Bubble dynamics in complex fluids

Valeria Garbin*

  • *Contact author: v.garbin@tudelft.nl
PDF

Phys. Rev. Fluids 11, 010502 – Published 7 January, 2026

DOI: https://doi.org/10.1103/hj5m-fcvt

Abstract

The field of bubble dynamics and cavitation, motivated initially by applications in underwater acoustics and later in biomedical ultrasound, continues to evolve. This article describes the recent focus and ongoing developments in understanding and utilizing bubble dynamics in complex fluids. An introductory overview is given of the phenomena of spherical bubble dynamics in complex fluids. The emerging interest in using bubble dynamics to probe high-frequency viscoelastic properties of complex fluids is then highlighted. This interest is motivated by the fact that timescales as short as 10−6s can be probed, comparable to the relaxation timescales for complex fluids containing suspended particles or macromolecules. The focus of the article then shifts to specific examples from my research group. First, I present our work on linear rheology of soft solids using ultrasound-driven bubbles. I then discuss how the deformation and flow fields generated by acoustically driven bubbles can modify the microstructure and properties of complex fluids, bearing potential for bubble removal from yield-stress fluids. Finally, I describe our observations of self-assembly of locally ordered microstructures in complex fluids driven by bubble dynamics. In closing, I discuss the growing synergy between the communities of cavitation and rheology, which will be instrumental to address new challenges in the characterization and manipulation of complex fluids.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (65)

