGU Fall Meeting Abstracts (AGU, Washington, DC, 2005), Vol. 2005, pp. GP31A–0083.
  23. H. Matsui and B. A. Buffett, Commutation error correction for large eddy simulations of convection driven dynamos, Geophys. Astrophys. Fluid Dyn. 101, 429 (2007).
  24. H. Matsui and B. A. Buffett, A dynamic scale-similarity model for dynamo simulations in a rotating plane layer, Geophys. Astrophys. Fluid Dyn. 101, 451 (2007).
  25. H. Matsui and B. A. Buffett, Large-eddy simulations of convection-driven dynamos using a dynamic scale-similarity model, Geophys. Astrophys. Fluid Dyn. 106, 250 (2012).
  26. J. Boussinesq, Théorie Analytique de la Chaleur: Mise en Harmonie avec la Thermodynamique et avec la Théorie Mécanique de la Lumière (Gauthier-Villars, Paris, 1903), Vol. 2.
  27. G. Ahlers, S. Grossmann, and D. Lohse, Heat transfer and large scale dynamics in turbulent Rayleigh-Bénard convection, Rev. Mod. Phys. 81, 503 (2009).
  28. K. Julien, E. Knobloch, A. M. Rubio, and G. M. Vasil, Heat transport in low-Rossby-number Rayleigh-Bénard convection, Phys. Rev. Lett. 109, 254503 (2012).
  29. P. A. Gilman, Nonlinear dynamics of Boussinesq convection in a deep rotating spherical shell-I, Geophys. Astrophys. Fluid Dyn. 8, 93 (1977).
  30. T. Gastine, J. Wicht, and J. Aubert, Scaling regimes in spherical shell rotating convection, J. Fluid Mech. 808, 690 (2016).
  31. R. S. Long, J. E. Mound, C. J. Davies, and S. M. Tobias, Thermal boundary layer structure in convection with and without rotation, Phys. Rev. Fluids 5, 113502 (2020).
  32. R. E. Ecke and O. Shishkina, Turbulent rotating Rayleigh–Bénard convection, Annu. Rev. Fluid Mech. 55, 603 (2023).
  33. S. Chandrasekhar, The instability of a layer of fluid heated below and subject to Coriolis forces, Proc. R. Soc. London A 217, 306 (1953).
  34. R. P. J. Kunnen, B. J. Geurts, and H. J. H. Clercx, Experimental and numerical investigation of turbulent convection in a rotating cylinder, J. Fluid Mech. 642, 445 (2010).
  35. A. J. Aguirre Guzmán, M. Madonia, J. S. Cheng, R. Ostilla-Mónico, H. J. H. Clercx, and R. P. J. Kunnen, Force balance in rapidly rotating Rayleigh–Bénard convection, J. Fluid Mech. 928, A16 (2021).
  36. J. S. Cheng, S. Stellmach, A. Ribeiro, A. Grannan, E. M. King, and J. M. Aurnou, Laboratory-numerical models of rapidly rotating convection in planetary cores, Geophys. J. Int. 201, 1 (2015).
  37. J. S. Cheng, M. Madonia, A. J. Aguirre Guzmán, and R. P. J. Kunnen, Laboratory exploration of heat transfer regimes in rapidly rotating turbulent convection, Phys. Rev. Fluids 5, 113501 (2020).
  38. M. Sprague, K. Julien, E. Knobloch, and J. Werne, Numerical simulation of an asymptotically reduced system for rotationally constrained convection, J. Fluid Mech. 551, 141 (2006).
  39. S. Maffei, M. J. Krouss, K. Julien, and M. A. Calkins, On the inverse cascade and flow speed scaling behavior in rapidly rotating Rayleigh–Bénard convection, J. Fluid Mech. 913, A18 (2021).
  40. J. M. Aurnou, S. Horn, and K. Julien, Connections between nonrotating, slowly rotating, and rapidly rotating turbulent convection transport scalings, Phys. Rev. Res. 2, 043115 (2020).
