Mysterious case of an evaporating binary drop

Pim J. Dekker, Christian Diddens, and Detlef Lohse*

  • Physics of Fluids Group, Department of Science and Technology, Max Planck Center for Complex Fluid Dynamics and J. M. Burgers Centre for Fluid Dynamics, University of Twente, P.O. Box 217, 7500 AE Enschede, The Netherlands

  • *Also at Max Planck Institute for Dynamics and Self-Organization, Am Fassberg 17, 37077 Göttingen, Germany.
PDF

Phys. Rev. Fluids 10, 110508 – Published 20 November, 2025

DOI: https://doi.org/10.1103/7x22-wmmw

Abstract

This paper is associated with a video winner of a 2024 American Physical Society's Division of Fluid Dynamics (DFD) Milton van Dyke Award for work presented at the DFD Gallery of Fluid Motion. The original video is available online at the Gallery of Fluid Motion, https://doi.org/10.1103/APS.DFD.2024.GFM.V2685343

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (11)

  1. Y. Li, P. Lv, C. Diddens, H. Tan, H. Wijshoff, M. Versluis, and D. Lohse, Evaporation-triggered segregation of sessile binary droplets, Phys. Rev. Lett. 120, 224501 (2018).
  2. L. Thayyil Raju, C. Diddens, Y. Li, A. Marin, M. N. van der Linden, X. Zhang, and D. Lohse, Evaporation of a sessile colloidal water–glycerol droplet: Marangoni ring formation, Langmuir 38, 12082 (2022).
  3. D. Dragoescu, F. Sirbu, and L. Almásy, Study of the thermophysical properties for aqueous alkanediols binary mixtures, J. Mol. Liq. 335, 116150 (2021).
  4. R. A. L. De La Cruz, C. Diddens, X. Zhang, and D. Lohse, Marangoni instability triggered by selective evaporation of a binary liquid inside a hele-shaw cell, J. Fluid Mech. 923, A16 (2021).
  5. C. M. Romero, M. S. Páez, J. A. Miranda, D. J. Hernández, and L. E. Oviedo, Effect of temperature on the surface tension of diluted aqueous solutions of 1,2-hexanediol, 1,5-hexanediol, 1,6-hexanediol and 2,5-hexanediol, Fluid Phase Equilib. 258, 67 (2007).
  6. Simulations were performed by a sharp-interface moving mesh finite element method using the framework pyoomph [10]. The weak formulation is a three-dimensional version of the method described in the supplementary information of Ref. [11] using a quarter droplet with symmetry boundaries and >600000 degrees of freedom.
  7. C. Diddens, P. J. Dekker, and D. Lohse, Non-monotonic surface tension leads to spontaneous symmetry breaking in a binary evaporating drop, arXiv:2402.17452.
  8. Y. O. Popov, Evaporative deposition patterns: spatial dimensions of the deposit, Phys. Rev. E 71, 036313 (2005).
  9. C. Diddens, H. Tan, P. Lv, M. Versluis, J. G. M. Kuerten, X. Zhang, and D. Lohse, Evaporating pure, binary and ternary droplets: thermal effects and axial symmetry breaking, J. Fluid Mech. 823, 470 (2017).
  10. C. Diddens and D. Rocha, Bifurcation tracking on moving meshes and with consideration of azimuthal symmetry breaking instabilities, J. Comput. Phys. 518, 113306 (2024).
  11. M. Jalaal, B. Ten Hagen, H. le The, C. Diddens, D. Lohse, and A. Marin, Interfacial aggregation of self-propelled Janus colloids in sessile droplets, Phys. Rev. Fluids 7, 110514 (2022).

Outline

Information

Phys. Rev. Fluids 10, 110508– Published 20 November, 2025
  • Received 31 May 2025
Crossmark - Check for updates button
Creative Commons Logo

Published by the American Physical Society under the terms of the Creative Commons Attribution 4.0 International license. Further distribution of this work must maintain attribution to the author(s) and the published article's title, journal citation, and DOI.