  1. B. Browne and L. Szramek, Rates of magma ascent and storage, in The Encyclopedia of Volcanoes 2nd ed., edited by H. Sigurdsson (Academic Press, 2015), pp. 203–214.
  2. O. Vincent, Negative pressure and cavitation dynamics in plantlike structures, in Soft Matter in Plants: From Biophysics to Biomimetics, edited by K. Jensen and Y. Forterre (Royal Society of Chemistry, London, 2022), pp. 119–164.
  3. T. Faez, M. Emmer, K. Kooiman, M. Versluis, A. F. van der Steen, and N. de Jong, 20 years of ultrasound contrast agent modeling, IEEE Trans. Ultrason. Ferroelectr. Freq. Control 60, 7 (2012).
  4. C. C. Coussios and R. A. Roy, Applications of acoustics and cavitation to noninvasive therapy and drug delivery, Annu. Rev. Fluid Mech. 40, 395 (2008).
  5. J. Blackmore, S. Shrivastava, J. Sallet, C. R. Butler, and R. O. Cleveland, Ultrasound neuromodulation: A review of results, mechanisms and safety, Ultrasound Med. Biol. 45, 1509 (2019).
  6. G. Astarita and G. Apuzzo, Motion of gas bubbles in non-Newtonian liquids, AIChE J. 11, 815 (1965).
  7. G. Pagani, M. J. Green, P. Poulin, and M. Pasquali, Competing mechanisms and scaling laws for carbon nanotube scission by ultrasonication, Proc. Natl. Acad. Sci. USA 109, 11599 (2012).
  8. B. Dollet, P. Marmottant, and V. Garbin, Bubble dynamics in soft and biological matter, Annu. Rev. Fluid Mech. 51, 331 (2019).
  9. H. Cochard and S. Delzon, Hydraulic failure and repair are not routine in trees, Ann. For. Sci. 70, 659 (2013).
  10. J. J. Choi, K. Selert, F. Vlachos, A. Wong, and E. E. Konofagou, Noninvasive and localized neuronal delivery using short ultrasonic pulses and microbubbles, Proc. Natl. Acad. Sci. USA 108, 16539 (2011).
  11. V. G. Krishnan, L. Fiorucci, A. Sarbu, and W. Drenckhan-Andreatta, Characterizing the foaming process of polymers: Review of experimental methods, Adv. Colloid and Interface Science 344, 103579 (2025).
  12. A. Lucas, C. Zakri, M. Maugey, M. Pasquali, P. van der Schoot, and P. Poulin, Kinetics of nanotube and microfiber scission under sonication, J. Phys. Chem. C 113, 20599 (2009).
  13. M. S. Plesset and A. Prosperetti, Bubble dynamics and cavitation, Annu. Rev. Fluid Mech. 9, 145 (1977).
  14. Rayleigh, On the pressure developed in a liquid during the collapse of a spherical cavity, London, Edinburgh, Dublin Philos. Mag. J. Sci. 34, 94 (1917).
  15. M. P. Brenner, S. Hilgenfeldt, and D. Lohse, Single-bubble sonoluminescence, Rev. Mod. Phys. 74, 425 (2002).
  16. A. Prosperetti, Thermal effects and damping mechanisms in the forced radial oscillations of gas bubbles in liquids, J. Acoust. Soc. Am. 61, 17 (1977).
  17. A. Prosperetti, A generalization of the Rayleigh–Plesset equation of bubble dynamics, Phys. Fluids 25, 409 (1982).
  18. R. G. Larson, The Structure and Rheology of Complex Fluids (Oxford University Press, Oxford, 1999).
  19. C. W. Macosko, Rheology: Principles, Measurements and Applications (Wiley-VCH New York, 1994).
  20. H. S. Fogler and J. D. Goddard, Collapse of spherical cavities in viscoelastic fluids, Phys. Fluids 13, 1135 (1970).
  21. C. C. Church, The effects of an elastic solid surface layer on the radial pulsations of gas bubbles, J. Acoust. Soc. Am. 97, 1510 (1995).
  22. C. Hua and E. Johnsen, Nonlinear oscillations following the Rayleigh collapse of a gas bubble in a linear viscoelastic (tissue-like) medium, Phys. Fluids 25, 083101 (2013).
  23. J. S. Allen and R. A. Roy, Dynamics of gas bubbles in viscoelastic fluids. II. Nonlinear viscoelasticity, J. Acoust. Soc. Am. 108, 1640 (2000).
  24. J. Jiménez-Fernández and A. Crespo, Bubble oscillation and inertial cavitation in viscoelastic fluids, Ultrasonics 43, 643 (2005).
  25. J. Naude and F. Méndez, Periodic and chaotic acoustic oscillations of a bubble gas immersed in an upper convective maxwell fluid, J. Non-Newtonian Fluid Mech. 155, 30 (2008).