  41. J. Song, O. Shishkina, and X. Zhu, Scaling regimes in rapidly rotating thermal convection at extreme Rayleigh numbers, J. Fluid Mech. 984, A45 (2024).
  42. H. P. Greenspan, The Theory of Rotating Fluids (Cambridge University Press, Cambridge, 1968).
  43. E. M. King, S. Stellmach, and J. M. Aurnou, Heat transfer by rapidly rotating Rayleigh–Bénard convection, J. Fluid Mech. 691, 568 (2012).
  44. E. M. King, K. M. Soderlund, U. R. Christensen, J. Wicht, and J. M. Aurnou, Convective heat transfer in planetary dynamo models, Geochem. Geophys. Geosyst. 11, Q06016 (2010).
  45. K. M. Soderlund, A. Sheyko, E. M. King, and J. M. Aurnou, The competition between Lorentz and Coriolis forces in planetary dynamos, Prog. Earth Planet. Sci. 2, 24 (2015).
  46. W. Kuang, B. Chao, and J. Chen, Decadal polar motion of the earth excited by the convective outer core from geodynamo simulations, J. Geophys. Res.: Solid Earth 122, 8459 (2017).
  47. C. Dong, H. Zhang, L. Jiao, H. Cheng, D. A. Yuen, and Y. Shi, The non-negligible effect of viscosity diffusion on the geodynamo process, J. Geophys. Res.: Solid Earth 126, e2020JB021281 (2021).
  48. J. Aubert, State and evolution of the geodynamo from numerical models reaching the physical conditions of earth's core, Geophys. J. Int. 235, 468 (2023).
  49. O. Barrois, T. Gastine, and C. C. Finlay, Quasi-geostrophic convection-driven dynamos in a thick spherical shell, Geophys. J. Int. 236, 1373 (2024).
  50. A. Oberbeck, Über die wärmeleitung der flüssigkeiten bei berücksichtigung der strömungen infolge von temperaturdifferenzen, Ann. Phys. (Leipzig) 243, 271 (1879).
  51. K. J. Burns, G. M. Vasil, J. S. Oishi, D. Lecoanet, and B. P. Brown, Dedalus: A flexible framework for numerical simulations with spectral methods, Phys. Rev. Res. 2, 023068 (2020).
  52. A. Tilgner, A. Belmonte, and A. Libchaber, Temperature and velocity profiles of turbulent convection in water, Phys. Rev. E 47, R2253 (1993).
  53. A. Belmonte, A. Tilgner, and A. Libchaber, Temperature and velocity boundary layers in turbulent convection, Phys. Rev. E 50, 269 (1994).
  54. B. I. Shraiman and E. D. Siggia, Heat transport in high-Rayleigh-number convection, Phys. Rev. A 42, 3650 (1990).
  55. D. W. Hughes and F. Cattaneo, Force balance in convectively driven dynamos with no inertia, J. Fluid Mech. 879, 793 (2019).
  56. E. Dormy, Strong-field spherical dynamos, J. Fluid Mech. 789, 500 (2016).
  57. R. J. Teed and E. Dormy, Solenoidal force balances in numerical dynamos, J. Fluid Mech. 964, A26 (2023).
  58. E. King, S. Stellmach, and B. Buffett, Scaling behavior in Rayleigh–Bénard convection with and without rotation, J. Fluid Mech. 717, 449 (2013).
  59. D. J. Stevenson, Turbulent thermal convection in the presence of rotation and a magnetic field: A heuristic theory, Geophys. Astrophys. Fluid Dyn. 12, 139 (1979).
  60. S. Grossmann and D. Lohse, Scaling in thermal convection: A unifying theory, J. Fluid Mech. 407, 27 (2000).
  61. M. Madonia, A. J. Aguirre Guzmán, H. J. Clercx, and R. P. Kunnen, Reynolds number scaling and energy spectra in geostrophic convection, J. Fluid Mech. 962, A36 (2023).
  62. W. V. R. Malkus, The heat transport and spectrum of thermal turbulence, Proc. R. Soc. London Ser. A 225, 196 (1954).