  26. M. T. Warnez and E. Johnsen, Numerical modeling of bubble dynamics in viscoelastic media with relaxation, Phys. Fluids 27, 063103 (2015).
  27. R. Gaudron, M. T. Warnez, and E. Johnsen, Bubble dynamics in a viscoelastic medium with nonlinear elasticity, J. Fluid Mech. 766, 54 (2015).
  28. A. T. Oratis, K. Dijs, G. Lajoinie, M. Versluis, and J. H. Snoeijer, A unifying Rayleigh-Plesset-type equation for bubbles in viscoelastic media, J. Acoust. Soc. Am. 155, 1593 (2024).
  29. B. Saint-Michel and V. Garbin, Bubble dynamics for broadband microrheology of complex fluids, Curr. Opin. Colloid Interface Sci. 50, 101392 (2020).
  30. P. S. Epstein and M. S. Plesset, On the stability of gas bubbles in liquid-gas solutions, J. Chem. Phys. 18, 1505 (1950).
  31. W. Kloek, T. Van Vliet, and M. Meinders, Effect of bulk and interfacial rheological properties on bubble dissolution, J. Colloid Interface Sci. 237, 158 (2001).
  32. J. B. Estrada, C. Barajas, D. L. Henann, E. Johnsen, and C. Franck, High strain-rate soft material characterization via inertial cavitation, J. Mech. Phys. Solids 112, 291 (2018).
  33. A. Jamburidze, M. De Corato, A. Huerre, A. Pommella, and V. Garbin, High-frequency linear rheology of hydrogels probed by ultrasound-driven microbubble dynamics, Soft Matter 13, 3946 (2017).
  34. K. Ando and E. Shirota, Quasistatic growth of bubbles in a gelatin gel under dissolved-gas supersaturation, Phys. Fluids 31, 111701 (2019).
  35. L. Mancia, J. Yang, J.-S. Spratt, J. R. Sukovich, Z. Xu, T. Colonius, C. Franck, and E. Johnsen, Acoustic cavitation rheometry, Soft Matter 17, 2931 (2021).
  36. J.-S. Spratt, M. Rodriguez, K. Schmidmayer, S. H. Bryngelson, J. Yang, C. Franck, and T. Colonius, Characterizing viscoelastic materials via ensemble-based data assimilation of bubble collapse observations, J. Mech. Phys. Solids 152, 104455 (2021).
  37. Z. Zhu, S. Remillard, B. A. Abeid, D. Frolkin, S. H. Bryngelson, J. Yang, M. Rodriguez, and J. B. Estrada, Parsimonious inertial cavitation rheometry via bubble collapse time, Soft Matter 21, 6717 (2025).
  38. S. M. van der Meer, B. Dollet, M. M. Voormolen, C. T. Chin, A. Bouakaz, N. de Jong, M. Versluis, and D. Lohse, Microbubble spectroscopy of ultrasound contrast agents, J. Acoust. Soc. Am. 121, 648 (2007).
  39. E. Hersey Jr., M. Rodriguez, and E. Johnsen, Dynamics of an oscillating microbubble in a blood-like carreau fluid, J. Acoust. Soc. Am. 153, 1836 (2023).
  40. A. van der Bos, M.-J. van der Meulen, T. Driessen, M. van den Berg, H. Reinten, H. Wijshoff, M. Versluis, and D. Lohse, Velocity profile inside piezoacoustic inkjet droplets in flight: Comparison between experiment and numerical simulation, Phys. Rev. Appl. 1, 014004 (2014).
  41. N. J. Balmforth, I. A. Frigaard, and G. Ovarlez, Yielding to stress: Recent developments in viscoplastic fluid mechanics, Annu. Rev. Fluid Mech. 46, 121 (2014).
  42. J. Tsamopoulos, Y. Dimakopoulos, N. Chatzidai, G. Karapetsas, and M. Pavlidis, Steady bubble rise and deformation in newtonian and viscoplastic fluids and conditions for bubble entrapment, J. Fluid Mech. 601, 123 (2008).
  43. M. Zare, M. Daneshi, and I. Frigaard, Effects of nonuniform rheology on the motion of bubbles in a yield-stress fluid, J. Fluid Mech. 919, A25 (2021).
  44. E. Chaparian and I. A. Frigaard, Clouds of bubbles in a viscoplastic fluid, J. Fluid Mech. 927, R3 (2021).
  45. M. Daneshi and I. A. Frigaard, Growth and static stability of bubble clouds in yield stress fluids, J. Non-Newtonian Fluid Mech. 327, 105217 (2024).
  46. M. De Corato, B. Saint-Michel, G. Makrigiorgos, Y. Dimakopoulos, J. Tsamopoulos, and V. Garbin, Oscillations of small bubbles and medium yielding in elastoviscoplastic fluids, Phys. Rev. Fluids 4, 073301 (2019).
  47. B. Saint-Michel and V. Garbin, Acoustic bubble dynamics in a yield-stress fluid, Soft Matter 16, 10405 (2020).
  48. G. Karapetsas, D. Photeinos, Y. Dimakopoulos, and J. Tsamopoulos, Dynamics and motion of a gas bubble in a viscoplastic medium under acoustic excitation, J. Fluid Mech. 865, 381 (2019).
  49. P. Saramito, A new elastoviscoplastic model based on the Herschel–Bulkley viscoplastic model, J. Non-Newtonian Fluid Mech. 158, 154 (2009).
  50. L. Martinie, H. Buggisch, and N. Willenbacher, Apparent elongational yield stress of soft matter, J. Rheol. 57, 627 (2013).
  51. K. Murakami, R. Gaudron, and E. Johnsen, Shape stability of a gas bubble in a soft solid, Ultrason. Sonochem. 67, 105170 (2020).
  52. A. Pourzahedi, M. Zare, and I. Frigaard, Eliminating injection and memory effects in bubble rise experiments within yield stress fluids, J. Non-Newtonian Fluid Mech. 292, 104531 (2021).
  53. N. Koumakis, E. Moghimi, R. Besseling, W. C. Poon, J. F. Brady, and G. Petekidis, Tuning colloidal gels by shear, Soft Matter 11, 4640 (2015).
  54. B. Saint-Michel, G. Petekidis, and V. Garbin, Tuning local microstructure of colloidal gels by ultrasound-activated deformable inclusions, Soft Matter 18, 2092 (2022).
  55. P. Marmottant and S. Hilgenfeldt, Controlled vesicle deformation and lysis by single oscillating bubbles, Nature (London) 423, 153 (2003).
  56. P. Marmottant, M. Versluis, N. De Jong, S. Hilgenfeldt, and D. Lohse, High-speed imaging of an ultrasound-driven bubble in contact with a wall: “Narcissus” effect and resolved acoustic streaming, Exp. Fluids 41, 147 (2006).
  57. R. Bolaños-Jiménez, M. Rossi, D. F. Rivas, C. J. Kähler, and A. Marin, Streaming flow by oscillating bubbles: Quantitative diagnostics via particle tracking velocimetry, J. Fluid Mech. 820, 529 (2017).
  58. F. Mekki-Berrada, T. Combriat, P. Thibault, and P. Marmottant, Interactions enhance the acoustic streaming around flattened microfluidic bubbles, J. Fluid Mech. 797, 851 (2016).
  59. K. W. Torre and J. de Graaf, Structuring colloidal gels via micro-bubble oscillations, Soft Matter 19, 2771 (2023).
  60. T. Gibaud, N. Dagès, P. Lidon, G. Jung, L. C. Ahouré, M. Sztucki, A. Poulesquen, N. Hengl, F. Pignon, and S. Manneville, Rheoacoustic gels: Tuning mechanical and flow properties of colloidal gels with ultrasonic vibrations, Phys. Rev. X 10, 011028 (2020).
  61. T. Chu, J. B. Estrada, and S. H. Bryngelson, Bayesian optimal design accelerates discovery of soft material properties from bubble dynamics, Comput. Mech. 76, 431 (2025).
  62. A. McGhee III, J. Yang, E. Bremer, Z. Xu, H. Cramer III, J. Estrada, and D. Henann, High-speed, full-field deformation measurements near inertial microcavitation bubbles inside viscoelastic hydrogels, Expt. Mech. 63, 63 (2023).
  63. J. Rapet, Y. Tagawa, and C.-D. Ohl, Shear-wave generation from cavitation in soft solids, Appl. Phys. Lett. 114, 123702 (2019).
  64. Y. Yokoyama, B. R. Mitchell, A. Nassiri, B. L. Kinsey, Y. P. Korkolis, and Y. Tagawa, Integrated photoelasticity in a soft material: Phase retardation, azimuthal angle, and stress-optic coefficient, Optics Lasers Eng. 161, 107335 (2023).
  65. G. T. Bokman, O. Supponen, and S. A. Mäkiharju, Cavitation bubble dynamics in a shear-thickening fluid, Phys. Rev. Fluids 7, 023302 (2022).

Outline

Information

Phys. Rev. Fluids 11, 010502– Published 7 January, 2026
  • Received 29 July 2025
  • Accepted 5 November 2025
Crossmark - Check for updates button
Creative Commons Logo

Published by the American Physical Society under the terms of the Creative Commons Attribution 4.0 International license. Further distribution of this work must maintain attribution to the author(s) and the published article's title, journal citation, and DOI.
